I-View AnyCam DM-12MIPS User manual

DM
-12MIPS/DM-5MIPS04/ DM-3MIPS
04
DM-2MIPS04 oPeratIon Manual
Version: V1.1
Doc. No.:
1060714001

2
Safety information
This symbol indicates that dangerous voltage consisting a risk of electric shock is
present within this unit.
This exclamation point symbol is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the
appliance.
WARNING
To prevent damage that may result in fire or electric shock hazard, do not expose this
appliance to rain or moisture.
To prevent injury, this apparatus must be securely attached to the floor / wall in accordance
with the installation instructions.
WARNING
1. Be sure to use only the standard adapter that is specified in the specification sheet using any
other adapter could cause fire, electric shock, or damage to the product.
2. Incorrectly connecting the power supply or replacing battery may cause explosion, fire,
electric shock, or damage to the product.
3. Do not connect multiple cameras to a single adapter. Exceeding the capacity may cause
the abnormal heat generation or fire.
4. Securely plug the power cord into the power receptacle, insecure connection may cause fire.
5. When installing the camera, fasten it securely and firmly. The fall of camera may cause
personal injury.

3
6. Do not place conductive objects (e.g. screwdrivers, coins, metal parts, etc.) or containers
filled with water on top of the camera. Doing so may cause personal injury due to fire,
electric shock, or falling objects.
7. If any unusual smells or smoke come from the unit, stop using the product. In such case,
immediately disconnect the power source and contact the service center. Continued use in
such a condition may cause fire or electric shock.
8. If this product fails to operate normally, contact the nearest service center and never
disassemble or modify this product in any way. (I-View is not liable for problems caused by
unauthorized modifications or attempted repair.)
9. When cleaning, do not spray water directly onto parts of the product. Doing so may cause
fire or electric shock.
CAUTION
Do not drop objects on the product or apply strong shock to it. Keep away from a location
subject to excessive vibration or magnetic interference.
Do not install in a location subject to high temperature (over 50°C), low temperature (below
-10°C), or high humidity. Doing so may cause fire or electric shock.
If you want to relocate the already installed product, be sure to turn off the power and then
move or reinstall it.
Remove the power plug from the outlet when then there is a lightning. Neglecting to do so
may cause fire or damage to the product.
Keep out of direct sunlight and heat radiation sources. It may cause fire.
Install it in a place with good ventilation.
Avoid aiming the camera directly towards extremely bright objects such as sun, as this may
damage the CCD image sensor.
Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids,
such as vases, shall be placed on the apparatus.
The Mains plug is used as a disconnect device and shall stay readily operable at any time.
Do not expose the camera to radioactivity. Radioactivity exposure may damage the CCD.

4
IMPORTANT SAFETY INSTRUCTIONS
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
Do not install near any heat sources such as radiators, heat registers, or other apparatus
(Including amplifiers) that produce heat.
Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a
third grounding prong. The wide blade or the third prong is provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
Only use attachments/accessories specified by the manufacturer.
Use only with cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus.
Unplug this apparatus when a card is used. Use caution when moving the cart/ apparatus
combination to avoid injury from tip-over.
Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.
Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids,

5
such as vases, shall be placed on the apparatus.
SAFETY INFORMATION
FCC STATEMENT
This device complies with part 15 of the FCC Rules. Operation is subject to the following
conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received including interference that may cause
undesired operation.
CAUTION
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
This marking on the product, accessories or literature indicates that the product and its
electronic accessories should not be disposed of with other household waste at the end of their
working life. To prevent possible harm to the environment or human health from uncontrolled
waste disposal, please separate these items from other types of waste and recycle them
responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their
local government office, for details of where and how they can take these items for
environmentally safe recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract. This product and its electronic
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of FCC Rules. These limits are designed to pr
ovide reasonable
p
rotection against harmful interference when the equipment is operated in a commercial
environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction m
anual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own
e
xpense.

6
accessories should not be mixed with other commercial wastes for disposal.
About This Guide
Conventions used in this guide
To make sure that you perform certain tasks properly, take note of the following symbols to use
throughout this manual.
WARNING: Information to prevent injury to yourself when trying to complete a task.
CAUTION: Information to prevent damage to the components when trying to complete a
task.
IMPORTANT: Information that you must follow to complete a task.
NOTE: Tips and additional information to aid in completing a task.
Trademark
I-View, e-Witness, @-Witness Pro, u-Witness XP, x-Witness, FreeView Pro,AnyCam, P D AVi r w
and MobileView are registered trademarks of I-View Communication Inc.
Microsoft, Windows 95, 98, ME, Windows2000, XP,Vista, 7 and 8 are registered trademarks of
Microsoft Corporation. All other trademarks are the property of their respective holders.
Customer Support
If technical problems arise with the use of our products in which you and your vendor cannot
resolve, please try the following: If you have an Internet connection, visit the I-View website
http://www.i-view.com.tw (Taiwan) for any software or product updates, or email to
[e-mail] (Taiwan) or Tel: [phone] Fax: [phone] (Taiwan). We
are dedicated to providing the highest quality support. E-mailing our tech support will give you
the chance to document each of the above items in a very clear and concise manner and will give
our support team a chance to document any problems and respond with thoroughly researched
answers.

7
Table of Contents
Chapter 1. Introduction ---------------------------------------------------------------------------------------- 8
1-1. Highlights of your new Network IP Camera ------------------------------------------------8
1-2. Product Specification ---------------------------------------------------------------------------9
1-3. Packaging Contents --------------------------------------------------------------------------- 19
1-4. Product Dimension---------------------------------------------------------------------------- 19
1-5. Product Parts Description -------------------------------------------------------------------- 20
Chapter 2. Camera Installation------------------------------------------------------------------------------ 22
2-1. Ceiling Mount installation ------------------------------------------------------------------- 22
Chapter 3. Running IP Camera by Witness Pro NVR software.------------------------------------- 25
3-1. Network Deployment------------------------------------------------------------------------- 25
3-2. Install Witness Pro NVR software ---------------------------------------------------------- 26
3-3. Setting IP camera for Witness Pro NVR software---------------------------------------- 28
Chapter 4. Accessing the Network Camera via I.E. Browser ----------------------------------------- 34
4-1. Install ActiveX Plug-in on I.E. Browser --------------------------------------------------- 36
4-2. Using RTSP Players--------------------------------------------------------------------------- 38
4-3. The Function Description of Live Window ----------------------------------------------- 38
4-4. The Network setup Function Description-------------------------------------------------- 41
Chapter 5. Troubleshooting ---------------------------------------------------------------------------------- 68

8
Chapter 1. Introduction
1-1.Highlights of your new Network IP Camera
Congratulates on purchasing this high-resolution 12MP/5MP network IP Camera! This IP
Camera provides 5M pixels high-resolution video quality, with its advanced megapixel lens; you
can view remote images in more detail than conventional close-circuit cameras.
Other highlights of this network IP Camera include:
Onvif compliant and CGI, RTSP protocol support.
H.265 compression save bandwidth and storage size.
Built in TVS surge protector..
Built in 802.3af compliant PoE.
Built in gyro sensor for tampering alarm.
Auto recording video into SD card when Network and NVR failed.
Video and interval snapshot schedule recording on SD card or FTP server.
WDR Enhancement for Unparalleled Visibility in Extremely Bright and Dark Environments.
Quick Zoom® to simple the Zoom and Focus adjustment remotely.
Removable IR-cut filter for Day & Night function.
Built-in 4 pieces VCSEL IR Illuminators, effective up to 30 meters.
Vandal-proof IK10-rated, IP 66 Weather-proof rated Housing.
Smart IR to adjust the IR LED light across the entire area to get a well illuminated image.
The housing must Anti-cut cable and junction box design for Protected installation.
H.265/ H.264 /MJPEG multiple simultaneous streams.
On-camera motion detection and privacy mask.
Pixel Counter for Image Clarity Measurement.
Virtual ePTZ for efficiency surveillance.
ROI (Region of Interest) encoding is used to enhance the quality of images which are specified
in advance.
Ultra Low Compress Rate (ULCR) technology: LESS storage space, SAME video quality.
Wide operation temperature (-40°C ~ 60°C) rage.
Free bundle 64-Channel NVR and CMS softwaret.

9
1-2.Product Specification
DM-12MIPS04 Series
System
Platform: High performance DSP; 1024MB Flash; 2048MB DDR III RAM and Linux
Embedded O.S.
Image Device
1/1.7" 12MP Sony progressive scan CMOS sensor
Video Setting
Compression: Video:0.1M ~ 20M bits/sec (CBR/VBR/LBR configurable) H.265/H.264
HP/MP/BP, M-JPEG; Audio: G. 7 1 1 μ-low/a-low Codec
Resolution:Main Streaming:12M(4000x3000),8M(3840×2160).
Sub streaming: 1280x720, 800x600, 704x576, 704x480, 640x480, 352x240,
320x240, 320x176
Frame Rate: 20fps @12MP; 30 fps for all resolution @ H.265/H.264/M-JPEG Mode; Frame
rate can be adjustable by user.
Streaming: Multi-Stream H.265/H.264 Base/Main/High Profile and Motion JPEG video
streaming
Control: Brightness, Contrast, Saturation, Sharpness, Exposure, Motion detection, Mirror,
Corridor mode, Shutter, Privacy mask, Flicker less, 3D Noise reduction, Defog, IRIS, AES,
AWB, AGC, BLC, WDR, ROI, Audio gain, Alarm in/out. Video recording by scheduling,
Network and NVR failed. Interval Snapshot schedule recording, CPU usage display.
Color: 0.0 5ux 1/F1.2 B/W: 0.01 Lux.; 0Lux (IR LED on) .
WDR: 100dB True WDR
Audio Setting
μ-Low/ a-Low G. 7 1 1 audio encoding and decoding;
2-way audio; External Microphone input; Speaker output.
2Vp-p audio input and audio output with 600Ωimpedance.
Network

10
Protocol: HTTP, HTTPS, TCP, IPv4, IPv6, PPPoE, UDP, SMTP V1/V2, FTP, SSH, QoS,
DHCP, DDNS, NTP, DNS, SNMP, RTSP, CGI, Onvif, Bonjour, 802.1x, UPnP, STARTTLS,
Multicast, RTMP.
Interface: 10BASE-T/100 BASE-TX.
Compatible: Onvif compliant
Security
Password Protection, User access log; IP address filtering, and Mac number filtering,
Multi-level user access with password protection.
I/O Port
Standard: Audio in x1; Audio out x1; DC power in, RJ-45.
Option: Alarm out; Sensor in x1; Video out, Reset, SD Card.
Surge Protector
Power: 2KV @ 1.2/50μS Common mode.
Signal: 6KV@ 102/700μS Differential mode.
Lens & IR Illuminators
Vari Focal lens: f= 3.6mm~11mm/ F1.4 Auto IRIS. Angle of View: H: 106 ˚~ 32 ˚
Motorized lens: f= 3.6mm~11mm/ F1.4 Auto IRIS. Angle of View: H: 106 ˚~ 32 ˚
IR Cut: Built on removable IR-cut filter for day & night function.
IR Illuminators: 4 pieces VCSEL IR Illuminators effective up to 30 meters
Storage
Micro SD slot for SD/SDHC card storage; Support Prerecording and Post recording; Alarm
trigger, Motion trigger, Network failed and NVR stop recording start recording on SD
card/FTP Server. Backup/Restore to device configuration file to FTP/SMTP sever
Management
Time management: Manual Time Setting; Time Server, NTP support, DST offset
and Real Time Clock
Event management: Events triggered by Motion detection or sensor with configured
schedule.

11
Event notification: Event notification via Pop up video, send snapshot via email and trigger
alarm output.
Update: On line Firmware updates.
Browse
I.E. 7.0 above; Safari Browser. Firefox and Chrome V3.0 above with plug in.
Housing
Aluminum housing with IP 66 Waterproof & IK10 Vandal resistant and 3-Axis bracket design.
Dimension/Weight
Ø 138mm x 100 mm (H) / 0.85Kg.
Operation
Power: Maximum 3 W & 8W(IR LED On); PoE IEEE 802.3af Class 3; DC12V
Temperature: Temperature -40°C ~ 60°C; Humidity 20% ~ 80% RH.
Certificated
CE, FCC, RoHS, IP66, IK10
DM-6MIPS04 Series
System
Platform: High performance DSP; 1024MB Flash; 2048MB DDR III RAM and Linux
Embedded O.S.
Image Device
1/1.8" 6.41MP Sony Starlight progressive scan CMOS sensor
Video Setting
Compression: Video:0.1M ~ 12M bits/sec (CBR/VBR configurable) H.265/H.264
HP/MP/BP, M-JPEG; Audio: G. 7 1 1 μ-low/a-low Codec
Resolution:Streaming 1:2592x1920, 2048x1536,1920x1080, 1280x720.
Streaming 2: 1280x720, 800x600, 704x576, 704x480, 640x480, 352x240,
320x240, 320x176.
Streaming 3: 352x240, 320x240., 320x176.

12
Frame Rate: 30 fps for all resolution @ H.265/H.264/M-JPEG Mode; Frame rate can be
adjustable by user.
Streaming: Multi-Stream H.265/H.264 Base/Main/High Profile and Motion JPEG video
streaming
Control: Brightness, Contrast, Saturation, Sharpness, Exposure, Motion detection, Mirror,
Corridor mode, Shutter, Privacy mask, Flicker less, 3D Noise reduction, Defog, IRIS, AES,
AWB, AGC, BLC, WDR, ROI, Audio gain, Alarm in/out. Video recording by scheduling,
Network and NVR failed. Interval Snapshot schedule recording, CPU usage display.
Color: 0.0 5ux 1/F1.2; B/W: 0.001 Lux.; 0Lux (IR LED on) .
WDR: 120dB True WDR
Audio Setting
μ-Low/ a-Low G. 7 1 1 audio encoding and decoding;
2-way audio; External Microphone input; Speaker output.
2Vp-p audio input and audio output with 600Ωimpedance.
Network
Protocol: HTTP, HTTPS, TCP, IPv4, IPv6, PPPoE, UDP, SMTP V1/V2, FTP, SSH, QoS,
DHCP, DDNS, NTP, DNS, SNMP, RTSP, CGI, Onvif, Bonjour, 802.1x, UPnP, STARTTLS,
Multicast, RTMP.
Interface: 10BASE-T/100 BASE-TX.
Compatible: Onvif compliant
Security
Password Protection, User access log; IP address filtering, and Mac number filtering,
Multi-level user access with password protection.
I/O Port
Standard: Audio in x1; Audio out x1; DC power in, RJ-45.
Option: Alarm out; Sensor in x1; Video out, Reset, SD Card.
Surge Protector
Power: 2KV @ 1.2/50μS Common mode.

13
Signal: 6KV@ 102/700μS Differential mode.
Lens & IR Illuminators
Vari -Focal Lens: f=3.6-11 mm / F1.4-F2.4 (H: 110.3°~45.6°; V: 55.5°~24.1°)
Motorized Lens: f=3.6-11 mm / F1.4-F2.4 (H: 110.3°~45.6°; V: 55.5°~24.1°)
IR Cut: Built on removable IR-cut filter for day & night function.
IR Illuminators: 4 pieces VCSEL IR Illuminators effective up to 30 meters
Storage
Micro SD slot for SD/SDHC card storage; Support Prerecording and Post recording; Alarm
trigger, Motion trigger, Network failed and NVR stop recording start recording on SD
card/FTP Server. Backup/Restore to device configuration file to FTP/SMTP sever
Management
Time management: Manual Time Setting; Time Server, NTP support, DST offset
and Real Time Clock
Event management: Events triggered by Motion detection or sensor with configured
schedule.
Event notification: Event notification via Pop up video, send snapshot via email and trigger
alarm output.
Update: On line Firmware updates.
Browse
I.E. 7.0 above; Safari Browser. Firefox and Chrome V3.0 above with plug in.
Housing
Aluminum housing with IP 66 Waterproof & IK10 Vandal resistant and 3-Axis bracket design.
Dimension/Weight
Ø 138mm x 100 mm (H) / 0.85Kg.
Operation
Power: Maximum 3 W & 8W(IR LED On); PoE IEEE 802.3af Class 3; DC12V
Temperature: Temperature -40°C ~ 60°C; Humidity 20% ~ 80% RH.
Certificated
CE, FCC, RoHS, IP66, IK10

14
DM-2MIPH04 Series
System
Platform: High performance DSP; 1024MB Flash; 2048MB DDR III RAM and Linux
Embedded O.S.
Image Device
1/2.8" 2MP Sony progressive scan CMOS sensor
Video Setting
Compression: Video:0.1M ~ 12M bits/sec (CBR/VBR configurable) H.265/H.264
HP/MP/BP, M-JPEG; Audio: G. 7 1 1 μ-low/a-low Codec
Resolution:Streaming 1: 1920x1080, 1280x1024, 1280x960, 1280x720.
Streaming 2: 1280x720, 800x600, 704x576, 704x480, 640x480, 352x240,
320x240, 320x176.
Streaming 3: 352x240, 320x240., 320x176
Frame Rate: 30 fps for all resolution @ H.265/H.264/M-JPEG Mode; Frame rate can be
adjustable by user.
Streaming: Multi-Stream H.265/H.264 Base/Main/High Profile and Motion JPEG video
streaming
Control: Brightness, Contrast, Saturation, Sharpness, Exposure, Motion detection, Mirror,
Corridor mode, Shutter, Privacy mask, Flicker less, 3D Noise reduction, Defog, IRIS, AES,
AWB, AGC, BLC, WDR, ROI, Audio gain, Alarm in/out. Video recording by scheduling,
Network and NVR failed. Interval Snapshot schedule recording, CPU usage display.
Color: 0.0 1ux 1/F1.2; B/W: 0.001 Lux.; 0Lux (IR LED on) .
WDR: 120dB True WDR
Audio Setting
μ-Low/ a-Low G. 7 1 1 audio encoding and decoding;
2-way audio; External Microphone input; Speaker output.
2Vp-p audio input and audio output with 600Ωimpedance.
Network

15
Protocol: HTTP, HTTPS, SSL, TCP/ IP, IPv4, IPv6, PPPoE, UDP, SMTP, FTP, QoS, DHCP,
DDNS, NTP, DNS, SNMP, RTSP, RTP/RTCP, Bonjour, UPnP, IGMP, 802.1X
Interface: 10BASE-T/100 BASE-TX.
Compatible: Onvif compliant
Security
Password Protection, User access log; IP address filtering
Multi-level user access with password protection.
I/O Port
Standard: Audio in x1; Audio out x1; DC power in, RJ-45.
Option: Alarm out; Sensor in x1; Video out, Reset, SD Card.
Surge Protector
Power: 2KV @ 1.2/50μS Common mode.
Signal: 6KV@ 102/700μS Differential mode.
Lens & IR Illuminators
Lens: f=3.0〜10.5mm/ F1.2〜F2.8 (DM-2MIPH04-F0311 & DM-2MIPH04-F0311-F )
Lens: f=2.7〜12mm/ F1.2〜F3.7 (DM-2MIPH04-F0312 & DM-2MIPH04-F0312-F )
Motorized Lens:
f=3.3〜10.5mm/ F1.2〜F2.8 (DM-2MIPH04-M0311 & DM-2MIPH04-M0311-F ).
f=2.8〜12mm/ F1.2〜F3.7 (DM-2MIPH04-M0312 & DM-2MIPH04-M0312-F )
IR Cut: Built on removable IR-cut filter for day & night function.
IR Illuminators: 4 pieces VSEL IR LED Illuminators.
Storage
Micro SD slot for SD/SDHC card storage; Support Pre-recording and Post recording; Network
failed start recording on SD card, SD card failed indicator.
Backup/Restore to device configuration file to FTP/SMTP sever.
Management
Time management: Manual Time Setting; Time Server, NTP support and Real Time Clock.
Event management: Events triggered by Motion detection or sensor with configured
schedule.

16
Event notification: Event notification using Alarm output triggered.
Update: On line Firmware updates.
Browse
I.E. 7.0 above; Safari Browser. Firefox and Chrome V3.0 above with plug in.
Housing
Aluminum housing with IP 66 Waterproof & IK10 Vandal resistant and 3-Axis bracket design.
Dimension/Weight
Ø 138mm x 100 mm (H) / 0.75Kg.
Operation
Power: Maximum 3 W & 8W(IR LED On); PoE IEEE 802.3af Class 3
Temperature: Temperature -10°C ~ 50°C; Humidity 20% ~ 80% RH.
DM-3MIPS04 Series
System
Platform: TI DM368 SoC CPU; Linux Embedded O.S.
Image Device
1/2.8" 3 M pixels (2048x 1536 pixels) progressive CMOS sensor.
Video Setting
Compression: Video:0.1M ~ 12M bits/sec (CBR/VBR configurable) H.265/H.264
HP/MP/BP, M-JPEG; Audio: G. 7 1 1 μ-low/a-low Codec
Resolution:Streaming 1: 2048x1536,1920x1080, 1280x720.
Streaming 2: 1280x720, 800x600, 704x576, 704x480, 640x480, 352x240,
320x240, 320x176.
Streaming 3: 352x240, 320x240., 320x176.
Frame Rate: 30 fps for all resolution @ H.265/H.264/M-JPEG Mode; Frame rate can be
adjustable by user.
Streaming: Multi-Stream H.265/H.264 Base/Main/High Profile and Motion JPEG video
streaming

17
Control: Brightness, Contrast, Saturation, Sharpness, Exposure, Motion detection, Mirror,
Corridor mode, Shutter, Privacy mask, Flicker less, 3D Noise reduction, Defog, IRIS, AES,
AWB, AGC, BLC, WDR, ROI, Audio gain, Alarm in/out. Video recording by scheduling,
Network and NVR failed. Interval Snapshot schedule recording, CPU usage display.
Color: 0.0 5ux 1/F1.2; B/W: 0.001 Lux.; 0Lux (IR LED on) .
WDR: 120dB True WDR
Audio Setting
μ-Low/ a-Low G. 7 1 1 audio encoding and decoding;
2-way audio; External Microphone input; Speaker output.
2Vp-p audio input and audio output with 600Ωimpedance.
Network
Protocol: HTTP, HTTPS, SSL, TCP/ IP, IPv4, IPv6, PPPoE, UDP, SMTP, FTP, QoS, DHCP,
DDNS, NTP, DNS, SNMP, RTSP, RTP/RTCP, Bonjour, UPnP, IGMP, 802.1X
Interface: 10BASE-T/100 BASE-TX.
Compatible: Onvif compliant
Security
Password Protection, User access log; IP address filtering
Multi-level user access with password protection.
I/O Port
Standard: Audio in x1; Audio out x1; DC power in, RJ-45.
Option: Alarm out; Sensor in x1; Video out, Reset, SD Card.
Surge Protector
Power: 2KV @ 1.2/50μS Common mode.
Signal: 6KV@ 102/700μS Differential mode.
Lens & IR Illuminators
Lens: f=3.0〜10.5mm/ F1.2〜F2.8 (DM-3MIPS04-F0311 & DM-3MIPS04-F0311-F )
Lens: f=2.8〜12mm/ F1.2〜F3.7 (DM-3MIPS04-F0312 & DM-3MIPS04-F0312-F )
Motorized Lens:
f=3.3〜10.5mm/ F1.2〜F2.8 (DM-3MIPS04-M0311 & DM-3MIPS04-M0311-F ).

18
f=2.8〜12mm/ F1.2〜F3.7 (DM-3MIPS04-M0312 & DM-3MIPS04-M0312-F )
IR Cut: Built on removable IR-cut filter for day & night function.
IR Illuminators: 4 pieces VSEL IR LED Illuminators.
Storage
Micro SD slot for SD/SDHC card storage; Support Pre-recording and Post recording; Network
failed start recording on SD card, SD card failed indicator.
Backup/Restore to device configuration file to FTP/SMTP sever.
Management
Time management: Manual Time Setting; Time Server, NTP support and Real Time Clock.
Event management: Events triggered by Motion detection or sensor with configured
schedule.
Event notification: Event notification using Alarm output triggered.
Update: On line Firmware updates.
Browse
I.E. 7.0 above; Safari Browser. Firefox and Chrome V3.0 above with plug in.
Housing
Aluminum housing with IP 66 Waterproof & IK10 Vandal resistant and 3-Axis bracket design.
Dimension/Weight
Ø 138mm x 100 mm (H) / 0.75Kg.
Operation
Power: Maximum 3 W & 8W(IR LED On); PoE IEEE 802.3af Class 3
Temperature: Temperature -10°C ~ 50°C; Humidity 20% ~ 80% RH.

19
1-3.Packaging Contents
Please check the contents of your new Network IP Camera when you unpack the package. If any
item is missing, please contact your dealer of purchase for help. The package includes the
following items:
Network IP Camera x 1ea
Bundle NVR & CMS software CD x 1ea
User manual x 1ea
Cable cover x 1 ea
Accessory package x 1 set.
1-4. Product Dimension
Anchor 7x27 *
4 ea
Screw 4 x27 Tp1
Bnd Sus *4 ea
Hexagon wrench 3.0mm L type * 1 ea
Mount hole sticker * 1ea
R
J-45 Female- Female Converter * 1ea
LAN Jumper * 1ea (Optional)

20
1-5. Product Parts Description
A:Video out Port ( Option）, B: Alarm
InpuOutput (Option)，
A: RJ45 LAN port B: SD card slot
IR Sensor
IR LED
Lens
A+: Alarm out A-: Alarm out
AI: Alarm in C: Alarm in
A/B: Audio in/out AG: Audio ground
V+: DC12V(+) V -: DC12V(+)
