i-MOBIL F-1 User manual

USER MANUAL FOR i-MOBIL F-1
- 0 -
USER MANUAL FOR
i-MOBIL F-1
V 1.0
USER MANUAL FOR i-MOBIL F-1
- 1 -
Copyright and Acknowledgements
Copyright © i-MOBIL. All rights reserved. Reproduction,
transfer, distribution or storage of any part or all of the
content in this manual in any form without the prior written
permission of i-MOBIL is prohibited.
Operating a policy of continuous development, i-MOBIL
reserves the right to make changes and improvements to any
of the products described in this manual with out prior notice.
Under no circumstances shall i-MOBIL be responsible for
any loss of data or income or any special, incidental,
consequential or indirect damages howsoever caused.
The content of this manual is provided “as is”. Except as
required by applicable law, no warranties of any kind, either
express or implied, including, but not limited to, the implied
warranties of merchantability and fitness for a particular
purpose, are made in relation to the accuracy, reliability or
content of this document. i-MOBIL reserves the right to
revise this document or withdraw it at any time without prior

USER MANUAL FOR i-MOBIL F-1
- 2 -
notice.
USER MANUAL FOR i-MOBIL F-1
- 3 -
Table Contents
FOR YOUR SAFETY.............................................7
FRONT /SIDE VIEW OF THE PHONE.............10
SIMPLIFIED MANUAL..................................13
BEFORE USING .........................................................13
SLIDING AND LOCKING KEYPADS.13
SIM LOCK.....................................................................14
CALL FUNCTION ......................................................15
NAMES........................................................................15
QUICKACCESS TO MENU.......................................16
ONE KEYPRESS TO WAP..........................................17
ONE KEYPRESS TO V-MEMO..................................17
QUICKACCESS TO CAMERA..................................17
GETTING START....................................................19
INSTALLING/CHANGING BATTERY......................19
INSERT/CHANGE SIM CARD ..................................20
CHARGING THE BATTERY .....................................20
SWITCH ON / OFF .....................................................22
MAKINGAND ANSWRING CALLS
...........................................................................................................23

USER MANUAL FOR i-MOBIL F-1
- 4 -
MAKING CALLS........................................................23
ANSWERING CALLS ................................................25
OPTIONS.....................................................................26
NAVIGATING THROUGH MENUS.28
NAMES..................................................................................29
SEARCH......................................................................29
ADD.............................................................................30
EDIT.............................................................................31
ERASE.........................................................................32
SPEED DIAL...............................................................33
SETTING.....................................................................33
COPY...........................................................................34
MOVE............................................................................35
MESSAGE..........................................................................36
SMS..............................................................................36
MMS ............................................................................40
BROADCAST..............................................................46
VOICE MAIL ..............................................................47
MULTIMEDIA..........................................................48
CAMERA.............................................................48
V-MEMO ...........................................................................51
USER MANUAL FOR i-MOBIL F-1
- 5 -
MEDIA FOLDER ................................................................53
FM RADIO........................................................................54
RECORD.............................................................................56
DIALED.......................................................................56
RECEIVED..................................................................57
MISSED.......................................................................57
ERASE.........................................................................57
TIME INFO..................................................................58
COSTINFO..................................................................58
GPRS INFO..................................................................59
SERVICE.............................................................................60
CALL DIVERT............................................................60
CALL BARRING.........................................................62
CALL WAITING..........................................................64
SETTINGS.........................................................................66
AUDIO SETTING .......................................................66
PHONE SETTING.......................................................69
CALL SETTING..........................................................74
NETWORK SECU.......................................................77
TOOLS............................................................................80
STK .................................................................................85

USER MANUAL FOR i-MOBIL F-1
- 6 -
GAMES................................................................................86
WAP............................................................................................88
HOME............................................................................88
ENTER URL ...................................................................89
FAVOURITES ...............................................................90
PUSH MESSAGES INBOX .........................................90
TOOLS..........................................................................91
HISTORY......................................................................93
APPENDIX........................................................................95
TECHNICAL DATA......................................................95
USE AND MAINTENANCE ........................................97
PROBLEMS AND SOLUTIONS..................................99
USER MANUAL FOR i-MOBIL F-1
- 7 -
For Your Safety
Switch off mobile in hospitals where sensitive
medical equipment in.
Switch off mobile at a refueling point, or near
chemicals and blasting areas.
SIM card can be removed from the phone, keep
it in a safe place out of the reach of young
children.
Don’t use incompatible power supplies.
Don’t dismantle the phone or battery by
yourself, instead of qualified personnel.
Damaged Seal will cause the invalidation of the
warranty.

USER MANUAL FOR i-MOBIL F-1
- 8 -
Uses only approved accessories, and follow the
local rules about useless batteries.
Mobile is a radio transmitter / receiver, so it
may interrupt PC, TV, and radio nearby.
Switch off mobile in an aircraft, for wireless
devices can cause interference in aircraft.
Use earphone while driving to avoid traffic
accident.
USER MANUAL FOR i-MOBIL F-1
- 9 -
Attention：The SAR limit of USA (FCC) is 1.6 W/kg
averaged over one gram of tissue. Device types N5603
(FCC ID: TTP05F-1) has also been tested against this SAR
limit. The highest SAR value reported under this standard
during product certification for use at the ear is 0.409
W/kg and when properly worn on the body is 0.210 W/kg.
This device was tested for typical body-worn operations
with the back of the handset kept 1.5cm from the body. To
maintain compliance with FCC RF exposure requirements,
use accessories that maintain a 1.5cm separation distance
between the user's body and the back of the handset. The
use of belt clips, holsters and similar accessories should
not contain metallic components in its assembly. The use
of accessories that do not satisfy these requirements may
not comply with FCC RF exposure requirements, and
should be avoided.
Warning：Improper use will cause invalidation of the
warranty

USER MANUAL FOR i-MOBIL F-1
- 10 -
Front / Side View of the Phone
Illustration 1 (for reference only)
USER MANUAL FOR i-MOBIL F-1
- 11 -
Index of the Mobile Key
1 Receiver Phone answering
2 LCD 260K TFT
3 Number Key Input number and characters, or
swiftly shift to menu
4 Mouthpiece Phone speaking
5 Left/Right
function key
Performs the function indicted at
the bottom left corner of LCD.
6 Navigation Key Left/Right/Up/Down
7 OK Key Select the highlighted manual or
item by pressing this key to
confirm; for detailed functions
refers to the following manual
8 Dial Key Dial numbers and answer a call
9 Power Key Long press to switch on/off the
mobile; short press to end or reject
a call & exit from any functions at
any time
10 Speaker Play the sound
11 Camera Built-in with 300K pixels
12 Side key Long press to turn on LCD when

USER MANUAL FOR i-MOBIL F-1
- 12 -
slide is closed; Long press to reject
from standby mode; Long press to
turn off alarm when it is on; Long
press to capture when slide is
open.
13 Port Port for Earphone
Please refer to the illustration 1 while you read this user menu.
USER MANUAL FOR i-MOBIL F-1
- 13 -
SIMPLIFIED MANUAL
BEFORE USING
1. Insert the SIM card into mobile
Support the SIM Card with a voltage of 1.8V and
3V
2. Please charge the battery for 12 hours without break
before using the phone for the first time.
3. At stand-by mode or in main menu, making a call by
pressing numbers, and then press Dial Key.
4. Press Power Key or close the slide to end up a call.
SLIDINGAND LOCKING KEYPADS
1. Move up the slide to unlock the keypad
automatically.
2. Move down the slide completely to lock the
keypad automatically.
3. Long press Left Function Key to lock/unlock

USER MANUAL FOR i-MOBIL F-1
- 14 -
the keypad when the slide is closed.
Note: Please move up and down the slide
properly. Do not press the bottom battery cap
hardly.
SIM Lock
Situations below may appear while using other SIM card:
1. After other SIM card is inserted, words "Enter PIN"
will appear while Power On the phone. Please key in
the PIN number accordingly.
2. After keying in the PIN number, words "Please
Restart the Mobile Phone" will be displayed. Please
restart your mobile phone in order to activate the
normal use.
If the PIM number is wrong, times of keying in will
be shown on the display. After 5 times' of keying in, the
phone will be locked up permanently, words "Please
update the software to activate the phone" will be
displayed.
USER MANUAL FOR i-MOBIL F-1
- 15 -
CALL FUNCTION
1. Press Dial Key or OK Key to receive an
incoming call.
2. When the slide is closed, press Side Key to
reject calls; when the slide is open, press Power
Key or simply close the slide to end calls.
3. Adjusting speaker Volume during a call: Press
Left/Right Navigation Key.
4. Redial number: Press Dial Key, then use
Up/Down Navigation Key to select the number
you are looking for. Press Dial Key to connect
the call.
NAMES
1. Under the sleep mode (slide is open or unlocked),
press Right Function Key to bring up names list.
Scroll Up/Down by using the Navigation Key, or
you can use the # Key and * Key to turn the page up
and down, then press OK Key.
2. If you would like to use names during a call, press

USER MANUAL FOR i-MOBIL F-1
- 16 -
Left Function Key to get into the next menu. Using
Up/Down Navigation Key to select Names and press
OK Key.
QUICK ACCESS TO MENU
1. Under the sleep mode (slide is open or unlocked),
press OK key to enter main menu and press the
“up”, ”down”, ”left” and “right” Navigation Key to
enter into Audio Setting, Camera, FM Radio and SMS
2. press Left Function Key to surf Wap and press Right
Function Key to bring up Names entry. Press Dial
Key to check the latest dialed numbers and long press
# Key to switch on/off the speaker.
3. Under main menu, use Up/Down Left/Right
Navigation Key to select icons you want and press
OK Key to enter. Press Dial Key to see the dialed
number. Short press Power Key to return to main
menu directly.
4. Press Left/Right Navigation Key to select among the
2nd level menu while Up/Down Navigation Key for
the 3rd level menu. Press OK Key to enter the 3rd
level menu.
USER MANUAL FOR i-MOBIL F-1
- 17 -
5. Press Right Function Key to return to the previous
Menu or short press the Power Key to return to the
main menu directly.
ONE KEYPRESS TO WAP
Under sleep mode or the slide is closed but unlocked,
press Left Function Key to menu of wap.
ONE KEYPRESS TO V-MEMO
Under sleep mode, long press Number Key 1 to record
voice. When record, press Left Function Key to play or
save.
QUICK ACCESS TO CAMERA
Under sleep mode or main menu, long press Side Key，
activate viewfinder(general mode) and press OK to
capture the picture, then press OK to store the picture.

USER MANUAL FOR i-MOBIL F-1
- 18 -
USER MANUAL FOR i-MOBIL F-1
- 19 -
GETTING START
INSTALLING/CHANGING
BATTERY
1. Make sure the phone is switched off before changing
battery.
2. Change Battery
3. Install Battery

USER MANUAL FOR i-MOBIL F-1
- 20 -
INSERT/CHANGE SIM CARD
1. Make sure your phone is switched off and the battery
is removed before you insert/change the SIM card.
2. Face the gold color contact point of SIM card towards
the cellular phone and push in the SIM card into the
slot.
This phone only supports 1.8 volt and 3 volt SIM cards.
CHARGING THE BATTERY
1. Make sure the battery is inserted into the phone
correctly before charging.
USER MANUAL FOR i-MOBIL F-1
- 21 -
2. Connect the lead of the charger to the socket on the
bottom of the phone and plug to an AC wall socket
Warning: Please DO NOT remove the battery
while charging!
3. The animation charging is displayed when the phone
is turned off. The phone can work while charging.
Please keep charging the battery continuously for 12
hours when you use the phone for the first time and
make sure the battery has been fully charged.
4. Black screen will appear during charging if the
voltage of the battery is too low (e.g. Not in use for a
long time, etc.).The animation Charging will appear
after several minutes.

USER MANUAL FOR i-MOBIL F-1
- 22 -
SWITCH ON / OFF
1. Long press the Power Key to turn on or off the
mobile phone.
Enter PIN code if asked (shown as ****). Please refer to
Settings/Network Security/PIN for more information.
USER MANUAL FOR i-MOBIL F-1
- 23 -
MAKING AND ANSWRING CALLS
MAKING CALLS
Making Calls by Pressing Number Key
1. (Slide is open or unlocked) Press the phone number
by using Number Key under sleep mode or main
menu mode. To edit the number, press “up” &
“down”, and “left” & “right” Navigation Key to
move the cursor and then press the Erase one time to
clear one number left to the cursor. Or long press this
key to delete all numbers left to the cursor in this line.
Long press "1", key in *86; Long press "9", key in
060. For International Call, long press the * Key until
change to “+” and then follow by entering the
number. To reach an extension number, enter the
switchboard number at first, long press # key until it
changes to “P”, and then enter the extension
number. ).
2. Press Dial Key to make the call.

USER MANUAL FOR i-MOBIL F-1
- 24 -
3. To end up the call, short press Power Key or simply
close the slide.
4. Press Dial Key to bring 20 records of the dialed
numbers under sleep mode or main menu mode.
Select a number, press OK Key and then press Dial
Key to make the call. If you want to Dial /Send
Message / Erase / Save, press Option.
Making Calls by Using Names
1. When the slide is open or unlocked, enter into the
names by using Right Function Key, then select the
name by using Navigation Key, press OK to bring up
the names entries.
2. When you enter into names entries, you can press
Dial Key to call the default number, or select another
number by using Up/Down Navigation Key, press
Dial Key to call.
3. You can also enter Names/Search menu to find the
number you are looking for.
Redial the last Dialed/Received/Missed
USER MANUAL FOR i-MOBIL F-1
- 25 -
1. In the main menu mode, use Up/Down Navigation
Key to select last Calls and press OK Key to enter.
2. Press Left/Right Navigation Key to select among
Dialed/Received/Missed.
3. Press Up/Down Navigation Key to the number you
are looking for and press Dial Key to connect.
Speed Dial
1. Long press Number Key 2-8 in the main menu for
speed dialing. Numbers are requested to be pre-set to
different number Key before dialing. (Please refer to
Names/Speed Dial).
2. After pressing a number key, the phone will connect it
automatically.
ANSWERING CALLS
1. Press the Dial Key to answer calls.
2. Short press Power Key or Reject to end or reject
calls.
3. Adjusting Receiver Volume while speaking on the

USER MANUAL FOR i-MOBIL F-1
- 26 -
phone: press Left/Right Navigation Key.
OPTIONS
This mobile phone provides varies functions during calls
(many of them are based on Network Service which must
be applied from Network Operators firstly). Below are the
functions that the phone provides by pressing Option
during a call. Use Up/Down Navigation Key to select the
following functions. Press OK Key to confirm.
1. Hold: To select this function, user can receive another
incoming call or dial another number without hang up
the current call.
2. Dial New: Select this function to make another call
while you are on the phone. (The current calling will
be held automatically).
3. End this call: Select this function to end the current
call.
4. End all calls: Select this Function to end up all the
calls.
5. Send DTMF: DTMF means duple tone & multiply
frequency. If this function is selected, the dialed
USER MANUAL FOR i-MOBIL F-1
- 27 -
number will be sent as DTMF meaning that you will
be connected to the number with extension #
automatically (Refer to Making a Call).
6. Mute: Select this Function to switch on/off the sound
of the microphone.
7. Names: Enter into names to select the number
needed.
8. Main Menu: Select this Function to display the main
menu during a call.
9. Conference Call: This option appears when there are
more than three phones being connected with. Select
this Function to enable call conference function. (This
function requires network support, please apply with
the Network Operators.

USER MANUAL FOR i-MOBIL F-1
- 28 -
Navigating Through Menus
Names
Search
Add
Edit
Erase
Speed Dial
Setting
Copy
Move
Message
SMS
MMS
Broadcast
Voice Mail
Multimedia
Camera
V-memo
Media Folder
FM Radio
Record
Dialed
Received
Missed
Erase
Time Info
Cost Info
GPRS Info
Service
Call Divert
Call Barring
Call Waiting
Setting
Audio Setting
Phone Setting
Call Setting
Network Secu.
Extras
Tools
STK
Games
Game1
Game2
Setting
WAP
Home
Enter URL
Favourites
Push messages
inbox
Tools
History
USER MANUAL FOR i-MOBIL F-1
- 29 -
NAMES
You can save the name, default number, cell phone number,
office number, home phone number, and email address to
your mobile phone in the Phone book record. But you can
only save one phone number to your SIM. There are
totally 500 entries you can save to your mobile phone.
User can use the following function to operate the phone.
When Fixed Dialing is on, Names can not be entered.
Under the sleep mode, press Right Function Key to show
the name list under Fixed Dialing. Details of Fixed
Dialing please refers to Call Setting/Fixed Dialing.
SEARCH
Under the main menu, use Up/Down Navigation Key to
select Names.
1. By Name: enter a name or the first letter of a name,
then press Search. Or find by Group, press Up/Down
Navigation Key to the group needed and press OK to
find. Press the # * to change the page.
2. Scroll to select a names entry and press Dial, the
number will be connected automatically.
3. Press Option to dial, send message, edit, erase, group,

USER MANUAL FOR i-MOBIL F-1
- 30 -
and etc.
4. Press Exit to return to the above menu or short
press Power Key to return to the main menu.
5. Press Ok to select the phone number under
Fixed Dialing, which you can make a call or
send SMS only.
ADD
Under main menu mode, scroll Up、Down、Left、Right to
select Names, press Right Navigation Key once to see the
menu Add containing following choices:
1. Use Up/Down Navigation Key to select
To -> Phone To ->SIM Card. Press OK
Key or Left Function Key to bring up the
new record that you can input the
following info. Please also input the area
code when you entry the numbers by using
the Number Key.
To save in the phone:
1st Line: To enter a name.
2nd Lind: To enter default number (This number
will be recognized by the mobile when you select
USER MANUAL FOR i-MOBIL F-1
- 31 -
the record and press Dial Key
3rd Line: To enter a mobile number.
4th Line: To enter an office number.
5th Line: To enter a home number.
6th Line: To enter an email address.
To save in the SIM card
1st Line: To enter a name.
2nd Lind: To enter default number
2. When finishing the entry, press Save or OK to
store the record.
3. Press Exit to return to the previous menu or short
press the Power Key to the main menu.
EDIT
You can edit your entry by pressing the Right/Left
Navigation Key under the menu of names.
1. All the records will be listed under the screen of Edit.
Use Up/Down Navigation Key to select the record
you want to edit. You can use the “#” Key and “*”
Key to turn page down and up to select the records.

USER MANUAL FOR i-MOBIL F-1
- 32 -
Press OK to get into the record screen and scroll up
and down to select the info you want to change.
2. Use Save to store the edited information.
3. Press Exit to return to the previous menu or short
press Power Key to the main menu.
ERASE
You can erase your record by pressing Left/Right
Navigation Key under the menu of Names.
1. One by One: Press OK to get into Erase menu. Use
Up/Down Navigation Key to select the record you
want to delete. Press OK Key to confirm.
2. SIM Card: If you want to erase all the records in you
SIM Card, select SIM Card and press OK to confirm.
3. Phone: To erase all the records that saved in your
mobile phone, select Phone, and Press OK to
confirm.
4. Press Exit to return to the previous menu or short
press the Power Key to the main menu.
USER MANUAL FOR i-MOBIL F-1
- 33 -
SPEED DIAL
Select Names under main menu and press Left/Rightt Key
to view speed dial menu. You can set up 8 speed dial
numbers from #2 to #8.
1. Use Up/Down Navigation Key to select the speed
dial number you would like to set up. The number has
not been set up will be displayed as “Empty”, press
OK Key to bring up the name list. Use Up/Down
Navigation Key to select a name entry in which you
will select a number as Speed Dial number. Press OK
Key to confirm.
2. If you select the number that has been set up before,
press Option to edit or erase.
3. Press Exit to return to the previous menu or short
press Power Key to the main menu.
SETTING
You can set up your names by pressing the Left/Right
Navigation Key to get into the Setting menu.
1. Status: You can check your names status by pressing
OK.

USER MANUAL FOR i-MOBIL F-1
- 34 -
2. Own Number: You can find out your own number by
pressing OK.
3. Group Tone: You can set up 4 group Ring tone by
pressing OK. After you get into the Group Tone menu,
use Up/Down Navigation Key to select the group
name, press OK to bring you to the next menu, select
the incoming tone by use Up/Down Navigation Key.
Press OK to confirm.
COPY
Select Names under main menu and press Left/Right
Navigation Key to view Copy menu.
1. Choose SIM →Phone or Phone → SIM,
press Ok to enter
2. You can choose One By One or All from SIM
card to Phone, or from Phone to SIM Card.
3. Press Ok to enter One By One, all names will
be shown. Choose the one you want to copy
and press Ok.
4. Press Ok Key to enter All, all default numbers
can be copied from SIM card to Phone or from
Phone to SIM card.
USER MANUAL FOR i-MOBIL F-1
- 35 -
Move
Choose Name under the main menu, press Left /
Right Navigation Key to see the menu of Move.
Press Up/Down Key to select:
1. Choose SIM →Phone or Phone → SIM,
press Ok to enter
2. You can choose One By One or All from SIM
card to Phone, or from Phone to SIM Card.
3. Press Ok to enter One By One, all names will
be shown. Choose the one you want to move
and press Ok.
4. Press Ok Key to enter All, all default numbers
can be moved from SIM card to Phone or from
Phone to SIM card.

USER MANUAL FOR i-MOBIL F-1
- 36 -
MESSAGE
SMS
Scroll Up/Down to select Message under the main menu
mode, press OK to get into the 3rd level menu of SMS.
Press Up/Down Navigation Key to select the wanted
sub-menu. Press OK Key to confirm. Password is needed
to get into a certain number of 3rd level menus if you have
set up Phone Lock in Settings/Network Secu.
When Fixed Dialing is On, please note:
1. Please add SMS info center number to the list of Fixed
Dialing. SMS info center number can be found
under Message/Setting/Info Center.
2. When you need to enter the call number after entering
the message, press Ok only to show the name list of
Fixed Dialing.
Fixed Dialing please refer to Call Setting/Fixed Dialing.
New
1. You can enter no more than 160 English letters (space
USER MANUAL FOR i-MOBIL F-1
- 37 -
included) for each message if New is selected This
mobile supports continuous SMS sending up to
6 items including 912 English letters.
2. Press Option to Send, Save to SIM, Send to Group,
Save to Phone, Insert Name, Insert Number.
3. Short press Erase to delete the letter left to the cursor;
long press Erase to delete all letters. Short press
Power Key to return to the Main Menu without
saving the SMS.
Received
All the SMS received are shown in this menu (including
messages that been read and not been read). Select Erase
All to delete all messages received
1. Press Up/Down Navigation Key to select the SMS
and press Read to read its content, the sender’s
number (or name), date and time. If the message is
too long and you cannot read them all in one screen,
use Up/Down Navigation Key to turn the page up
and page down.
2. Reply: To reply this SMS by pressing OK Key or
Left Function Key.

USER MANUAL FOR i-MOBIL F-1
- 38 -
Erase: To delete this message.
Forward: To send this message out again.
Edit: To edit the content of the message and save it
Call: To call the sender
Extract: to extract useful data such as number and
URLfrom the message.
Send to Group：To send this message to a number of
people.
Save to SIM: To save the message to SIM card.
Save to Phone: To save the message to the phone (this
does not work if the SIM card is with big capacity).
3. Press Exit to return to the previous menu or short
press Power Key to the main menu.
Saved
All the saved message (In SIM Card and In Phone) are
shown in this menu (with either saved or sent status). Press
Up/Down Navigation Key to select the menu and press
Option to enter.
Press Navigation Key Up/Down to select messages stored
USER MANUAL FOR i-MOBIL F-1
- 39 -
in SIM card or Mobile. Press OK Key to enter into list.
1. Press Up/Down Navigation Key to select one to
read. Use Up/Down Navigation Key to page up and
page down the content of the message. (All the
message will be saved In SIM Card but not in Phone
if the SIM card is with big capacity.
2. Press OK Key or Left Function Key to bring up the
next menu. Use the Up/Down Navigation Key to
select functions including Erase, Send, Edit, Extract
Sent to Group , and save to phone. (Please refer to the
same function in Received SMS). Press OK to
confirm. The SMS In SIM Card can be saved to the
phone. You can pick up numbers and URL from
message in Extract.
3. Press Right Function Key to return to the previous
menu or short press Power Key to the main menu
Setting
1. Info. Center is a set number for receiving or sending
SMS from the network. This number must be set
before using SMS. Press OK to get into this selection
and save the number after setting.
