SummaSketch' II Plus
User's Guide
for IB:\1" \ersions of the SummaSketch II Plus
and SummaSketch II Professional Plus
Graphics Tablets

1. Re-orient the radio or TV antenna.
2. Move your computer equipment away from the radio or TV.
3. Plug your equipment and the radio or TV into separate outlets, so
that they'
re on different branch circuits.
If necessary, consult a radio
or television dealer or technician. You may also find
the booklet How to Identify
and Resolve Radio-TV Interference Prohlems helpful.
It was pr epa red by the FCC and is available from the U.S. Government Printing
Office, Washington, D.C. 20402, Stock No. 004-000-00345-4.
LE PRE SENT APPAREIL NU MERIQUE N 'EMET PAS DE BRUITS RADIOELECTRIQUES DEPASSANT LES
LIMITES
AP PLICABL ES AUX APPAREILS NUMERIQUES DE CLASSE B PRESCRITES DANS LE
RECLEMENT SUR LE BROUILLA GE RADJOELECTRIQUE EDICTE PAR LE MINISTERE DES
COMMUNICATIONS DU CANADA .
Other Certifications
The SummaSketch II Plus and SummaSketch 11 Professional Plus are certified by
UL, CSA, and TUY. German EMI Compliance, Class
B, General Permit: The
SummaSketch
II Plus and SummaSketch II Professional Plus are shielded against
radio interference in accordance with the provisions
of Vfq 1046/1984. The
Gernian Postal Service has been advised that this equipment
is being put on the
market and that they have been given the right to inspect the series for compliance
with
th e regulations. This equipment has been tested concerning compliance with
the relevant RFI protection requirements both individually and on the system level
(to simulate normal operating conditions). However, its possible that these RF!
requirements are not met under certain unfavorable conditions
in other installations.
It is the user who is responsible for compliance of his or her particular installation.
WARNING: COMPLIANCE WITH APP LICABLE REGULATIONS DEPENDS ON THE USE OF SH IELDED
CABLES. IT IS THE USER WHO IS RESPONSIBLE FOR PROCURING THE APPROPRIATE CABLE S.
Heirmit wird bescheinight, dass der SummaSketch II Plus und SummaSketch II
Professional Plus in Ubereinstimmung mil den Bestimmungen der Vfg I046/1984
funk-cnstort sind. Die deutsche Bundespost wurde das lnverkehrbringen dieses
Gerates angezeigt und die Berechtigung zur Uberprufung der Serie auf Einhaltung
der Bestimmungen eingeraumt.

Copyright
Thi, 111anu,tl and tlw ,pftv.an: dc,crihl'd 111 it arl' n,p,ri121t1nl "itlt all
ri ght, r c"· n,'d 1S!lll\\ , tr< .'. 1 11 th, · ,· ,Hlll '\l ol 1111, '"i''nghL can he· 111 am
form. Jill lud 111 g linll \\ ar e. I Y"u ma, U>L' the· "'lt11 .ire llll an, ,·olllputcT
nwned h, ,.,u. hut ex tra co p1e , cannot hl' llladc for 11t1, purp, . "c l 111kr
the copyright lavis. this manual llr the ,olrnan: ma, rtllt he cop1,·d 111
whole
or in part. without written l'IH1' L' lll of Sum111agraph1, ·, . nce pt in the
normal use of the s oftwar e or to make a had.up cop) l ndcr the law.
,·
op, · 111g 111 c ludc, trans lating into anoth er langua ge or format. Th e s am e
propnetar ) and u1pyright notices must he affi ,ed to any pcrrnitted copies
as we re affixed to the o riginal. This exception does not allow copies to be
mad e for others. w heth er or not sold. hut all of the material purchased
(with all hackup copies) ma y he sold. given, or loaned to anoth er person.
Copyright Summagraphic s Corporation I991
All Rights R ese rved.
Summa g raphic s Corporation
Sixty Silve rmine Road
S ey mour. Connecticut 06483 U.S.A.
Trademarks
Summagraphics and SummaSk etch are r eg istered trademarks of
Summa g raphic s Corporation. IBM 1s a r eg ist ered trademark of Inte rna-
tional Busin ess Machin es Corporation.
Document Ordering Number
X-l-'iO 'i0 - 00 4
Radio Frequency Interference (RFI)
The SummaSketch II Plus and SummaSk etch II Prof ess ional P /11.1 . h erea ft er
referred to co ll ec ti ve ly as 'the E quipm e nt·. g en erate and use radio fre 4u encies. If
not installed and u se d in strict accordance with Summagraphics' ins truclion s. 1h c
E4uipm ent could i rn crkre with y our radio or le k, ·ision reception.
The Equipm ent ha, he,·n 1 c, 1 ed and found 10 perfonn "ithin the C la" B !unit, for a
c
omputin .e dc\'iCe acc nrdin .e 10 1he ,p ec 1f ica 1i ons in Subpart J. Pan 15 of the
Federal Co mmunication , Cnmmis,inn <FCC , Ku lc,. The Equipment d es ign
provid es re asonahk pru tcctinn a .e a11N Kl ·I 111 a rc,11kntial ins tallation. Ho weve r.
keep the foll< rn ing in mind :
Onl) Summa~raph 1c, :tcL·c, . ,nric.-.. and 11ption, ,uld f()r u:,.t' \\ i th th t' e4 ui pm1...·nt
may be u,ed
Sum111a~r:iph1,, Coq1,11:11ion "not res pon sihle for radio or tel ev ision
in lnfrrc nc,· ca u sc·d h, unauthori zed modi fi ca tion of the equipment.
Compl,ancc "1th Cla" B ,pcul ,cati on, does not guarantee that inte rference
v.1 11 not Ol'l'Ur in a part1rnlar in stallatio n. So. if a probl em arises. tr y one or
more nf th1...· follnv,1in g. measur es:

workmanship for the life of the product. This warranty is made only to the
original purchaser/owner (the "Purchaser") and only if the purchase
is
made from an authorized Summagraphics dealer and the purchaser
completes and returns the attached warranty registration card within
fifteen (15) days after the date
of purchase. Completion and return of the
warranty registration are conditions precedent to the effectiveness
of this
warranty.
This warranty does not extend to cursors, styli, accessories, cables or
software. Summagraphics warrants cursors, styli, cables, and accessories
for a period
of two (2) years from date of purchase subject to the warranty
registration requirements described above.
If the product is sent prepaid to Summagraphics, and if Summagraphics
determines that the product
is defective in either materials or workman-
ship,
it will, at its option, repair or replace the product without charge for
parts or labor.
A minimum fee of $25 will be charged for handling. Payment must be
included with the equipment sent for repair or replacement and can be
in
the form of a check or money order. This handling fee will be waived for
the initial six
(6) months, calculated from the date of purchase by the
original owner.
This warranty applies only to equipment purchased
in the United States
and Canada. For equipment purchased outside
of the United States and
Canada contact your local dealer or distributor.
This warranty
is void if the product has been damaged hy accident. abuse,
misuse, negligence,
or misapplication, or has been modified or repaired by
others without the written permission
of Summagraphics.
THE WARRANTIES AND REPRESENTATIONS SET FORTH AROVF ARE EXCII SIVE AND
IN LIEL OF ALL OTHERS, EXPRESS OR IMPLIED, IN FACT OR IN I.AW. No
Summagraphics dealer, agent, or employee is authoriz.ed to make any
modification, extension, or addition to this warranty.
Summagraphics reserves the right to make changes to the product without
notice.
IN NO EVENT WILL St:MMAliRAPHICS CORPORATIO'-: HI I l"BI I. !OR DIRECT,
INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQ\IENTIAL lJA\14(,1 S Rl·SI I I I'-<(; FROM
ANY BREACH OF WARRANTY OR LNDER ANY LE(iAL rHEORY. I·\ I'\ II \ll\ ISUl iJI·
THE POSSIBILITY OF SUCH DAMAGES.
Some states and countries do not allow the cxclus,on or lnrntat1011 of
implied warranties or liability for incidental or con,et1uc1111al dama!,!es, so
the above limitation or exclusion may not apply
to ynu. This warranty

Contents About Thi~ Book
Did You
Get EvL'rything·1
1
What Is The SummaSketch !
2 How Does It Work ')
4 Preparation
4 Is
Your Computer Set Up
Correctly?
4 UIOF And MM Configurations
5 A Word About Software
5 Installing The SummaSketch
8 lh 1ng Th e SummaSketch
9 Caring For The SummaSketch
10 Stylus Refills
I I
Troubleshooting And Service
12 Appendix A: Interfac e/Po wer
Cable Pin Assignments
12 Appendix 8: 9-pin-to-25-pin Serial
Adapter Wiring Diagram
13 Appendix C: Communication
Parameters

About This Book
Did You Get
Everything'?
This book provides the infonnation you
need to install, use, and care for your
SummaSketch
II Plus ( l 2x 12) and
SummaSketch
II Professional Plus
(I8x 12) . (To simplify, we refer to both
models collectively
as 'SummaSketch'.)
The package should contain the
following:
tablet
four-button cursor or
sixteen-button cursor
PC compatible interface cable
25-to-9 pin serial adapter
power supply
software (documented separately)
two-button stylus (optional)
~ powcrsuppl)
_j (opu rn w. 11
ff==__.,
~ ~: i:1: · an· ~
1ab le1
~tylw, ;. 4- butw n lb- button
:= -·. -curso, cursor
· >J >'
(I),
If something was missing from the
package, contact the dealer where you
purchased the unit.

What is the
SummaSketch'?
How Does it Work'?
The SurnmaSketd1
1, a graphics tahlct.
A graphics tahlet
1s an input dev1n: that
lets you translate two-dimensional
information. such as a drawing. into a
computer readahle format. Its many
uses include:
tracing pictures. drawings. and
photos
freehand drawing
steering the pointer on a
computer
screen
picking locations on a menu
or
template
The
SummaSketch is a sophisticated
device.
It uses the latest advances in
electronics and electromagnetic
technology, which make it accurate and
reliable.
The SummaSketch has two main parts,
the tablet and the pointing device. The
pointing device can be either the stylus
or cursor. The cursor/stylus emits a
low-intensity signal. A grid within the
tablet picks up the signal to
'read' the
cursor/stylus location. Therefore, for
the
SummaSketch to do its job, the
cursor/stylus must be
over the grid and
close enough to
it to sense the signal.
Two terms describe this. They are
·active area· and
·proximity', which are
defined on the next page.

How l>ot'S it Work'?
(cont.)
active area --· -- ---- -
proximity= 1/2"
The area of the tablet where the
grid
is located is called the tablet
active area. Unless you have X-ray
vision, you can't see the active
area. So we etched a groove in the
tablet
surrounding it.
c===i !
The SummaSketch II active area is
I 1.7" x 11.7" (shown above). The
SummaSketch II Professional
active area is 18" x J2".
Proximity is the maximum distance
above the active area that the
cursor/stylus can be held and still
be
read by the tablet.
The proximity of the cursor/stylus
is 1/2-inch_ The cursor/stylus does
function at greater heights. but per-
formance, such as accuracy. begins
to suffer.
The advantage of pro ximity is that
the
cursor/stylus and tablet ne ed
not be in direct contact with each
other to work. You L·an draw and
trace through layers of materials ,
e.g.
drawings and rhotos . ur to the
proximity limit - - 1/ .:! -inch.

Preparation
Is Your
Computer
Set Up Correctly?
UIOF and MM
Configurations
For the tahlet to funl'lion with your
computer. the nnnputer hardware must
he set up correctly. and the
computer
software must support the
SummaSketch.
The comput er must have an RS-2.12-C
port.
This is an asychronous. serial,
communications port. The port mu.st be
configured as DTE (Data Tenninal
Equipment). which specifies that the
port transmit
data on Pin 2 and r ece ive
data on Pin 3. The port can have eith er
a 25-pin male D connector or a 9-pin
male D connector.
Additional
configuration information
appears in the appendices. If you are
unsure
whether your computer is set up
correctly, refer to the computer owner's
guide or call yo ur dealer.
The tablet operates in either the UIOF
(Universal Input Output Format) or MM
configuration. Each configuration has
its
own unique set of operating charac-
teristics
and report formats. When you
turn
on or reset the tablet. it defaults to
one of these configurations . It defaults
to the
MM configuration when the
stylus
or four-button cursor is attached.
It defaults to the UIOF configuration
when th e sixteen-button cursor is
attached.
Software is available to override the
defaults
and let you mix and match
configurations and pointing devices .
Refer to the
SummaSketch Drivers /
U1i/1ties
User 's Guide for details.

A Word About
Software
Installing the
SummaSketch
5
For the tablet to act as an input device,
your application must include a driver for the
tablet model you are using. The driver
allows your tablet and the application to
communicate with each other. It converts the
tablet output into information that the application
can understand and use. Most programs have
Summagraphics drivers built right in. (To
be
sure, refer to the software manual or contact the
software manufacturer.) Below
is a listing of
drivers required by the SummaSketch II Plus
tablets. If you are using a
SummaSketch II Plus (or SummaSketch
II Professional Plus) with a four-button
cursor or stylus, you must select the
SummaSketch (or
MM series) driver
within the application.
SummaSketch II Plus (or SummaSketch II
Professional Plus) with a 16-button cursor,
you must select the Microgrid (or UIOF)
driver within the application.
Below are the steps to installing your
SummaSketch.
1. Plug the cursor or stylus into the
top right socket.
The cursor and stylus are interchange-
able. However, when changing from
one to the other, tum
off the tablet.
(This allows the tablet's internal
firmware to fine tune for each device.)

Installing the
SummaSketch (cont.I 2.
C,,nnect thl' tahkt to the n1111rutl'r
hy rlugging the phone - type
connector of the interface cahle
into the tor left socket.
1
,.........---lf
I ~
I
I I
u /I
Next. plug the 25-pin connector of
the interface cable into the host
communications port. If your
computer has a 9-pin port. use the
9-pin-to-25 -pin adapter between
the tablet cable and the computer.
3. Connect the power supply by
plugging its barrel connector into
the
interface cable's D connector.
Now. plug the power supply into a
st
andard clcl'lrical outlet. Use only
a SummaSkctch power supply. A
suhstitutc could damage the tablet
and would void the FCC certifica-
tion and
warranty.

Installing the
SummaSketch
(cont.)
7
4. Power up the tablet by pressing the
on/off switch. (Pressing it again
turns the tablet off).
on/off switch
power/prox light
The tablet is now up and running!
The power/prox light serves two
purposes. First, it lets you
know that
the tablet is on and receiving power.
Second, it is a proximity indicator. The
light remains lit when the cursor/stylus
is in-prox (in proximity). It blinks
when the cursor/stylus is out-of-prox
(out
of proximity). If the light blinks
when the cursor/stylus
is in-prox, two
possible problems exist. Either the
cursor or stylus is not connected to the
tablet,
or the tablet is malfunctioning.
Turn off the tablet, then turn it on. If it
fails again, contact your local dealer for
service.

Using the
SummaSketch
8
Using the SummaSketch is easy.
However, you·
II get the most from your
tablet if you follow these guidelines:
The cursor/slylus must be
in 1he
tablet active area and in proximity
(within I/2-inch
of th e tablet .
surface) for the tablet to work as a
pointing devic
e. Note: The tablet
power light is also a proximity
indicator. When the cursor/stylus
is in proximity, the tablet power
light is on. When the cursor/stylus
is out of proximity, the power light
blinks.
You can tape things down to the
tablet, like pictures and drawings.
Tape doesn't bother the tablet.
You can even stack materials up to
1/2-inch high between the tablet
and the cursor/stylus.
The
cur s or and stylus have the
same functionality. You can use
them to draw, trace, etc. Which
one should you use? The stylus is
mote natural to the hand, so it is
better for freehand drawing. The
cursor has the cross-hair for
precisely sighting points, so
it is
better for tracing and menu picking.
The cursor and stylus are inter-
changeable. However, when
changing from one to the other,
tum off the tablet. (This allows the
tablet's internal firmware to fine
tune for
each device.)
The cursor is most accurate when
held parallel with the tablet surface.
To activate a cursor button, press it.
When tracing, use the cross hair to
precisely sight information.

Using the
SummaSketch
(cont.)
Caring for the
SummaSketch
The Environment
9
The stylus has two buttons. the
barrel button and the refill tip.
To
activate. press gently.
The unit is affected by conductive
materials. Don't trace through
metal
or metallized paper. Don't
use metal objects. such as rulers on
the tablet. With the cursor.
however, you can trace through
some conductive materials, such as
X-rays
or drawings in pencil or
conductive ink.
When you turn off the computer,
also turn
off the tablet.
Below are some basic guidelines for the
care and maintenance
of your
SummaSketch.
Operating Temperature:
45 degrees to I
IO degrees Fahrenheit
(7 degrees to 43 degrees Celsius)
Storage Temperature:
-45 degrees to 145 degrees Fahrenheit
(-43 degrees to 63 degrees Celsius)
Be careful. Extreme temperatures can
occur in some rather surprising places
- - the top
of a TV set, in direct sunlight,
or in the car on a hot or cold day.
Humidity:
8 to
80 percent relative humidity,
non-condensing

Care and Cleaning
Stylus Refills
IO
The SurnmaSkctd1 rc4uires minimal
care and cleaning. ll1,wcver, these
guidelines are important:
Tum the tahlet and computer off
and unplug them hcfore cleaning .
Unp lug thl'. power supply from the
electrical outlet.
Using a soft.
damp (not wet). lint-
free
cloth , wipe the case clean with
a mild detergent solution.
Cursor:
The transparent part of the
cursor that encases the cross-hair is
called the paddle. Protect the
paddle. Do not scratch, mar. or
separate. To clean. wipe with a
lint-free
cloth dampened with
water.
Do not use spray cleaner or
any other type of cleaner or
solvent.
Never disassemble the
SummaSketch.
Never immerse in liquid.
Never bang it around or drop it.
Never scratch or mar the tablet.
You can nhtain stylus refills from your
SummaSkct ch dealer. To change the
refill, unscrl'.w the
cap and pull the refill
straight out.
Insert the
new refill and screw on the
the
ca p.

Troubleshooting and
Sen ice
11
You .~hould have no probkms with your
SurmnaSketch. However. if a problem
arises, try one or more of the following:
Check the hardware conneL'lions
and ensure that the tablet is
turned
on. The power/prox light should
be lit.
Ensure that the computer is
working.
Turn off the computer and tablet.
Turn them on again .
Reread this booklet to ensure that
you have installed and are using the
unit properly.
Run the MMTEST utility, de-
scribed in the D1-il'ers!Utilities
User's Guide.
If the problem persists. contact the
dealer where you purchased your
SummaSketch. If your dealer instructs
you to return the unit to
Summagraphics. contact our Customer
Service Department at ( 103) 881-5400
for instructions and a Return Authoriza-
tion Number .
Do not return a unit 1, ·i 1ho111fir . 11
ohtClining a Return A.111hnri : u1in11
N11111her 011d i11 . 11rnc11011 .1 j,u111 our
C11 .11omer Sc1Tice /Jc1,11u11w111 .

Appendix A
Interface/Power Cable Pin Assignments
For those of you who want to use an extension or adapter cable
between our interface cable and the computer, the table below may
be helpful. It identifies the pin assignments of the 25-pin D
connector terminating our interface/power cable:
Pin Wire Name Description
I ground protective ground
2 RXD receives data from host
3 TXD transmits RS-232-C data
to host
1]
RTS Request To Send
CTS Clear To Send
6
DSR
Data Set Ready
7 ground signal ground
20 DTR Data Terminal Ready
Appendix B
9-pin-to-25-pin Serial Adapter Wiring Diagram
The table below identifies the wiring of the Summagraphics 9-pin-
to-25-pin serial adapter. If you're using an adapter other than the
one we supply, ensure that it has the same specifications.
9-Pin Female Connector 25-Pin Male Connector
-------------8
2-----------3
~------------ 2
4-----------20
5 7
6 6
7 4
8 5
9 22
12

Appendix C
Communication Parameters
SummaSketch (MM) Format
Fonnat: RS-232-C
Baud rate: 9600
Number of data bits:
eight
Parity bit: odd
Number of stop bits:
one
Data fonnat:
MSB LSB Transmit
7 6 5 4 3 2 0 Sequence
PH PR T Sx Sy
Fe Fb Fa 1st byte
0 X6 XS X4
X3
X2 XI XO 2nd byte
0
Xl3 Xl2 XII XIO X9
XS X7 3rd byte
0 Y6
Y5 Y4 Y3 Y2 YI
YO
4th byte
0 Yl3 Yl2 YI! YlO Y9 Y8 Y7 5th byte
Key:
LSB is the least significant bit. MSB is the most significant
bit.
Fa,
Fb, and Fe are the flag bits. They identify the status of the
stylus and cursor buttons.
Stylus Cursor Buttons Fe Fb Fa
none pressed none pressed
()
() 0
tip button I 0 0 I
barrel button 2
()
0
tip and barrel 3 0 I I
4 () 0
1+2
0 I I
1+3
() 0
1+4
0
2+3
()
2+4 ()
1+2+3 0
1+2+4
2+3+4
1+2+3+4
IJ

Sx and Sy are the X and Y coordinate signs. I is positive. 0 is
negative. In absolute coordinates. the sign is always
positive.
In relative coordinates, the sign can be positive or
negative.
T
is the Tablet Identifier. Your choice of I or 0. Command
controlled.
PR is the proximity bit. 0 is in-prox. I is out-of-prox.
PH
is the phasing bit. which is always I.
XO, XI, etc. and YO, YI. etc. are the X and Y coordinate bits.
UIOF Format
Format: RS-232-C
Baud rate: 9600
Number of data bits: seven
Parity bit: even
Number
of stop bits: two
Data format:
MSB
6 5 4 3
PH
0 0 Mb
0 0 Fe
Fd
0 XS
X4
x.,
0 XII XIO
X9
0 0 Sx
XIS
0 YS
Y4
Y.,
0 YII YlO
Y9
0 0 Sy YIS
2
Ma
Fe
X2
xx
X14
Y2
YX
Yl4
T
Fb
XI
X7
XU
'{ I
Y7
YI :l
LSB Transmit
0 Sequence
PR Isl byte
Fa 2nd byte
XO 3rd byte
X6 4th byte
Xl2
5th byte
YO
6th byte
Y6
7th byte
Yl2
8th byte
LSB is the least significant bit. MSB is the most significant
bit.
PR is the proximity hit. 0
1, 1n-prox. I
is out-of-prox.
14

. T ,~ the
Tab let Identifier.
Ma and Mb are the model identifiers:
Mb
Ma Model
0 0 Mi crog ri d
0 I MM 1812
0 SummaMouse
un assigned
Ph is the ph as ing bit , which is al ways I.
Fa
throu gh Fe are the fl ag bit s.
Th ey ide ntif y the status of the
c
ur s or button s:
16-Button 4-Button
Fe Fd Fe
Fb Fa
Cursor Cursor
none none 0 0 () () ()
I I 0
()
0
()
I
2 2 0
() () 0
3 3 0
() ()
I
C 4 0 () I () 0
4 0 (l () I
5
() () 0
6 0 ()
D 0 ()
{) ()
7 0 () 0 I
8 0
(J
()
9 0 ()
E 0 I () 0
A 0 I 0
0 0 I ()
B 0
F
{) (I
() ()
XO , X I, etc.• a nd YO , YI. etc.. are the.\'. and Y coo rdinate bits.
Th e coord inat es are in c ounts of resolution. 110 1 in ch es or
millim et ers .
Sx a
nd Sy are the X and Y n 1Pr drnatc , 1µ 1 1, . is n ega ti ve. 0
is p
os itive.
