Hyundai power products HM20V User manual

1
CORDLESS ANGLE GRINDER
HM20V
ORIGINAL INSTRUCTIONS

2
Warning: Please read the manual carefully before using the unit!
1. INSTRUCTIONS OF SECURITY
WARNING Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference. The term "power tool" in the
warnings refers to your mains-operated (corded) power tool or battery-operated (cordless)
power tool.
1) Work area safety
a) Keep work area clean and well lit.Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks which
may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions
can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do
not use any adapter plugs with earthed (grounded) power tools. Unmodified
plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric shock if
your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool
will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging
the power tool. Keep cord away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric
shock.
f) If operating a power tool in a damp location is unavoidable, use a residual
current device (RCD) protected supply. Use of an RCD reduces the risk of electric
shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating a
power tool. Do not use a power tool while you are tired or under the influence
of drugs, alcohol or medication. A moment of inattention while operating power
tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position
connecting to power source and/or battery pack, picking up or carrying the
tool. Carrying power tools with your finger on the switch or energizing power tools
that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of the power tool may result in
personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables
better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewelry or long hair can be
caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of dust collection
can reduce dust-related hazards.

3
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application.
The correct power tool will do the job better and safer at the rate for which it was
designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power
tool that cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the
power tool before making any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce the risk of starting the power
tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to be
performed. Use of the power tool for operations different from those intended could
result in a hazardous situation.
Battery tool use and care
a) Recharge only with the charger specified by the manufacturer. A charger that is
suitable for one type of battery pack may create a risk of fire when used with another
battery pack.
b) Use power tools only with specifically designated battery packs.Use of any
other battery packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it away from other metal objects, like
paper clips, coins, keys, nails, screws or other small metal objects that can
make a connection from one terminal to another. Shorting the battery terminals
together may cause burns or a fire.
d) Under abusive conditions, liquid may be ejected from the battery; avoid contact.
If contact accidentally occurs, flush with water. If liquid contacts eyes,
additionally seek medical help.Liquid ejected from the battery may cause irritation
or burns.
5) Service
a) Have your power tool serviced by a qualified repair person using only identical
replacement parts.This will ensure that the safety of the power tool is maintained.
Safety instructions for all operations
Safety Warnings Common for Grinding, Sanding, Wire Brushing, Polishing or Abrasive
Cutting-Off Operations
a) This power tool is intended to function as a grinder or cut-off tool. Read all
safety warnings, instructions, illustrations and specifications provided with this
power tool. Failure to follow all instructions listed below may result in electric shock,
fire and/or serious injury.
b) Operations such as sanding, wire brushing or polishing are not recommended
to be performed with this power tool. Operations for which the power tool was not
designed may create a hazard and cause personal injury.
c) Do not use accessories which are not specifically designed and recommended
by the tool manufacturer. Just because the accessory can be attached to your
power tool, it does not assure safe operation.
d) The rated speed of the accessory must be at least equal to the maximum speed
marked on the power tool. Accessories running faster than their rated speed can
break and fly apart.

4
e) The outside diameter and the thickness of your accessory must be within the
capacity rating of your power tool. Incorrectly sized accessories cannot be
adequately guarded or controlled.
f) Threaded mounting of accessories must match the grinder spindle thread. For
accessories mounted by flanges, the arbour hole of the accessory must fit the
locating diameter of the flange. Accessories that do not match the mounting
hardware of the power tool will run out of balance, vibrate excessively and may cause
loss of control.
g) Do not use a damaged accessory. Before each use inspect the accessory such
as abrasive wheels for chips and cracks, backing pad for cracks, tear or excess
wear, wire brush for loose or cracked wires. If power tool or accessory is
dropped, inspect for damage or install an undamaged accessory. After
inspecting and installing an accessory, position yourself and bystanders away
from the plane of the rotating accessory and run the power tool at maximum
no-load speed for one minute. Damaged accessories will normally break apart
during this test time.
h) Wear personal protective equipment. Depending on application, use faces
shield, safety goggles or safety glasses. As appropriate, wear dust mask,
hearing protectors, gloves and workshop apron capable of stopping small
abrasive or workpiece fragments. The eye protection must be capable of stopping
flying debris generated by various operations. The dust mask or respirator must be
capable of filtrating particles generated by your operation. Prolonged exposure to
high intensity noise may cause hearing loss.
i) Keep bystanders a safe distance away from work area. Anyone entering the
work area must wear personal protective equipment. Fragments of workpiece or
of a broken accessory may fly away and cause injury beyond immediate area of
operation.
j) Hold the power tool by insulated gripping surfaces only, when performing an
operation where the cutting accessory may contact hidden wiring or its own
cord. Cutting accessory contacting a "live" wire may make exposed metal parts of the
power tool "live" and could give the operator an electric shock.
k) Position the cord clear of the spinning accessory. If you lose control, the cord
may be cut or snagged and your hand or arm may be pulled into the spinning
accessory.
l) Never lay the power tool down until the accessory has come to a complete stop.
The spinning accessory may grab the surface and pull the power tool out of your
control.
m) Do not run the power tool while carrying it at your side. Accidental contact with
the spinning accessory could snag your clothing, pulling the accessory into your body.
n) Regularly clean the power tool’s air vents. The motor’s fan will draw the dust
inside the housing and excessive accumulation of powdered metal may cause
electrical hazards.
o) Do not operate the power tool near flammable materials. Sparks could ignite
these materials.
p) Do not use accessories that require liquid coolants. Using water or other liquid
coolants may result in electrocution or shock.
Further safety instructions for all operations
Kickback and Related Warnings
Kickback is a sudden reaction to a pinched or snagged rotating wheel, backing pad, brush or
any other accessory. Pinching or snagging causes rapid stalling of the rotating accessory
which in turn causes the uncontrolled power tool to be forced in the direction opposite of the
accessory’s rotation at the point of the binding.
For example, if an abrasive wheel is snagged or pinched by the workpiece, the edge of the
wheel that is entering into the pinch point can dig into the surface of the material causing the
wheel to climb out or kick out. The wheel may either jump toward or away from the operator,
depending on direction of the wheel’s movement at the point of pinching. Abrasive wheels
may also break under these conditions.
Kickback is the result of power tool misuse and/or incorrect operating procedures or
conditions and can be avoided by taking proper precautions as given below.

5
a) Maintain a firm grip on the power tool and position your body and arm to allow
you to resist kickback forces. Always use auxiliary handle, if provided, for
maximum control over kickback or torque reaction during start-up. The operator
can control torque reactions or kickback forces, if proper precautions are taken.
b) Never place your hand near the rotating accessory. Accessory may kickback over
your hand.
c) Do not position your body in the area where power tool will move if kickback
occurs. Kickback will propel the tool in direction opposite to the wheel’s movement at
the point of snagging.
d) Use special care when working corners, sharp edges etc. Avoid bouncing and
snagging the accessory. Corners, sharp edges or bouncing have a tendency to
snag the rotating accessory and cause loss of control or kickback.
e) Do not attach a saw chain woodcarving blade or toothed saw blade. Such
blades create frequent kickback and loss of control.
Additional safety instructions for grinding and cutting-off operations
Safety Warnings Specific for Grinding and Abrasive Cutting-Off Operations:
a) Use only wheel types that are recommended for your power tool and the
specific guard designed for the selected wheel. Wheels for which the power tool
was not designed cannot be adequately guarded and are unsafe.
b) The grinding surface of centre depressed wheels must be mounted below the
plane of the guard lip. An improperly mounted wheel that projects through the plane
of the guard lip cannot be adequately protected.
c) The guard must be securely attached to the power tool and positioned for
maximum safety, so the least amount of wheel is exposed towards the operator.
The guard helps to protect the operator from broken wheel fragments, accidental
contact with wheel and sparks that could ignite clothing.
d) Wheels must be used only for recommended applications. For example: do not
grind with the side of cut-off wheel. Abrasive cut-off wheels are intended for
peripheral grinding, side forces applied to these wheels may cause them to shatter.
e) Always use undamaged wheel flanges that are of correct size and shape for
your selected wheel. Proper wheel flanges support the wheel thus reducing the
possibility of wheel breakage. Flanges for cut-off wheels may be different from
grinding wheel flanges.
f) Do not use worn down wheels from larger power tools. Wheel intended for larger
power tool is not suitable for the higher speed of a smaller tool and may burst.
Additional safety instructions for cutting-off operations
Additional Safety Warnings Specific for Abrasive Cutting-Off Operations:
a) Do not “jam” the cut-off wheel or apply excessive pressure. Do not attempt to
make an excessive depth of cut. Overstressing the wheel increases the loading
and susceptibility to twisting or binding of the wheel in the cut and the possibility of
kickback or wheel breakage.
b) Do not position your body in line with and behind the rotating wheel. When the
wheel, at the point of operation, is moving away from your body, the possible
kickback may propel the spinning wheel and the power tool directly at you.
c) When wheel is binding or when interrupting a cut for any reason, switch off the
power tool and hold the power tool motionless until the wheel comes to a
complete stop. Never attempt to remove the cut-off wheel from the cut while the
wheel is in motion otherwise kickback may occur. Investigate and take corrective
action to eliminate the cause of wheel binding.
d) Do not restart the cutting operation in the workpiece. Let the wheel reach full
speed and carefully re-enter the cut. The wheel may bind, walk up or kickback if
the power tool is restarted in the workpiece.
e) Support panels or any oversized workpiece to minimize the risk of wheel
pinching and kickback. Large workpieces tend to sag under their own weight.
Supports must be placed under the workpiece near the line of cut and near the edge
of the workpiece on both sides of the wheel.

6
f) Use extra caution when making a “pocket cut” into existing walls or other blind
areas. The protruding wheel may cut gas or water pipes, electrical wiring or objects
that can cause kickback.
Additional safety warnings:
a) Check that the maximum speed indicated on the grinding disc corresponds to the
maximum speed of the machine. The speed of the machine must not exceed the
value on the grinding disc.
b) Make sure that the dimensions of the grinding disc correspond to the specifications of
the machine.
c) Make sure that the grinding disc has been mounted and fastened properly. Do not
use reducing rings or adapters to make the grinding disc fit properly.
d) Do not use the machine for grinding workpieces with a maximum thickness exceeding
the maximum grinding depth of the grinding disc.
e) Do not use grinding discs for deburring.
f) When grinding discs have to be mounted on the thread of the spindle, make sure that
the spindle has sufficient thread. Make sure that the spindle is sufficiently protected
and does not touch the grinding surface.
g) Before use, inspect the grinding disc for any damage. Do not use grinding discs
which are cracked, ripped or otherwise damaged.
h) Before use, let the machine run idle for 30 seconds.
i) Immediately switch off the machine in case of abnormal vibrations or occurrence of
another defect. Carefully inspect the machine and grinding disc before switching the
machine on again.
j) Make sure that sparks do not put people into danger or that they contact highly
flammable substances.
k) Make sure that the workpiece is sufficiently supported or clamped. Keep your hands
away from the surface to be cut.
l) Always wear safety goggles and hearing protection. Also use a helmet when
appropriate.
m) Ensure that mounted wheels and points are fitted in accordance with the
manufacturer's instructions.
n) Ensure that blotters are used when they are provided with the bonded abrasive
product and when they are required.
o) The tool must be always used with the guard. Never use the tool without the guard.
p) For tools intended to be fitted with threaded hole wheel, ensure that the thread in the
wheel is long enough to accept the spindle length.
q) Ensure that ventilation openings are kept clear when working in dusty conditions. If it
should become necessary to clear dust, first disconnect the tool from the mains
supply (use non-metallic objects) and avoid damaging internal parts.
Symbols
Refer to the instructions manual
Wear ear protection
Wear eyes protection
WEEE symbol for disposal

7
2. THE PRODUCT
a. Description
1. Hand grip
2. Li-on Battery
3. wrench for disk installation
4. Side handle
5. Guard
6. Backing washer
7. Disc clamping nut
8. guard clamp lever
9. ON/OFF trigger with safety latch
10. Spindle lock
11. Battery release catch
1
2
3
4
5
6
7
8
9
10
11

8
b. Technical data
Model
HM20V
Voltage
20V dc.
Rated speed in revolution per
minute
10000/min
Rated capacity in mm
Ø125mm
Spindle thread size
M16
Sound pressure level Lpa
88 dB(A), K=3 dB(A)
Sound power level Lwa
99 dB(A) , K=3 dB(A)
Vibration value
4.9 m/s2,K=1,5 m/s²
Information
The declared vibration total value has been measured in accordance with a standard test
method and may be used for comparing one tool with another;
The declared vibration total value may also be used in a preliminary assessment of
exposure.
Warning
The vibration emission during actual use of the power tool can differ from the declared
total value depending on the ways in which the tool is used;
It is necessary to identify safety measures to protect the operator that are based on an
estimation of exposure in the actual conditions of use (taking account of all parts of the
operating cycle such as the times when the tool is switched off and when it is running idle
in addition to the trigger time).
Intended use
This angle grinder is designed for grinding and roughing metal such as metal or stone. The
capacity of the tool is 125 mm maximum. Specially design to work with Hyundai range of
battery and charger.
Do not use this tool for commercial purposes; it is only for a private household use.

9
3. OPERATION
NOTE: Supplied without battery or charger
(4)

10
a. Charging (Attention: Charger and battery not included in this model)
1) Take the battery pack out of the equipment. Do this by pressing the push lock button.
2) Check that your mains voltage is the same as that marked on the rating plate of the battery
charger. Insert the power plug of the charger into the socket outlet. The RED LED will then
begin to light.
3) Insert the battery pack into the battery charger .then the red LED on charger will begin to
Green flash light.
4) You will find a label with “Charger indicator” of the LED indicator on the charger.
The battery pack can become a little warm during the charging. This is normal.
If the battery pack fails to charge, check:
Voltage at the power socket
Whether there is good contact at the charging contacts.
Whether the battery pack is warm or not. The battery protection system will not allow the
battery to be charged if the battery temperature is over 40℃after use. Allow the battery
pack to cool to room temperature before commencing with the charging.
If the battery pack still fails to charge, send the charging unit and the battery pack to our
customer service center.
To ensure that the battery pack provides long service, you should take care to recharge it
promptly. You must recharge the battery pack when you notice that the power drops. Never
allow the battery pack to become fully discharged. This will cause it to develop a defect.
Battery capacity indicator
Press the switch for the battery capacity indicator . The battery capacity indicator shows the
charge status of the battery using 4 LEDs as following:
All 4 LEDs are lit:
The battery is fully charged.
3 LED(s) are lit:
The battery has approx. 75% remaining charge.
2 LED(s) are lit:
The battery has approx. 50% remaining charge.
1 LED is lit:
The battery will be empty soon, please recharge the battery.

11
Charger indicator
Indicator status
Explanations and actions
Ready for use
The charger is connected to the mains and is ready for use; there is no
battery pack in the charger.
Charging
The charger is charging the battery pack in charge mode.
Battery pack is full of charge.
Charging is finished and battery pack in the charger.
The temperature of battery is too high or too low, the charger is under
protection status. The charging function can be recovered after the
temperature is normal.
Unrecoverable battery malfunction.
b. Assembly
WARNING: Be sure that the tool is switched off and the battery is removed
from the tool before assembly.
Installing the handle
The handle can be installed to either side of the tool (Fig. 3). Screw the handle in the
hole. Be sure that the handle is well installed but it is no need to over tighten.
Guard adjustment
Never use the angle grinder without the guard in place and properly adjusted!
- Unlock the guard clamp lever (Fig. 4).
- Rotate the guard to the correct position as shown in figures 5 and 6.
- Lock the guard clamp lever and retighten clamp screw securely if needed.
WARNING! Never place the guard so that it is on the front of the angle grinder. This
could serious injuries.
Never use the tool without the guard. It has been designed for use only with the guard
installed.
Installing battery pack
Slide the battery pack into the tool base, fig7. Make sure that the battery pack snaps
into place and that battery pack is secured in the tool before beginning operation.
Improper installation of battery pack can cause damage.
Removing the battery pack
Push the battery release catch (fig 8). While holding down the battery release catch,
slide the battery pack away from the tool.

12
Removing the disc clamping nut
Depress the spindle lock button (fig 10). Use a wrench, insert the pins into the holes
on the disc clamping nut. Turn the wrench anticlockwise to release the disc clamping
nut.
If the disc backing washer is removed it must be replaced the correct way round. The
correct way to fit this onto the shaft can be seen in Fig 11.
NOTE: There are different types of discs used for different applications. Select the
correct one for the work being done. Make sure the disc backing washer flats are
located correctly with the flats on the shaft. The grinding disc should be placed onto
the angle grinder with the writing facing upwards
Installing new disc
Place the disc over the shaft locating it onto the disc backing washer. It can be seen
that the backing washer has a raised lip.
The hole in the disc should match the diameter of the raised lip, keeping the disc
mounted central. Refit the disc clamping nut (fig 12). Tighten with fingers until the disc
is clamped. Depress the spindle lock and using the supplied wrench (Fig 13). Tighten
the locking washer in clockwise direction until the disc is firmly clamped but do not
over tighten. Release the spindle lock and turn the angle grinder over.
WARNING! Always install grinding disc and abrasive with the depressed center
against the backing washer. Failure to do so will cause the grinding disc to crack
when tightening the disc clamping nut. This could result in serious personal injury
because of loose articles breaking off and being thrown from the angle grinder. Do
not over tighten.
c. Starting and stopping (pic. 14)
CAUTION! Before inserting the battery into the tool, always check to see that
the trigger switch actuates properly and return to the OFF position when the
trigger is depressed.
To start the tool, pull back the safety lever (14.1) towards the rear of the machine and
then squeeze the ON/OFF trigger (14.2).
To stop the tool, release the trigger
d. Operation
WARNING! It should never be necessary to force the tool. The weight of the tool
applies adequate pressure. Forcing and excessive pressure could cause dangerous
disc breakage.
Always replace disc if the tool is dropped while grinding.
Never band or hit grinding disc or wheel onto the workpiece
Avoid bouncing and snagging the disc, especially when working corners, sharp edges.
This can cause loss control and kickback.
Never use tool with wood cutting blades and others saw blades. Such blades when
used on a grinder frequently kick and cause loss of control leading to personal injury.
After operation, always switch off the tool and wait until the wheel has come to a
complete stop before putting the tool down.
If the tool is operated continuously until the battery is discharged, allow the tool to rest
for 15 minutes before proceeding with a fresh battery.

13
e. Grinding
Secure all work before beginning any operation.
Secure small workpiece in a vise or clamp to a workbench.
They key to efficient operation is controlling the pressure and surface contact
between the grinding wheel and workpiece.
Always hold the tool firmly with one hand on housing and the other on the side handle.
Turn the tool on and then apply the disc to the workpiece.
In general, keep the edge of the disc at an angle of about 15 degrees to the
workpiece surface (fig 15). During the break-in-period with a new disc, do not work
the grinder in the B direction or it will cur into the workpiece. Once the edge of the
wheel has been rounded of by use, the wheel may be worked in both A and B
direction.
If the angle grinder is held is one sport too long, it will gouge and cut grooves in the
workpiece.
If the angle grinder is held at too sharp an angle, it will also gouge the workpiece
because of concentration of pressure on a small area.
Use enough pressure to keep the angle grinder from chattering or bouncing. Heavy
pressure will decrease its speed and put a strain on the motor.
Normally the weight of the tool alone is adequate for most grinding jobs.
Use the light pressure when grinding jagged edges or loose bolts where this in the
potential for the angle grinder to snag on the metal edge.
Lift the angle grinder away from the workpiece before turning the angle grinder off.
4. MAINTENANCE AND STORAGE
a. Maintenance
-Clean the housing only with a damp cloth. Do not use solvents! Then wipe
thoroughly.
-Check the condition of the tool. If the tool is damaged or has malfunction, do not use
it and bring it to a qualified service for inspection or reparation.
-To maintain the optimum battery power, we recommend that the battery be
discharged and recharged every two months.
b. Storage
Remove the battery from the tool.
Store the tool in a dry place and protected from freezing, the ambient temperature should
not exceed 50◦c. Put it out of the reach of children.
5. DISPOSAL
Electric power tools, as well as their accessories and packaging, must each be
able to follow an appropriate recycling pathway. Only for the countries of the
European Union:
Do not throw away your electrical appliance with the household waste! In
accordance with the European Directive 2012/19/EU on waste electrical and
electronic equipment and its implementation in national laws, power tools that can no longer
be used must be separated and follow an appropriate recycling pathway.

14
6. CE DECLARATION
Declaration of conformity
BUILDER SAS
ZI, 32 RUE ARISTIDE BERGES – 312070 CUGNAUX – FRANCE
Declares that the machinery designated below:
CORDLESS ANGLE GRINDER
Model: HM20V
Serial number: 20200816205-20200816504
Is in conformity with the requirements of the Directive Machine 2006/42/EC and to the
followings Europeans Directives:
EMC Directive 2014/30/EU
ROHS Directive (EU)2015/863 amending 2011/65/EU
This tool is also in conformity with the following these standards:
EN 60745-1: 2009+A11:2010
EN 60745-2-3:2011+A2:2013+A11:2014+A12:2014+A13:2015
EN 55014-1:2017
EN 55014-2:2015
Responsible of the technical file: Mr Michel Krebs
Cugnaux, 08/07/2020
Philippe MARIE / PDG

WARRANTY
The manufacturer guarantees the product against defects in material and workmanship for a period of 2
years from the date of the original purchase. The warranty only applies if the product is for household use.
The warranty does not cover breakdowns due to normal wear and tear.
The manufacturer agrees to replace parts identied as defective by the designated distributor. The
manufacturer does not accept responsibility for the replacement of the machine, in whole or in part , and/or
ensuing damage.
The warranty does not cover breakdowns due to:
• insu󰀩cient maintenance.
• abnormal assembly, adjustment or operations of the product.
• parts subject to normal wear and tear.
The warranty does not extend to:
• shipping and packaging costs.
• using the tool for a purpose other than that for which it was designed.
• the use and maintenance of the machine done in a manner not described in the user manual.
Due to our policy of continuous product improvement, we reserve the right to alter or change specications
without notice. Consequently, the product may be di󰀨erent from the information contained therein, but a
modication will be undertaken without notice if it is recognized as an improvement of the preceding
characteristic.
READ THE MANUAL CAREFULLY BEFORE USING THE MACHINE.
When ordering spare parts, please indicate the part number or code, you can nd this in the spare parts list
in this manual. Keep the purchase receipt; without it, the warranty is invalid. To help you with your product,
we invite you to contact us by phone or via our website:
• +33 (0)9.70.75.30.30
• https://services.swap-europe.com/contact
You must create a "ticket" via the web platform.
• Register or create your account.
• Indicate the reference of the tool.
• Choose the subject of your request.
• Describe your problem.
• Attach these les: invoice or sales receipt, photo
of the identication plate (serial number), photo
of the part you need (for example: pins on the
transformer plug which are broken).
7. WARRANTY
15

WHAT TO DO IF MY MACHINE BREAKS DOWN?
If you bought your product in a store:
a) Empty the fuel tank.
b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case,
the repairer will refuse the machine.
Go to the store with the complete machine and with the receipt or invoice.
If you bought your product on a website:
a) Empty the fuel tank.
b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case,
the repairer will refuse the machine.
c) Create a SWAP-Europe service ticket on the site: https://services.swap-europe.com When making the
request on SWAP-Europe, you must attach the invoice and the photo of the nameplate (serial number).
d) Contact the repair station to make sure it is available before dropping o󰀨 the machine.
Go to the repair station with the complete machine packed, accompanied by the purchase invoice and the
station support sheet downloadable after the service request is completed on the SWAP-Europe site
For machines with engine failure from manufacturers BRIGGS & STRATTON, HONDA and RATO, please
refer to the following instructions.
Repairs will be done by approved engine manufacturers of these manufacturers, see their site:
• http://www.briggsandstratton.com/eu/fr
• http://www.honda-engines-eu.com/fr/service-network-page;jsessionid=5EE8456CF39CD572AA2AEEDFD
290CDAE
• https://www.rato-europe.com/it/service-network
Please keep your original packaging to allow for after-sales service returns or pack your machine
with a similar cardboard box of the same dimensions.
For any question concerning our after-sales service you can make a request on our website https://
services.swap-europe.com
Our hotline remains available at [phone].
8. PRODUCT FAILURE
16

THE WARRANTY DOES NOT COVER:
• Start-up and setting up of the product.
• Damage resulting from normal wear and tear of the product.
• Damage resulting from improper use of the product.
• Damage resulting from assembly or start-up not in accordance with the user manual.
• Breakdowns related to carburetion beyond 90 days and fouling of carburetors.
• Periodic and standard maintenance events.
• Actions of modication and dismantling that directly void the warranty.
• Products whose original authentication marking (brand, serial number) has been degraded, altered or
withdrawn.
• Replacement of consumables.
• The use of non-original parts.
• Breakage of parts following impacts or projections.
• Accessories breakdowns.
• Defects and their consequences linked to any external cause.
• Loss of components and loss due to insu󰀩cient screwing.
• Cutting components and any damage related to the loosening of parts.
• Overload or overheating.
• Poor power supply quality: faulty voltage, voltage error, etc.
• Damages resulting from the deprivation of enjoyment of the product during the time necessary for repairs
and more generally the costs related to the immobilization of the product.
• The costs of a second opinion established by a third party following an estimate by a SWAP-Europe repair
station
• The use of a product which would show a defect or a breakage which was not the subject of an immediate
report and/or repair with the services of SWAP-Europe.
• Deterioration linked to transport and storage*.
• Launchers beyond 90 days.
• Oil, petrol, grease.
• Damages related to the use of non-compliant fuels or lubricants.
* In accordance with transport legislation, damage related to transport must be declared to carriers within 48
hours maximum after observation by registered letter with acknowledgement of receipt.
This document is a supplement to your notice, a non-exhaustive list.
Attention: all orders must be checked in the presence of the delivery person. In case of refusal by the
delivery person, it you must simply refuse the delivery and notify your refusal.
Reminder: the reserves do not exclude the notication by registered letter with acknowledgement within 72
hours.
Information:
Thermal devices must be wintered each season (service available on the SWAP-Europe site). Batteries must
be charged before being stored.
9. WARRANTY EXCLUSIONS
17

15
