Hyundai H-1416 User manual

КАССЕТНАЯ CD/MP3/USB/SD/
MMC-СТЕРЕОМАГНИТОЛА
PORTABLE STEREO RADIO
CASSETTE RECORDER WITH
CD/MP3/USB/SD/MMC
Руководство по эксплуатации Instruction manual
H-1416

2 3
Instruction manual Instruction manual
Dear customer!
Thank you for purchasing our product. For safety, it is strongly recommended to read
this manual carefully before connecting, operating and/or adjusting the product and keep
the manual for reference in future.
Description
1. PAUSE button
2. STOP/EJECT button
3. F.FWD button
4. LCD display
5. REW button
6. PLAY button
7. REC button
8. Handle
9. USB slot
10. SD/MMC memory card slot
11. STOP/CD/USB/SD/FM MODE button
12. REPEAT/PROGRAM/MEMORY button
13. SKIP +10/FOLDER/MEM SET button
14. Left speaker
15. Cassette compartment door
16. CD door finger grip
17. PLAY/PAUSE/BAND (AM/FM) button
18. NEXT/TUNE UP button
19. BACK/TUNE DOWN button
20. Right speaker
Not indicated:
Battery compartment (bottom panel)
Power cord socket (back panel)
Telescopic FM antenna (back panel)
Headphone socket (back panel)
FUNCTION switch (back panel)
VOLUME regulator (left panel)
BASS BOOST switch (back panel)
1 2 3 4 5 6 7 8
9
10
11
12
13
14
15
16
17
18
19
20

2 3
Instruction manual Instruction manual
Power supply
Battery operation
• Open the battery compartment cover.
• Insert 6 x UM-2/LR14 “C” size batteries.
Please observe correct battery polarities or the
set will not work.
• Close the battery compartment cover.
AC operation
• Before the first connecting of the appliance
check that voltage indicated on the rating label
corresponds the mains voltage in your home.
• Plug the corresponding end of cord into
the AC socket on the rear of the set.
• Insert the plug into power supply.
Caution:
• When the set is only used with AC or is
not used for 2 weeks or more, please remove
the batteries, to avoid damage to the set from
leakage of batteries.
• Always switch off the unit when not in use.
• Always unplug the appliance from power
supply, when no use long time.
Headphone jack
• For private listening, insert 3.5 mm
headphone into the stereo headphone jack.
• Adjust volume control to the appropriate
level as desired.
• When the stereo headphone jack is
plugged, speaker will disconnect automatically.
Radio operation
• Set FUNCTION switch to RADIO position.
• Select your desired broadcasting band by
pressing PLAY/PAUSE/BAND (AM/FM) button.
AM of FM will be displayed.
• Press NEXT/TUNE-UP button or BACK/
TUNE-DOWN button and then release the button
when the fast scanning starts. The frequency will
continue to change and will automatically stop
Remote controller
1. BAND/PLAY/PAUSE button
2. BACK/TUNE- button
3. PLAY MODE/MEMORY button
4. STOP/FM MODE button
5. NEXT/TUNE+ button
6. SKIP+10/FOLDER/MEM.SET button
7. CD/USB/SD button
Important safeguards
• Attention: The owner’s manual contains
important operating and maintenance
instructions. For your safety, it is necessary to
refer to the manual.
• Dangerous voltage: Uninsulated
dangerous voltage that may be of sufficient
magnitude to constitute a risk of electrical
shock to persons is present within this product
enclosure.
• Caution: To reduce the risk of electric
shock, do not dismantle the body. Prefer
servicing to qualified service personnel. Do not
use the unit in places where it can be exposed
to water, moisture and dust. Make sure that
pins or other foreign objects do not get inside
the unit; they may cause malfunctions, or
create safety hazards such as electrical shock.
1
2
3
4
5
6
7

4
Instruction manual
when a broadcast station is received.
• To receive a weak broadcast signal press
the NEXT/TUNE-UP or BACK/TUNE-DOWN
button by one press at a time and adjust the
frequency you wish to receive.
Saving Stations to Memory
• 50 broadcast stations: 30 FM band and 20
AM stations can be stored to the preset memory.
• During tuner mode, find a desired station.
• Press SKIP +10/FOLDER/MEM.SET
button to activate memory setting mode. The
“MEM” symbol will appear on the display.
• Press NEXT/TUNE-UP button or BACK/
TUNE-DOWN button to choose the desired
memory location. The location number is
flashing on the left side of the screen.
• Press SKIP +10/FOLDER/MEM.SET
button again to store the desired station.
• Repeat steps for storing stations to other
locations.
• To clear the memory of any location simply
save a new station to the same memory.
Selecting stored stations
• Press REPEAT/PROGRAM/MEMORY
button on the unit or PLAY MODE/MEMORY
button on the RC once. “MEM” symbol will
appear on the display.
• Press NEXT/TUNE-UP or BACK/TUNE-
DOWN button to choose the memory location.
The stored station will be selected.
Antenna
• For FM reception, adjust the telescopic
antenna appropriately to obtain the best
reception on the band selected.
• The AM signals are picked up through
the built-in ferrite antenna. The set should be
placed to a position for the best reception.
FM/FM stereo reception
• In particular when stereo signal is weak
and much noise are received, it is preferable to
receive the programmer in mono. Press STOP/
CD/USB/SD/FM MODE button on the unit or
STOP/FM MODE on the RC to switch between
FM stereo and mono modes.
• If the program is received in FM stereo,
“ST” indicator will light up.
CD operations
Insertion and removal of discs
• Place a CD into the compartment with the
label-side (printed side of disc) facing upwards.
Press down in the center part of disc until the
disc locks onto the center spindle.
• When the CD has been placed onto the
center spindle, gently lower the CD-door
downwards until it locks shut.
• The CD is now ready to be played.
• When opening the CD-door, always
ensure the disc is not in motion (not spinning)
when you open the CD-door. Always press
STOP/CD/USB/FM MODE button on the unit or
STOP/FM MODE button on the RC to stop the
disc spinning first.
• To remove a disc, follow the same
procedure as described above, except to
remove the CD instead of inserting it into the
compartment, by placing one finger at the
middle of disc (center spindle) and the other at
the edge of the disc and gently pulling upwards.
Always hold a CD by its edges. Avoid
getting any fingerprints, smudges or dirt onto
the surface of a disc. In case this happens, use
a special CD-cleaning cloth or cleaning kit to
remove the dirt or smudges.
Important: Please make sure to always fold
down the handle before opening the CD door.
Compact disc operation
• Set FUNCTION switch to USB/SD/CD
position.
• Put a CD into the CD compartment and
close the CD door.
• The LCD display will show the total
number of tracks after a few second.
Play/pause mode
• Press PLAY/PAUSE/BAND (AM/FM)
button on the unit or BAND/PLAY/PAUSE

5
Instruction manual
button on the RC to start playback, the LCD
display will show the first track.
• Press PLAY/PAUSE/BAND (AM/FM) button
on the unit or BAND/PLAY/PAUSE button on the
RC to pause at any track when playing, track
number on the LCD display flashes.
• To stop playback, press STOP/CD/USB/
FM MODE button on the unit or STOP/FM
MODE button on the RC.
Skip and search mode
• Press the NEXT/TUNE UP button once
to skip to the next track. Press and hold this
button to search for a particular point at high
speed forward. Release the button to resume
normal play.
• Press the BACK/TUNE DOWN button
once to skip back to previous track. Press and
hold this button to search for a particular point
at high speed backward. Release the button
resume normal play.
Repeat mode
• Press REPEAT/PROGRAM/MEMORY
button on the unit or PLAY MODE/MEMORY
BUTTON on the RC once for single track
repeat playing.
• Press twice for all track repeat playing.
• To cancel repeat play, press REPEAT/
PROGRAM/MEMORY button on the unit or
PLAY MODE/MEMORY BUTTON on the RC
again.
Program mode
Up to 60 tracks can be programmed for disc
play in any order or the same track can be
repeated up to 60 times.
• Before use, be sure to stop the CD by
pressing STOP/CD/USB/FM MODE button on
the unit or STOP/FM MODE button on the RC.
• Press REPEAT/PROGRAM/MEMORY
button on the unit or PLAY MODE/MEMORY
button on the RC. The display will show “P01”
and “PROG” symbol. This indicates that the set
is now in memory programming mode, at the
first memory position.
• Select a desired track by using the BACK/
TUNE DOWN and NEXT/TUNE UP buttons.
• Press REPEAT/PROGRAM/MEMORY
button on the unit or PLAY MODE/MEMORY
BUTTON on the RC again to confirm. The
set will advance to next memory position,
the display will show “P02”. Repeat steps
described above to enter additional memories
into the program if necessary.
• After a maximum of 60 songs (or less)
have been selected as described above, press
PLAY/PAUSE/BAND (AM/FM) button on the
unit or BAND/PLAY/PAUSE button on the RC
to start playing the programmed tracks.
• The “PROG” symbol will remain to indicate
that you have saved a program-memory
(sequence).
• The program memory will be cleared when
you press STOP/CD/USB/FM MODE button on
the unit or STOP/FM MODE button on the RC
or turn off the CD or power supply.
MP3 operation
• Set FUNCTION switch to USB/SD/CD
position.
• Open the CD door. Put a MP3 disk into the
CD compartment and close the CD door.
• The disk will spin and perform a full check
of the disc to count the total number of songs.
Then playback of the first song (track) will
begin and the display will indicate the current
track number.
• If your disc has folders, the display will show
the folder number (e.g. F01) every 5 seconds.
• At any time during playback, press and
release BACK/TUNE DOWN or NEXT/TUNE
UP buttons to skip backwards or forwards by
one track.
• If your MP3 disc has no folders, you can
use SKIP +10/FOLDER/MEM SET button to
jump 10 songs ahead.
• Press SKIP +10/FOLDER/MEM SET several
times until you reach a song number near to
your desired song, and then press BACK/TUNE
DOWN or NEXT/TUNE UP repeatedly to arrive
and the exact song you desire.
• If your MP3 disc has folders, you can
select the folder to playback. Press and hold
