Hussmann RL User manual

P/N 0387177_K
PARTS LIST
Item
Quantity Description
RL/RM RLN RLNI
RM/RMF RMN RLNIE RLT
1. 2 2 4 2 Donut Gasket
2. 1 1 2 2 Gasket, 1 x
1/2 x 180 in.
3. 1 1 2 1 Gasket,
1/2 x 1/4 x 180 in.
4. 8 8 14 6 Cap Screw
5/16 -18 x 11/4
5. 8 8 14 6 Split Lock Washers 5/16
6. 1 12 1 Joint Molding
7. 5 5 10 5 Binder Post and Screw
8. 1 12 1 Splice Connector
RL / RM / RMF, RLT
RLN / RMN / RLNI / RLNIE
Joining Instructions
Joining Instructions
NOTE: Be sure first merchandiser has been leveled
according to the main installation instruction.
Carefully unpack and inspect the joining parts listed
above to verify completeness and that there is no
damage.
1Prepare cases for joining (both sides of islands) as shown in Figure 1.
A. Remove bumpers, rails, packing materials, and splashguards from the both cases.
B. Remove shelves (if installed).
C. Remove display racks and pans from ends to be joined.
D. Remove rear shelf supports.
Splashguard brackets must
be installed before piping or
wiring case.
B
A
CD
E
C
Figure 1. Prepare Cases
A
Bumper
Bumper
Retainer
Splashguard
SIDE VIEW
A
RLT
Bumper
Bumper
Retainer
Splashguard
SIDE VIEW
MANUAL- KIT REACH-IN JOINING
®
Æ

2
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
Reach-in Joining Instructions P/N 0387177_K
PARTS LIST
Item
Quantity Description
RL/RM RLN RLNI
RM/RMF RMN RLNIE RLT
1. 2 2 4 2 Donut Gasket
2. 1 1 2 2 Gasket, 1 x
1/2 x 180 in.
3. 1 1 2 1 Gasket,
1/2 x 1/4 x 180 in.
4. 8 8 14 6 Cap Screw
5/16 -18 x 11/4
5. 8 8 14 6 Split Lock Washers 5/16
6. 1 12 1 Joint Molding
7. 5 5 10 5 Binder Post and Screw
8. 1 12 1 Splice Connector
E. Remove back panels from ends to be joined by lifting up and out near the
bottom. No tools are necessary. The RLT
models have upper and lower back panels
that must be removed.
F. Remove joint molding from any door frames that will be joined to another case.
G. RLNI Only: Remove screws and inte-
rior top panel on both sides of the island
case end to be joined (see Figure 1).
E
GG
RLNI Only
Alignment Pin
F
E
RL / RM / RMF
RLN / RMN
and RLNI
RLT

3HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
P/N 0387177_K
2Locate and remove the shipping block in the center of the heat exchanger in the interior
bottom of each case, see Figure 2.
Snap a chalk line on the floor to use as a guide
for positioning the front of the cases in the
line-up. The front base frame should be on the
chalk line.
3Once cases are close to final placement, remove the shipping braces from the ends to be joined,
see Figure 3. Discard bolts and flat washers
used to hold shipping braces. Bolts are too
long to be used for joining.
RMN
Figure 3. Remove Shipping Braces
Donot use shipping bolts to join cases!
Shipping Brace
Figure 2. Remove Shipping Block
(One From Each Side of Island Models)
Shipping
Block
RLNI / RLNI

4
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
Reach-in Joining Instructions P/N 0387177_K
4If not already installed make
sure NutRetainers and
Alignment Pins are in place in
the right end frame as shown
in Figure 4A or 4B.
Figure 4A. Verify Nut Retainer Installation
RLT
RL / RM / RMF
and
RLN / RMN
Alignment Pin

5HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
P/N 0387177_K
RLNI

6
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
Reach-in Joining Instructions P/N 0387177_K
5Apply Donut Gasket– 1 in recess around both left end as shown in Figure 5A, Part 1; 5B or
5C, Part 1, and right end frames as shown in
Figure 5A, Part 2; 5B or 5C, Part 2.
Apply the wider Foam Tape Gasket — 2
around the right end frame as shown in Figure
5A, Part 2, 5B or 5C, Part 2.
Figure 5A, Part 1. Apply Gasket to Left End of
RL/RM/RMF and RLN/RMN
RL / RM / RMF
and
RLN / RMN
F
R
O
N
T
Right EndLeft End
F
R
O
N
T
PadShoeSealer
1- Donut
2- 1 in x in
3- in x in
Use all three gaskets
When applying an end
assembly.
Left End Case
F
R
O
N
T
Right EndLeft End
F
R
O
N
T
PadShoeSealer
1- Donut
2- 1 in x in
3- in x in
Use all three gaskets
When applying an end
assembly.
Left End Case
Right End Case
F
R
O
N
T
Right EndLeft End
F
R
O
N
T
PadShoeSealer
1- Donut
2- 1 in x in
3- in x in
Use all three gaskets
When applying an end
assembly.
1

7HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
P/N 0387177_K
Figure 5A, Part 2. Apply Gaskets to Right End of RL/RM/RMF and RLN/RMN
RL / RM /
RMF
and
RLN / RMN
notes:
1. The perimeter gasket, Item 3, is required by NSF.
2. Butyl is NOT an acceptable
substitute for donut or foam
gasket.
F
R
O
N
T
Right EndLeft End
F
R
O
N
T
PadShoeSealer
1- Donut
2- 1 in x in
3- in x in
Use all three gaskets
When applying an end
assembly.
2
3
Apply Pad Shoe Sealer first,
then apply the narrower Foam
Tape Gasket — 3 around
the perimeter of the right end
frame outside of the donut
gasket as shown in Figure 5A,
Part 2, 5B or 5C, Part 2.
• Lap gaskets at lower
corners.
• Check that there are no gaps between gasket and case.
• Do not stretch gasket,
especially around corners.
To make sharp corners,paper
backing can be torn without
removing from gasket.
• Do not butt gaskets; always lap joints.
• Remove paper backing after
gasket is applied to keep gasket
free of debris.
• Gasket has high tack
adhesive and must be properly
placed the first time.
Right End Case
1
Overlap
Gasket
Pad Shoe
Sealer
F
R
O
N
T
Right EndLeft End
F
R
O
N
T
PadShoeSealer
1- Donut
2- 1 in x in
3- in x in
Use all three gaskets
When applying an end
assembly.
ALL MODELS: Apply
gasket between
wipes.

8
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
Reach-in Joining Instructions P/N 0387177_K
Figure 5A. Apply Gaskets to Left End of RLNI
RLNI
Left End Case
Pad Shoe
Sealer

9HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
P/N 0387177_K
1 in. x in.
in. x in.
Figure 5B. Apply Gaskets to Right End of RLNI
RLNI Right End Case
Pad Shoe
Sealer

10
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
Reach-in Joining Instructions P/N 0387177_K
Figure 5C, Part 1. Apply Gasket to Left End of RLT
PadShoeSealer
F
R
O
N
T
F
R
O
N
T
Left End
Right End
1- Donut
2- 1 in x in
3- in x in
Use all three gaskets
When applying an end
assembly
Left End Case
PadShoeSealer
F
R
O
N
T
F
R
O
N
T
Left End
Right End
1- Donut
2- 1 in x in
3- in x in
Use all three gaskets
When applying an end
assembly
Left End Case
Right End Case
F
R
O
N
T
Right EndLeft End
F
R
O
N
T
PadShoeSealer
1- Donut
2- 1 in x in
3- in x in
Use all three gaskets
When applying an end
assembly.
1
RLT

11 HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
P/N 0387177_K
6Move the second merchandiser
against first, mating alignment
pins with corresponding holes.
Use care when pushing the
cases together.
RL / RM / RLN / RMN /
RLNI: Do not to cut wires
routed along the front bumper
retainer. See detail in Figure 6.
The RLT has no alignment
pin and the wireway is at the
top front.
Figure 5C, Part 2. Apply Gasket to Right End of RLT
PadShoeSealer
F
R
O
N
T
F
R
O
N
T
Left End
Right End
1- Donut
2- 1 in x in
3- in x in
Use all three gaskets
When applying an end
assembly
Right End Case
RLT
PadShoeSealer
F
R
O
N
T
F
R
O
N
T
Left End
Right End
1- Donut
2- 1 in x in
3- in x in
Use all three gaskets
When applying an end
assembly
1
2
3
PadShoeSealer
F
R
O
N
T
F
R
O
N
T
Left End
Right End
1- Donut
2- 1 in x in
3- in x in
Use all three gaskets
When applying an end
assembly
Apply Pad Shoe
Sealer

12
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
Reach-in Joining Instructions P/N 0387177_K
Figure 6. Move Cases Together
RL or RM
RLN or RMN
RLNI
Do not cut wires in
bumper retainer.

13 HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
P/N 0387177_K
Figure 7A. Joining Sequence for RL, RM, RMF,
RLN and RMN Cases
RL, RM, RMF, RLN, RMN
D
E
C
B
A
5
4
Nut Reta iner
Figure 7B. Joining Sequence for RLT Cases
RLT
7Loosely insert Cap Screw–5 with Lock
Washer – 6 into each nut retainer follow-
ing the sequence shown in Figures 7A and
7B.
Do not tighten fully.
A. Fasten bottom fronts together, but tight-
en only until front panels touch.
B. Move to the bottom back position and join (2 places).
C. Join at the top front
position.
D. Go to the middle back
wall position and join.
E. Join at the lower back wall.
F.Finally, join at the top back wall posi-
tion.
Following the same sequence, tighten each
cap screw fully until the merchandisers are joined
with a snug fit and gaskets are compressed.
When joining two RLNIE
models, nut retainers and
alignment pins are used on
one case only.
8Refer to Section 1 of the
Reach-In Installation and Service Manual
to install splashguard brackets and bum-
pers. Section 3 provides direction for
installing splashguards, including splash-
guard
Splice Connector – 8.
shown in Figure 9.
Note that RLT cases have steel splash-
guards that do not use a splice connector.

14
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
Reach-in Joining Instructions P/N 0387177_K
A
A
E
B
6
5
F
D
C
RLNI
Alignment Pin Alignment Pin
Nut Retainer
Figure 7C. Joining Sequence for RLNI Cases

15 HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
P/N 0387177_K
9Align holes in frame with holes
in Joint Molding – 6.
Fasten cases together using Binder
Post and Screws – 7 as shown
in Figure 8.
10Refer to Section 1 of the
Reach-In Installation and
Service Manual to install splash-
guard brackets and bumpers.
Section 3 provides direction for
installing splashguards, including
splashguard
Splice Connector – 8.
shown in Figure 9.
Note that RLT cases have steel
splashguards that do not use a
splice connector.
6
7
7
6
Figure 8. Installing “J” Molding
Figure 9. Installing Splashguard Splice Connector
Splice Connector
Splashguard
SIDE VIEW
9
Splashguard
Splice Connector
Side View

16
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
Reach-in Joining Instructions P/N 0387177_K
INSTALLING SPLASHGUARD
BRACKETS
1. Attach splashguard retainer and splashguard
retainer support to splashguard support bracket
using two screws per bracket.
2. Install splashguard support brackets
before pIpIng case.The leveling brackets have a
maximum extension of one(1) inch (25mm) for
uneven floors.
DO NOT place shIms under
splashguard brackets.

17 HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
P/N 0387177_K
INSTALLING BUMPERS
Offsetting the bumpers and top rails helps to
disguise the joint locations, giving the lineup a
smoother look.
Begin at the left end of the line-up. A starter bumper is
factory-installed with end kits. Insert the internal joint
trim, then add the full-length bumper.
Align each bumper section with its retainer and push
into place, working from the end of the lineup. Install
full length bumpers and internal joint trims offset
across joints. Make sure that no gaps exist between
sections. Continue installing bumpers the length of the
line up.
Do NOT install the last bumper sections at this time.
These sections will be installed in the last step.
Once all except the last section of bumper have been
installed, refrigerate the case line-up for at least six
(6) hours. The last sections of bumper should be kept
inside a refrigerated case or cooler during this time to
allow the bumpers to contract.
Before installing the last full-length section,
measure the remaining space. Use a miter box and
fine-tooth saw to cut last bumper to length. Install
the last section. Remove protective film from bumpers
once installation is complete. Optional end bumpers are
factory-installed.
Bumper End Caps can be adjusted horizontally to eliminate
gaps.
