МУЛЬТИМЕДИЙНЫЙDVD/CD/MP3-РЕСИВЕРСО ВСТРОЕННЫМ 4.3”TFT-ДИСПЛЕЕМ И ТВ-ТЮНЕРОМMULTIMEDIA DVD/CD/MP3RECEIVER WITH BUILT-IN 4.3” TFT DISPLAY AND TV TUNERРуководство по эксплуатации Instruction manualH-CMD4001G

23Table of contentsTable of contentsDear customer!Thank you for purchasing our product. For safety, it is strongly recommended to read this manual carefully before connecting, operating and/or adjusting the product and keep the manual for reference in the future.Table of contents Before you start Utilization of the product Important safeguardsInstallation/ConnectionInstallationGeneral notesDin Front/Rear-Mount1. DIN front-mount (Method A)Dismantling the unitTrim frame installation2. DIN rear-mount (Method B)Detachable control panelAnti-theft systemConnectionConnection diagramISO connection tableUsing the ISO connectorParking wire connectionReverse driving cable connectionOperationControl elementsFront panel Inner panelRemote controller Changing batteryGeneral operationsTouch screenReset the unitPower buttonMonitor tilt angleVolume controlTurning the sound offMode selectionNavigation (option)On-screen display (OSD)Setting the sound characteristicsAV in jackSubwooferDual zone function24445555556666777888999910101111111111111111111112121212System setupSound pageDisplay pageDate and Time pageRDS and Radio pageSystem pageCalibration pageUtilitiesCalculatorCalendarRadio operationsUser interface of Radio modeBand selectionManual/automatic tuningProgramming tuner stationsAuto memory store/Preset scanRDS functionAF (Alternative frequencies) functionTA (Traffic alarm) functionPTY (Program type) functionTV tuner operationsAV-IN modeDIsc/USB/SD/MMC operationsUSB/SD/MMC notesInsert/Eject discInserting an SD/MMC card/USB deviceDVD touch interfaceVCD touch interfaceMP3/DivX/JPEG disc touch interfaceColor settingDVD setupPlay/pauseStop playbackSelecting tracksFast forward/rewindA-B segment repeatRepeat playbackIntro playbackGOTORandom playback12131313131313141414141415151515151515151616171717171717181819192020202020202020

OSD (On Screen Display) functionZooming in/outPBC (Playback Control) (for VCD only)Changing angle (for DVD only)Selecting audio language (for DVD only)Selecting subtitle language (for DVD)Selecting sound channel (for VCD only)Menu navigation (for DVD only)ID3 Tag functionGeneral informationHandling compact discsCleaning discs Cleaning the unit body AccessoriesTroubleshooting guideSpecification23Table of contentsTable of contents20202020212121212122222222222324

4Before your startIf you want to dispose this product, do not mix it with general household waste. There is a separate collection system for used electronic products in accordance with legislation that requires proper treatment, recovery and recycling.Please contact your local authorities for the correct method of disposal. By doing so, you will ensure that your disposed product undergoes the necessary treatment, recovery and recycling and thus prevent potential negative effects on the environment and human health.Utilization of the productImportant safeguards• Read carefully through the manual to familiarize yourself with this unit.• Keep this manual handy as a reference for operating procedures and precautions. Do not allow persons who have not read through this manual to use this unit.• “CLASS 1 LASER PRODUCT”This product contains a laser diode of higher class than 1. Laser beams from the optical pickup are dangerous to the eyes. To ensure continued safety, do not remove any covers or attempt to gain access to the inside of the product. Refer all servicing to qualified personnel.• Do not allow this unit to come into contact with liquids. Electrical shock could result. Also, damage to this unit, smoke, and overheating could result from contact with liquids or dust. Protect this unit from moisture.• Make sure that foreign objects do not get inside the unit; they may cause malfunctions, or create safety hazards such as electrical shock or laser beam exposure.• The beginning of operation is the moment of the unit installation. Before use the device in winter it is recommended to heat up the passenger compartment during 20 seconds or to the operation temperature.• Using the unit with the temperature that goes beyond the operation temperature greatly decreases the operation resource of the screen and other components of the unit and can result in an outage.• Disconnect the vehicle’s negative battery terminal while mounting and connecting the unit.• The unit is designed for negative terminal of the battery, which is connected to the vehicle metal. Please ensure it before installation.• When replacing the fuse, be sure to use one with an identical amperage rating. Using a fuse with a higher amperage rating may cause serious damage to the unit.• Do not allow the speaker wires to be shorted together when the unit is switched on. Otherwise it may overload or burn out the power amplifier.• Make sure you disconnect the power supply and aerial if you will not be using the system for a long period or during a thunderstorm.• Make sure you disconnect the power supply if the system appears to be working incorrectly, is making an unusual sound, has a strange smell, has smoke emitting from it or liquids have got inside it. Let a qualified technician check the system.• Always keep the volume low enough so that you can hear sounds from outside the vehicle.• Should this product fail to operate properly, contact your dealer or nearest service center.

5Installation/ConnectionInstallationGeneral notes• Choose the mounting location where the unit will not interfere with the normal driving function of the driver.• Before finally installing the unit, connect the wiring and make sure that the unit works properly.• Consult with your nearest dealer if installation requires the drilling of holes or other modifications of the vehicle.• Install the unit where it does not get in the driver’s way and cannot injure the passenger if there is a sudden stop, like an emergency stop.• If installation angle exceeds 30° from horizontal, the unit may not perform properly.• Avoid installing the unit where it would be subject to high temperature, such as from direct sunlight, or from hot air, from the heater, or where it would be subject to dust, dirt or excessive vibration.Din Front/Rear-MountThis unit can be properly installed either from ‘Front’ (conventional DIN Front-mount) or ‘Rear’ (DIN Rear-mount installation, utilizing threaded screw Holes at the sides of the unit chassis). For details, refer to the following illustrated installation methods.1. DIN front-mount (Method A)1. Car dashboard2. Sleeve3. Screw4. Nut (5 mm)5. Spring washer6. Screw (5 х 25 mm)7. Metal strap8. Flat washer321182531. Install the sleeve into the dashboard; ensure it is installed with the correct side and there are no obstacles (wires, dashboard elements, etc) for the unit installation.2. After installing the sleeve into the dashboard, bend tabs fitting to the size of the dashboard to fix the sleeve in place.3. Use the metal strap to fix the rear side of the unit. Determine a place for fixing and install the strap as shown in the picture. You can bend the strap to the needed angle with your hands.4. Make the necessary wire connections. Ensure the connections are correct.5. Install the unit into the sleeve until the side locks are fixed.3546817Dismantling the unita – Trim frameb – Frame uninstall directionc – Release key insertion

6Installation/Connectionвба1. Switch off the unit and detach the front panel.2. Insert your fingers into the groove in the front side of the trim frame (apply some effort to detach the frame). Pull the frame to detach it.3. Insert the supplied release keys into the both sides of the unit body to click, as shown in the picture. To extract the unit from the dashboard, pull the release keys or the unit body to pull it out. Before detaching the unit, ensure it is not fixed with the metal strap.Trim frame installationTo install the trim frame, press it to the unit body and push it to fix it in place. This should be done before installing the front panel; otherwise you are not able to install the trim frame. When the trim frame being installed, the side with the groove should face down and fixed first.2. DIN rear-mount (Method B)For this method, use the screw holes in the lateral sides of the unit. Fix the unit with the help of the factory radio mounting brackets.1. Select a position in which the screw holes of the brackets (3) are aligned with the screw holes in the unit body, and screw in two screws (2) in each side.2. Screw.3. Factory radio mounting brackets.4. Vehicle dashboard.5. Lock (remove this part). The outer trim frame and mounting sleeve are not used for method of installation.225543Detachable control panelInsert the left lockers of the panel into the fixing holes on the left side of the body, then press on the right part of the panel until a click.To detach the front panel, press OPEN button. When it unfastens, carefully pull the panel out. The control panel can easily be damaged by shocks. After removing it, place it in a protective case and be careful not to drop it or subject it to strong shocks. The rear connector that connects the main unit and the control panel is an extremely important part. Be careful not to damage it by pressing on it with fingernails, pens, screwdrivers, etc. If the control panel is dirty, wipe off the dirt with soft, dry cloth only. And use a cotton swab soaked in isopropyl alcohol to clean the socket on the back of the control panel.Anti-theft systemThe front panel of this unit can be stored in the included protective case when not in used and carried away when you leave the vehicle to deter theft.Switch off the power of the unit. Detach the front panel, then put it to the protective case and take it with you.

7Installation/ConnectionConnectionConnection diagramISO connection tableLocationFunctionConnector AConnector B1-Rear right (+) - Purple2-Rear right (-) - Purple/Black3-Front right (+) - Grey4Battery +12V/YellowFront right (-) - Grey/Black5Power antenna/BlueFront left (+) - White6-Front left (-) - White/Black7Ignition key (+12V)/RedRear left (+) - Green8Ground/BlackRear left (-) - Green/Black Power antenna wire is intended for power supply of the antenna and for remote control of an additional amplifier.Video out (yellow)Video in (yellow)Audio out (red=right)Audio in (red=right)RCA AV outRCA AV inAudio out (white=left)Audio in (white=left)Radio antenna jackSubwoofer out (blue)TV antenna jackFuse 15 AGPS antenna (option)Parking (Brown)Reverse (Pink)RCA out (rear) grey RCA out (front) brown right (red) right (red) left (white) left (white) 12

89Installation/ConnectionOperationUsing the ISO Connector1. If your car is equipped with the ISO connector, then connect the ISO connectors as illustrated. 122. For connections without the ISO connectors, check the wiring in the vehicle carefully before connecting, incorrect connection may cause serious damage to this unit.Cut the connector, connect the colored leads of the power cord to the car battery as shown in the colour code table above for speaker and power cable connections.Parking wire connectionParking brake leadBrake lightCar frameBatteryBrown WireIf Parking cable is connected to hand brake switch, the video display of the TFT monitor will be controlled by driving status. When the car is moving ahead, if the video disc is played, the screen shows warning and blank screen. The warning screen will prevent the driver from watching images.Reverse driving cable connectionCar frameCar frameRear view video camera leadReverse driving lightGearboxPink wireBatteryIf the rear view video camera is connected, the unit automatically switches to camera mode during reverse driving. The unit returns to the original work mode after the reverse driving is done.

89Installation/ConnectionOperationControl elementsFront panel1. EJECT button2. VOL+/VOL- buttons3. OK button4. Display5. Slot for Navigation memory card (not shown)6. MODE button7. 4/ button8. 1/ button9. IR sensor10. 2/ button11. OPEN button123456789101112131415161718192021222324252612. 3/ button13. TUN+/TUN- buttons14. 6/ button15. 5/ button16. BAND button17. MENU button18. AF/REG button19. AMS button20. POWER/MUTE button21. TA/EON button22. DUAL button23. AV input24. DSP button25. USB port26. MAP buttonInner panel12341. Disc slot (available when front panel is open)2. RESET button (hole)3. Panel status indicator (blinks when front panel detached)4. Memory card slot

10OperationRemote controller123456789101617181920212223242526272830293111121314151. MODE button2. POWER button3. UP cursor button4. BND/RDM button5. ENTER button6. LEFT cursor button7. DOWN cursor button8. EJECT button9. PTY button10. P.SCN/RPT button11. SEEK-/ button12. AF/TA button13. OSD button14. /PBC button15. Digit buttons16. button17. MUTE button18. MENU button19. SUB-T button20. RIGHT cursor button21. SETUP button22. ANGLE button23. INT button24. VOL+ button25. A-B/ZOOM button26. SEL button27. SEEK+/ button28. VOL- button29. AUDIO/GOTO button30. TILT button31. DUAL buttonChanging the battery1. Press the catch and at the same time pull out the battery tray.2. Insert the 1 lithium battery, type CR2025 (3 V) battery with the stamped (+) mark facing upward. Insert the battery tray into the remote controller. • Store the battery where children cannot reach. If a child accidentally swallows the battery, consult a doctor immediately.• Do not recharge, short, disassemble or heat the battery or dispose it in a fire.• Do not expose or bring into contact the battery with other metallic materials. Doing this may cause the battery to give off heat, crack or start a fire.• When throwing away or saving the battery, wrap it in tape and insulate; otherwise, the battery may give off heat, crack or start a fire.• Please direct the Remote controller to the IR sensor of the front panel.

11Operation- - -In the menu, touch the item of the mode you need to select the corresponding mode. Touch the arrow icon in the right part of the screen to switch between the 2 menu pages. The DVD, USB and SD modes are only available when a disc, USB or SD/MMC card is inserted into the unit.Navigation (option)• To enable navigation mode, touch NAVI button in the main menu. To enable or disable NAVI mode you can also press MAP button on the panel.• Insert Navigation memory card into the Memory card slot of the unit before enabling navigation mode. The device will warn you if the memory card is not properly inserted into the card slot.• For more details about operations with navigation program, please read the instruction manual to the navigation software. You can download the quickstart guidance and full instruction manual for the navigation program from the web site of the navigation software manufacturer.On-screen display (OSD)Press OSD button to show the current mode General operationsTouch screenDue to the touch screen, you can fulfill most functions not only by pressing buttons but also by touching the options you need.Reset the unitOperating the unit for the first time or after replacing the car battery, you must reset the unit. Press EJECT button and then press RESET button (hole) under the panel to restore the unit to the original factory settings.Power buttonPress any button (except OPEN button on the panel) to turn on the unit. Press POWER button on the RC or press and hold POWER/MUTE button on the panel to turn off the unit.Monitor tilt anglePress TILT button to adjust monitor title angle as follows: TILT1 => TILT2 => TILT3 => TILT4 => TILT5 => TILT6 => TILT7. The monitor will flip down accordingly.Volume controlPress VOL+ button to increase the volume level. Press VOL- button to decrease the volume level.Turning the sound offWhen the power is on, press POWER/MUTE button on the panel or MUTE button on the RC to turn the sound off. Press it again or adjust volume to turn the sound on.Mode selection• Repeatedly press MODE button on the RC or on the panel to select an operation mode.• In any mode press MENU button to display the Main menu consisting of two pages:

1213OperationOperationinformation on the display.Setting the sound characteristicsPress SEL button to open the following menu:12341. Setting list. Touch a setting to select its adjustment.2. Adjustment buttons. Touch them to adjust corresponding setting.3. Page selection buttons. Touch to select a menu page.4. Return button. Touch to return to previous menu level.Following settings are available for adjustment:Page 1• Equalizer: Select Flat, Classic, Pop, Rock or DSP OFF equalizer mode.• TA volume: Adjust the volume level for TA radio service.Page 2• Bass: Adjust the low-frequency level.• Treble: Adjust the high-frequency level.• Balance: Adjust the balance between left and right channels.• Fader: Adjust the balance between front and rear channels.Page 3• Beep: Select ALL (beep is heard at any button pressing), 2ND (beep is heard when a button is pressed and held) or OFF (no beep).• Loud: Selecting loudness ON will emphasize the low frequency output.• Subwoofer: set the subwoofer on or off. You can also press / buttons on the RC to select menu pages; press UP/DOWN cursor buttons to select a setting, press LEFT/RIGHT buttons to adjust the setting.AV in jackAV jack is intended to receive audio and video signals by connecting to external device.SubwooferConnect a subwoofer to this unit using the Subwoofer output of this unit. For subwoofer operation an external amplifier is required.Dual zone functionDUAL - dual zone function enabling user to listen to radio or watch TV in the front zone, and at the same time play audio or video from disc, USB or memory card.For Dual zone an external monitor with is required having its own acoustic system and possibility of volume adjustment.Press DUAL button to select between C-DUAL (buttons perform operations for the current mode of the front zone) or D-DUAL (buttons perform DVD functions).System setupWhen you select SETTING mode, the menu will be displayed, in which you can touch any item to select corresponding setting page:After selecting a menu page you can navigate in the menu by pressing cursor buttons on the RC and confirm your selection by pressing ENTER button on the RC. Menu subpages are selected by pressing / buttons on the RC. Or touch the items on the

1213OperationOperationscreen to select them.Sound pageSound setting is described in details in paragraph “Setting the sound characteristics“ above.Display pagePage 1• Brightness: adjust the display brightness.• AV1: select REAR CAM or OTHER mode (for more details see Rear Gear description below).• Rear gear: When REAR CAM is selected, Rear Gear can switch between Enable and Disable. When Enable is selected, the unit will receive the picture from car rear view camera. When Disable is selected, the unit will not receive the picture from car rear view camera, and the unit have AV-IN 2 Setting only. In OTHER mode, the Rear Gear can be set to Disable mode only and have AV-IN 1 and AV-2 setting.• Screen saver: turn on/off the screensaver.Page 2• Dual: Select ON or OFF the Dual zone function.• Key: Use buttons at FRONT (buttons perform operations for the current mode of the front zone) or REAR (buttons perform DVD functions). This function is available only if ON is selected for DUAL.Date and Time page• Date: set current year, month and date.• Time: set current time.RDS and Radio pagePage 1• Stereo: Select STEREO (stereo reception mode) or MONO (mono reception). When the received stereo signal is weak, switch to mono mode to improve the signal. The function is available only in FM bands.• DX: Select LOCAL (only local station reception) or DX (local and distant station reception).• TA: Seek/Alarm. In TA SEEK mode, the unit will seek for traffic announcement program when TA is pressed; in TA ALARM mode, no TA/TP is displayed and the alarm is set off.Page 2• EON TA: DX/Local. If you want to receive information from local stations only, select EON TA Local mode. Otherwise, select EON TA DX mode.• REG: REG ON (the receiver accepts regional variants of the tuned station with REG icon turned on), and REG OFF (the receiver ignores regional variants).• PI: Mute/Sound. PI sound refers to the reception noise when the AF function tries to scan alternative frequency.• Retune: RETUNE refers to the time period the unit allows for radio scan when reception is interrupted. “SHORT” represents a time period of 30 seconds and “LONG” represents a time period of 90 seconds.• Mask: DPI/ALL. During MASK DPI mode, the unit will mask only the AF which has different PI, this is the default mode; during MASK ALL mode, the unit will mask the AF which has different PI and no RDS signal with high field strength.Page 3• Radio Area: Select the radio broadcast area (Europe/USA/ASIA/SOUTH AMERICA).System pageIn this menu you can see the current version information.Calibration page“Carefully press and hold stylus on the center of the target. Repeat as the rarget moves around the screen” is displayed. Touch and hold the cross in each position until it moves to a different position. After repeating it 4 times, the calibration of the screen is complete; touch the screen anywhere to return to menu. The calibration procedure is useful when some malfunction occur with the touch screen, and it needs adjustment.

14OperationUtilitiesIn the main menu touch UTIL item to go to utility menu consisting of Calculator and Calendar items. Touch an item to go to correspondent function.CalculatorWhen you select Calculator an interface will show in which you can perform basic arithmetical operations by touching buttons on the screen including following:MC memory numeric clearMR memory numeric restoreC current numeric clearMS numeric save memoryM+ add edit numeric to memory numericCE clear errorbackspace back spaceTouch arrow in the right upper corner to exit calculator.CalendarWhen you select Calendar an interface will show in which you can select year and month by touching arrow icons.Touch arrow in the right upper corner to exit calendar.Radio operationsUser interface of Radio modeWhen the unit is switched to Radio mode, the below touchable user interface will be displayed on the display:123457689101112131415161718NAVI1. PTY button. Touch to enable/disable PTY function. In the PTY list, touch a program type to start its search.2. TA button. Touch to enable/disable TA function.3. AF button. Touch to enable/disable AF function.4. ST button. Touch to select stereo/mono reception mode.5. Current band and frequency.6. Touch to enable navigation mode.7. Preset station button. Touch to select the station. Touch and hold to save the current frequency under the preset number.8. LOC button. Touch to select local/distant station reception.9. Mute button; touch to switch sound on/off.10. Volume down button. Touch to decrease volume.11. Volume level.12. Volume up button. Touch to increase volume.13. BAND button. Touch to select bands.14. AS/PS button. Touch to scan all saved stations in current band. Touch and hold to find and save 6 availble stations in current band.15. button. Touch for automatic search of the nearest station downwards.16. button. Touch repeatedly to change frequency step by step downwards.17. button. Touch repeatedly to change frequency step by step upwards.18. button. Touch for automatic search of

15Operationthe nearest station upwards.Band selectionSelect the RADIO mode. Press BAND button on the panel or BND/RDM button on the RC to select the desired band: FM1, FM2, FM3, AM1 (MW1), AM2 (MW2).Manual/automatic tuning• Manual tuning: press TUN-/TUN+ buttons on the panel or SEEK-/ and SEEK+/ on the RC and hold for 2 seconds to enter the manual tuning mode. Press these buttons repeatedly to select a frequency downward or upward step by step.• Automatic tuning: press TUN-/TUN+ buttons on the panel or SEEK-/ and SEEK+/ on the RC repeatedly, the automatic search will start. It will play when finds the station.Programming tuner stationsThere are 6 numbered preset buttons on the RC and panel, with which you can store and recall stations for each band (18 FM, 12 AM). Select a station, then press and hold a preset button. The station will be saved in the memory under the corresponding number. To recall a stored station, press the corresponding preset button.Auto memory store/Preset scanAuto store: Select a band, press and hold AMS button on the panel or P.SCN/RPT button on the RC to enter auto store mode. The radio will automatically store 6 stations to the 6 preset memories of the current band. To stop auto store, press the button again. During auto station preset, the unit will search and store stations with the strong signal first, and then weaker signal stations until the memories are full.Preset scan: Select a band, press AMS button on the panel or P.SCN/RPT button on the RC to scan all preset stations in the memories of the current band. To stop preset scan, press the button again.RDS functionRDS (Radio Data System) service availability varies with areas. Please understand if RDS service is not available in you area, the following service is not available, either.AF (Alternative frequencies) functionPress AF/TA button on the RC or AF/REG button on the panel to enable AF function. When the radio signal strength is poor, enabling the AF function will allow the unit to automatically search another station with the same PI (Program Identification) as the current station but with stronger signal strength. AF indicator on the display will flash until RDS information is received. If RDS service is not available in your area, turn off the AF mode.TA (Traffic alarm) functionPress TA/EON button on the panel to activate the traffic alarm function.When TA function is activated, it will search the station with TA information automatically. If there is no TA information, it will search the station with TP information automatically, if there is no TP information either, it will return to the previous station after searching.When receiving the station with TP information but without TA information, TP icon is on and TA icon keeps blinking; when receiving the station with TP and TA information, both TP and TA icons are on.When playing in other mode and TA information is received, it will change to the radio mode automatically. After playing over, it will return to the previous mode. Press TA/EON button on the panel once to ignore the received TA information, do it twice to turn off the function.PTY (Program type) functionPress PTY button on the RC to activate the PTY function, press it repeatedly to show Music group/Speech group/PTY off. Choose

16Operationthe needed PTY type by pressing the icon in the touchable screen or pressing the corresponding number buttons on the RC. When PTY search is on, and the selected type matches, PTY information is displayed. If PTY code is different or not available, PTY NONE icon will blinks, PTY engaging automatically exit to normal mode.TV tuner operationsConnect a TV antenna to the TV antenna jack of the unit. Select TV mode, then touch the center of the display; following interface will be displayed:12346751. Touch to enable navigation mode.2. Touch to go to auto setting of channels.3. Touch to go to manual setting menu.4. Touch to go to color setting menu.5. Touch to hide the TV menu.6. Touch to switch channels.7. Touch to go to the main menu.• To access the TV mode menu, press MODE button on front panel or RC to select TV mode or touch TV icon on main menu screen to enter TV mode. Then touch the center of the display to call the TV interface. To select a menu page (Auto Setting or Manual Setting) touch these items on the screen. Press cursor buttons on the RC or touch the needed item on the screen to select and adjust a parameter. Touch BACK item on the screen to return to last settings list.AUTO PROGRAM• System: select TV system (SECAM/PAL/NTSC).• Audio: select sound system (Audio1/Audio2/Audio3).• Search: select to start automatical search and storing of TV channels.MANUAL PROGRAM• Storage: select the storage number of the channel.• System: select TV system (SECAM/PAL).• Audio: select sound system (Audio1/Audio2/Audio3). • Channel: Select the number of the channel.• Fine: perform fine tuning of picture quality.• Memory: select on (memorize the found channel) or off (not memorize).AV-IN modeConnect an external audio/video signal source to this unit. Select AV-IN mode in the main menu or by pressing repeatedly MODE button, then select AV-IN1 or AV-IN2. Touch the center of the screen; following interface will be displayed:1231. Touch to enable navigation mode.2. Touch to go to color setting menu.3. Touch to quit AV-IN mode. Do not connect AV inputs on the rear panel at the same time with the AV input on

17Operationthe front panel. Interference of the signals can damage the unit.Disc/USB/SD/MMC operationsUSB/SD/MMC notesUSB format supports 2.0. Capacity: up to 8 Gb.For correct and satisfactory operation, licensed SD/MMC memory cards of famous brands should be used with this unit. Avoid using memory cards of unknown brands. Capacity: up to 8 Gb.Insert/Eject disc• Press EJECT button and insert a disc into the disc slot with label side up. The disc will be automatically loaded into the unit. The first file in the root folder will be played.• Press EJECT button to eject the disc from the slot. If the disc is not removed from the slot within several seconds, it will be automatically loaded into the slot again. When the disc is ejected and removed, the unit will automatically switch to another mode.Inserting an SD/MMC card/USB deviceOpen the front panel and insert an SD/MMC memory card into the card slot. Open the USB slot cover on the front panel and insert a USB into the USB slot. Then the playing mode will be changed into Card or USB mode automatically. The first card/USB device track playback will start. When SD/MMC card and USB device are both inserted, the playing mode will be changed into the mode of the device inserted later.DVD touch interfaceWhen a DVD is played, touch the center of the screen; the screen will show following interface:123456789101112131415161. Touch to adjust the monitor tilt angle.2. Touch to enable navigation mode.3. Touch to go to color setting menu.4. Disc type.5. Current playback title/chapter/track number.6. Current playback time.7. Touch to select previous or next track.8. Touch to go to main menu.9. PLAY/PAUSE button. Touch to start, pause or resume playback.10. STOP button. Touch to stop playback11. button. Touch repeatedly to change rewind speed.12. button. Touch repeatedly to change fast forward speed.13. REPEAT button. Touch repeatedly to select repeat playback mode.14. SUBT button. Touch to select disc subtitle language.15. AUD button. Touch to select disc audio language.16. MENU button. Touch to go to the disc root menu.VCD touch interfaceWhen a VCD is played, touch the center of the screen; the screen will show following interface:

18Operation3217456891011121314151. Touch to adjust the monitor tilt angle.2. Touch to enable navigation mode.3. Touch to go to color setting menu.4. Disc type5. Current playback title/chapter/track number and PBC status6. Current playback time7. Touch to select previous or next track.8. Touch to go to main menu.9. PLAY/PAUSE button. Touch to start, pause or resume playback.10. STOP button. Touch to stop playback11. button. Touch repeatedly to change rewind speed.12. button. Touch repeatedly to change fast forward speed.13. REPEAT button. Touch repeatedly to select repeat playback mode.14. AUD button. Touch to select audio channel.15. PBC button. Touch to switch BPC function on or off.MP3/DivX/JPEG disc touch interfaceWhen a file disc, USB or a memory card is played, touch the center of the screen; the screen will show following interface:123456789101112131415161. RDM button. Touch for random playback.2. RPT button. Touch to select repeat playback modes.3. INT button. Touch for intro playback.4. Touch the button to go to the previous file list page.5. ID3-tag window.6. File list. Touch the needed file to start its playback.7. Touch the button to go to the next file list page.8. MDC button. Touch to go to folder selection.9. Mute button; touch to switch sound on/off.10. Touch to enable navigation mode.11. STOP button. Touch to stop playback.12. PLAY/PAUSE button. Touch to pause or resume playback.13. Touch the button to go to the previous file/track.14. Touch the button repeatedly to select track rewind speed.15. Touch the button repeatedly to select track fast-forward speed.16. Touch the button to go to the next file/track.Use cursor buttons to navigate in the interface and press ENTER button to confirm your selection. Manufacturer guarantees regular playback of licensed discs only. Some AVI files cannot be played due to their parameters and recording conditions.Color setting
