SANTA FE Quick Reference Guide Commonly Asked Questions

INSTRUMENT PANEL
01 02 03 04 05* 06 08 0907
01 Hood Release
02 Parking Brake
03 Electronic Stability Control (ESC)
04 All-Wheel Drive (AWD) Lock
05 Headlights
06 Steering Wheel Audio Controls
07 Tire Pressure Monitoring System (TPMS)
08 Trip Computer
09 Cruise Control

10* 14 15 1611 1312
*Behind steering wheel
10 Wiper / Washer
11 Infinity CD Changer
12 Automatic Climate Control
13 Heated Seats
14 Automatic Transmission
15 Clock Adjustment
16 Occupant Classification System

01 HOOD RELEASE
To unlatch the hood, pull the release
lever. The hood should pop up slightly.
INSTRUMENT PANEL FEATURES
02 PARKING BRAKE
PUSH
ON OFF
AUTOMATIC TRANSMISSION
• To engage the parking brake,
depress the parking brake pedal.
• To disengage the parking brake,
depress the parking brake pedal a
second time.
PUSH
ON OFF
MANUAL TRANSMISSION
• To engage the parking brake, pull the lever up as
far as possible.
• To disengage the parking brake, pull the lever up
and press the thumb button. Then, while holding
the button in, lower the brake lever.

ESC
OFF
AWD
LOCK
ESC
OFF
AWD
LOCK
03 ELECTRONIC STABILITY
CONTROL (ESC) SYSTEM OFF
The ESC system is designed to help the
driver maintain vehicle control under
adverse driving conditions.
When you turn the system off by
pressing the ESC button, the ESC OFF
indicator will come on and stay on. In
the ESC OFF mode, the stability control
will be deactivated. Adjust your driving
accordingly. To turn the system back on,
press the button again. The ESC OFF
indicator should go off.
The ESC indicator light in the instrument
cluster will illuminate for 3 seconds
after the key is turned ON. If the light
remains illuminated, take your vehicle
to an authorized Hyundai dealer.
04 ALL-WHEEL DRIVE (AWD) LOCK
(if equipped)
During off-road or low-friction
driving conditions, press the AWD
lock button to drive in full-time
AWD dividing the power between
the front and rear wheels (for
vehicles equipped with optional
AWD). The AWD lock indicator
light in the instrument cluster is
illuminated. To turn AWD lock
off, press the button again. The
AWD lock indicator should go off.
05 HEADLIGHTS
HEADLIGHT SWITCH
To operate the headlights, twist the
switch on the end of the lever:
OFF – Headlights off
– Parking lights on
– Headlights on
AUTO – Auto Light (if equipped)
NOTE: The ignition must be in the
“ON” position to turn on the headlights.
HIGH BEAM ACTIVATION
Push the lever forward.
Flash-To-Pass Feature: Pull the lever towards you and release.

MUTE
MODE
VOL
SEEK
LOW TIRE PRESSURE INDICATOR:Illuminates if one or more of your tires is
significantly under-inflated.
AMODE SWITCH
Each press of the MODE switch
changes the audio source as follows:
AM gXM1gXM2gXM3gCDgFM1gFM2
BVOL SWITCH
Press the VOL switch to increase or
decrease the volume.
CSEEK SWITCH
Press the SEEK switch once to
navigate through radio presets, or
CD / MP3 tracks. Press and hold
to quickly scroll through radio
frequencies or fast-forward / rewind
through CD / MP3 tracks.
DMUTE SWITCH
Press the MUTE switch to turn the
sound on or off.
06 STEERING WHEEL AUDIO
CONTROLS (if equipped)
07 TIRE PRESSURE MONITORING SYSTEM (TPMS)
Pushing in the TRIP switch when the ignition
is in the “ON” position changes the display
as follows:
TRIPMETER
DISTANCE TO EMPTY
AVERAGE FUEL CONSUMPTION
OUTSIDE TEMPERATURE (not available with Limited models)
08 TRIP COMPUTER (if equipped)
TRIP
ODO
miles
3
23 4
724
LOW TIRE PRESSURE POSITION INDICATOR:Indicates which tire is
significantly under-inflated by illuminating the corresponding
position light.
TPMS MALFUNCTION INDICATOR:Illuminates and stays illuminated when
there is a problem with the Tire Pressure Monitoring System. If this
happens, the system may not monitor tire pressure. Have the system
checked by an authorized Hyundai dealer as soon as possible.

CANCEL
RES
ON
OFF
ACCEL
09 CRUISE CONTROL
AON / OFF SWITCH
Press to turn the cruise control
system on or off.
BRES (RESUME) / ACCEL SWITCH
Press to automatically resume the
speed set prior to cancellation.
CCOAST / SET SWITCH
Press to set the desired
cruise speed.
DCANCEL SWITCH
Press to cancel the current
set speed. D
10 WIPER / WASHER
MIST
OFF
OFF
INT
TIM
ON
REAR
PULL
INT
LO
HI
F
S
OFF
INT
MIST
LO
HI
AWIPER SPEED
The windshield wiper switch has four
positions: intermittent, low
speed, high speed and
mist. For mist (single
wipe), move the lever
up one position.
B
INTERMITTENT WIPERS
With the windshield
wiper switch in the “INT” position, the
interval between wipes can be varied by turning the
intermittent wiper switch.
CWIPE / WASH OPERATION
To use the windshield washer, pull the wiper / washer lever toward you. The washer
continues to operate until the lever is released. When the washer is operated, the wipers
automatically make two passes across the windshield.
DREAR WIPER / WASHER
The rear wiper / washer has four positions:
• - wash with continuous wipe
• ON - wiper operates continuously
• OFF
• - wash with 2-3 wipes

AM/FM XM CD/RSE LOGIC7 SCAN
LOAD
DIRSEEK
1 2 3
RPT
VOLUME
PWR
TUNE FILE
ENTER
AUDIO
CONTROL
PUSH
RDM MARK INFO
A/C
AUTO MODE
DUAL
TEMP TEMP
OFF
A/C
REAR
REARFRONT
4 5 6
TRACK CAT
A
11 INFINITY CD CHANGER (if equipped)
SETTING PRESET MEMORY BUTTONS
(AM/FM OR XM)
01 Turn radio on by pressing the PWR button
02 Select AM, FM, or XM radio
03 Turn the Audio Control knob to the
desired channel
04 Press and hold any preset button
(1-6) until an audible beep is heard
to memorize the current channel
NOTE: FM has 2 bands for up to 12 presets. XM has
3 bands and up to 18 presets.
TUNING AND LISTENING TO XM CHANNELS
01 Press the XM button
02 Selecting an XM channel:
• Turn the Audio Control knob to scroll
through the XM channels
• Press the Audio Control knob to select
the desired XM channel
CATEGORY SEARCH (XM)
01 While in XM mode, press DIR or
CAT to scroll through music categories
02 Press the Audio Control knob to select
the desired category
SCANNING THROUGH AUDIO CHANNELS
(AM/FM, XM, OR CD/MP3)
01 To Scan:
• Press the SCAN button to preview each
channel/track before moving on to the next
• Press the SCAN button again to stop
the scan feature
• For AM/FM/XM only: Press and hold
the SCAN button until an audible beep is
heard to scan through the channel presets
ADJUSTING THE EQUALIZER (SOUND
QUALITY CONTROL)
01 To adjust the sound quality:
• Press the Audio Control knob to select
the following sound qualities:
gBass gMiddle gTreble gFader g
Balance gEqualizer gCurrent State g
• Turn the Audio Control knob to adjust
the sound quality
DISPLAYING INFORMATION
01 XM:
• Press the INFO button to cycle through
the following information:
gTitle gArtist gCategory g
Current State g
CD/MP3:
• Press the INFO button to cycle through:
Artist gTitle gCurrent State g
NOTE:
• AM/FM tuner with 6-disc changer CD player with optional factory-installed RSE system shown. The buttons on your audio
system may differ. See your Owner’s Manual for information on available audio systems.
• A clear view of the southern sky is recommended to ensure good XM radio reception.
Trial XM subscription ends 3 months following the vehicle date of sale. Please contact XM Radio at
1-800-XM-RADIO (1-800-967-2346) to renew your XM subscription.
01
04
01
03 02
02
01
01
01
02
01

AM FM CD/AUX LOGIC7 SCAN
LOAD
DIRSEEK
1 2 3
RPT
VOLUME
PWR
TUNE FILE
ENTER
AUDIO
CONTROL
PUSH
RDM MARK INFO
A/C
AUTO MODE
DUAL
TEMP TEMP
OFF
A/C
REAR
REARFRONT
4 5 6
TRACK
A
01 AUTO (Automatic Control)
02 OFF
03 Air Conditioning
04 Display Window (Driver’s side)
05 Temperature Control
(Driver’s side)
06 Blower Fan Control
07 Air Recirculation
08 Air Quality System (if equipped)
09 Display Window (Front passenger’s side)
10 Temperature Control
(Front passenger’s side)
11 Dual Temperature Control
12 Air Flow Control
13 Front Window Defroster
14 Rear Window Defroster
15 Rear Air Conditioning
12 AUTOMATIC CLIMATE CONTROL (if equipped)
TO REMOVE FROST OR FOG ON THE WINDSHIELD:
1. Press the front window defroster button 13. (The A/C will turn on automatically and the
“Fresh” mode will be activated.)
2. Set the fan speed 06 to the highest setting.
3. Set the temperature 05 to the desired setting.
NOTE: If the air conditioner filter for the evaporator blower is not replaced per the scheduled
maintenance section, excessive window fogging may result. This filter is located in the
evaporator housing behind the glove box. Your dealer can replace this filter for you.
DUAL TEMPERATURE CONTROL
Press the DUAL button 11 to operate the driver and passenger side temperatures
individually. The indicator light on the button will illuminate. Press the DUAL button again
to deactivate DUAL mode (The indicator light on the button goes off.) The passenger side
temperature 10 will be set to the same as the driver side temperature.
AIR QUALITY SYSTEM
Press the air quality system button 08 to turn the air quality system on. The light on the
button will be illuminated when the system is activated.
01
02
03 04
05 06
07 08
09
10
11
13 14 15
12

H M R 2:32
POWER
AC
119V
OUTLET
12V120W
P
R
N
D
R
1
2 4
3 5
15 CLOCK ADJUSTMENT
There are three control buttons for the
digital clock. Their functions are:
H: Push “H” to advance the hours.
M: Push “M” to advance the minutes.
R: Push “R” to reset minutes to
“:00”. Continue to press and hold
the “R” button to toggle between
military time and standard time.
13 HEATED SEATS (if equipped)
With the ignition key in the
“ON” position, push either of the
buttons to warm the driver’s seat
or the passenger’s seat.
Each time you push the buttons,
the temperature setting of the
seat is changed as follows:
OFF LOW HIGH
14 AUTOMATIC
TRANSMISSION (if equipped)
To select automatic mode, shift to
“D.” To select “SPORTS” mode,
move the shift lever right to the
manual shift gate. The instrument
cluster displays the selected forward
gear. Refer to the Owner’s Manual for
detailed information.
MANUAL TRANSMISSION
(GLS models only)
When shifting into reverse gear, pull
the mis-shift prevention tab and shift
into reverse gear position.
