I-Tech ENP100 User manual

i-Tech Company LLC
TOLL FREE:
(
888
)
483-2418 • EMAIL: [email protected] • WEB: www.iTechLCD.com

V3.0(06198) 2 9/16/2008
Table of Contents:
I. Introduction
II. Board Spec and Components
III. Evaluation Kit
IV. Playlist and Operation
V. Client Device Setup
1. Client board Installation
2. Client Main Menu
3. Client Setup Screen
4. Remote Control Key Definition
5. Scrolling Text Format
VI. CAT Server Software
1. CAT.exe
2. Tools Tab
3. Account
4. Sever Utility Setup
5. Client Utility Setup
6. Playlist Scheduler (*new)
7. Graphics Command ICON
8. Playlist Commander
9. Remote HTTP Server
10.Remote FTP Server
11.Web Server Configuration

V3.0(06198) 4 9/16/2008
IV. Playlist and Operation
1. Playlist:
Playlist is a script text file including command, time schedule, download filename and
content server IP address for client to execute line by line.
Playlist is created by administrator using CAT (Client Administration Tool) software.
2. Basic Operation without CAT (Server management software):
Pre-configure network setup and save. Network setup includes username, password,
server IP, client DHCP or static IP, and HTTP or FTP server’s URL address to download
playlist.
Administrator uploads playlist file into the specific URL path of HTTP or FTP server
Connect audio/video cables to any TV display, and Ethernet cable to RJ-45 connector
Power up unit, it will load network settings from EEPROM, initialize LAN, connect to
internet and download playlist from fixed URL and store into CF card automatically
Interpret playlist file and execute tasks including download files, playback files, time
schedule …etc. Playback media files repeatedly until stop or reboot command
Administrator can update new playlist, just keep same filename for network player to
load new playlist file when player power-up manually, or daily reboot time is hit, or set
pre-defined interval time that allow player to visit this URL.
3. Server Monitoring and Management Tool – CAT (Client Administration Tool)
CAT is a Windows application software to manage multiple client devices thru LAN or
internet connection
CAT has many useful commands and editor tools to monitor and control client devices

V3.0(06198) 5 9/16/2008
V. Client Device Setup
1. Client board Installation
-High speed CF memory card is required (Sandisk Ultra II recommended)
-Use PC to format CF card with FAT32 selection for better performance
-Plug in CF card into CF slot
-Plug in LAN cable that connect to your LAN or internet network
-Connect video cable (RCA or S-Video) to your TV unit or VGA to your PC monitor
-Switch to right video source input channel on TV unit
-Connect audio cable to TV unit’s audio connectors
-Connect AC power adapter
-Power on network player (led light should be ON and screen displays ‘Initializing’)
2. Client Main Menu
-TV screen will show “Initializing”, “Initializing LAN”, “Connecting DHCP Server..”,
“IPAddress”, “CF Card” then main menu
Note: It will take some time on the “Connecting to DHCP Server” depending on the IP
assignment speed from network router
-Main menu will show the following items on left side
•Client Local IP: xxx.xxx.xxx.xxx
•Server IP: xxx.xxx.xxx.xxx or Host name
•Time: 2007/06/01 15:30
•MAC Address: xx-xx-xx-xx-xx-xx
•Server Connection: ON or OFF or Error
•Storage: xxxMB
-Main Menu will show the following items on the right side
•Setup : press ENTER key to go into Client Setup screen
•Storage : Press ENTER key to go to file folder of CF card
3. Client Setup Screen
-Use remote control to navigate and make changes
-Press ENTER from main menu to Setup screen
-Setup has ‘Network’, ‘Time’, ‘Device Schedule’, ‘Auto Start’,‘Language’, ‘Factory
Default’, ‘Save and Reboot’and ‘Return to Menu’selections.
-Press ENTER on any item to go to its page
‘Network’Setup Screen
a. User Name and Password: Use “Select” or “Goto” key to open virtual keyboard.
Move cursor to any letter and press ENTER, or use ‘0’ (zero) to erase letter. After

V3.0(06198) 6 9/16/2008
finished, press “Select” or “ Goto” key again to exit virtual keyboard mode. Press
ENTER key on ‘user name’or ‘password’to go to next page
b. Server IPand Host Name: Move cursor to select ‘Server static IP’or ‘Host
Name’. Use numeric key pad of remote to type 3 digits for static IP or use virtual
keyboard to type ‘Host Name’. Press ENTER to next page. (Server IP is the PC’s
IP where your CAT program is running. Host Name is go out to internet server)
c. Server Port (new feature): default is 5021. If not, please use remote control to
enter ‘05021’. This port number must match with CAT’s. Please go to CAT’s
Server Setup Utility to modify server’s port number if 5021 is already occupied.
After port changed, close CAT and open again to make new port effective.
d. Client DHCPor Static IP: Move cursor to select ‘DHCP’or ‘Static IP’and press
ENTER on ‘Static IP’to Static IP page or DHCP to Setup screen. (DHCP is
recommended.)
‘Time’Setup Screen
a. Time Server: Use cursor left or right to select ‘time.nist.gov’or
‘windows.time.com’. Use cursor down to next item
b. Date: you can ignore this because client board will get internet time during
power up initialization unless you don’t have internet connection
c. Time: Same as Date
d. Time Zone: Use cursor left or right to select your local time zone
e. DST(Day Saving Time): Use cursor to select On or OFF. If On, it will add one
hour
f. Date Format: This date format will appear on scroll bar only. User can select
either mm/dd/yyyy or dd/mm/yyyy format.
g. Press ENTER on any field to go back to Setup screen
‘Device Schedule’Setup Screen
a. Reboot Time: Move cursor to select ‘OFF’or type 2 digits for daily reboot
time. When time is up, client will reboot itself. If auto start is set to network
mode, it will download new playlist file. Also player will send playback log
data back to server for further usage.
b. Device Schedule: Move cursor to ‘OFF’or ‘ON’. If ‘ON’, another line below
will display ‘HH MM to HH MM’. Device ON time will turn on video and start
to play from existing playlist file in the CF card. Device OFF time will turn off
video and stop playing.
Auto Start Screen
a. OFF: After power up, client will do nothing and wait for server’s command
b. Local CF: After power up, client will playback according to playlist file stored
in the CF card or playback A-Z order files if no playlist file is found.
c. HTTP URL: Use CAT’s client setup utility to enter network URL path. After
power up, client will go to this URL path to download playlist file and execute
action item listed in the playlist file. (also described on page 2 item IV)

V3.0(06198) 7 9/16/2008
d. iCAT: This is a web based management software like CAT, but iCAT allows
user to use browser to access from any PC, anywhere. iCAT is not like CAT has
more interactive commands. iCAT is more schedule-oriented automatic method.
Get 10 digit ID from iCAT program’s “Add player”. When player powers up, it
will login to iCAT server, user will see its on-line. For more detailed, please
refer to iCAT user guide document.
Language:
If revision # on the main menu has ‘U’which means European fonts are installed.
Selections are ‘English’, ‘East-South European’, ‘Western European’, and
‘Turkish’. This font is used for RSS and instant message display on the scroll bar.
Factory Default: load pre-defined values into Setup settings. For example;
a. Device Name: NDSP01 b. Password: 123 c. Server IP: 192.168.1.106
d. Server Port: 5021 e. Device IP: DHCP
Save and Reboot: save all the changes and reboot client
Return to menu: just return to main menu
[Note-1]: All these client setup settings can be modified in the “Client Setup Utility” of
CAT software. You can save as “autoconfig.mia” filename into CF card then plug into CF
slot and power up client board. It will show “Auto Updating” message and save into
EEPROM. Remove CF card and delete this file to avoid reload again.
[Note-2]: You can save as “autoconfig.mib” filename, it will do the same thing to update
EEPROM except this autocinfig.mib file will be deleted after update.

V3.0(06198) 8 9/16/2008
4. Remote Control Key Definition
Label
(EG-D10) Label (MP715 Remote) Remote Key Function
Main Menu SEARCH Switch to main menu screen from SmartNavi screen
Video Mode TV MODE Switch between S-Video/Composite Video and VGAoutput
Keyboard SELECT Only available in Setusp screen to enter or exit virtual keyboard
page (use key ‘0” as erase key)
MUTE MUTE Mute/Un-mute sound
VOL + VOL + Sound level control
VOL - VOL - Sound level control
Position + SHUFFLE Adjust down scrolling text bar position
Position - EDIT/PROGRAM Adjust up scrolling text bar position
Background
Color TITLE Background color for scrolling text bar (8 colors)
Foreground
Color SUBTITLE Foreground color for scrolling text bar (white and black)
Transparent REPEAT Scrolling text transparent level (0%, 25%, 50%, 75%, 100%)
Speed ANGLE/ROTATE Scrolling text speed settings (fast, normal and slow)
Scroll Bar
Clock A-B Turn On/off Clock display on the scrolling text bar
EZ-Play >>
FORWARD Do auto download/playback files in A-Z order from CF card or execute “playlist.mpl” file in the CF card
5. Scrolling Text Format
A regular .txt file can be used to store any text data including English, Chinese or Japanese.
This text file data will be scrolled like stock symbol or news ticker along with any photo or
video file.
At the 1st line of the text file, user can program some settings for the text color, and
position.
osd_settings=[B/G color], [F/G color], [Transparent], [Speed], [Font Size], [Clock]
e.g. “osd_settings=2,1,0,0,0,0
1. B/G color: a digital number from 0 to 7 (0blue, 1grey, 2red, 3ligh blue, 4green, 5yellow,
6magenta, 7orange)
2. F/G color: 0(white). 1(black)
3. Transparent: 0(no transparent effect), 1(75%), 2(50%), 3(25%), 4(100%)
4. Speed: 1(slow)，2(normal), 4(fast)
5. Clock/Date: 1(On), 0(Off)
[Note]: Defaults are white color text on grey color background if no OSD_Setting line.

V3.0(06198) 9 9/16/2008
VI. CAT Software
1. CAT (Client Administration Tool) can be executed on any Windows XP system. Just
click on CAT.exe, it will display like photo below. Home is the default group.
2. When click Tool tab, it will pull down useful tools (see photo below). CAT UI and
language can be customized per request.
3. Account is to create or manage group name and user account name. You can create
multiple groups and assign different account names. When any client logs into CAT, it
will go under its corresponding group if account name is matched. If not matched, it will
go under default Home group.

V3.0(06198) 10 9/16/2008
4. AutoPlay is a new feature after V0225. When players power up and log in to CAT, CAT
will automatically send playlist file and its content media files as specified here. Instead of
EZ-Play (manual mode), this AutoPlay mode can be more useful for users. For AutoPlay
mode, make sure AutoStart=CAT in the player Setup. It won’t work ifAutoSart=http URL.
5. Sever Setup is for administrator to make changes for CAT server.
a. Server port 5021 is for port forwarding function of network router to access CAT
program.
b. PASV default port starts from 5022 – 5031 and can be changed to match
company’s firewall setting. This is for player to connect CAT using internet and
thru company router and firewall.
c. Current version allows up to 10 client devices to log in. You need to contact your
supplier for more users copy.
d. RSS Ticker: Default is set, but can be changed to match your PC’s path and
filename. When RSS ICON is clicked, CAT will send this file to players.

V3.0(06198) 11 9/16/2008
Note: CAT is required to be closed for new port change! Then open again to take effective.
6. Client Setup is an editor to create or open autoconfig.mia file. This file is used to update
client’s setup values. Save autoconfig.mia into CF card, then plug into network player
and power up. It will show “Auto Updating” message and then reboot again.

V3.0(06198) 12 9/16/2008
a) IP or Hostname: Type in static IP for local LAN server or hostname for remote
internet server. Example: 192.168.1.100.
b) Port: default is 5021. If 5021 is used on the server side, then change to different
number. But make sure also change same port # in CAT and router’s port
forwarding setting.
c) Client Account Name and Password: Type in user name and password for this
client device. After client powers up and logs into CAT server, it will go to its
matched group.
d) DHCP or Static IP: Select Dynamic IP by router or fixed static IP for client device
e) Time Zone: Select your local time zone
f) Daylight Saving: Check will add one hour
g) Reboot time: Check will reboot client when time is hit
h) Device On: will turn on video and start to play from existing playlist file in the CF
card when time is hit
i) Device Off: will turn off video and stop playing when time is hit
j) Video output: select S-Video(including Composite video), VGA, YPbPr output.
You can use ‘Angle’or “Video mode” key on remote control to switch
k) Off/CF Card/Http URLAddress: type in URL address and playlist filename, so
client will download playlist file from remote URL and execute.
l) Update Client is a remote command. It will send current settings to all client
devices of the selected group. Client device will reboot after save settings into
EEPROM. It will take approximately 15-20 seconds to reboot till re-login.
7. Playlist Scheduler
This is a new feature for AutoPlay mode. User can program advanced schedule instead
of daily schedule only. Firmware version must be v0508 or after to work with this
feature.

V3.0(06198) 13 9/16/2008
a. Make sure when you create playlist.mpl file in the playlist editor, and save
into same group folder. Ex. Home group, then save into CAT\Home\.
b. Browse your predefined playlist file from same group folder and enter start
date, end date and weekday for this playlist’s campaign schedule then click
‘Add’. You can repeat to add more playlist file with different schedule.
c. From above picture, you can set one month program with weekday and
weekend campaign. Media file’s start time and end time are set in the
playlist editor.
d. Make sure you don’t conflict your playlist with two same date schedules.
e. Click File to Save your current schedule into a .sch filename into same
group name’s folder. Ex. CAT\HOME\1.test.sch
f. Go back to Account-> Select Group -> Edit -> AutoPlay page and browse
your .sch file, then click Finish
g. After all these settings, CAT will return a corresponding playlist based on
this .sch file schedule when player login to CAT.
8. Graphics ICON:
From ‘Start’to ‘Options’Icon is the group command. Highlight cursor on the group is the active
group. Command will be sent to all the client devices under active group.
From ‘Status’to ‘Playlist’Icon is the client command. Highlight cursor on the user name is the
active client. Command will sent to this client only.
a) Account: create group and account user name for group management

V3.0(06198) 14 9/16/2008
Below is command that goes to all clients of same group, one by one.
b) Play: Send ‘Playback’command manually to group of clients
c) Stop: Send ‘Stop’command manually to group of clients
d) Message: Instant message editor will pop up. You can select any .txt file or manually type
in text message, then send to group of clients. A news ticker type of OSD will scroll text
from right to left on the bottom of client screen
e) Message Off: Send “Message Off” command to group of clients
f) Volume: It has Mute and 15 levels of volume. Will send volume command manually
g) Video: It has video ON or OFF to turn On/Off client’s screen
h) Options: Less frequent use commands are located here.
- Format: Send format CF card command to client. All files in CF card will be erased.
- Reboot: Send reboot client command to client.
- Group Status: inquire all clients in the same group to send status back, similar to j)
Below is individual client command, not group command
i) Status: inquire client to send back current status data including time, current playback
filename, music and instant message. Example: Playing [01:54:30]
BATMANBEGINS_1.DIVX(5/11,16) 0:0:6, Scrolling Text: IntoTheBlue.txt
j) Capacity: inquire client to report CF card capacity and firmware version #. Example:
Storage Total Size: 977MB, Free Space: 762MB. F/W version: v2.2.86.0619U
k) CF Data: Inquire client to report all the filenames on the CF card. It will display
filenames on the CF tab screen of CAT.
l) CF Data [Delete]: Click right mouse button on CF window, a ‘Delete’ will pop up. You
can check all the files to be deleted first then click ‘Delete’. CAT will send delete
command to client to remove those checked files and update CF Data screen.
m) Playlist: Inquire client to report current playlist file. It will display the playlist file order
on the playlist tab screen of CAT
[Note] Log data:
When you move mouse cursor on the log window area, you can click right mouse button.A
menu will pop up to choose “Save As” or ”Clear”. Clear is to clear up the log data. Save As
is to allow you to save all the log history for technical support. You can send this .log file to
MIA for data analysis.

V3.0(06198) 15 9/16/2008
9. Playlist Commander
a. Local Directory: Load media files from local PC’s directory. Once files are moved to
right window, press ‘EZ-Play’ on selected group, server will transfer files to clients.
b. Remote HTTP Server: Type URL address and filename from remote HTTP server
c. Remote FTP Server: allow to log in any FTP and browse files to generate playlist
d. File Type: mpl : file filter check box is for playlist extension (.mpl) only. This feature is
to support multiple playlist with time range settings.
e. Open: Open existing playlist file
f. Save: Save new playlist file or overwrite existing one
g. >: move single file to playlist window
h. >>: move all files to playlist window
i. Select Group: user must specify which group to execute “EZ-Play” and “Playlist”
buttons
j. EZ-Play: all the media files on the right playlist window will be downloaded to client
and playback immediately. This is manual mode, controlled by user.
k. AutoPlay: New feature on v.0225-2008. ‘Playlist’ is changed to ‘AutoPlay’. Create
Autoplaylist.mpl file under that group and enable Autoplay mode.
This will not be effective until player reboot or power up next time. User can pre-assign
playlist file for particular group’s players.

V3.0(06198) 16 9/16/2008
l. Duration/Times: allow to enter loop counter for video file or duration time (seconds) for
JPEG file
m. Start Time/End Time: (format:HHMM)
1. If time range is “blank” that means “always playback, no time limit for 24 hours”.
2. Allow each media file to playback in its time range. For example, abc.jpg 30 0800
to 1200 means abc.jpg will be active for 4 hours, each time its duration is 30
seconds. Start to playback from 0800 onward, and stop to playback after 12pm.
Examples:
Filename Duration/Counter From hhmm To hhmm Comments
A000.jpg Blank Blank Blank A000 will display 3 seconds for 24 hours
A001.jpg 30 Blank Blank A001 will display for 30 seconds for 24 hours
A002.jpg Blank 0800 1200 A002 will display 3 seconds from 8am to 12pm
A003.mpg Blank Blank Blank A003 video will play 1 time each loop for 24 hours
A004.mpg 3 0800 1200 A004 video will play 3 times each loop from 8am-12pm
P001.mpl Blank 0800 1200 P001 playlist file will start from 8am to 12pm
P002.mpl Blank 1200 1800 P002 playlist file will start from 12pm to 6pm
n. Del: Remove single file from playlist window
o. Clear: Remove all files from playlist window and reset values in the Setting menu
p. Up/Down arrows: Move up or down on the highlight filename to proper position
q. Settings: Some useful settings for playlist file

V3.0(06198) 17 9/16/2008
r. Picture Play Time: control interval time between JEPG files
s. Picture Transition Mode: 3 modes (Full screen, Random, and Cross Fade) are available
to change picture transition effect
t. Delete Files:
a. No Action: default value, do nothing.
b. Format CF card: Will delete all files in the CF card then download new files
based on playlist.mpl.
c. Files not in the playlist: If CF card has many files, the files not in the playlist will
be deleted. If on the playlist, will be kept to avoid download again.
d. Files in the playlist: This is like multiple file deletion command. It will only delete
files in the playlist.
u. Mute Sound: Mute sound in the playlist, all the content playback will be silent.
v. Download schedule: will write download time into playlist file. Player will not start
download immediately until download time is up, then player will start to download
content according to playlist file.

V3.0(06198) 18 9/16/2008
11. Remote HTTP Server
Playlist commander also supports HTTP server. Just type URL path and filenames in HTTP
server storage. Click EZ-Play or save playlist file for future use.

V3.0(06198) 19 9/16/2008
12. Remote FTP Server
The feature allows user to access FTP server and create a FTP playlist. All the navigation is
the same as local directory. But need to enter your regular FTP information including user
name, password ..etc. You can click EZ-Play to execute immediately or save playlist for
future use.
“Upload playlist” is a new feature from V0115-2008. When click, it will save the playlist
file into FTP server where the file folder is instead of local hard drive directory. For
example, ‘EZplaylist.mpl’has been saved and uploaded under testData\MIA.DataBank
folder. It can combine with auto start=FTP url to update your playlist file and reflect to
player within 3 minutes. No need to use another FTP client software to upload playlist
separately.

V3.0(06198) 20 9/16/2008
13. WebServer Configuration
Webserver is a tool that allow administrator to read client device’s current status and
re-configure server’s and client’s IP, username and password from IE (Internet Explorer).
In case Client’s network setup values needs to be changed. Administrator doesn’t need to go
to client site and use remote control to change. Just use IE for remote control.
1) To use this function, open Microsoft IE and type client’s IP address (for example
192.168.1.16) on the address line.
2) If IP is correct and client is in the same network, IE will pop up a confirmation window.
Enter username and password below. User Name = admin Password = admin
3) IE will read data back from client device and display status home page. Click Client Status
on the left side, it will refresh screen for new update.
