Hydrocowl Safe-t-cover 800s series User manual

The information contained herein is intended for the use of the individual(s) named above and those authorized to receive it. Dissemination, distribution

or copy of this information is strictly prohibited.

ASSEMBLY INSTRUCTIONS PLEASE READ CAREFULLY

Model No.

Inside

Dimensions

Outside

Dimensions

Recommended Concrete

Pad Dimensions

800S Series

38"W x 144"L x 56"H

41 3/4"W x 147"L x 59 1/4"H

52"W x 158"L x 6" Thick

1000S Series

40"W x 174"L x 78"H

43 3/4"W x 177"L x 81 1/4"H

54"W x 188"L x 6" Thick

1000TS Series

40"W x 174"L x 90"H

43 3/4"W x 177"L x 93 1/4"H

54"W x 188"L x 6" Thick

1. The concrete base should be 6”thick x 14”longer than enclosure ID x 14”wider than enclosure ID.

A. Mark the concrete base for the outside of the enclosure (3” wider than ID and 3” longer than ID).

2. The PVC masking film will help to protect the finish of the metal panels during installation. These

coatings should be left intact and removed only after assembly of the enclosure is complete.

A. Assemble the “B-A-B” (side-end-side) assemblies using hex headed screws. (For best results, insert a

bead of silicone caulk into the inside bend of the “A” panel corners.) Position both sets of assembled

panels on the marked concrete base (Fig 2).

The information contained herein is intended for the use of the individual(s) named above and those authorized to receive it. Dissemination, distribution

or copy of this information is strictly prohibited.

NOTE: model sizes and configurations vary, see the chart.

3. Inspect the alignment of the “C” (access) panels during the assembly process. Verify that their

removal and replacement allows adequate space and positioning within the openings and with the

adjacent panels prior to attaching any bracket to the concrete.

4. Set the “C” (access) panels and the “F” (support) post in place with about a 3/16” gap on each side of

the “C” panels as the roof is assembled.

A. Set the “D1” (roof) panel on a “B-A-B” (side-end-side) assembly. Fasten the “D1” (roof) panel to the

“B-A-B” (side-end-side) assembly through the holes provided (Fig 1) using two (2) hex headed screws.

B. Insert an Inside Roof Clip into the “D1” (roof) panel at the “B”panel studs (Fig. 1C). Attach the clip to

the “B” panel studs as shown using one (1) hex headed screw per clip.

C. Repeat step 4A and 4B for the “D2” (roof) panel and second “B-A-B” (side-end-side) assembly.

Side View of Roof Panels

The information contained herein is intended for the use of the individual(s) named above and those authorized to receive it. Dissemination, distribution

or copy of this information is strictly prohibited.

5. Place the Inner Roof Connection Bracket under the “D1-D2” 2x4 connection on the inside. Fasten the

Inner Roof Connection Bracket into place (Fig. 1E) using hex headed screws.

A. The Inner Roof Connection Bracket has tabs on each end that will fasten to the tops of the “F” post studs

later.

6. Attach an Outside Corner Anchoring Bracket to an “A-B” (corner) assembly using two (2) hex

headed screws. Fasten the bracket to the concrete (Fig 1A) using one (1) anchor. Fasten one (1)

Outside Corner Anchoring Bracket at both “A-B”(corner) assemblies on one side.

A. Attach the Inside Anchoring Brackets to the “B” panel studs at the bottom, inside at the concrete

(Fig 1B) using two (2) hex headed screws per bracket. Fasten them to the concrete using one (1) anchor

per bracket. Fasten the Inside Anchoring Brackets to the “B” panel studs and concrete along one side of

the enclosure.

B. Repeat Steps 6 and 6A on the other side of the enclosure.

7. With the “F” (support) posts aligned within the spaces between the “C” panels. Install an Inside

Anchoring Bracket (Fig 1B) at the bottom of the “F” (support) posts.

A. Attach the “F” (support) posts to the Inner Roof Connection Bracket tabs using hex headed screws.

8. Install Roof Cover Plates on the “D1-D2”roof seams (Fig. 1D) using two (2) hex headed screws per

plate.

9. Provide a ground-fault interrupter device in all electrical circuits per all applicable codes. Install the

heater(s) as per the manufacturer’s instructions and governing local and national codes.

10. For maximum protection, it is suggested that the area between the bottom of the enclosure and the

concrete base should be caulked except for the “C”panels. DO NOT CAULK THE BOTTOM OF

THE “C”PANELS.

11. REMOVE THE PVC MASKING FILM IMMEDIATELY AFTER INSTALLATION. If the panels

get wet with the masking film in place, water will irreversibly stain the panels. Summertime heat will

bake the masking film onto the panels.

The information contained herein is intended for the use of the individual(s) named above and those authorized to receive it. Dissemination, distribution

or copy of this information is strictly prohibited.

Model No. 800S-AL Series

Model No. 1000S-AL Series

Model No. 1000TS-AL Series

CONTENTS

1. Your assembly should include

A. 2- “A”(end) Panels

B. 4- “B” (side) Panels

C. 3- “C”(access) Panels

D. 1- “Cw/d” (access) Panel

E. 1- “D1” (roof) Panel

F. 1- “D2” (roof) Panel
