IBASE Technology IB530F Series User manual

IB530F/IB530 Series
AMD Geode LX
3.5-inch Disk Size SBC
USER’S MANUAL
Version 1.0A

ii IB530F User’s Manual
Acknowledgments
Award is a registered trademark of Award Software International, Inc.
PS/2 is a trademark of International Business Machines Corporation.
AMD, AMD Geode, and combinations thereof, are trademarks of
Advanced Micro Devices, Inc.
Microsoft Windows is a registered trademark of Microsoft Corporation.
All other product names or trademarks are properties of their respective
owners.

IB530F User’s Manual iii
Table of Contents
Introduction.......................................................1
Product Description.............................................................1
Checklist..............................................................................2
Specifications......................................................................3
Board Dimensions...............................................................4
Installations.......................................................5
Installing the Memory.........................................................6
Setting the Jumpers .............................................................7
Connectors on IB530F ......................................................10
BIOS Setup.......................................................19
Drivers Installation......................................35
Entertainment Encryption/Decryption Controller Driver..36
VGA Drivers Installation ..................................................38
Audio Driver Installation ..................................................41
PCI Bridge Driver Installation ..........................................44
Appendix...........................................................47
A. I/O Port Address Map...................................................47
B. Interrupt Request Lines (IRQ)......................................48
C. Watchdog Timer Configuration....................................49

iv IB530F User’s Manual
This page is intentionally left blank.

INTRODUCTION
IB530F User’s Manual 1
Introduction
Product Description
The IB530F 3.5-inch disk size SBC incorporates the AMD Geode LX
processor with speeds of 433MHz (LX700), 500MHz (LX800) or
600MHz (LX900). It comes with one DDR SO-DIMM socket that has a
capacity of 1GB system memory. The board supports two 10/100Mbps
Ethernet, using Realtek RTL8100C controllers. A 2D graphics
controller comes integrated on the board that supports CRT and TFT
LCD displays. Useful interface includes four USB 2.0 ports, 4 COM
ports, and one PC-104 expansion slot (Non-DMA ISA ONLY, PCI not
supported). Other expansion options are available with the Compact
Flash socket.
IB530F FEATURES:
-Embedded AMD Geode LX processor, 433MHz (LX700) /
500MHz (LX800), 600MHz (LX900).
-DDR SO-DIMM x 1, Max. 1GB
-Realtek RTL8100C 10/100Mbps Ethernet x2
-Integrated LX800/LX700 2D VGA controller, supports CRT
and TFT LCD display
-4 x USB 2.0, 4 x COM, CF socket, Watchdog timer, Digital I/O
-PC-104 expansion (Non-DMA ISA only, PCI not supported)
-Dimensions: 145mm x 102mm (5.7” x 4”)

INTRODUCTION
2 IB530F User’s Manual
Checklist
Your IB530F package should include the items listed below.
•The IB530F AMD Geode LX 3.5-inch Disk Size SBC
•This User’s Manual
•1 CD containing chipset drivers and flash memory utility
•Heatsink for AMD Geode LX processor
•Options:
•cable kit (IDE, COM, PS/2, LPT, USB, Audio, Power cable)

INTRODUCTION
IB530F User’s Manual 3
Specifications
[
CPU AMD Geode LX CPU, 481-ball BGA
CPU Internal
Speed LX800 @500MHz
LX700 @433MHz
LX900@600MHz
Power
Management APM
BIOS Award BIOS
Chipset AMD CS5536 I/O companion multi-function south bridge
Memory One DDR SO-DIMM socket, Max. up to 1GB
Graphic LX900/LX800/LX700 built-in high performance 2D graphic
controller, supports TFT, LVDS LCD & CRT display
LVDS 18-bit single channel LVDS
Ethernet 2x Realtek RTL8100C-LF 10/100Mbps Ethernet chip
IDE CS5536 built-in one channel UDMA100 IDE
- 44-pin header x1
- Compact Flash (type II) connector x1
Audio Realtek ALC203 AC97 audio codec, supports 2-CH Line-Out,
Line-In & MIC
USB CS5536 built-in USB2.0 controller, support 4 ports
LPC I/O Winbond W83627HF: KB/Mouse controller, Parallel, IrDA,
Floppy, COM1, COM2 (RS232) & Hardware monitor (3 thermal
inputs, 4 voltage monitor inputs, VID0-4 & 2 Fan Headers)
Secondary I/O Fintek 81216 for COM3/COM4
PCI Arbiter IT8209R PCI arbiter/clock buffer, extend PCI devices (master)
from 1 to 3
RTC CS5536 built-in, with on board Lithium battery
Edge Connectors DB-9 connector x1 for COM1 (RS232 only)
DB-15 connector x1 for CRT
RJ-45 connector x2 for LAN
Onboard Headers 6-pin header x1 for PS/2 KB/Mouse (Y cable)
DF13-20 header x1 for LVDS channel
Compact Flash Socket x1 for CF card
10-pin header x1 for COM1 (RS232 only)
30-pin header x1 for COM2/3/4
8-pin header for USB0, 1
8-pin header x1 for USB2, 3
26-pin header x1 for LPT port
44-pin header x1 for IDE
26-pin header x1 for FDD
12-pin header x1 for Audio
4-pin header x1 for IrDA
10-pin header x1 for Digital I/O
44-pin header x1 for TFT LCD panel
Expansion Slot PC-104 w/ 4 mounting holes(Non DMA ISA ONLY,Not support PCI)
Digital I/O Supports 4 In / 4 Out
Power +12V DC-in
Watchdog Timer Software programmable, supports 1~255 sec. system reset
RoHS Compliant Yes
Board Size 145 x 102mm

INTRODUCTION
Board Dimensions
4 IB530F User’s Manual

INSTALLATIONS
IB530F User’s Manual 5
Installations
This section provides information on how to use the jumpers and
connectors on the IB530F in order to set up a workable system. The
topics covered are:
Installing the Memory.................................................................. 6
Setting the Jumpers...................................................................... 7
Connectors on IB530F............................................................... 10

INSTALLATIONS
Installing the Memory
The IB530F board supports one SODIMM DDR memory socket for a
maximum total memory. The memory module capacities supported are
128MB, 256MB, 512MB and 1GB.
Installing and Removing Memory Modules
To install the DDR modules, locate the memory slot on the board and
perform the following steps:
1. Hold the DDR module so that the keys of the DDR module align with
those on the memory slot. Insert the module into the socket at a slight
angle (approximately 30 degrees). Note that the socket and module
are both keyed, which means that the module can be installed only in
one direction.
2. To seat the memory module into the socket, apply firm and even
pressure to each end of the module until you feel it slip down into the
socket.
3. With the module properly seated in the socket, rotate the module
downward. Continue pressing downward until the clips at each end
lock into position.
4. To remove the DDR module, press the clips with both hands.
6 IB530F User’s Manual

INSTALLATIONS
IB530F User’s Manual 7
Setting the Jumpers
Jumpers are used on IB530F to select various settings and features
according to your needs and applications. Contact your supplier if you
have doubts about the best configuration for your needs. The following
lists the connectors on IB530F and their respective functions.
Jumper Locations on IB530F......................................................... 8
JP1: Clear CMOS Setting............................................................... 9
JP2: LVDS VDD Select (5V / 3.3V).............................................. 9
JP3: HDD LED Pin Header............................................................ 9
JP4: CF Connector master/Slave Setting........................................ 9
JP5, JP6: COM3,4 RS232 +5V/+12V Power Setting..................... 9

INSTALLATIONS
Jumper Locations on IB530F
Jumpers on IB530F...............................................................................Page
Jumper Locations on IB530F......................................................................8
JP1: Clear CMOS Setting...........................................................................9
JP2: LVDS VDD Select (5V / 3.3V) ..........................................................9
JP3: HDD LED Pin Header........................................................................9
JP4: CF Connector master/Slave Setting....................................................9
JP5, JP6: COM3,4 RS232 +5V/+12V Power Setting .................................9
8 IB530F User’s Manual

INSTALLATIONS
JP1: Clear CMOS Setting
Use JP1 to clear the CMOS contents. Note that the power connector
should be disconnected from the board before clearing CMOS.
JP1 Function
Normal (default)
Clear CMOS
JP2: LVDS VDD Select (5V / 3.3V)
JP2 VDD Setting
3.3V
5V
JP3: HDD LED Pin Header
Pin # Signal Name
1 VCC
2 HDD_LED-
JP4: CF Connector master/Slave Setting
JP4 Setting Function
Short/Closed Master
Open Slave
JP5, JP6: COM3,4 RS232 +5V/+12V Power Setting
JP5, JP6 Setting Function
Pin 1-2
Short/Closed +12V
Pin 3-4
Short/Closed Normal
Pin 5-6
Short/Closed +5V
IB530F User’s Manual 9

INSTALLATIONS
10 IB530F User’s Manual
Connectors on IB530F
The connectors on IB530F allows you to connect external devices such
as keyboard, floppy disk drives, hard disk drives, printers, etc. The
following table lists the connectors on IB530F and their respective
functions.
Connector Locations on IB530F...................................................11
CN1, CN2: RJ45 Connector.........................................................12
CN3: VGA CRT Connector..........................................................12
CN4: Compact Flash Card Socket................................................12
CN5: FDD Connector...................................................................12
CN6, J13: Serial port ....................................................................13
CN6 is the D-sub type COM1 serial port connector.....................13
CN7: PC-104 Connector...............................................................14
J2: Reset Switch............................................................................15
J4: External Audio Connector ......................................................15
J5: TFT Panel Connector..............................................................15
J6: LVDS Connectors...................................................................16
J7: IrDA Connector ......................................................................17
J9, J15: USB Connectors..............................................................17
J10: PS/2 Keyboard and Mouse Connector..................................17
J11: Parallel Port Connector.........................................................17
J14: Power DC-In.........................................................................18
J16: Digital 4-in 4-out Connector.................................................18
IDE1: IDE Connector...................................................................18
SODIMM1: SO DIMM Socket ....................................................18

INSTALLATIONS
Connector Locations on IB530F
Connectors on IB530F...............................................................Page
CN1, CN2: RJ45 Connector...................................................................................... 12
CN3: VGA CRT Connector...................................................................................... 12
CN4: Compact Flash Card Socket ............................................................................ 12
CN5: FDD Connector ............................................................................................... 12
CN6, J13: Serial Ports............................................................................................... 13
CN7: PC-104 Connector (Non DMA ISA ONLY,Not Support PCI) ...................... 14
J2: Reset Switch ........................................................................................................ 15
J4: External Audio Connector................................................................................... 15
J5: TFT Panel Connector .......................................................................................... 15
J6: LVDS Connectors ............................................................................................... 16
J7: IrDA Connector................................................................................................... 17
J9, J15: USB Connectors .......................................................................................... 17
J10: PS/2 Keyboard and Mouse Connector.............................................................. 17
J11: Parallel Port Connector ..................................................................................... 17
J14: Power DC-In...................................................................................................... 18
J16: Digital 4-in 4-out Connector ............................................................................. 18
IDE1: IDE Connector................................................................................................ 18
SODIMM1: SO DIMM Socket................................................................................. 18
IB530F User’s Manual 11

INSTALLATIONS
CN1, CN2: RJ45 Connector
Pin # Signal Name
1 TD+
2 TD-
3 RD+
4 RJ45-4A
5 RJ45-5A
6 RD-
7 RJ45-7A
8 RJ45-8A
CN3: VGA CRT Connector
[
Signal Name Pin Pin Signal Name
Red 1 2 Green
Blue 3 4 NC
GND 5 6 GND
GND 7 8 GND
Vcc 9 10 GND
N.C. 11 12 DDCDA
HSYNC 13 14 VSYNC
DDCCLK 15
CN4: Compact Flash Card Socket
CN5: FDD Connector
Signal Name Pin # Pin # Signal Name
VCC 1 2 INDEX
VCC 3 4 DRV_SEL
VCC 5 6 DSK_CH
NC 7 8 NC
NC 9 10 MOTOR
DINST 11 12 DIR
NC 13 14 STEP
GND 15 16 WDATA
GND 17 18 WGATE
GND 19 20 TRACK
NC 21 22 WPROT
GND 23 24 RDATA
GND 25 26 SIDE
12 IB530F User’s Manual

INSTALLATIONS
CN6, J13: Serial port
CN6 is the D-sub type COM1 serial port connector
Pin # Signal Name (RS-232)
1 DCD, Data carrier detect
2 RXD, Receive data
3 TXD, Transmit data
4 DTR, Data terminal ready
5 Ground
6 DSR, Data set ready
7 RTS, Request to send
8 CTS, Clear to send
9 RI, Ring indicator
J13 (COM2/3/4) is a 30-pin header type COM2/3/4 serial port (RS232)
connector.
Signal Name Pin # Pin # Signal Name
DCD2 1 2 DSR2
SIN2 3 4 RTS2
SO2 5 6 CTS2
DTR2- 7 8 RI2
GND 9 10 N/A
DCD3 11 12 DSR3
SIN3 13 14 RTS3
SOUT3 15 16 CTS3
DTR3 17 18 RI3-
GND 19 20 N/A
DCD4 21 22 DSR4
SIN4 23 24 RTS4
SOUT4 25 26 CTS4
DTR4 27 28 RI4
GND 29 30 Protect pin
IB530F User’s Manual 13

INSTALLATIONS
CN7: PC-104 Connector
The PC-104 connector* is a dual-in-line pin headers that support
PC-104 ISA modules, with 64 pins and 40 pins in each line. The
following table shows the their pin assignments. *(Non-DMA ISA
ONLY)
CON1 CON2
Pin Signal Name Pin Signal Name Pin Signal Name Pin Signal Name
A1 IOCHK B1 GND C1 GND D1 GND
A2 D7 B2 REST C2 SBHE D2 MEMCS16
A3 D6 B3 VCC C3 LA23 D3 IOCS16
A4 D5 B4 IRQ9 C4 LA22 D4 IRQ10
A5 D4 B5 -5V C5 LA21 D5 IRQ11
A6 D3 B6 DRQ2 C6 LA20 D6 IRQ12
A7 D2 B7 -12V C7 LA19 D7 IRQ15
A8 D1 B8 OWS C8 LA18 D8 IRQ14
A9 D0 B9 +12V C9 LA17 D9 DACK0
A10 IOCHRDY B10 Key C10 MEMR D10 DRQ0
A11 AEN B11 SMEMW C11 MEMW D11 DACK5
A12 A19 B12 SMEMR C12 D8 D12 DRQ5
A13 A18 B13 IOW C13 D9 D13 DACK6
A14 A17 B14 IOR C14 D10 D14 DRQ6
ZA15 A16 B15 DACK3 C15 D11 D15 DACK7
A16 A15 B16 DRQ3 C16 D12 D16 DRQ7
A17 A14 B17 DACK1 C17 D13 D17 VCC
A18 A13 B18 DRQ1 C18 D14 D18 MASTER
A19 A12 B19 REFRESH C19 D15 D19 GND
A20 A11 B20 CLK C20 KEY PIN D20 GND
A21 A10 B21 IRQ7
A22 A9 B22 IRQ6
A23 A8 B23 IRQ5
A24 A7 B24 IRQ4
A25 A6 B25 IRQ3
A26 A5 B26 DACK2
A27 A4 B27 TC
A28 A3 B28 BALE
A29 A2 B29 VCC
A30 A1 B30 OSC
A31 A0 B31 GND
A32 GND B32 GND
14 IB530F User’s Manual

INSTALLATIONS
J2: Reset Switch
Pin # Signal Name
1 Reset
2 Ground
J4: External Audio Connector
J4 is a 12-pin header that is used to connect to the optional audio cable
card that integrates jacks for Line In, Line Out and Mic.
Signal Name Pin # Pin # Signal Name
LINEOUT R 1 2 LINEOUT L
Ground 3 4 Ground
LINEIN R 5 6 LINEIN L
Ground 7 8 Ground
Mic-In 9 10 VREFOUT
Ground 11 12 Protect pin
J5: TFT Panel Connector (when board supports 24-bit)
Here is the pin definition of J5 when it supports for 24-bit TFT flat panel
LCD displays.
Signal Name Pin # Pin # Signal Name
+12V 1 2 +12V
Ground 3 4 Ground
5V/3.3V 5 6 5V/3.3V
N.C. 7 8 Ground
R0 9 10 R1
R2 11 12 R3
R4 13 14 R5
R6 15 16 R7
G0 17 18 G1
G2 19 20 G3
G4 21 22 G5
G6 23 24 G7
B0 25 26 B1
B2 27 28 B3
B4 29 30 B5
B6 31 32 B7
Ground 33 34 Ground
SHFCLK 35 36 FLM(VSYNC)
DISPENA(MDE) 37 38 LP(HSYNC)
Ground 39 40 ENABKL
Ground 41 42 N.C.
ENAVDD 43 44 5V/3.3V
*Depends on JP2 setting (1-2 for 3.3V / default, 2-3 for 5V).
IB530F User’s Manual 15

INSTALLATIONS
J5: TFT Panel Connector (when board supports 18-bit)
Here is the pin definition of J5 when it supports for 18-bit TFT flat panel
LCD displays.
Signal Name Pin # Pin # Signal Name
+12V 1 2 +12V
Ground 3 4 Ground
5V/3.3V 5 6 5V/3.3V
N.C. 7 8 Ground
N.C. 9 10 N.C.
R0 11 12 R1
R2 13 14 R3
R4 15 16 R5
N.C. 17 18 N.C.
G0 19 20 G1
G2 21 22 G3
G4 23 24 G5
N.C. 25 26 N.C.
B0 27 28 B1
B2 29 30 B3
B4 31 32 B5
Ground 33 34 Ground
SHFCLK 35 36 FLM(VSYNC)
DISPENA(MDE) 37 38 LP(HSYNC)
Ground 39 40 ENABKL
Ground 41 42 N.C.
ENAVDD 43 44 5V/3.3V
*Depends on JP2 setting (1-2 for 3.3V / default, 2-3 for 5V).
J6: LVDS Connectors
Signal Name Pin # Pin # Signal Name
TX0- 2 1 TX0+
Ground 4 3 Ground
TX1- 6 5 TX1+
5V/3.3V 8 7 Ground
TX3- 10 9 TX3+
TX2- 12 11 TX2+
Ground 14 13 Ground
TXC- 16 15 TXC+
5V/3.3V 18 17 ENABKL
+12V 20 19 +12V
*Depends on JP2 setting (1-2 for 3.3V/default, 2-3 for 5V).
16 IB530F User’s Manual
