RUBY 10 Safety and Care
© 2021 Freedom Scientific, Inc. All Rights Reserved. RUBY®is a registered trademark of
Freedom Scientific, Inc. in the United States and other countries.
Read these instructions carefully before setting up your RUBY 10. Keep this
document for future reference.
Cleaning the LCD Screen
Before cleaning the LCD screen, power off and unplug the device. Use a dry,
clean microfiber cloth to gently wipe the cloth across the screen. Optionally, use
an appropriate LCD cleaning liquid and follow its instructions.
Warning: Do not use a paper towel. Do not press down hard on the screen.
Cleaning the RUBY 10 Body
Unplug the device before cleaning the body. Use a lightly dampened, soft,
clean cloth with water or mild detergent.
Product Specifications
Trade name
RUBY 10
Magnification range
1.8x to 22x
Full-page magnification
0.4x to 13x
Color modes
Full color, high contrast positive, high
contrast negative, yellow on black, and
yellow on blue
Focus
Auto-focus
Screen
10-in TFT, 450 cd/m2
Screen resolution
1280 x 800
Camera
60 fps
Depth of focus
Approximately 20 cm
Dimensions
261 x 189 x 36 mm / 10.28 x 7.44 x 1.42 in
Weight
915 grams / 2.02 lb
Battery
Approximately 3.5 hours continuous use and
4 hours charging time
Li-ion battery
Rechargeable, 3.7 V, 7600 mAh, 28.12 Wh
Connections
USB-C, 3.5 mm audio jack
Medical power supply
Adapter Technology Co., LTD.
ATM012T-W052VU
Consumer power supply
Shenzhen Fujia Appliance Co., Ltd.
FJ-SW1260502500UN
Adapter input power rating
100-240 VAC, 50-60 Hz, 0.19-0.32 A
Adapter output power rating
5.1 VDC, 2.4 A

2 RUBY 10 Safety and Care
Warnings and Precautions
Do not remove any parts or disassemble your unit as it will void the warranty.
Contact an authorized service organization in your area.
Note these warnings and precautions:
To avoid the risk of electric shock, this equipment must only be connected
to a supply main with protective earth.
Critical diagnostic, medical or legal decisions should not be based on
images displayed by this device as the device is not intended for
processing of important medical, legal, or other information of a sensitive
nature.
Only use the cables provided with the unit and do not force the power
connector into the device’s power port.
Do not spray any cleaning solutions directly on the LCD screen.
Do not use alcohol, solvents, abrasives, aerosols, or any cleanser that
contains acetone, ethyl alcohol, ethyl acid, ammonia, or methyl chloride.
Do not expose the RUBY 10 to excessive heat, direct sunlight, extreme or
rapid changes in temperature or humidity.
To avoid risk of electrical damage, keep your device away from fluids and
chemicals.
Handle the RUBY 10 with care. Rough handling will damage the internal
components.
Do not use the RUBY 10 near inadequately shielded medical devices.
Do not touch or look directly at the illumination lights.
Be careful that your fingers and clothing do not get stuck in moving parts
(swing-out arm, stand).
To prevent possible hearing damage, do not listen at high volume levels for
long periods.
Common side effects of using an electronic display device for prolonged
periods of time can lead to eye fatigue and headaches.
Do not place the device on an unstable surface. It may fall, causing serious
damage to the unit, or injury to the user.
Precautions for Battery Pack
Do not charge your battery if your device appears damaged, deformed, or
defective. Contact your Freedom Scientific distributor or the nearest Freedom
Scientific office for further instructions prior to use.
BATTERY MUST BE REPLACED BY CERTIFIED SERVICE PERSONNEL.
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE REGULATIONS.

RUBY 10 Safety and Care 3
English
Contacting Product Support
For product support, contact your Freedom Scientific dealer or email
[email protected] or call [phone] weekdays between
8:30 AM and 7 PM ET. If any serious incident occurs in relation to the
RUBY 10, report to Freedom Scientific and the competent authority of the
country or Member State where you are established.
Freedom Scientific, 17757 US Hwy 19 N #560, Clearwater, FL 33764,
United States, www.FreedomScientific.com
Optelec Nederland BV, Pesetastraat 5a, 2991 XT, Barendrecht, The
Netherlands, www.in.Optelec.com
Operating Conditions
Storage and Transportation
Conditions
Temperature +10°C to 35°C /
50°F to 95°F
Relative humidity < 70%, no
condensation
Altitudes up to 3,000 m (9,842 ft)
Pressure 700 – 1060 hPa
Temperature +10°C to 40°C /
50°F to 104°F
Relative humidity < 95%, no
condensation
Altitudes up to 12,192 m (40,000 ft)
Pressure 186 – 1060 hPa
RUBY 10 is tested by a recognized body and independent laboratory for safety
and regulatory compliance.
Description
Requirement
FCC / EMC
47 CFR Part 15 FCC Class B
Safety
UL/EN/CSA 62638-1:2014; IEC 60601-1:2012 reprint
CE / EMC
EN 55022:2010; IEC 60601-1-2:2014;
EN 60601-1-2:2015
Usability
IEC 60601-1-6:2013, IEC 62366:2015
Risk management
ISO 14971:2019
ICC
CAN/CSA-CISPR22-10
Environmental
Consumer Product Safety Improvement Act of 2008
Environmental
FDA/OSHA/EPA regulations for toxic substances
Environmental
California Proposition 65
Safety (battery)
IEC62133-2:2017 CB report
Transportation
(battery)
UN38.3 6th revision, amend 1/CNAS/SDS

4 RUBY 10 Safety and Care
Clinical Benefit
Magnifiers empower the user, helping to instill independence, increase
productivity, and improve self-esteem. In short, those who struggle with daily
tasks due to low vision find their quality of life enhanced by utilizing magnifiers.
Intended Purpose
This device is intended to be used as a vision enhancement product by people
who require vision assistance when performing reading of printed materials or
viewing objects encountered during everyday use. The device is not intended to
be relied upon exclusively for the interpretation of sensitive or professional
material, such as medical or legal documents.
Intended Use Environment
The RUBY 10 is for use in a home, work, or school environment for the purpose
of enlarging and enhancing images.
Intended User
The RUBY 10 is intended to be used by anyone with a visual impairment.
Performance Characteristics
Magnification and enhancement of images.
Expected Service Life
The RUBY 10 does not create any unacceptable hazardous conditions (as
defined by IEC 60601-1 Medical electrical equipment—General Requirements
for Basic Safety and Essential Performance) and will be safe to use for 10
years or longer. Expected service life does not represent the actual operating
life or warranty period of the device.
Reasonably Foreseeable Misuse
Dropping the device from desk height. Operating the device forcefully. Using
wrong accessories. Using device to read medical or legal documents.
Layperson Information
For use by laypersons. Freedom Scientific is not responsible for any uses of
this device other than those described in this manual.
Guideline
Input rating for RUBY 10: 5 VDC, 3 A
Protection against electric shock: Class I
WEEE Notice
The directive on Waste Electrical and Electronic Equipment (WEEE), which
entered into force as European law on February 13, 2003, resulted in a major
change in the treatment of electrical equipment at end-of-life.
The purpose of this Directive is the prevention of WEEE, and in
addition, to promote the reuse, recycling, and other forms of
recovery of wastes to reduce disposal. The WEEE logo on the
product or its box indicates that this product must not be disposed of
or dumped with your other household waste.

RUBY 10 Safety and Care 5
English
You are liable to dispose of your electronic or electrical waste equipment
placing it in the specified collection point for recycling of hazardous waste.
Isolated collection and proper recovery of your electronic and electrical waste
equipment at the time of disposal will help conserve natural resources.
Moreover, proper recycling of the electronic and electrical waste equipment will
ensure the safety of human health and the environment. For more information
about electronic and electrical waste equipment disposal, recovery, and
collection points, contact your local city center, household waste disposal
service, shop from where you purchased the equipment, or manufacturer of the
equipment.
Warranty Conditions
Freedom Scientific warrants the RUBY 10, effective from the date of delivery, to
be free of any defects in material and workmanship. The warranty is not
transferable and does not apply to groups or multi-users. The RUBY 10 was
designed for the individual purchaser to be used at home, school, and work.
Freedom Scientific reserves the right to repair or replace any purchased RUBY
10 with a similar or improved product.
In no event shall Freedom Scientific or its suppliers be held liable for any
indirect or consequential damages. The original user’s remedies are limited to
replacement of RUBY 10 modules. This warranty is valid only when serviced in
the country of original purchase, and with intact seals. For additional warranty
claims or service during or after warranty period, contact your Freedom
Scientific distributor. Use of the RUBY 10 other than described in this manual
will exclude it from warranty conditions. Any changes or modifications not
expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment. Contact your local dealer for details
about the duration of this warranty.
Declaration of Conformity
We declare under our sole responsibility that this product, to which this
declaration relates, is in conformity with the council EMC directive 2014/30/EU
and the RED directive 2014/53/EU. This device bears the CE and FCC
approval mark.
Compliance Notice
EU MDR 2017/745
UL 1642, 5th Edition
This product complies with Directive 2011/65/EU of the European Parliament
and of the Council of 3 January 2013, on the restriction of the use of certain
hazardous substances in electrical and electronic equipment (RoHS-II) and its
amendments.

6 RUBY 10 Safety and Care
Susceptibility to Interference
There may be temporary degradation of the image when the RUBY 10 HD is
subjected to a strong radio frequency field, electrostatic discharge, or transient
electrical noise. An electrostatic discharge (caused by static electricity) may
cause the screen to go blank. If this happens, follow these steps:
1. Disconnect the DC adapter power supply from the electrical outlet.
2. Turn off the device.
3. Wait 30 seconds.
4. Connect the DC adapter power supply again and turn on the device.
External Influences
Electronic devices can be sensitive to electric discharge and electromagnetic
fields caused by other electronic equipment. The device should be operated at
a minimum distance of one meter away from other electronic or
telecommunication devices. All external influences tested for as required by
60601 standards.
Federal Communications Commission (FCC) Notice
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures: reorient or relocate the receiving antenna; increase the
separation between the equipment and receiver; connect the equipment into an
outlet on a circuit different from that to which the receiver is connected; consult
the dealer or an experienced radio or television technician for help. Changes or
modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
FCC RF Radiation Exposure and SAR Statements
The RUBY 10 has been tested for body-worn Specific Absorption Rate (SAR)
compliance. The RUBY 10 radio module has been evaluated under FCC
Bulletin OET 65C (01-01) and found to be compliant with the requirements as
set forth in CFR 47 Sections, 2.1093, and 15.247 (b) (4) addressing RF
exposure from radio frequency devices. This model meets the applicable
government requirements for exposure to radio frequency waves. The highest
SAR level measured for this device was 0.15 W/kg.
Frequency range Wi-Fi: 2412~2472 MHz BT 2402~2480 MHz
Max. transmit power Wi-Fi: 18.0 dBm BT 5.0 dBm

RUBY 10 Safety and Care 7
English
Industry Canada (IC) Notice
This Class B digital apparatus complies with Canadian ICES-003.
Label Markings
WEEE icon Fragile
This side up Keep dry
CE mark
FCC mark
Warning/precaution
Power rating
Manufacturer Date of manufacture
Barcode Serial number
Authorized representative Catalog number
Consult instructions
Medical device
Refer to instruction
manual/booklet
