HW Group HWg-PWR 3 User manual

HWg-PWR 3/12/25
MANUAL

HWg-PWR 3 / 12 / 25 MANUAL
HW group
September 2013
page 2
Package contents
A complete shipment contains the following items:
HWg-PWR25 (HWg-PWR12) unit
Printed manual + datasheet
Safety information
The device complies with regulations and industrial standards in force in the Czech Republic and the
European Union. The device has been tested and is supplied in working order. To keep the device in this
condition, it is necessary to adhere to the following safety and maintenance instructions.
HWg-PWR connects directly to a 230VAC supply; therefore, it should be installed by qualified
personnel only!
Using the device in a manner other than prescribed by the manufacturer may cause its
safeguards to fail!
The power supply outlet or disconnection point must be freely accessible.
The device must not be used under any of the following conditions:
The device is noticeably damaged
The device does not function properly
Unfastened parts can move inside the device
The device has been exposed to moisture or rain
The device has been serviced by unauthorized personnel
The power adapter or power supply cable are noticeably damaged
If the device is used in a manner other than designed for, the protection provided by the
device may fail.
The local electrical system must include a power switch or a circuit breaker and
overcurrent protection.
If you have any problems with installing or operating the device, please contact technical
support:
When contacting technical support, please keep at hand the exact type of your device (at the
type plate) and, if possible, the firmware version (see later in this manual).

HWg-PWR 3 / 12 / 25 MANUAL
HW group
September 2013
page 3
Table of Contents
Package contents............................................................................................................................................. 2
Safety information........................................................................................................................................... 2
What is HWg-PWR 3 / 12 / 25.......................................................................................................................... 4
Usage examples .......................................................................................................................................... 4
Basic features of HWg-PWR12/25 ................................................................................................................... 5
Description of connectors and connections .................................................................................................... 6
LED indicators ............................................................................................................................................. 6
Restoring factory defaults........................................................................................................................... 7
HWg-PWR wiring ........................................................................................................................................ 7
Technical specifications ................................................................................................................................... 8
First steps......................................................................................................................................................... 9
1) Connecting the cables............................................................................................................................. 9
2) Configuring the IP address –UDP Config ................................................................................................ 9
3) WWW interface of the device .............................................................................................................. 10
Adding connected meters and measured values........................................................................................... 11
Automatic discovery of meters:................................................................................................................ 12
Activating and adding discovered meters to HWg-PWR........................................................................... 14
WWW interface ............................................................................................................................................. 16
Home tab .................................................................................................................................................. 16
Graph tab .................................................................................................................................................. 17
General Setup tab ..................................................................................................................................... 19
SNMP tab .................................................................................................................................................. 20
ModBus TCP Server................................................................................................................................... 22
E-mail tab.................................................................................................................................................. 23
Time tab.................................................................................................................................................... 25
Záložka Remote SMS................................................................................................................................. 26
Input tab ................................................................................................................................................... 27
Portal ........................................................................................................................................................ 28
Device tab ................................................................................................................................................. 29
System tab ................................................................................................................................................ 34
Meter types ................................................................................................................................................... 39
Internal memory size..................................................................................................................................... 39
Datalog format of devices HWg-PWR and HWg-Ares.................................................................................... 40
Mechanical................................................................................................................................................ 42
Accessories .................................................................................................................................................... 44
Manufacturer................................................................................................................................................. 44

HWg-PWR 3 / 12 / 25 MANUAL
HW group
September 2013
page 4
What is HWg-PWR 3 / 12 / 25
The HWg-PWR is an Ethernet-enabled device for remote monitoring and metering of
electricity, heat, water or gas consumption using electricity, water, gas, heat, or other meters
equipped with the M-Bus interface. In addition to metering, the device also supports alarming
through e-mail or SNMP traps whenever allowed values are exceeded.
HWg-PWR is designed for remote reading of values from meters equipped with the M-Bus
interface. Each meter can provide multiple variables, depending on the meter type and model.
Typically, electricity meters provide the total electricity consumption and also the immediate
value at the time of reading, line voltage and/or line current; water meters indicate total water
consumption as well as immediate consumption or liquid flow rate; and so on.
Note: HWg-PWR is designed to be universal; hence, all discovered values are read out from
every connected meter, until a specified limit is reached. To improve user comfort, it is possible
to enable or disable each discovered value (disabled value is hidden from view), and to turn on
or off the recording of measured readings for each enabled value (in order to increase the
available recording time for the remaining values).
The M-Bus protocol also allows reading value names, units of measurement, or tariff
information from the meters. The user can customize all of these data (e.g. change the unit of
measurement or its exponent).
Usage examples
Remote monitoring of electricity meters in small server rooms and BTS
Monitoring of energy consumption in rented premises
Reading out energy consumption in remote or inaccessible areas
Control over energy costs
Checking for individual line overloads in three-phase wirings
Checking for undervoltage in electric wirings
Monitoring the flow of liquids

HWg-PWR 3 / 12 / 25 MANUAL
HW group
September 2013
page 5
Basic features of HWg-PWR 3 / 12/ 25
Ethernet: RJ45 (100BASE-TX)
WEB: Embedded WEB server / GUI
M-Bus meters: up to 3 / 12 / 25 M-BUS meters (electricity, gas, ...)
Various values: up to 100 various values (independent from the connected meters)
Automatic detection of meters and supported values
8x 110/230V voltage inputs (phase detection - common PE) for any use
Logging of measured values & plot charts: Logs up to 170,000 values
Configuration of allowed ranges for measured values
Configuration of the unit of measurement and the exponent
Conversion of measured values to currency
Supports M-Bus primary and secondary addressing
Configuration of remote primary M-Bus address
Periodic submission of measured values over HTTP (HWg-PUSH)
Periodic submission of measured values by e-mail
Periodic e-mailing of differences in measured values (day, week, month, year)
Periodic e-mailing of differences in measured values
DIN rail mount with a power supply for M-BUS
M2M communication protocols: SNMP, XML, Modbus/TCP
Support for sending alarm SMS through Poseidon SMS GW (netGSM)
Response to thresholds: SNMP trap, Email, netGSM
Support for programmers: HWg SDK
Supported software
oHWg-PD Trigger: Control of other IP devices, alarm redirection to SMS
oHWg-PDMS:Logging, export to MS Excel
o>> Third-party SNMP software
(HP OpenView, IBM Tivoli, Nagios, Zabbix, Monitor one, The Dude, Paessler IPCheck, Ipswitch WhatsUp,
Axence nVision, CBR little:eye, LoriotPro, GFi NSM, SNMPc 7, CA NSM, ActiveXperts NM, Intellipool NM,
MSC Operations Manager 2007)
* Displayed variables depend on the actual meter

HWg-PWR 3 / 12 / 25 MANUAL
HW group
September 2013
page 6
Description of connectors and connections
LED indicators
Power (green) –lights up when the device is powered.
Alarm (red) –lights up whenever a monitored variable is in alarm.
M-Bus (blue) –flashes whenever M-Bus communication takes place.
Status (green) –HWg-PWR status.
oSolid on –HWg-PWR is in regular operation.
oSlowly flashing –HWg-PWR is starting up.
oRapid flashing –firmware is being uploaded.
Link (amber) –flashes whenever communication takes place over the Ethernet
interface.

HWg-PWR 3 / 12 / 25 MANUAL
HW group
September 2013
www.HW-group.com
page 7
Default switch: Restoring factory defaults
Press and hold the Reset (Default switch), connect power, and hold the switch pressed for
10 more seconds. The HWg-PWR resets itself to factory defaults.
Be careful when working with HWg-PWR in a distribution box.
HWg-PWR wiring

HWg-PWR 3 / 12 / 25 MANUAL
HW group
September 2013
page 8
Technical specifications
Ethernet port
+ Interface
RJ45 (10BASE-T / 100BASE-Tx)
+ Compatibility
Ethernet: Version 2.0/IEEE 802.3
+ Supported protocols
IP: ARP, TCP/IP (HTTP, SMTP, Modbus/TCP), UDP/IP (SNMP, SNMP Traps, DHCP, SNTP)
+ SNMP
Ver:1.00 compatible, partial ver. 2.0 implementation
M-Bus
+ M-Bus meters
HWg-PWR 3 = Max 3 meters
HWg-PWR 12 = Max 12 meters
HWg-PWR 25 = Max 25 meters
+ M-Bus power load
Max. 25 connected meters (EN 13757-2)
Environment
+ Operating
-5 to +50 °C (+23 to +122 °F) / 5 to 95 %RH
+ Storage
-5 to +75 °C (+23 to +167 °F) / 5 to 95 %RH
LED indicators
+ POWER (green)
lights up when the device is powered
+ LINK (red)
flashes whenever communication takes place over the Ethernet interface
+ Status (red)
HWg-PWR status:
-Solid on –HWg-PWR is in regular operation
-Slowly flashing –HWg-PWR is starting up
-Rapidly flashing –firmware is being uploaded
+ Alarm (red)
lights up whenever a monitored variable is in alarm
+ M-Bus (amber)
flashes whenever communication takes place over M-Bus
Buttons
+ Default switch
When depressed at power up, resets the device to factory defaults
Digital Inputs
+ Ports
L IN1 –L IN8
+ Type
110/230V AC voltage input for the phase failure detection
+ Impedance
120kOhm
Miscellaneous
+ Supply voltage
110/230 V AC - 10VA; terminal block
+ Dimensions
143 x 90 x 57 [mm]
+ Fixing
DIN rail; device is intended for installation into a distribution box
+ Mass
390 g
+ Protection
200mA fuse –T200L

HWg-PWR 3 / 12 / 25 MANUAL
HW group
September 2013
page 9
First steps
1) Connecting the cables
HWg-PWR connects directly to a 110/230VAC supply; therefore, it should be installed by
qualified personnel only!
Connect the unit to the Ethernet (a patch cable to a switch, or a cross-over cable to
a PC).
Connect the M-Bus with meters. Pay attention to the polarity!
Connect HWg-PWR to the electrical network.
The green Power LED lights up.
If the Ethernet connection works properly, the LINK (amber) LED lights up after a
short while, and then flashes whenever data transfer takes place (activity
indication).
After power up, the amber LINK LED flashes rapidly to indicate IP address
negotiation over DHCP.
The blue M-Bus LED indicates communication over the M-Bus.
2) Configuring the IP address –UDP
Config
UDP Config utility –root directory of the
supplied CD (Windows and Linux versions).
Available for download
Software > UDP Config.
Click the icon to launch UDP
Config. The program
automatically looks for connected
devices.
To search for devices, click the Find
Devices icon.
The program searches for devices in your local
network. Double-click a MAC address to open a
basic device configuration dialog.
Configure the network parameters
IP address / HTTP port (80 by default)
Network mask
Gateway IP address for your network
Device name (optional)
Click the Apply Changes button to save the settings.

HWg-PWR 3 / 12 / 25 MANUAL
HW group
September 2013
page 10
Restoring factory defaults
Right-click a device MAC address. Within 60 seconds after powering up the unit,
factory defaults can be restored using UDP Config.
Disconnect power, press the Default switch, power up the device and wait for 10
seconds. Release the switch. The device is ready in the factory default configuration.
3) WWW interface of the device
To open the WWW interface of the device:
Enter the IP address into a web browser
Click the IP address in UDP Config
Click the underlined IP address in UDP
SETUP
