ITEM NUMBER REMARK Q'TY
32S00231 B5 01 PCB ASSY IBZ10A 1
32S00129 B5 01 CF RESISTOR 1 RCF01R003JUH 1
32S00005 B5 01 CF RESISTOR 220 RCF022103JUH 1
32S00006 B5 01 CF RESISTOR 1K RCF010203JUH 1
32S00007 B5 01 CF RESISTOR 2.2K RCF022203JUH 2
32S00236 B5 01 CF RESISTOR 2.4K RCF024203JUH 1
32S00008 B5 01 CF RESISTOR 2.7K RCF027203JUH 2
32S00009 B5 01 CF RESISTOR 3.3K RCF033203JUH 1
32S00011 B5 01 CF RESISTOR 4.7K RCF047203JUH 5
32S00013 B5 01 CF RESISTOR 10K RCF010303JUH 3
32S00241 B5 01 CF RESISTOR 10K RCF010303JUA 1
32S00242 B5 01 CF RESISTOR 12K RCF012303JUH 1
32S00136 B5 01 CF RESISTOR 18K RCF018303JUH 2
32S00014 B5 01 CF RESISTOR 22K RCF022303JUH 4
32S00016 B5 01 CF RESISTOR 33K RCF033303JUH 1
32S00017 B5 01 CF RESISTOR 47K RCF047303JUH 3
32S00018 B5 01 CF RESISTOR 56K RCF056303JUH 1
32S00248 B5 01 CF RESISTOR 82K RCF082303JUH 1
32S00020 B5 01 CF RESISTOR 100K RCF010403JUH 5
32S00250 B5 01 CF RESISTOR 120K RCF012403JUH 1
32S00251 B5 01 CF RESISTOR 150K RCF015403JUH 1
32S00252 B5 01 CF RESISTOR 220K RCF022403JUH 2
32S00253 B5 01 CF RESISTOR 330K RCF033403JUH 3
32S00254 B5 01 CF RESISTOR 680K RCF068403JUH 1
32S00022 B5 01 CF RESISTOR 1M RCF010503JUH 4
32S00256 B5 01 MOF RESISTOR 220 RMO022103JUH 1
32S00257 B5 01 JUMPPER 5MM JPW060XXX050 2
32S00025 B5 01 JUMPPER 7.5MM JPW060XXX075 2
32S00026 B5 01 JUMPPER 10MM JPW060XXX100 6
32S00027 B5 01 JUMPPER 15MM JPW060XXX150 2
32S00261 B5 01 JUMPPER 20MM JPW060XXX200 2
32S00029 B5 01 VOLUME POT A50K VRRE1ECPA50A VOLUME 1
32S00144 B5 01 VOLUME POT A100K VRRE1ECPAA0A HIGH,BASS 2
32S00141 B5 01 VOLUME POT B5K VRRE1ECPB05A MIDDLE 1
32S00265 B5 01 VOLUME POT B10K VRRE1ECPB10A DEPTH 1
32S00032 B5 01 EL CAP 1UF CAE105FMLRBC 3
32S00267 B5 01 EL CAP 2.2UF CAE225FMLRBC 1
32S00033 B5 01 EL CAP 10UF CAE106DMLRBC 9
32S00269 B5 01 EL CAP 100UF CAE107CMLRCC 1
32S00037 B5 01 EL CAP 2200UF CAE228DMLRGK 2
32S00150 B5 01 POLY CAP 0.001UF CPF102D10KGR 3
32S00151 B5 01 POLY CAP 0.01UF CPF103D10KGR 1
32S00039 B5 01 POLY CAP 0.047UF CPF473D10KGR 1
32S00274 B5 01 POLY CAP 0.056UF CPF563D10KGR 1
32S00041 B5 01 POLY CAP 0.1UF CPF104D10KGR 4
32S00153 B5 01 POLY CAP 0.22UF CPF224D10KGR 3
32S00277 B5 01 CERAMIC CAP 20P CCR200D05KNC 1
32S00278 B5 01 CERAMIC CAP 47PF CCR470D05KSC 1
32S00042 B5 01 CERAMIC CAP 100P CCR101D05KSC 1
32S00280 B5 01 CERAMIC CAP 220P CCR221D05KSC 1
32S00281 B5 01 CERAMIC CAP 470P CCR471D05KEC 1
32S00044 B5 01 DIODE 1N4148 DID1N4148DHB 6
32S00045 B5 01 DIODE 1N4004 DID1N4004RHB 6
32S00284 B5 01 ZENNER DIODE 15V DZN15005H100 2
32S00055 B5 01 LED DIA5 LEDC050HDANA 1
32S00048 B5 01 TRANSISTOR TST2SC1815GS 2SC1815GR 3
32S00049 B5 01 TRANSISTOR TST2SC1384RS 2SC1384R 1
32S00288 B5 01 TRANSISTOR TST2SA684XRS 2SA684R 1
32S00053 B5 01 IC NJM4558DD IGCN4558DDAO 2
32S00290 B5 01 IC HA17358 IGCHA17358AO 1
32S00291 B5 01 IC BL3102 IGCBL3102XAE 1
32S00292 B5 01 IC BL3207 IGCBL3207XAE 1
32S00160 B5 01 IC TDA2030V IGCTDA2030BP POWER AMP 1
32S00294 B5 01 IC 78L05 IGC78L05XXBR REGULATOR 1
32S00059 B5 01 PUSH SWITCH LOCK SWP2PS01NL03 2P2T 1
32S00058 B5 01 3.96CONNECTOR WAF4Y03SHH01 1
32S00056 B5 01 DIA6.3 JACK MONO JKP6R3MOLA4N JK1,INPUT JACK 1
32S00057 B5 01 DIA6.3 JACK STRO JKP6R3STDA6O JK2 PHONE JACK 1
32S00060 B5 01 HEATSINK HSK-33 HSKP74294233 1
32S00063 B5 01 MICA SHEET TO220 SPTMGATO220X 1
32S00064 B5 01 TR INSLT PLATE PPTTWH203530 1
DESCRIPTION
IBZ10A PARTS LIST

IBZ10A PARTS LIST
32S00302 B5 01 205 CONNECT WIRE HSN30XX2802A 1
32S00062 B5 01 205 CONNECT WIRE HSN20XX2800A 1
32S00065 B5 01 SCREW NI M3 P0.5 MSRR30XR510N 2
32S00066 B5 01 SCREW M3 P0.5L10 MSRR30XR510B 1
32S00067 B5 01 NUT M3 P0.5 NUTM30XPR5HS 3
32S00068 B5 01 TOOTH WASHER D3 WSRO0632R5WS 3
32S00308 B5 01 CHASSIS IBZ10A STCIBZ-10AZC IBZ-10A-2 1
32S00309 B5 01 TRANS120V IBZ10A TRMGEW105XX GEW-105 120V 50 1
32S00310 B5 01 TRANS230V IBZ10A TRMGEW105XX GEW-105 230V 50 1
32S00072 B5 01 POWER SWITCH SWRNNBB2NQ1A 1
32S00073 B5 01 CERAMIC CAP0.01U CCR103A40ZYS 1
32S00074 B5 01 AC SOCKET ACS3QKPUM102 1
32S00075 B5 01 POWER CABLE TIE PPTSRBFTL7K8 1
32S00315 B5 01 KNOB RKN-20 RKNLBDY18R20 LIGHT BROWN 5
32S00077 B5 01 PUSH KNOB BK PKNS050510B4 PKN-4 FOR PUSH SWITCH 1
32S00078 B5 01 SOLDERING PLATE SPTSDPXXTP-1 TP-1 1
32S00079 B5 01 SCREW BK M4 P0.7 MSRU40XR710B 2
32S00080 B5 01 SCREW NI M4 P0.7 MSRU40XR712N 1
32S00065 B5 01 SCREW NI M3 P0.5 MSRR30XR510N 2
32S00081 B5 01 WASHER FOR VOLUME POT
32S00082 B5 01 NUT FOR VOLUME POT
32S00067 B5 01 NUT M3 P0.5 NUTM30XPR5HS 2
32S00083 B5 01 NUT M4 P0.7 NUTM40XPR7HS 4
32S00084 B5 01 TOOTH WASHER D4 WSRO0844R5WS 4
32S00068 B5 01 TOOTH WASHER D3 WSRO0632R5WS 2
32S00086 B5 01 WASHER10DX4.2DX1 WSRF104210WS 1
32S00326 B5 01 CABLE TIE PPTCBTB08025 3
32S00327 B5 01 LABEL GND LABWHBKAG001 1
32S00089 B5 01 HEATSINK TUBE40M PPTHST251240 1
32S00090 B5 01 HEATSINK TUBE15M PPTHST040215 1
32S00091 B5 01 187 CONNECT WIRE HSN17XX1402A 1
32S00092 B5 01 187 CONNECT WIRE HSN17XX060DA 1
32S00093 B5 01 FUSE 0.25A/250V FUS520NSVR25 230V/240V 2
32S00094 B5 01 FUSE T0.5A/250V FUS520NFVR50 100V/120V
32S00095 B5 01 SPEC LABEL LABWHORBF001 ORANGE 2
32S00335 B5 01 CABINET IBZ10A BOXIBZ-10771 1
32S00336 B5 01 SPEAKER IBZ10A SPKIBZ-10A01 1
32S00337 B5 01 CORNER SCN-15 SCNSTZNI1015 NI 8
32S00099 B5 01 STRAP HANDLE HDP190P23603 HDP-3 1
32S00339 B5 01 HANDLE CLAMP HDCSTEKNIK04 NI/HDC-4 2
32S00101 B5 01 RUBBER FOOT PPTRFT112001 RUB-1 4
32S00102 B5 01 POWER CODE UL PWCA--DBSVT3A PWC-AB,120V 1
32S00342 B5 01 POWER CODE JP GA-1040RC-5 PWC-AB
32S00104 B5 01 POWER CODE EU PWCE-DBH5V3A PWC-AB 1
32S00344 B5 01 POWER CODE ITALY GA-1040RC-5 PWC-AB
32S00345 B5 01 POWER CODE UK GA-1040RC-5 PWC-AB 1
32S00346 B5 01 POWER CODE SWISS GA-1040RC-5 PWC-AB
32S00347 B5 01 LOGO PLATE PLGIVXXIBN0B IBANEZ SPAGHETTI 1
32S00109 B5 01 SCREW BK M4 P0.7 MSRU40XR715B L15 4
32S00110 B5 01 SCREW BK M4 P0.7 MSRS40XR725B L25 6
32S00350 B5 01 TAPPING SCREW TSRS35X10WDN NI3.5×10 16
32S00113 B5 01 TAPPING SCREW TSRS35X20WDB BK3.5×20 2
32S00114 B5 01 TAPPING SCREW TSRS35X28WDB BK3.5×28 2
32S00115 B5 01 TAPPING SCREW TSRS40X18WDB BK4×18 4
32S00116 B5 01 PLASTIC WASHER WSRP174530BP PWH-1 4
32S00355 B5 01 U SHAPE WASHER WSRT1239R3RB DIA12 2
32S00356 B5 01 MANUAL IBZ10A ISTIBNIB10AA 1
32S00118 B5 01 WARRANTY CARD JP GRTIBZIBZ10A 1
32S00358 B5 01 LABEL FOR WARNTY LABWHBKBD029 CARD IBZ10A 2
32S00359 B5 01 BAR CODE LABEL LABWHBKBC0## IBZ10A JAN 2
32S00360 B5 01 BAR CODE LABEL LABWHBKBC0## IBZ10A UPC 2
32S00361 B5 01 SERIAL NO. LABEL LABSVBKBA002 IBZ 4
32S00123 B5 01 POLYBAG IBZ10 PEB305178533 1
32S00363 B5 01 INDIVIDUAL BOX CTNIB10AIB01 B/W CARTON,FOR "J" ONLY 1
32S00364 B5 01 SHIP BOX IBZ10A CTNIB10AIB02 1/3
32S00365 B5 01 COLOR BOX IBZ10A CCTIB10AIB01 EXCEPT FOR "J" 1
32S00229 B5 01 JP INSTRUCTION ISTIBZGENERA MANUAL IBZ10 1
