IBP HDM97 Pocket Series User manual

HDM97Pocket Reference Meter Series
User Manual
HDM97BL
HDM97BH
HDM97BN
HDM97BO
HDM97BP
HDM97BQ

Preface
The information contained in this is subject to change without notice. IBP Medical GmbH, its distributors and subsidiaries take no
responsibility for any errors or omissions in this document. The contained software is being delivered on the basis of a general licence
contract or in single license. Use or reproduction of the software is allowed only in agreement with the contractual arrangements.
Whoever transfers this software and/or this manual on magnetic tape, diskette or any other media, except for the purpose of own use,
without written authorization of the IBP Medical GmbH, is liable to prosecution.
Copyright (C) 2008 … 2019 IBP Medical GmbH.
All rights reserved
All brand names mentioned in this document are property of their respective owners.
Publishers: IBP Medical GmbH
Ikarusallee 15
D 30179 Hannover
Germany
From USA and Canada
Phone: [phone]
Fax: [phone]
Internet: http://www.ibpmedical.com http://www.ibpmedical.com
E-Mail: [e-mail] [e-mail]
Manual authors: Dipl. Ing. Werner Pfingstmann
Holger Kleinert
Document Number DHDM97.0220.11
Revision history Rev. 0. 29.05.08
Rev. 1. 18.03.09 Update Hard- und Software release 2.0
Rev. 2. 01.10.09 Update Flow sensor
Rev. 3. 04.11.09 Update Flow sensor Cleaning
Rev. 4. 20.01.10 Added Reading of Min- and Max-Values
Rev. 5. 13.04.10 Additional Conductivity Temperature Coefficients
Rev. 6. 02.02.11 CE Declaration modified
Rev. 7. 11.08.14 Environmental conditions added
Flow and Option H Pressure Specifications corrected
Rev. 8. 18.06.15 Table “Tolerances” Page 33, pH 14 corrected to pH 13
Rev. 9. 15.02.16 BH Pressure Specifications added
Rev. 10 06.07.18 Flow-Sensor Specification modified
Rev. 11 20.11.19 Temperature Specification modified
This manual is only valid for the software revisions listed below:
Meter: 1.53, 2.72, 2.74
IBPView 2.00

SAFETY INSTRUCTIONS
For your and your patients safety read and consider the safety instructions below carefully
•Read the entire manual carefully before using the HDM97Pocket.
•Keep the instrument away from unauthorised persons.
•Only use the HDM97Pocket as reference instrument to measure Conductivity, Temperature,
Pressure, Flow and pH depending to it's equipped features.
•Never use the HDM97Pocket as a replacement of sensors of a medical device.
•Do not use the HDM97Pocket in conjunction with a medical device during a treatment.
•Only use the instrument in a dry environment and do not touch it with wet hands.
•Make sure that no liquids intrude inside the instrument or it's inlets / outlets.
•Always use a clean protection filter for the pressure transducer inlet.
•Prevent every mechanical overstraining of electrical wires. Never buckle or pull the cable of the
conductivity probe.
•If the acquired values seem to be not believable, make sure that the HDM97Pocket is not defective
•Prevent electrostatic discharge on the connectors. This can lead to substantial damage of the
instrument. Make sure to be completely discharged before touching the connectors or cables
connected to the instrument.
•Adjust the meter only, if you are familiar with the consequences of the adjustment. Consider the
hints for reference solutions in the user manual.
•Potentials above 42V against earth ground are dangerous. This potentials can lead to electrical
shock and therefore to health hazards. Make sure that none of the connectors has higher voltage
than mentioned before.
•The direct connection of earth potential to any connector of the instrument is not applicable for
safety purposes and may substantially damage the instrument. Make sure that the medical device
itself is properly connected to earth ground according to its instruction manual.
•Make sure that the instrument never heats over 60°C / 140°F. Prevent direct sunlight.
•Never sterilize the instrument using an autoclave. Danger of explosion of the battery!
•Never throw the meter into a fire. Danger of explosion of the battery!
•Never open the meter. There are no parts inside you can repair.
•Never try to replace or repair the internal battery. Handled in the wrong way these part is
dangerous. Extreme risk of fire and explosion!

1
Table of content
Introduction...................................................................................................................................3
Application....................................................................................................................................3
License..........................................................................................................................................4
Europe........................................................................................................................................................... 4
USA............................................................................................................................................................... 4
Delivery Content ...........................................................................................................................5
Warranty........................................................................................................................................6
Battery and Electronic Recycling................................................................................................6
Product Details..............................................................................................................................7
Appliance Part............................................................................................................................................... 7
The options at a glance................................................................................................................................. 8
Measuring Channels ..................................................................................................................................... 9
Charging the battery.................................................................................................................................... 10
Performing measurements while the battery is being charged................................................................... 10
Flow-through adapter for conductivity and temperature measurement ...................................................... 10
Keypad ........................................................................................................................................................ 11
Switching on the instrument........................................................................................................................ 12
Display test during start up.......................................................................................................................... 12
Power saving function................................................................................................................................. 12
Displaying battery charge progress and finish ............................................................................................ 12
Battery gauge display during operation....................................................................................................... 13
Battery aging ............................................................................................................................................... 13
Battery replacement –ONLY BY MANUFACTURER................................................................................. 13
Value adjustment......................................................................................................................................... 16
Measuring....................................................................................................................................17
Conductivity and temperature measurement .............................................................................................. 17
Fundamentals of temperature compensation.............................................................................................. 17
Background of temperature coefficients...................................................................................................... 18
Temperature compensation ........................................................................................................................ 19
Selecting the temperature coefficient.......................................................................................................... 20
Temperature measurement......................................................................................................................... 22
Pressure measurement............................................................................................................................... 22
Pressure drop measurement....................................................................................................................... 23
pH measurement......................................................................................................................................... 24
Temperature compensation ........................................................................................................................ 24
Background of pH measurement ................................................................................................................ 24
Flow measurement..................................................................................................................................... 25
Attenuation of reading................................................................................................................25
TIMER ..........................................................................................................................................26
Adjustment and Calibration .......................................................................................................27
Precautions.................................................................................................................................................. 27
Definitions.................................................................................................................................................... 27
General........................................................................................................................................................ 27
Handling of Reference Solutions................................................................................................................. 28
Adjusting the HDM97Pocket ....................................................................................................................... 28
Maintenance of HDM97Pocket ...................................................................................................31
Troubleshooting..........................................................................................................................34
Technical data.............................................................................................................................35
PC Interface.................................................................................................................................38
USB Interface.............................................................................................................................................. 38
Interface parameters for serial COM port emulation................................................................................... 38
Driver installation, example for Microsoft®Windows®XP Service Pack 2.................................................. 39
Example....................................................................................................................................................... 41
IBPView .......................................................................................................................................42
What is IBPView.......................................................................................................................................... 42
Installation ................................................................................................................................................... 43
Quickstart .................................................................................................................................................... 43
Disconnect USB .......................................................................................................................................... 43
Main Window............................................................................................................................................... 43
Selecting hardware...................................................................................................................................... 44

Inhaltsverzeichniss 2
Assigning graphs to hardware channels ..................................................................................................... 45
List of channels ........................................................................................................................................... 46

3Delivery
Introduction
The HDM97Pocket meter series are reference instrument designed for the calibration of medical devices such
as hemodialysis machines. Please read this entire manual carefully before the first use of the instrument.
Application
Depending on the version the HDM97Pocket may be equipped with up to 5 acquisition channels:
Channel
HDM97BL
HDM97BH
HDM97BN
HDM97BO
HDM97BP
HDM97BQ
Conductivity




Temperature




Timer






Pressure




pH

Flow


The instrument was designed to be used as a dialysis machine maintenance instrument, but can also be used
as laboratory measuring instrument as well as instrument for environmental purposes.
This instrument displays measuring values numeric. Graphical displays are available through a PC or
Notebook using the optional Software IBPView.
Using the USB communication interface it is possible to obtain measuring values regardless of the
instrument display's content. These values can be displayed in any way or stored for further processing.

Delivery
4
License
Europe
EC DECLARATION OF CONFORMITY
We hereby declare, that the following product(s) conform to the below mentioned European Directive.
Manufacturer
IBP Medical GmbH
Ikarusallee 15
30179 Hannover
Product
HDM97BL
HDM97BH
HDM97BN
HDM97BO
HDM97BP
HDM97BQ
Relevant EC-Directives
Compliance with
Place and Date
Legally binding signature
2004/108/EG EMV-Richtlinie
2006/95/EG Niederspannungs-Richtlinie
EN60601-1:2006
EN61000-4-2:1996
EN62353:2008
VDE 0750-1:2006
VDE 0751-1:2008
Hannover 15.02.16
Dipl. Ing. Werner Pfingstmann
(Managing Director)
USA
FDA Registration No. K020908

5Delivery
Delivery Content
Pos.
Description
Version
Standard
Option
1
HDM97Pocket BL, BH, BM, BN, BO, BP, BQ

2
Conductivity/Temperature Probe
BN, BO, BP, BQ

3
Dialyser Line Adapter
BN, BO, BP, BQ

4
Hose and adapter for pressure measurement
BH, BO, BP, BQ

5
14,00 mS/cm Conductivity Reference Solution
BN, BO, BP, BQ

6
Battery charger with wall plug adapters
All

7
USB interface cable
All

8
CD - HDM97Pocket with USB drivers, Software
and User Manual
All

9
Safety instructions and quick start guide
All

10
Flow Sensor
BL

11
Flow Sensor
BQ

12
pH Probe with buffer solution pH6, 7 and 8
BP

13
Carrying case
All

14
Holder Infusion pole
All

15
CD - IBPView Data Acquisition Software
All


Delivery
6
Warranty
IBP Medical GmbH warrants that it will repair or replace, at its option, any defective or malfunctioning part
without charge for the terms listed below. Parts used for repair or replacement are warranted for the
remaining warranty period only.
The warranty period is 24 month from date of delivery by IBP.
The device must be delivered free of charge to IBP Medical GmbH.
The warranty does not cover:
•Disposable parts as battery or pH electrode
•Annually calibration
•Cell cleaning
•Defects caused by:
1. Modification, alteration, repair or service of the product by anyone
other than IBP Medical or an authorized service center
2. Misuse due to negligence or accident
3. Operation or maintenance of the product in a manner contrary
to IBP instructions
Any express warranty not provided herein, and any remedy for breach of contract that but for this provision
might arise by implication or operation of law, is hereby excluded and disclaimed. The implied warranties of
merchantability and of fitness for any particular purpose are expressly limited to the terms mentioned above.
Some states do not allow limitations on the duration of an implied warranty, so the above limitation may not
apply to you.
Under no circumstances shall IBP Medical GmbH be liable to the original purchaser or to any other person
for any special or consequential damages, whether arising out of breach of warranty, breach of contract, or
otherwise. Some states do not allow the exclusion or limitation of special or consequential damages, so the
above exclusion or limitation may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights that vary from state to state.
For further warranty information, contact IBP Medical GmbH.
Battery and Electronic Recycling
The meter is equipped with a rechargeable battery.
The symbol on the meter indicates that this product may not be treated as household waste.
Instead it shall be handed over an applicable collection point for the recycling of electronic
equipment. By ensuring this product correctly you will help to prevent potential negative impact
for the environment and human health.
You can send the meter also free of charge back to IBP.

7General
Product Details
Appliance Part
HDM97BL
HDM97BH
Flow
Pressure
HDM97BN
HDM97BO
Conductivity
Temperature
Pressure Conductivity
Temperature
HDM97BP
HDM97BQ
pH Pressure Conductivity
Temperature
Flow Pressure Conductivity
Temperature
HDM97BQ with Option C (Conductivity Probe Connector)
Flow Pressure Conductivity
Temperature
Depending on the configuration the appliance part consists of a BNC inlet for pH electrode connection, a
male connector for pressure transducer inlet, a connectorfor the flow probe and a directly attached cable
which leads to the conductivity / temperature probe or connector for the probe. The appliance part is isolated
against the USB-Connector withstanding 4000V AC or 6000V DC for one minute minimum according to
ISO EN 60601-1.

General
8
The options at a glance
Your device might be equipped with one of the following options.
Option H
Option H is a higher accuracy in pressure measurement.
Please note that the sensor is not fluid resistant with this option.
Option identification is an Hbehind the product name, for example HDM97BQH.
Option C
Option C is a connector for the conductivity probe.
Please note that the probe is calibrated with the meter and cannot be used with other meters.
To use the probe with other meters a new adjustment of the temperature and conductivity is needed. After
these adjustments the meter will accept the probe in the future.
Option identification is a Cbehind the product name, for example HDM97BQC or HDM97BQHC.

9General
Measuring Channels
Only use accessories provided with the HDM97Pocket . Use of other devices may damage the instrument and
will void the warranty.
Conductivity/Temperature Probe
The conductivity/temperature transducer is a quadropole design for greater accuracy and longevity than other
designs.
Standard precision pressure transducer
This pressure transducer is watertight. However it is recommended to keep fluids away from the sensor
because residues like salt can falsify measurement results. In this case the sensor needs to be flushed with
deionized water.
High precision pressure transducer
To avoid damage or inaccurate measurement, ensure that no fluids enter the instrument. We recommend the
use of a Transducer Protector for this purpose. Never flush the sensor.
Pressure drop measurement
This is not a real channel, it is a function for measuring pressure loss in systems for a specified time.
Timer
This is not a real channel, it is a function to help performing anything where time is a crucial element.
pH
The input connector is designed exclusively for pH electrodes. It is optimized for glass electrode single-rod
measuring cells with a slope of ΔEof 59mV at 20°C. Its absolute maximum allowable input voltage span
extends from -3 Volts to +3 Volts with respect to BNC Shield. Applying any voltage beyond these
boundaries will possibly destroy the instrument.
Flow
This connection is designed to be used with the HDU FLOW97 probe only. Do not connect any other
devices to this port even when the connector may fit.

General
10
Charging the battery
The HDM97Pocket is internally equipped with a high performance Lithium-Ion-Polymer battery. It can be
charged using the external power supply, a PC or a laptop which is connected via the USB cable to the
instrument. The battery of the HDM97Pocket can only be charged from USB ports which are capable of
delivering 500 mA of current.
This is appropriate to most connectors of laptops or PC's. Connecting the meter to a
passive (e.g. not externally powered) USB hub, the battery can not be charged and
the communication may not work well. During the charging process the battery
symbol in the display is animated.
Performing measurements while the battery is being charged
The HDM97Pocket can be used for measuring while the battery is being charged.
ATTENTION: The USB connector is not part of the appliance part.
Flow-through adapter for conductivity and temperature measurement
The adapter is suitable for measuring pressure, temperature and conductivity
in flow-though mode. With immersion usage of the probe it is suitable for
measuring temperature and conductivity concurrently. The preferred
orientation of the adapter is vertical. The axial connector must point down
(see picture). In flow-through mode the axial connector is to be used as inlet
meanwhile the side connector is to be used as outlet. The connection to the
pressure transducer inside the HDM97Pocket is accomplished by the lateral
connection above the inlet. Before measurement it is necessary to shake the
adapter slightly, so that air bubbles trapped inside can pass off through the
outlet.
For immersion usage the probe must be unscrewed from the flow-through
adapter. To accomplish that do not turn the upper shank, the probe may be
damaged. Only turn the nut as shown in the picture left.
Never touch the carbon ring electrode surfaces with
your fingers or other objects.
Do not buckle the probe cable. The minimum allowed
bending radius is 3 cm or 1¼ inches.
Dialysate
pressure outlet
Screw cap



11 General
Keypad
Main functions
The keypads main functions of the HDM97Pocket are listed below:
Key for switching the instrument on and off
Key for selecting the measuring channel
Key for selecting the unit to display or temperature coefficient
Key leads to channel dependent special functions
Key to tare the pressure transducer
The keypad layout is shown in the left picture.
The keys , and have different sub functions depending on the channel
displayed. These sub functions are explained later in chapter "Measuring"
Additional functions
The yellow keys below the display can be used to
set values and navigate through menu options or
setting. These functions become available when
the symbols shown in the right picture appear at the
bottom of the display.
Cancels the current setting or selection and returns to measuring mode.
Decreases a value or selects the previous option in a menu or a setting.
Increases a value or selects the next option in a menu or a setting.
Applies a value or a selects an option in a menu or a setting.

General
12
Switching on the instrument
The instrument is switched on and off by pressing the key.
Display test during start up
Immediately after switching on the instrument the display shows all
possible segments dark for two seconds. Compare the display with
the picture on the right side. Do not use the instrument further if you
discover any missing segment, because wrong values could be
displayed which may lead to misreading.
The content of the display must be shown exactly like this picture
right from this text.
Power saving function
The HDM97Pocket switches off automatically if the battery is empty. If enabled, it also switches off after a
specified time if one of the conditions listed below becomes true for the specified time period.
•In pressure mode: The value remains 0 for the specified time period
•In conductivity mode: The conductivity is 0 µs/cm for the specified time period
•In pH mode: The pH probe is not connected for the specified time period
The HDM97Pocket does not switch off when one of the conditions below are met
•A computer is connected to the meter
•The TIMER / stopwatch is running, regardless if displayed or hidden.
Displaying battery charge progress and finish
If the battery is being charged the symbol at the left top corner in the display is animated in 4 steps. There is
a delay of one second displaying each step. After the last step has been displayed the animation starts from
again like illustrated in the picture below.
➔ ➔➔
 
    
After the battery has been charged up to its maximum capacity, the inner 3 columns of the battery symbol
start to blink in a one second period as shown is the illustration below.
 ➔
 
   

13 General
Battery gauge display during operation
If nothing is connected to the USB port during operation the internal battery is used to supply power to the
instrument. The battery symbol in the left top corner of the display shows the remaining capacity of the
internal battery. The combinations have the meanings listed below:
The battery is 100% full.
The battery has approx. 2/3 of its capacity left.
The battery has approx. 1/3 of its capacity left.
The battery is empty, approx 10% is left.
If this symbol starts flashing the battery is totally empty and the meter will switch
off shortly.
Battery aging
The battery technology of the HDM97Pocket is based on Lithium-Ion-Polymer technology. This technology
has many advantages compared with Nickel-Metal-Hydride technology which are lower weight, smaller size,
longer life, no memory effect and higher efficiency. However, after a couple of years (5 years estimated) the
battery's capacity will start decreasing.
Battery replacement –ONLY BY MANUFACTURER
Do not try to replace the battery by yourself. The battery is mounted directly onto the main PCB inside the
HDM97Pocket, and the main PCB itself contains the battery protection circuit. If the battery is not handled in
the right way, there is extremely danger of fire and explosion. Therefore, this battery can only be replaced
from IBP personnel who have run through a special training in handling Lithium-Ion batteries.

Base Installation
14
Basic settings
To invoke the installation menu please follow the steps below:
1. Switch on the meter using the key.
2. Press during the display test.
3. After this procedure the instruments starts the basic settings dialog instead of entering any measurement
functions.
4. In the basic settings dialog you are able to adjust a variety of settings.
Parameter
Meter Versions
Description
AUTO-OFF
All
Set the delay time fort he auto power off function or disables it.
BEEP
All
enables / disables the keypad acknowledge beep
CAL-RES
All
Overwrites the user calibration dataset with the device initial
calibration dataset.
LANGUAGE
All
Adjusts the display language.
PHT
BO, BP, BQ
Target time adjustment for pressure holt test (PHT)
TIMER
All
enables / disables the stopwatch function
Flow
BL, BQ
enables / disables the Flow channel
pH
BP
enables / disables the pH channel
TEMP
BN, BO, BP, BQ
enables / disables the sole readout of the temperature channel
PR HR-Res
BH, BO, BP, BQ
enables / disables the high resolution for pressure channel
→AUTO-OFF
→OFF →disables function
→30 MIN →30 minutes delay
→60 MIN →60 minutes delay
→90 MIN →90 minutes delay
Then to apply and save this setting,
or to discard this setting.
→BEEP
→ON →keypad beep enabled
→OFF →keypad beep disabled
Then to apply and save this setting,
or to discard this setting.

15 Base Installation
→CAL-RES
→Press 5 seconds until the counter in the display reaches zero.
Then a calibration dataset reset will be performed. This takes
a couple of seconds. The instrument performes a restart afterwards.
→LANGUAGE
→DEUTSCH →german language
→ENGLISH →english language
Then to apply save this setting,
or to discard this setting.
→TIMER
→ON →stopwatch function enabled
→OFF →stopwatch function disabled
Then to apply and save this setting,
or to discard this setting.
→PHT (pressure hold test)
→increases the value
→lowers the value
Then to apply and save this setting,
or to discard this setting.
→PH
→ON →pH enabled
→OFF →pH disabled
Then to apply save this setting,
or to discard this setting.
→FLOW only available with version BQ
→ON →FLOW enabled
→OFF →FLOW disabled
disabled
Then to apply save this setting,
or to discard this setting.
→TEMP
→ON →sole readout of temperature enabled
→OFF →sole readout of temperature
disabled
Then to apply and save this setting,
or to discard this setting.

Base Installation
16
→PR H-Res only available with version BH, BM, BO, BP and BQ
→ON →High Resolution reading enabled
→OFF →High Resolution reading disabled
Attention: The higher resolution does not give a higher measuring accuracy.
Then to apply and save this setting,
or to discard this setting.
→EXIT
A save dialog will appear, if changes have been made.
→SAVE
→YES to apply and save all settings by exiting
→NO to discard all settings by exiting
Then to exit the basic settings dialog,
or to return to the basic settings dialog.
Value adjustment
The adjustment of values is done via the navigation keys and . By pressing and holding down
one of these keys the last (right) digit of the value will be incremented or decremented depending on the key.
If this digit reaches the boundary it remains 0 and the next digit will begin to change. If the key is being
released and pressed again the procedure will start again beginning with the last digit.
Example showing a value, which has an allowable range from 0.00 to 7.50:
Display: 0.00 ; navigationkey is hold down:
Order of value incements (every change follows with a delay of 0.3 seconds):
0.01→0.02→0.03→0.04→0.05→0.06→0.07→0.08→0.09(carry-over)
0.10→0.20→0.30→0.40→0.50→0.60→0.70→0.80→0.90 (carry-over)
1.00→2.00→3.00→4.00→5.00→6.00→7.00→7.50 (Max value reached)
If the value will exceed the range limits (in this case from 7.00 to 8.00) the value will be truncated to the
maximum allowed value, 7.50 in this particular example. The Symbol will become blank and the
meter does not react on the corresponding navigation key. The values can only be changed down to 0.00
using the other key.
