I-Tech KPC Series User manual

User Manual
KPC Series
i-Tech Company LLC
TOLL FREE:
(
888
)
483-2418 • EMAIL: info
@
i-techcom
p
an
y
.com • WEB: www.i-techcom
p
an
y
.com

2
Safety
IMPORTANT SAFETY INSTRUCTIONS
1. Todisconnectthe machinefromtheelectrial power supply, turn offthepower
switchandremovethe power cordplug fromthe wallsocket.Thewallsocket
must be easilyaccessibleand incloseproximity tothemachine.
2. Readtheseinstructionscarefully. Savetheseinstructionsforfuturereference.
3. Follow allwarningsandinstructionsmarked on theproduct.
4. Do not usethis product nearwater.
5. Do notplacethis productonanunstablecart,stand,or table.Theproduct may
fall,causingserious damagetotheproduct.
6. Slots and openingsinthe cabinetand the back or bottomare provided for
ventilation;toensurereliableoperationoftheproduct andtoprotectitfrom
overheating.Theseopeningsmust notbeblockedor covered.Theopenings
shouldneverbe blocked byplacingthe producton abed,sofa,rug,orother
similar surface.Thisproductshouldneverbeplaced nearor over aradiator or
heatregister,or inabuilt-ininstallation unlessproper ventilationis provided.
7. Thisproductshouldbeoperatedfromthetypeofpower indicatedon the
marking label.If you arenotsureofthe type ofpower available,consultyour
dealeror localpowercompany.
8. Do notallow anythingtoreston thepower cord.Do notlocatethisproduct
where persons willwalk onthecord.
9. Neverpushobjectsof anykind intothisproductthroughcabinetslotsasthey
maytouchdangerousvoltagepointsorshortoutparts thatcouldresultina
fireorelectric shock. Never spill liquidof anykindontheproduct.
CEMARK
This devicecomplieswiththerequirementsoftheEECdirective
2004/08/ECwithregard to “Electromagnetic compatibility”and
2006/95/EC “LowVoltageDirective”.
FCC
This devicecomplieswithpart15 of theFCC rules. Operationis subject tothe
followingtwo conditions:
(1) Thisdevicemaynotcauseharmfulinterference.
(2)Thisdevicemust acceptanyinterferencereceived, including interferencethat
may causeundesired operation.

3
CAUTION ONLITHIUMBATTERIES
Thereis adanger of explosion if thebatteryis replacedincorrectly.Replaceonly
withthe sameorequivalenttyperecommendedbythemanufacturer.Discard
usedbatteriesaccording tothemanufacturer’sinstructions.
LEGISLATION AND WEEESYMBOL
2002/96/EC WasteElectricaland ElectronicEquipmentDirectiveonthe
treatment,collection,recyclinganddisposalofelectricandelectronic
devicesandtheircomponents.
Thecrosseddustbinsymbolonthe devicemeans thatit shouldnotbe disposed of
withotherhouseholdwastes atthe endofitsworkinglife.Instead, thedevice
shouldbe takentothewastecollection centers foractivation of thetreatment,
collection, recycling anddisposalprocedure.
Topreventpossibleharmtothe environmentorhumanhealthfrom uncontrolled
wastedisposal, pleaseseparatethisfrom othertypesof wastesandrecycleit
responsiblytopromotethe sustainablereuseof materialresources.
Householdusersshouldcontact eitherthe retailer where theypurchased this
product, or theirlocalgovernmentoffice,fordetails ofwhereand how theycan
takethis itemforenvironmentally saferecycling.
Businessusersshouldcontacttheirsupplierand check thetermsand conditions
of thepurchasecontract.
This product shouldnotbe mixed withothercommercialwastesfor disposal.

4
TableofContents
1. Item Checklist.............................................................................................. 5
2. System View ................................................................................................ 6
2.1.FrontView...............................................................................................6
2.1.Rear View................................................................................................6
2.2.I/OView 7
3. DriversInstallation...................................................................................... 8
3.1.DriverList................................................................................................8
3.2.ChipsetDriverInstallation........................................................................8
3.2.USB 2.0Driver Installation ....................................................................10
3.3.VGADriverInstallation..........................................................................13
3.4.ELOTouchDriverInstallation................................................................15
3.5.POSTouchDriver Installation ................................................................18
3.6.10/100MbLANDriverInstallation..........................................................20
4. System Disassembly................................................................................. 21
4.1.ReplacingtheSlimlineHDD..................................................................21
4.2.OpeningtheRearCover.......................................................................22
4.3. ReplaceHeatsink/Fan &CPU..............................................................23
4.4. ReplacingtheTouchBoard...................................................................24
4.5. ReplacingtheInverter Board.................................................................24
4.6. ReplacingtheSpeakers ........................................................................25
4.7. ReplacingtheMotherboard...................................................................25
5. Specification.............................................................................................. 27
6. JumperSettings........................................................................................ 29
7. BIOS Settings............................................................................................ 36
8.AirflowRequirements................................................................................... 39

5
1. ItemChecklist
Take thesystem unit outof the carton.Removethe unit fromthe carton byholding
it by the foaminserts:
a. Driver CD b. Comport Cable
c. PowerCable d. PowerAdapter
e. System

6
2. System View
2.1. Front View
2.1. Rear View
TouchScreen
HDD Cover
I/OPorts
VESA
Mount

7
2.2. I/O View
VGA
DC IN
LAN
Cash
Drawer
Line in
Line
out
COM1,2,3,4
USB
Power
Switch
P
arallel

8
3. Drivers Installation
3.1. DriverList
Folder/File FileDescription
<CD>:\K790_B78\B78.htm B78 Driver List
<CD>:\COMMON\INTEL\Chipset Chipset Driver
<CD>:\COMMON\INTEL\USB 20 USB 2.0Driver
<CD>:\COMMON\INTEL\VGA\i85x VGA Driver
<CD>:\COMMON\Elo_Touch\Win2K_XP\SAW\V4.30 ELOTouchDriver
<CD>:\COMMON\POS_Touch POSTouchDriver
<CD>:\COMMON\Lan_driver\R8139_810x 10/100MbLANDriver
-The followingproceduresarefor Windows2000/XP, other platforms aresimilar.
3.2. ChipsetDriverInstallation
a. Double click “infinst_enu_6.0.1.1007”
on the Mycomputer window. b. Click the “Next”button on the Welcome window.

9
c. Click the “Yes”buttonon the License
Agreement window. d. Click the ”Next”button on the Readme Informationwindow.
e. Clickthe “Finish”button andrestart
your system.

10
3.2. USB2.0 DriverInstallation
OS Requirements
OS USB2.0requirements
Windows
XP USB 2.0driversareprovided in ServicePack 1 (SP1) for Windows XP,whichis availablethrough WindowsUpdate.
Windows
2000 USB 2.0driversareavailablethrough Windows Update or Service Pack4.
Windows
98SE/Me USB 2.0driversareavailableon the Inteldeveloper site.
Windows
98(Retail)
Developers andOEMsshouldcontact OrangeWare.For end-users,
if your devicedoes notshipwithWindows98drivers, contactyour
deviceor systemmanufacturer.If USB 2.0driversarenotavailable,
your devicewill operateatUSB1.1speeds
Linux USB 2.0supportis availablein kernel2.4.19 orlaterdevelopment
kernels, or inthe 2.4.19 or later production kernel. Moreinformation.
a. Rightclick MyComputeron the
desktopandselect “properties”b. Select “Hardware”à”DeviceManager” onsystemproperties.

11
c. Select ”OtherDevices”à“UniversalSerialBus (USB)Controller”à”Properties”on
DeviceManager.
d. Select “Device”à“UpdateDriver…”. e. Click the ”Next”button on the welcome
window.
f. Select “Searchforasuitable…”and
clickthe “Next”button on theInstall
Hardware DeviceDrivers window.
g. Select “Specify alocation”andclick the
“Next”buttonontheLocateDriverFiles
window.

12
h. Press “Browse”toselect the driver and
then clickthe “OK”buttonto gotothe
next page.
i. Click the “Next”button on the Driver
FilesSearchResults window.
j. Clickthe “Finish”button tocomplete
this process. k. Finished.

13
3.3. VGADriverInstallation
a. Clickthe “Win2K_XP”on the My
Computerwindow. b. Click the “v14.19.50”on theMy Computer window.
c. Select “win2K_xp141950”on the
v14.19.50window. d. Click the “Next”button on theIntel(R) Chipset Graphics DriverSoftware-
InstallShield(R)Wizard window.

14
e. Clickthe “Next”buttonon the Intel(R)
GraphicsMediaAccelerator Driver
window.
f. Click the “Yes”buttonon theIntel(R)
Graphics MediaAccelerator Driver
window.
g. Select “Yes,Iwant torestartmy
computer now”andclick the “Finish”
button onthe Intel(R)GraphicsMedia
AcceleratorDriver window.

15
3.4. ELO TouchDriverInstallation
a. Click ”sw500930”ontheMy computer
window. b. Click the “OK”button onthe Welcome window.
c. Click the ”Unzip”button on the WinZip
Self-Extractor window. d. Select “Install SerialTouchscreen Drivers”and then clickthe “Next”
button
ontheWelcomewindow.

16
e. Clickthe “Yes”button onthe License
Agreementwindow. f. Click the “Next”button on theon the “Selectthe COMports…” window.
g. Select “COM5”andclick the “Next”
button onthe ChoosetheCOM ports…
window.
h. Click the “Next”button on theYouhave
selected theCOM ports…window.

17
i. Clickthe “Finish”button ontheSetup
Completewindow j. Click the “Yes”button and restart your system.
k. After the computer has restarted,click
“Align”onthe EloTouchscreen
Properties window.
l. Follow theinstructionsonthescreen to
calibratethetouchpanel.

18
3.5. POSTouchDriverInstallation
a. Double click the ”Setup”on the “My
Computer”window.
b. Click the “Next“button on the
“Welcomewindow”.
c. Click the ”next”button onthe
“Wellcome”window.
d. Select “Install the software
automatically”andclick the ”Next”
button on the “URTC1000”window
e. Click the “Next”button on the “
License
Agreement”window.
f. Click the “Next”button on the “Install
Folder”window.

19
g. Click the “Next “buttonon the
“ShortcutFolder”window.
h. Select the “USB”and click the ”Next”
buttonon the “Options”window.
i. Click the :Next”button onthe “Ready
toInstall”window
j. Click the “Continue Anyway”buttonon
theURTC-1000 window
k. Click the “Finish”button on the
“InstallationSuccessful”window.
l. Click the “OK”button torebootyour
computer

20
3.6. 10/100MbLAN DriverInstallation
a. Click “Win9X,ME. 2K.XP”b. Double click ”V616(20040809)”onthe
My Computerwindow.
c. Double click ”Setup”ontheMy
Computer window. d. Click the “Finish”buttononthe Maintenance Completewindow.
e. Click the ”OK”button and restartyour
system.
