Hyperion Wireless MSE Installation Guide www.wrensolutions.com 7L781 Rev A 200428
INSTALLATION GUIDE
HYPERION MODULAR SECURITY ENCLOSURE
HYP-MSEWENR-W

Hyperion Wireless MSE Installation Guide www.wrensolutions.com 7L781 Rev A 200428
ABOUT THIS DOCUMENT
This document pertains to installation of the Hyperion Modular
Security Enclosure (HYP-MSEWENR-W). Before installation, please
familiarize yourself with this installation guide and review the Hyperion
User Guide to understand system configuration and setup.
PRODUCT MODIFICATIONS
This product is to be installed and used for the specific purpose for
which it was designed. It is not to be modified or serviced by anyone
other then Wren. Unauthorized changes or modifications to the
product will result in the warranty being voided and could possibly
invalidate regulatory certifications.
WARRANTY
Unless otherwise noted, all products are covered by Wren's Standard
Limited Manufacturer's Warranty as set forth in the current version of
Wren's Terms and Conditions
INTELLECTUAL PROPERTY RIGHTS
Wren maintains certain intellectual property rights that may pertain to
this product. To see a list of our patents, please refer to our
TRADEMARK ACKNOWLEDGMENTS
Wren®. the Wren logo, Hyperion® and the Hyperion logo are
trademarks of Wren. The trademarks that are followed by ® are
registered trademarks in the U.S. All other trademarks and/or
registered trademarks mentioned herein are properties of their
respective owners and are for reference purposes only. The use of
such third party trademarks does not indicate any affiliation with or
sponsorship of or by Wren. All rights reserved.
NOTICES
RF Exposure for FCC
WARNING: To satisfy FCC RF exposure requirements for mobile
transmitting devices, a separation distance of 31 cm or more should be
maintained between the antenna of this device and persons during
device operation. To ensure compliance, operations at closer than this
distance is not recommended. The antenna used for this transmitter
must not be co-located in conjunction with any other antenna or
transmitter.
RF Exposure for IC
WARNING: To satisfy IC RF exposure requirements for mobile
transmitting devices, a separation distance of 44 cm or more should be
maintained between the antenna of this device and persons during
device operation. To ensure compliance, operations at closer than this
distance is not recommended. The antenna used for this transmitter
must not be co-located in conjunction with any other antenna or
transmitter.
AVERTISSEMENT: Pour satisfaire IC RF exigences d’exposition pour
les appareils mobiles de transmission, une distance de séparation de 44
cm ou plus doit être maintenue entre l’antenne de cet appareil et des
personnes pendant le fonctionnement de l’appareil. Pour assurer la
conformité, les opérations au plus près que cette distance ne sont pas
recommandés. L’antenne utilisée pour cet émetteur ne doit pas être
situé en conjonction avec une autre antenne ou émetteur.
[phone]
PRODUCT SUPPORT
For comprehensive product support including manuals, FAQs and troubleshooting, visit our customer support portal.
WWW.WRENSOLUTIONS.COM
/HYPERION/HYPERION-SUPPORT

Hyperion Wireless MSE Installation Guide www.wrensolutions.com 7L781 Rev A 200428
Prior to installation, verify that all hardware is included. If there are missing components, please contact Wren.
COMPONENT LIST
Hyperion MSE Unit
w/ Hyperion Radio
REQUIRED TOOLS AND ACCESSORIES
Wrench Hammer Drill
Mounting Hook Mounting Hardware
(includes masonry bit)
Steps to install masonry sleeve anchors
• Using a hammer drill and drill bit provided in Hardware Anchor Kit, drill a hole 3.5” deep.
• Clean out the hole of all debris.
• Set the nut ush with the top of the sleeve anchor
• Insert the sleeve anchor through the xture into the hole in the wall until the washer and nut are
tight against the mounting plate.
• Turn the nut until nger tight then use a wrench to set the anchor by turning the nut three to four
full turns.
BEFOR MOUNTING, PLEASE READ THE ANCHOR INSTALLATION
INSTRUCTIONS BELOW.
Power Supply

Hyperion Wireless MSE Installation Guide www.wrensolutions.com 7L781 Rev A 200428
IDENTIFY MOUNTING LOCATION
1
Mounting Surface
The Hyperion MSE should be mounted to a structurally solid surface. When selecting a mounting location, take
care to ensure that there are no obstructions, especially solid metal surfaces in the immediate vicinity of the
radio and antenna. We suggest a minimum 3 foot zone surrounding the area.
Mounting Height
The minimum recommended mounting height for the Hyperion Radio is 10 feet from ground level. Mounting
heights over or under 10 feet are acceptable but the areas must be free and clear of any obstructions.
NOTE:
• OBSTRUCTIONS WILL NEGATIVELY IMPACT RADIO PERFORMANCE
• ENSURE THAT THERE ARE NO OBSTRUCTIONS, ESPECIALLY METAL, NEAR THE HYPERION RADIO
OR ANTENNA
• IT MAY BE NECESSARY TO RELOCATE THE RADIO IF PERFORMANCE /RECEPTION IS POOR.
Antenna
R 3’-0”

Hyperion Wireless MSE Installation Guide www.wrensolutions.com 7L781 Rev A 200428
2MOUNTING HOOK INSTALLATION
Install the Mounting Hook in the desired location. Use 2 of the anchors provided in the hardware kit.
Refer to the masonry sleeve anchor instructions in this document for proper installation of anchors.
3PREP THE WALL FOR MOUNTING
Hang the MSE on the Mounting hook. Mark all four anchor locations and the cable entry location.
Install the
Anchors

Hyperion Wireless MSE Installation Guide www.wrensolutions.com 7L781 Rev A 200428
4INSTALL MSE ANCHORS
Remove the MSE from the hanger and drill the anchor holes using the masonry bit provided.
Install the anchors per the instructions provided in this document.
Drill a 3/4” cable entry hole in the marked location.
5MOUNT THE MSE
Hang the MSE on the hanger and secure the device to all four installed anchors.

Hyperion Wireless MSE Installation Guide www.wrensolutions.com 7L781 Rev A 200428
6MOUNT THE POWER SUPPLY
The Hyperion MSE power supply should be located in-
side of the building near an AC110V outlet.
7RUN CABLING
Cabling Specications
For extended low voltage runs, we suggest the
use of 18AWG or larger. The maximum cabling
distance is 100 feet.
Cabling Procedure
Run power cable through wall and into the
MSE. Attach the cable to the DC power con-
nector
on the
Power IN
Power IN
NOTE:
• ONLY USE THE POWER SUPPY PROVIDED WITH
THE DEVICE
• IMPROPER CABLING COULD DAMAGE THE
EQUIPMENT AND VOID PRODUCT WARRANTY
Power
Supply

Hyperion Wireless MSE Installation Guide www.wrensolutions.com 7L781 Rev A 200428
8SEAL CABLE PENETRATION
Seal the Cable Penetration using an appropriate
outdoor sealant.
9ATTACH THE DOOR
Attach the door and secure all four fasteners.
10 CONNECT POWER
Connect the power supply to AC110V.
11
The device is now powered on and ready to be added
to Hyperion.
Refer to the Hyperion User Manual for setup details.
