increments,3.18 cm to 11.43 cm)
Main Blades Heavy-duty,heat-treated, 10B38 steel blades
36 in Deck 20.5 in x 2.50 in x .204 in LH blade
13.75 in x 2.50 in x .204 in RH blade
48 in Deck: 16.5 in x 2.50 in x .204 in
Fusion™blades feature tungsten carbon material fused to the
bottom of the blade.This material is very hard and blades stay
sharper longer necessitating sharpening less often and better
cutting quality for longer periods of time.
Blade Tip Speed 36 & 48 in Deck 18,500 fpm
Blade Drive V-belt drive to spindles. Spring tension idler pulleys
Spindles Aluminum casting with steel shafts and sealed ball
bearings
Trim Capacity (left side):36 in Deck:0 in (0 cm)
48 in Deck: 2 in (5.08 cm)
Configurations 36”SD Deck, 15 hp
48” SD XR-7 Deck,17 hp
Accessories
Mulch Kits Recycles clippings under deck allowing clippings to
be cut and recut,then discharged down into grass.Reduces han-
dling of clippings, improves appearance,and recycles nutrients
back to the soil
Deck-Mounted Catcher Easily-installed,side-mounted catcher
holds 3.75 bushels.
Roll-On™Striping Sulky A stand-on sulky that features a strip-
ing roller instead of tires.Produces beautiful striping results
because weight of operator improves striping performance.
Compatible with after-market sulkies and trailers
Weight Kit
Specifications subject to change without notice.
Engine Specifications
Model Kawasaki Kawasaki
Horsepower 15 17
No.of Cylinders 2 2
Displacement 26.3 cu in (431 cc) 30.1 cu in (585 cc)
Compression Ratio 8.5:1 8.5:1
Max.Torque 23.6 ft lbs @ 2400 rpm 36.2 ft lbs @ 2000 rpm
Form No.799 163 4-06
Starting Recoil
Ignition Electronic
Charging System 12-volt,15-amp
Fuel Unleaded gasoline
Fuel Filter Replaceable,automotive-type
Air Cleaner Dual element
Cooling Air cooled.Fly-wheel fan
Governor Mechanical
Traction Drive System
Type Dual hydrostatic.Hydro-Gear IZT
Pump Drive V-belt drive from engine crankshaft
Ground Speed 0-6.0 mph (0-9.7 kph) forward and 0-2 mph
(0-3.2 kph) reverse,infinitely variable
Steering Patented, self-centering H-Bar™ (Hustler Bar) Plus
Steering provides independent control of each drive wheel.
Speed,forward,reverse,brake, and turns are all controlled with
the easy to learn, easy to operate H-Bar Plus Steering.Now
with cruise control.
Turning Radius True zero turning radius.Turns within its own
length. Counter-rotating,independent drive wheels
Brakes Service: Hydrostatic dynamic braking
Parking: Sprocket and cog
Mower Drive Warner electromagnetic clutch.
Tires Front: Two – 11 x 4 – 4, smooth,semi-pneumatic
Drive: 18 x 9.50 – 8, turf tread (18 x 6.50 – 8 on 36”model)
Capacities
Fuel System: 5 US gal
Dimensions
Height: 41.4 to 45.4 in (105.16 to 115.32 cm) adjustable
W/36 in Deck Length: 74 in (187.96 cm)
Overall Width: 37.7 in (95.76 cm)
w/discharge chute up
Tire-to-tire Width: 33.25 in (84.5 cm)
Weight: 550 lbs (249.48 kg)
W/48 in Deck Length: 73.5 in (186.69 cm)
Overall Width: 49.5 in (125.73 cm)
w/discharge chute up
Tire-to-tire Width: 39.5 in (100.33 cm)
Weight: 550 lbs (249.48 kg)
Safety Features
Operator presence safety-interlock system.Side discharge
deck with discharge chute
Construction Mainframe is reinforced 1/8 in welded steel
construction.
Controls Hand-operated throttle/choke, ignition switch,
mower clutch switch
Indicators Hour meter
Warranty 2-year parts and labor warranty on entire unit
3-year limited warranty on front caster fork bearings
and blade spindle bearings Lifetime warranty on leading
edge of the deck
Decks 36” and 48”XR-7 Side-Discharge Decks. Free-
floating,side-discharge mower using three blades (36”
deck uses 2 blades). Mower is suspended at the corners
by four height-adjustment pins.48” XR-7 deck includes
FreeFlow™ triangles for improved cutting and reduced
build up under the deck, deck-mounted anti-scalp rollers
to improve flotation in rolling and uneven terrain.
Construction
36 in Deck: 7-gauge deck plate with 7-gauge doublers.
48 in Deck:11-gauge deck plate with 11-gauge doublers.
1-1/2” x 1/2”steel bar reinforced impact areas on front
and trim edges, heavily-reinforced front edge.Lifetime
warranty on leading edge of deck. Deck housing is 4
in deep to provide room for high-capacity mowing
Discharge Side
Cutting Heights Pin-type adjustment at four corners of
deck in .25 in increments from 1.25 in to 4.5 in (.1 cm
Hustler Turf Equipment • Hesston, Kansas 67062 • 1-800-395-4757
For more information : www.hustlerturf.com
• No daily lube points!
• A full two-year bumper-to-bumper warranty – parts and labor!
• Lifetime warranty on the
leading edge of the deck
• 3-years on the blade spindle bearings
• 3-years on front-caster fork bearings
• Simple, efficient drive system – integrated,
serviceable IZT transmissions. No hoses, no leaks.
• Patented H-BarTM Plus
steering system – the easiest-to-learn,
easiest-to-use, walk-behind steering system. The mower
seems to glide over the lawn effortlessly! Now with cruise control!
With the addition of the Hustler Roll-OnTM striping sulky you really will
glide over the lawn while creating beautiful striping.
• Competitive price – the TrimStar Hydro is
priced lower than competitive hydrostatic,
floating-deck units for a tremendous value
in the commercial mowing market.
THE TRIMSTAR HYDRO-WALKBEHIND
But where to begin?
They’re not easily discussed, these new TrimStar Hydro walk-
behinds, their benefits many, their advantages everywhere.
So pick any reason why… productivity, ergonomic ease
of use, quality of cut and accessibility to tight lawn
spaces, simplicity of maintenance… and let that be
your rationale for running the most innovative,
most technologically advanced walk-
Behind on the market today. The
TrimStar Hydro WalkBehind
will deliver. And we’re
now about to count
the ways.
• The newly-designed,full-floating decks
offer the highest-quality cut and finished
appearance on the market.In side-discharge
or mulch, theTrimStar Hydro will produce an
immaculate lawn

SOMETHING NEW IN A WALK-BEHIND!
The look it leaves behind.
The TrimStar Hydro’s full-floating decks lead directly to grass
straight from Sunday afternoons on The Golf Channel: uniform,
perfectly cut, striped, flawlessly finished. An air-flow kit, stan-
dard on all TrimStar decks, does its part for these immaculate
lawns by minimizing blowout, as does the optional Roll-On™
striping sulky. Optional deck-mounted catchers and grass-guz-
Good times. Even better times.
Hustler TrimStar Hydro mowers will help you break records for
productivity.They will take hours off even the most tedious and
time-consuming mowing jobs, thanks to Hustler’s patented
H-Bar™Plus steering system. With H-Bar Plus, the mower
glides over the grass, tightly controlled without effort, steered
and slowed without strain, as cruise control holds the TrimStar
Hydro at ideal speed. Meanwhile, spring-loaded control handles
make adjustments a quick flick of the wrist.As blade-tips whirl
at 18,000+ fpm for enhanced quality of cut and maximized
production in wide-open spaces, the TrimStar squeezes into
backyards and little cul de sacs, around shrubs and trees, cutting
close, reducing time on the weed-whacker.
“H” for Hustler.
“H” for hydro.
“H” for hassle-free.
All the expected Hustler considerations for
ease of operation and maintenance are here,
and some new big ideas as well. The TrimStar
Hydro’s drive system, for example, is a study in simplicity: the
integrated IZT transmissions are essentially foolproof, with no
hoses to leak as a transmission lever sets the built-in parking
brake or slides the transmission into drive or tow. Sealant in the
drive tires almost eliminates flats, and semi-pneumatic tires up
front eliminate flats entirely. Deck heights — with cuts arriving
in .25” increments from 1.25” to 4.5” — adjust in seconds,
through four pins at the corners. All operator controls wait
within arm’s reach, the steering fully adjustable for height and
• 48” deck features
XR-7 Mowing technol-
ogy including: FreeFlow
Triangles for minimized
clumping, larger discharge
opening for improved finished
appearance and the easiest-to-
install mulch kits on the market!
• Simple, efficient drive system -
integrated,ser viceable IZT
transmissions. No hoses,no leaks.
• Transmission lever to put trans-
missions in drive, tow,or set the
integrated park brake.
• Patented H-BarTM Plus steering system –
the easiest to learn, easiest-to-use walk-
behind steering system.The mower seems
to glide over the lawn effortlessly! Now
with cruise control!
• 36” or 48”full-floating decks
• 5-gallon fuel tank with sight-line
• Recoil start is indexed to the
rear of the machine. Pull starts
in enclosed trailer are possible
• No daily lube points!
• 15 hp or 17 hp Kawasaki air-cooled gasoline engines
• Fusion™ Blades last 2-3 times longer before needing
to be re-sharpened.
• Discharge chute flips over, completely out of the way
to pass through gates,for trailering, etc.
• Best blade-spindle design in the industry! Sealed
bearings require minimal maintenance,less horse
power, and generate less heat. Grease every 500
hours! 3-year warranty on bearings.
• Available attachments include;easily-installed,
deck-mounted catcher (below),mulching kits,
after market sulkies and the new Hustler
Roll-On™riding striper (left).
B E S T W A R R A N T Y*I N TH E B U S I N E S S
• A full two-year bumper-to-bumper warranty – parts and labor!
• Lifetime warranty on the leading edge of the deck
• 3-years on the blade spindle bearings
• 3-years on the front caster fork bearings
Hustler TrimStar™
Hydro WalkBehinds
finish the job fast,
finish lawns
beautifully.
responsiveness.The operator-presence safety system (yet another
soon-to-be-patented Hustler exclusive) requires no squeezing,
no gripping to engage. Because the TrimStar is first and last a
Hustler, expect a blade spindle proven amid 35 years of durable,
reliable service. Expect bearings that refuse to waste horsepower
as heat, that shove power where it belongs, toward cutting grass. Natu-
rally, expect no daily lube points.
And behind all this technology stands the strongest
warranty for walk-behinds in the industry: two years
parts and labor, three years on the front caster fork
bearings and on the blade spindle bearings, a
lifetime on the leading edge of the deck.
Oh. And money in your pocket.
Discount, if you wish, all the operational benefits a Hustler TrimStar
will bring your way. Forget its performance, its ergonomic comfort, its
advantages up and down the line. Just think of this mower as you would
any other hydrostatic, floating-deck walk-behind.And then buy on price
alone. Fact is, the TrimStar costs less than any wannabe competitive units.
Start strong — Finish stronger.
Own a Hustler TrimStar Hydro.
Or two.
zling mulch kits are standing by to deal with the clippings
immediately, efficiently, lawn by lawn. Meanwhile, out of sight
on the aft-side of the blades, yet another Hustler innovation
(Free-Flow™Triangles we call them, and a patent is pending.)
accelerates the flow of material under the deck to minimize
clumping, even in deep, wet grass.
* Contact your local dealer for complete warranty information
