Husqvarna 326E X-series User manual

EE
EEnn nngg ggll llii iiss sshh hh
326E
X-series
Oper ator’s manual
Please r ead the operator’s manual carefully and make sure you understand the instructions
before using the machine.

KEY T
O SYMBOLS
2 – English 1153255-95 Re v .1 2010-02-02
Symbols
W ARNING! Edgers can be
dangerous! Careless or incorrect
use can result in serious or fatal
injury to the operator or others.It is
extremely important that you read
and understand the contents of the
operator’s manual.
Please read the operator’s manual
carefully and make sure you
understand the instructions before
using the machine.
Always wear:
• A protective helmet where there
is a risk of falling objects
• Approved hearing protection
• Approved eye protection
Max. speed of output shaft, rpm
This product is in accordance with
applicable CE directives.
Watch out for thrown objects and
ricochets.
Warning for rotating blade.Keep
hands and feet clear.
Warning! The blade continues to
rotate even after the engine has
stopped.When the engine has
stopped, stop the blade from rotating
by letting the blade come in contact
with the ground.
The operator of the machine must
ensure, while working, that no
persons or animals come closer than
15 metres.
Arrows which show limits for handle
positioning.
Always wear approved protective
gloves.
Wear sturdy, non-slip boots.
Other symbols/decals on the mac hine refer to special
certification requirements for certain markets.
The engine is s witched off by moving
the stop switch to the stop position.
CAUTION! The stop switch
automatically returns to the start
position. In order to prevent
unintentional starting, the spark plug
cap must be removed from the spark plug when
assembling, checking and/or performing maintenance.
Always wear approved protective
gloves.
Regular cleaning is required.
Visual check.
Approvedeyeprotectionmustalways
be used.
50FT
15 m
50FT
15 m

CONTENTS
English
–
3
1153255-95 Re v .1 2010-02-02
Contents Note the f ollowing before
starting:
Please read the oper ator’s manual carefully.
Maintenance, replacement, or repair of the emission
control devices and system may be performed by any
nonroad engine repair establishment or individual.
The Emissions Compliance Period referred to on the
Emission Compliance label indicates the number of
operating hours for which the engine has been shown to
meet Federal and Californian emissions requirements.
KEY TO SYMBOLS
Symbols ................................................................ 2
CONTENTS
Contents ............................................................... 3
Note the following before starting: ........................ 3
INTR ODUCTION
Dear customer! ..................................................... 4
WHA T ISWHAT?
What is what? ....................................................... 5
GENERAL SAFETY PRECA UTIONS
Impor tant .............................................................. 6
Personal protective equipment ............................. 6
Machine ′ s safety equipment ................................. 7
ASSEMBL Y
Fitting the loop handle .......................................... 11
Assembling the angle gear ................................... 11
Assembling the cutting equipment ....................... 11
Assembling the blade ........................................... 11
FUEL HANDLING
Fuel saf ety ............................................................ 13
Fuel ...................................................................... 13
Fueling .................................................................. 14
ST ARTING AND STOPPING
Chec k before starting ........................................... 15
Starting and stopping ........................................... 15
W ORKINGTECHNIQUES
Gener al working instructions ................................ 17
Basic working techniques ..................................... 17
MAINTENANCE
Carb uretor ............................................................ 19
Muffler .................................................................. 19
Cooling system ..................................................... 20
Spark plug ............................................................ 20
Air filter ................................................................. 21
Angle gear ............................................................ 21
Lubricating the flexible drive shaft ........................ 22
Adjusting the edger’s cutting depth ...................... 22
Maintenance schedule ......................................... 23
TECHNICAL D ATA
T echnical data ...................................................... 24
FEDERAL AND CALIFORNIA EMISSIONS
CONTROLWARRANTY STATEMENT
Y OURWARRANTY RIGHTS AND OBLIGATIONS 25
!
W
ARNING! Long-term exposure to noise
can result in permanent hearing
impairment. So always use approved
hearing protection.
!
W ARNING! Under no circumstances may
the design of the machine be modified
without the permission of the
manufacturer. Always use genuine
accessories. Non-authorized
modifications and/or accessories can
result in serious personal injury or the
death of the operator or others.
Your warranty may not cover damage or
liability caused by the use of non-
authorized accessories or replacement
parts.
!
W ARNING! An edger can be a dangerous
tool if used incorrectly or carelessly, and
can cause serious or fatal injury to the
operator or others. It is extremely
important that you read and understand
the contents of this operator’s manual.
The engine exhaust from this product
contains chemical known to the State
of California to cause cancer, birth
defects or other reproductive harm.

INTR
ODUCTION
4 – English 1153255-95 Re v .1 2010-02-02
Dear customer!
Cong ratulations on your choice to buy a Husqvarna product! Husqvarna is based on a tradition that dates back to 1689,
when the Swedish King Karl XI ordered the construction of a factory on the banks of the Huskvarna River, for production
of muskets.The location was logical, since water power was harnessed from the Huskvarna River to create the water-
powered plant.During over 300 years of continuous operation, the Husqvarna factory has produced a lot of different
products, from wood stoves to modern kitchen appliances, sewing machines, bicycles, motorcycles etc.In 1956, the first
motor driven lawn mowers appeared, followed by chain saws in 1959, and it is within this area Husqvarna is working
today.
Today Husqvarna is one of the leading manufacturers in the world of forest and garden products, with quality as our
highest priority.We develop, manufacture and market high quality motor driven products for forestry and gardening as
well as for building and construction industry.
Your purchase gives you access to professional help with repairs and service whenever this may be necessary. If the
retailer who sells your machine is not one of our authorized dealers, ask for the address of your nearest servicing dealer.
It is our wish that you will be satisfied with your product and that it will be your companion for a long time.Think of this
operator
′ s manual as a valuable document.By following its ′ content (using, service, maintenance etc) the life span and
the second-hand value of the machine can be extended. If you ever lend or sell this machine, make sure that the
borrower or buyer gets the operator ′ s manual, so they will also know how to properly maintain and use it.
Thank you for using a Husqvarna product.
Husqvarna AB has a policy of continuous product development and therefore reserves the right to modify the design and
appearance of products without prior notice.
For customer assistance, contact us at our website:www.usa.husqvarna.com

WHA T IS WHA
T?
English
–
5
1153255-95 Re v .1 2010-02-02
What is what?
10
16
8
7
9
6
5
4
3
1
2
17 11
14
13
21
19
20
22
23
24 25
18
26
15
1
4
12
1 Blade
2 Grease filler cap
3 Angle gear
4 Blade guard
5 Shaft
6 Loop handle
7 Throttle control
8 Stop switch
9 Throttle lockout
10 Cylinder cover
11 Starter handle
12 Fuel tank
13 Choke control
14 Air purge
15 Air filter cover
16 Clutch cover
17 Handle adjustment
18 Locking nut
19 Support flange
20 Drive disc
21 Locking knob
22 Socket spanner
23 Operator’s manual
24 Locking pin
25 Allen key
26 Spark plug cap and spark plug
