iCeeO2 700 User manual

www.iCeeO2.com 1 iCeeO2-700_A009D_US_076c.UserMan.doc
Product may vary from picture.
To ensure safety, please read this manual carefully before installation and
follow the instructions herein.
Store this manual in a secure place for future reference
WARNING: CHOKING HAZARD - Accessories contain small parts
Printed by color ink, water will smudge.
Contents
Getting Started............................................2
Package Contents........................................2
Features at a Glance ...................................2
Operating Instructions ................................2
LCD Display..................................................3
Trend Chart..................................................4
Trend Chart Zoom....................................... 4
Max/Min...................................................... 4
LED Display.................................................. 4
Main Menu Functions................................. 5
CRR .............................................................. 7
Specifications .............................................. 7
Instruction manual
CO2/ Temp / RH Monitor
models -700

www.iCeeO2.com 2 iCeeO2-700_A009D_US_076c.UserMan.doc
Getting Started
Hello there! Congratulations on your new iCeeO2product! Our products are packaged
and shipped with the utmost care. In the unlikely event that your item is incorrect,
incomplete, or unsatisfactory, please contact us and we will see to fix it immediately. Feel
free to contact us with any questions, comments, or concerns at www.iCeeO2.com.
Package Contents
CO2 Monitoring Unit
Micro USB Cable for power x2
AC adapter (optional)
User Manual
Rope Strap; Screws
Features at a Glance
CO2/Temperature/RH Monitor; Tracer
Chart with variable time Zoom Levels
2-Channel Low Drift NDIR Sensor
Build-In Plant Types Directory
3 color LEDs for Easy-Reading
Foolproof “Hold Home”function
CRR, CO2 Replenish Reminder
Operating Instructions
Initial Setup : When first unboxing, plug in the unit to the included Micro USB (or one of
your own) to almost any cell phone charger or USB power source. If successfully
connected, 3 things will happen while booting up:
3 LEDs flash one by one
Chart display shows the current software version & “Warm Up”
Main display shows a countdown from 10
Once the countdown is complete, your product is ready to use. No initial setup or
calibration is needed.
1. Deploy the Stand 2.Plug in USB Power Cable

www.iCeeO2.com 3 iCeeO2-700_A009D_US_076c.UserMan.doc
LCD Display
1. CO2 Chart
1A. x10 multiplier for ppm reading
2. Max Reading of Chart
3. Indicates what the chart will show:
CO2, TEMP or RH
4. Automatic cycle between CO2, RH,
and Temperature on the chart
5. Min Reading of Chart
6. Plant or Human mode
7. Audible Alarm On/Off
8. Main Menu
9. Temperature Reading
11. RH Reading
12. CO2 Reading
13. Time per Division –indicates the
chart’s time per unit division
14. Automatic cycle between zoom
levels of time
15. Zoom Level of Time –indicates the
chart’s span of time
16. Good Zone Indicator
CO2, Temperature, RH Readings
The device has three built-in main measureable parameters: ambient carbon dioxide(12),
temperature (9), and RH (11). They are constantly displayed on screen.

www.iCeeO2.com 4 iCeeO2-700_A009D_US_076c.UserMan.doc
Trend Chart
The trend chart (1) displays the past readings for any of the three parameters
(CO2/Temp/RH). There are 4 modes that can be toggled by using UP key: CO2, TEMP,
RH, and Cycle (automatically cycles through CO2/Temp/RH), as shown below.
Trend Chart Zoom
Below is a table that show the available Zoom Levels for all parameters CO2/Temp/RH,
as well as the duration of each division for corresponding Zoom Levels:
Zoom Level
(Time Span) (15)
Time Per
Division(13)
1m (minute)
5sec /div
1h (hour)
5m/div
1d (day)
2h/div
1w (week)
0.5d/div
Auto Cycle Zoom
Cycle
Using DOWN will toggle the available Zoom Levels for each parameters. Note that in
addition to the Zoom Levels for each parameter, there is an option that will
automatically cycle between the Zoom Levels. This can be achieved just by pressing
DOWN until icon(14) appears at the bottom left of the chart.
Max/Min
At the top right corner of the display, there are two numerical indicators: Max (2)and Min
(5). As the Zoom Level is changed, the Max and Min values will reflect the maximum and
minimum values on the chart of the selected parameter(CO2; Temp and RH). At startup,
the unit will automatically display values for CO2.
LED Display
at Plant Mode

www.iCeeO2.com 5 iCeeO2-700_A009D_US_076c.UserMan.doc
at Human Mode
Main Menu Functions
The Main Menu (8) functions can be toggled through by using MENU. If the main menu
is not brought up, the green bar will remain blank, leaving the UP and DOWN buttons
to toggle between parameters and Zoom Levels, respectively.
Pressing MENU once will bring up the main menu, with an underlining flashing bar
indicating the current choice.
To select the function, press ENTER when it is underlined by the flashing bar. Note that
after 1 minute if nothing is pressed, the Main Menu will disappear and the device will
revert to the normal state.
HOLD HOME
To revert to start up settings at any point, hold ENTER for 3 seconds until an audible
beep. The device will revert to Home Setting, as if the power was reset, displaying “Back
Home done.” Note that this is not the same as Restore to factory settings.
Below is a table showing what main menu selection is made by pressing MENU multiple
times as well as their functions. Note that the device will display “Done,” followed by the
confirmed selection if selected correctly.
Function
Directions
ALARM
By default , an audible alarm will resound if the CO2 level exceeds

www.iCeeO2.com 6 iCeeO2-700_A009D_US_076c.UserMan.doc
varying levels in Plant Mode (depending on the plant selection) or
1000ppm in Human Mode.
Once ALARM is selected (by pressing ENTER), use either UP or DOWN
to toggle the selection from ON to OFF or vice versa. Press ENTER one
more time to confirm. A regular bell icon will be displayed if alarm is on;
a silenced bell icon will appear on the screen if the alarm is set to be off.
PLANT
This function allows the user to select between types of plants for
optimal setting. Once selected, the chart area will display the current
plant setting. Use UP and DOWN to toggle to the desired plant. In
order, the selections are: Bean, Chillies, Custom Plant, Cucumber,
General Plant, Grape, Orchid, Potato, Strawberry and Tomato. Press
ENTER on the desired plant to confirm. Note that selecting a plant will
automatically change the unit’s mode to For Plant instead of For Human.
To change it back, see function ADV.
With Custom Plant, the user can define the low and high Good zone for
custom optimum CO2 levels. After selecting this option, Low Good Zone
selection will appear. Press ENTER, then use UP and DOWN to define
Low. Press ENTER to confirm.
The device will now emit alarms (if enabled) and display the 3
corresponding LED indicators according to the defined range.
LOG
This feature allows the user to see historical data recorded in the log at
any point that is displayable on the chart. First make sure the desired
Zoom Level is selected before enabling this function. Then once LOG is
enabled, use UP and DOWN toggle between the time divisions to see
all parameters’ measurements for each division. Press ENTER once more
to exit this mode.
CALI
Use this function to calibrate your device with outside atmospheric CO2
level ~ 400ppm. Select this mode, hold ENTER for 3 seconds until a beep
and the chart will read “Calibrating”, then place the device outside for
20min. To escape, press MENU. Make sure the device is far from a source
of CO2, not in direct sunlight, and not exposed to water.
ALTI
This feature provides an altitude correction to the CO2 level for
increased accuracy. Select this feature, then use UP and DOWN to input
the current altitude (look it up if unknown) in meters. Press ENTER once
altitude is correct.
ºC/ºF
Use this feature to toggle between Celsius and Fahrenheit for the
temperature display. First use UP and DOWN, then ENTER when the
desired one is selected.
ADV
This function toggles between 3 things when selected: changing the
alarm and lights to suit levels For Plant, or For Human, or Restore factory
setting.
Restore factory setting will reset the device to factory settings and erase
all stored data in the chart. To use any of these modes, press ENTER
when the desired mode is selected. Then use UP and DOWN to toggle
Yes, then press and hold ENTER for 3 seconds until an audible beep
Select NO to exit the main menu.
(Return)
Exits the main menu. No options will be displayed on the green bar. A
different audible beep be heard in this option.

www.iCeeO2.com 7 iCeeO2-700_A009D_US_076c.UserMan.doc
CRR
Predicts the remaining CO2 supply and reminds the user to add or replace the CO2
generator. For example, hydrocarbon fuel, fermentation (sugar + yeast), etc.
in case CRR is Available:
in case CRR is Not Available(not stable; difficult to predict):
Specifications
Typical test conditions, unless otherwise specified: Ambient Temp =23+/-3°C,
RH=50%-70%, Altitude=10meter
Measurement
Specifications
Operating Temperature
32°F to 122°F (0°C to 50°C)
Storage Temperature
-4°F to 140°F (-20°C to 60°C)
Operating & Storage RH
0-95%, non-condensing
CO2Measurement
Accuracy at 0~3000ppm
±50ppm or ±5% of reading, whichever is greater
Accuracy over 3000ppm
±7% when >3000ppm
Repeatability
20ppm at 400ppm (standard dev. of 10 readings in 1 minute)
Measurement Range
0-5000ppm
Display Resolution
1ppm (0-1000); 5ppm (1000-2000); 10ppm (>2000)
Temp Dependence
±0.1% of reading per °C or ±2ppm per °C, whichever
is greater, referenced to 25°C
Pressure Dependence
0.13% of reading per mmHg (corrected by user’s
altitude input)
Response Time
<2min for 63% of step change or <4.6min for 90%
step change
Warm-up Time
<30 sec
Temp Measurement

www.iCeeO2.com 8 iCeeO2-700_A009D_US_076c.UserMan.doc
Operating Temperature
32°F to 122°F (0°C -50°C)
Display Resolution
0.2°F (0.1°C)
Accuracy
±1°F (±0.5°C)
Response Time
<20min (63%)
RH Measurement
Range
0-100%
Accuracy
±5%
Resolution
1% on Main Reading, 0.1% on Max Min Reading
Power Requirements
160mA Peak, 15mA average at 5.0V
Battery Life
Battery is not included.
below is calculation by theory: (reference only, not a
guarantee)
For 5000mAh battery, 200Hr/8.3day
For 8000mAh battery, 400Hr/16.6day
Dimension
120*91.2*27mm (4.7*3.6*1.1inch)
Weight
148g ( 5.22oz) Device only, AC Adapter not included
Rear View:
Disclaimers:
USB connection is for power supply only; no communication with PC. Unplugging the device may result in loss of
most recent logged data on the chart.
This device is not intended for workplace hazard CO2 monitoring, nor intended as a definitive monitor for human
or animal health institutions, life sustenance, or any medical-related situation.
iCeeO2and the manufacturer assumes no responsibility for any damage or loss suffered by the user or any third
party arising through the use of this product or its malfunction.
iCeeO2reserve the right to change without notice.
* * * *
