Icebreeze PORTABLE AIR CONDITIONER & COOLER User manual

PORTABLE AIR CONDITIONER & COOLER
OWNER’S MANUAL

The patent-pending portable air
conditioner and ice cooler is designed
to keep you and your beverages cool:
• The lake or beach
• The Boat
• Youth sports
• On the job
• Travel
Welcome To Your New IcyBreeze
Helpful Hints
When using the IcyBreeze as an air conditioner, for best
results the use of blocked ice is recommended in your
IcyBreeze unit. e use of ice from self-serve ma-
chines may not perform as well as block ice in your
unit. IcyBreeze has also found that freezing gallon jugs
with water and placing them inside the unit along with
cubed ice lengthens cooling time. Be sure to ll water
to the “Minimum Water Fill” line.
• To avoid danger of suocation,
dispose of plastic packaging bag;
keep away from children and pets.
• Do not use dry ice. Use of dry ice in
an enclosed area can cause serious
injury or death.
• Do not operate your unit if any
power supply cords are damaged.
• Do not sit or stand on the unit.
• Be sure to secure the unit while
traveling in any moving vehicle.
• Keep the outow vent clear of
any obstructions.
• Do not add salt to any part of the
unit. Salt will cause damage.
• Always pull the unit by the handle,
do not push.
• Empty excess water before liing up
on the handle, water could pour out.
• Do not immerse the unit in water.
• Do not let the unit run dry, as this
could damage the pump.
• Liing too high on the pull handle
could result in tipping and loss of
contents.
• Do not store with lid open.
Safety First
1

3 Speed
Fan Switch
Pull Handle
Drain
Wheel
Cup Holders Multi-Directional Vent
Remote Cord &
Battery Charger
Receptacles
Stay Put
Flexi-Hose
38 quart interior
Interior dimensions:
L-18.5” W-11.25” D-11”
Exterior dimensions:
L-23” W-16.25” H-18.5”
Dry weight: 21 lbs.
The IcyBreeze Unit
2

Unpacking Your IcyBreeze
Take your IcyBreeze unit out of its protective
plastic bag and safely dispose of the plastic
bag. Plastic bags can be hazardous to children
and pets. Unwrap and prepare all chargers and
accessories purchased with your IcyBreeze. En-
sure that all parts and pieces are removed from
the IcyBreeze packaging (box and bag) before
discarding.
Charge Your Battery
Locate your 12 Volt battery charger that is
included with your IcyBreeze. Plug the charger
into the control panel on the top of the Icy-
Breeze lid to begin charging the battery pack.
1) Make sure that the charger’s solid red light is
on. is light indicates that your battery pack is
charging and will be ready in approximately 6
to 8 hours. Charging times may vary. 2) A solid
green light indicates a full charge. 3) If the light
is ashing green, check to make sure unit is o,
check connections. If the light is ashing red,
allow more time to charge (See Page 6).
Other Power Options
If you purchased the optional 12 V automotive
continuous power adapter or 110 V continuous
power wall adapter, you can use your IcyBreeze
immediately without charging the battery pack
completely. Please note: e 12 V automotive
and 110 V adapters will not charge the battery
pack. Follow the rest of the directions for lling
the cooler before turning the unit on.
Battery Charger Outlet
110 V Power Adapter
& 12 V Power Adapter
Installation & Setup
3

Filling Your Cooler
Before lling your IcyBreeze cooler, make sure
the drain plug is properly tted to the drain
tube. Next, ll the unit with approximately 2 1/2
quarts of cold tap water or until the water level
covers the “Minimum Water Level” line clearly
marked inside the unit. Adding hot water will
reduce cooling performance. is will ensure
optimum operation.
Fill the IcyBreeze with the desired amount of
ice. Do not use dry ice. is can cause serious
health risks and even death. Be sure not to
overll the cooler; the lid should close with-
out impacting any ice. e unit holds up to 30
pounds of ice.
Using Your Portable
Air Conditioner
By this step, your IcyBreeze should have power,
water, and ice. Turn the switch to one of the
three fan positions to start your IcyBreeze. It
takes the pump about 20 seconds to run water
through the cooling system. Once the ice begins
cooling the water, you should begin to feel cool
air. e air of the IcyBreeze comes out through
the vent or you may also pull the exible vent
tube to direct the airow.
Minimum Water
Level Line
3 Speed Fan Switch
Installation & Setup
4

Battery & Charging
Battery and Charger
When fully charged, your IcyBreeze
is designed to operate up to 6 hours
on low, 4 hours on medium, and 2.5
hours on high speed. Actual perfor-
mance may vary. e charger that
comes with your IcyBreeze is a smart
charger designed specically for
use with an IcyBreeze unit. Do not
attempt to use this charger with any
other devices. Do not attempt to use
any other charging unit or device on
your IcyBreeze. Damage to your unit
and/or charger could occur.
Upon opening your unit, IcyBreeze
recommends that you immediately
charge the battery with the charger
provided for a minimum of 6 hours,
or until the light on your charger
turns solid green, which indicates a
full charge.e maximum charge time
is 8 hours. e unit cannot be le to
charge for long periods of time. Aer
8 hours, the charger must be reset by
being unplugged from the unit.
Charger Indicator Lights
Solid Green: Fully charged
Solid Red: Battery is above 5 V, and
is properly charging
Flashing Green: Unit is not turned
o, charger not connected properly
Flashing Red: Battery is below 5 V,
allow more time to charge. If a red
ashing light persists aer several
hours of charging, please contact
IcyBreeze for assistance.
Storing Your IcyBreeze
If you are storing your IcyBreeze for
an extended amount of time, it is
best stored in a cool, dry location.
Do not expose the battery pack or
other electrical components to long-
term direct sunlight or temperature
extremes. Your IcyBreeze should be
stored in temperatures between 35 to
120 degrees Fahrenheit.
e battery pack will deplete in 30 to
60 days and will need recharging be-
fore use. Simply plug in your provided
charger and charge the battery for a
minimum of 6 hours, or until the light
on your charger turns solid green,
which indicates a full charge.
Battery Specications
Chemistry: Nickel Metal Hydride
Nominal Voltage: 12 V DC 10Ah
Amp Draw:
1.7A Low, 2.5A Medium, 4A High
Charge Time:
Up to 5 hours on dead battery
Charge Lasts:
6 hours Low, 4 hours Medium,
2.5 hours High
5

Optional Power Adapters & Accessories
Optional IcyBreeze Adapters
e IcyBreeze unit currently has two op-
tional power source adapters available for
purchase. e 12 V adapter plugs into all
standard cigarette and power adapters. is
12 V adapter automatically bypasses the in-
ternal battery pack to power your IcyBreeze
unit directly. e 12 V adapter will not
charge your battery pack. e battery pack
can only be charged with the 110 V battery
charger provided with the IcyBreeze unit at
time of purchase.
e 110 V power adapter is designed to
plug into standard U.S. wall receptacles. It
is not designed for use with non-U. S. wall
plug-ins. e 110 V power adapter will au-
tomatically bypass the internal battery pack
and run your IcyBreeze directly. e 110 V
adapter will not charge your battery pack.
e battery pack can only be charged with
the unit at the time of purchase.
Using the Corded Remote
A corded remote switch is available as an
accessory with your IcyBreeze unit. Simply
plug in the remote switch to its receptacle
on the control panel, then turn on your unit
to the desired fan speed. You can now switch
the power on and o remotely.
12 Volt Power Adapter
110 Volt Power Adapter
4 Foot Hose Extension Kit
Corded Remote
110 V - 12 V Wall Charger
6

Troubleshooting
I hear a loud whining noise.
If you hear a loud whine, this is an indication that
the pump is running dry. Make sure the unit has
been lled with water to the minimum ll line
with 2 quarts of water.
Battery will not charge.
(See page 5 for more information) Check to make
sure the unit is turned o. e unit is o when
the switch wheel has been rotated all the way
forward to the bare position on the switch. Be
sure the connection to the charging unit is tted
properly to the control panel and the charge plug
is locked into the panel.
Check that the LED light on the charger is solid
red, this indicates the battery pack is charging. If
a ashing red light is indicated aer checking the
above, the battery has dropped below 5 V and is
in trickle charge mode until the battery reaches
5 V. It will then switch to a solid red light indicat-
ing that the unit is charging.
If a ashing green light is present on the charger,
conrm that the charger is tted properly to the
control panel and that the unit is in the o posi-
tion. If issue persists, please contact IcyBreeze.
Submersible Pump
Charger LED Lights
7

Troubleshooting
There is no air blowing.
e fan gets its power from the battery pack or
continuous power. If you are going to run the
unit on battery power, be sure the battery pack is
fully charged. e solid-state control panel does
not contain any user-serviceable parts. If you are
experiencing diculties, contact IcyBreeze.
IcyBreeze not cooling effectively.
• Make sure the lid is closed. Do not run unit
with the lid opened.
• Check that there is sucient ice and appropri-
ate water level up to the “Minimum Water Fill”
line inside cooler.
• Check to see if the fan is working properly at
all three speeds.
• Check to see if the water is owing from the
return line.
• Check that there are no obstructions at the
bottom of the pump cover.
• Turn the unit o and then on, allow 20 seconds
for the water to ow through the system and
come out of the discharge hose aer turning
the unit back on.
• IcyBreeze contains a submersible pump that
has been tested before installation. e pump
does not contain any user-serviceable parts.
• If ow or cooling does not resume, then please
contact IcyBreeze.
Radiator
Fan Switch Off
8

Return Policy
Return Policy
An Icybreeze unit and/or accessories may be returned for
credit or refund within 30 days from date of purchase. Units
being returned must be in resalable condition. Damaged units
are not eligible for return or refund. IcyBreeze reserves the
right to review each return request based on its sole discretion.
Step One: Call IcyBreeze to process a return
To process a return, please call us at 918-970-2300 to obtain
a return authorization rst. IcyBreeze will then help you with
steps needed to properly return a unit.
Step Two: Shipping the unit back to IcyBreeze
e unit being returned should be packed in an appropriately
prepared box or in our original manufacturer’s box, complete
with the owner’s manual and all components (if applicable).
A copy of the original order showing purchase and the return
authorization with reason for return must accompany the
article. Please do not mail purchase information in letter form
under separate cover. Shipping should be prepaid. IcyBreeze
can’t accept COD shipments at our facility. Also, IcyBreeze
won’t refund shipping costs unless it is a manufacturers defect.
Step ree: Processing the credit
e original credit card used to make the purchase will be
credited the purchase price plus any tax charged.
All returns must be shipped to:
IcyBreeze, LLC
Attn: Returns Department
14989 S. Grant St.
Bixby, OK 74008
9

Cleaning Your IcyBreeze
e IcyBreeze functions best when kept clean. Aer use, pull
the drain plug and be sure to drain any remaining water from
the cooler area of the unit. e outside and inside surfaces of
the IcyBreeze can be cleaned with most mild cleaning solu-
tions and rinsed thoroughly aerwards. Store the unit in a
cool, dry area at temperatures above 35 degrees Fahrenheit to
avoid water freezing in the unit.
IcyBreeze recommend periodically running the system using
a white vinegar and water solution in the areas of the country
with hard water. ese mineral deposits can build up in the
pump, tubing, and radiator reducing heat exchange eciency
and possibly plugging the system.
Specications
Holds 30 lbs. of ice
38 qt. interior holds 49 cans
Interior dimensions: L-18.5”, W-11.25”, D-11”
Exterior dimensions: L-23”, W-16.25”, H-18.5”
Dry weight: 21 lbs.
Storage & Cleaning
10

IcyBreeze products and accessories are
guaranteed against manufacturing de-
fects for one year from the original date
of purchase, excluding the battery which
has a 90 day warranty.
IcyBreeze’s sole obligation in the event of
such defects during this period is to repair
or replace the defective item with a com-
parable item at IcyBreeze’s sole discretion.
Except for such repair or replacement, the
sale, processing or other handling of this
product is without warranty, condition or
other liability even though the defect or
loss may be caused by negligence or other
fault. Damage resulting from use, accident,
or normal wear and tear is not covered by
this or any warranty. IcyBreeze assumes no
liability for any accident, injury, death, loss,
or other claim related to or resulting from
the use of this product. In no event shall
IcyBreeze be liable for incidental or con-
sequential damages relating to or resulting
from the use of this product or any of its
parts or accessories. is limited warranty
covers all defects encountered in normal
use of the products, and does not apply in
the case of loss of or damage to the product
due to abuse, mishandling, improper
installation by you, improper packaging by
you, alteration, accident, failure to follow
operating, maintenance or environmental
instructions prescribed in IcyBreeze’s user
manual, use of parts or supplies that cause
damage to the product, or services per-
formed by someone other than IcyBreeze
or an IcyBreeze authorized service provider
for the product. Returns or replacements of
products and/or accessories may be subject
to shipping, handling, replacement and/or
restocking fees.
Warranty
IcyBreeze, LLC
14989 S. Grant St.
Bixby, OK 74008
918-970-2300
1-855-216-6300
www.icybreeze.com
