Ibanez IBZ10A User manual

ITEM NUMBER REMARK Q'TY
3200186 AA 01 POWER IC TDA2040A IC3 1
3200002 AA 01 OP AMP IC NJM 4558D IC1,2 2
3200188 AA 01 IC LM358 IC4 1
3200189 AA 01 IC MN3207 IC5 1
3200190 AA 01 IC MN3102 IC6 1
3200191 AA 01 IC KIA78LS05 BP IC7 1
3200004 AA 01 TRANSISTOR KTC3198GR Q1,2,3 3
3200003 AA 01 TRANSISTOR KTC1027-Y Q4 1
3200194 AA 01 TRANSISTOR KTA1023-Y Q5 1
3200009 AA 01 RECTIFIER DIODE 1N4004 D1,2,9,10,11,12 6
3200010 AA 01 SWITCHING DIODE 1N4148 D3,4,5,6,7,8 6
3200011 AA 01 ZENER DIODE 15V/0.5W(IN965B) D13,14 2
3200198 AA 01 LED KLR124 LED15 1
3200199 AA 01 VOLUME POT VS16P1100C15B5K VR4 1
3200200 AA 01 VOLUME POT VS16P1100C15B10K VR1 1
3200017 AA 01 VOLUME POT VS16P1100C15A50K VR5 1
3200119 AA 01 VOLUME POT VS16P1100 A100K VR2,3 2
3200013 AA 01 PHONE JACK W201M J1 1
3200014 AA 01 PHONE JACK W201S J2 1
3200015 AA 01 PUSH SWITCH JPS2251 SW1 1
3200055 AA 01 POWER SWITCH JRS-1102A 1
3200123 AA 01 C.F. RESISTOR 1 OHM 1/4W R14 1
3200025 AA 01 C.F. RESISTOR 220 OHM 1/4W R7 1
3200026 AA 01 C.F. RESISTOR 1 KOHM 1/4W R13 1
3200027 AA 01 C.F. RESISTOR 2.2 KOHM 1/4W R44,48 2
3200211 AA 01 C.F. RESISTOR 2.4 KOHM 1/4W R31 1
3200028 AA 01 C.F. RESISTOR 2.7 KOHM 1/4W R33,35 2
3200029 AA 01 C.F. RESISTOR 3.3 KOHM 1/4W R25 1
3200031 AA 01 C.F. RESISTOR 4.7 KOHM 1/4W R6,24,38,46,47 5
3200033 AA 01 C.F. RESISTOR 10 KOHM 1/4W R11,21,22,32 4
3200216 AA 01 C.F. RESISTOR 12 KOHM 1/4W R10 1
3200217 AA 01 CABINET ASS'Y PB 15T IBZ10A 1
3200218 AA 01 MAIN CHASSIS EGI1.0T 1
3200219 AA 01 FRONT PANEL PVC0.5T 1
3200220 AA 01 CAUTION LABEL IBZ10A 1
3200221 AA 01 CORNER IBZ10A 8
3200085 AA 01 FOOT ASS'Y TB25 4
3200223 AA 01 HANDLE ASS'Y SW25DX 1
3200224 AA 01 CONTROL KNOB LIGHT BROWN 5
3200089 AA 01 HEAT SINK AL 2.5T 1
3200226 AA 01 LOGO (SPAGHETTI) 1
3200227 AA 01 INSTRUCTION MANUAL IBZ10A 1
3200093 AA 01 STAR WASHER DIA4 CHASSIS GND 1
3200094 AA 01 GND LABEL 1
3200230 AA 01 SPEAKER LABEL 1
3200096 AA 01 INNER CARTON DW1 IBZ10 1
3200097 AA 01 INNER CARTON DW1 IBZ3 1
3200098 AA 01 OUT CARTON DW1 IBZ10 1
3200099 AA 01 OUT CARTON DW1 IBZ3 1
3200100 AA 01 PAD DW1 2
3200236 AA 01 SCREW1 TAPPING DIA4X10L,BH,BK CHASSIS GND:1,TRANSFORMER:2 3
3200102 AA 01 SCREW2 TAPPING DIA3X10 W/WASHER HEAT SINK+CHASSIS:2,PCB+HEAT SINK:2 4
3200103 AA 01 SCREW3 MACHING M3X10L,BH TR+HEAT SINK 2
3200104 AA 01 SCREW4 TAPPING DIA3.5X10,TH,BK CORNER 16
3200240 AA 01 SCREW5 TIPPING1WW DIA4X25,W/WASHER CHASSIS 4
3200106 AA 01 SCREW6 MACHING M4X25,OV BK HANDLE 2
3200107 AA 01 SCREW7 TAPPING DIA2.6X10,OV,BK LOGO 2
3200108 AA 01 SCREW8 TAPPING DIA3.5X30,TH,BK BAFFLE 4
DESCRIPTION
IBZ10A(IBZ3A) PARTS LIST

IBZ10A(IBZ3A) PARTS LIST
3200109 AA 01 SCREW9 TAPPING DIA3.5X25,TH,BK BACK COVER 5
3200056 AA 01 SLIP ON RECEP. GP881191-2 SEMKO 2
3200057 AA 01 CONNECTOR(W) LW1143-03 1
3200064 AA 01 HEATING TUBE DIA4 20MM 3
3200065 AA 01 HEATING TUBE DIA6 20MM 2
3200249 AA 01 LOCKING PAINT 1401B 3
3200147 AA 01 SPEAKER PSR-010B 1
3200251 AA 01 FUSE 61NM 250V 0.5A UL/CSA, JIS 1
3200252 AA 01 FUSE FC-6C 230/240V 2
3200253 AA 01 FUSE HOLDER CLIP PT1 : AC100/120V 1
3200066 AA 01 POWER TRANSFRMER 048032AC AC100V/120V 1
3200067 AA 01 POWER TRANSFRMER 048033YZ AC230V/240V 1
3200068 AA 01 STRAIN RELIEF SR4N-4 1
3200069 AA 01 STRAIN RELIEF SR6N-4 1
3200077 AA 01 AC CORD JAPAN KKP-211(S/T) 7FT JAPAN 1
3200070 AA 01 AC CORD USA/CAN SVT-125V 10A UL/CSA 0
3200260 AA 01 AC CORD VDE H05VV-F3G VDE 0
3200072 AA 01 AC CORD SEMKO KOCE-3 SEMKO 0
3200073 AA 01 AC CORD SAA KLSA-3 SAA 0
3200074 AA 01 AC CORD ITALY H03VV-F ITALY 0
3200264 AA 01 AC CORD UK GS302,H05VV-F/3G ENGLAND 0
3200075 AA 01 AC CORD SWISS H05VV-F SWISS 0
3200266 AA 01 PCB ASSY IBZ10A 1
