ICOP Technology VEX-6225 User manual

User Manual
VEX-6225
with
DM&P Vortex86EX
400MHz processor
Version 1.0

VEX-6225 User Manual
ICOP Technology Inc. I
Copyright
The information in this manual is subject to change without notice for
continues improvement in the product. All rights are reserved. The
manufacturer assumes no reasonability for any inaccuracies that may be
contained in this document and makes no commitment to update or to keep
current the information contained in this manual.
No part of this manual may be reproduced, copied, translated or transmitted,
in whole or in part, in any form or by any means without the prior to written
permission of ICOP Technology Inc.
ⓒCopyright 2017 ICOP Technology Inc
Trademarks Acknowledgement
Vortex86EXTM is the registered trademark of DM&P Electronics Inc.
Other brand names and product names that appear in this document are the
properties and registered trademarks of their respective owners. All names
mentioned herewith are served for identification purpose only.

VEX-6225 User Manual
ICOP Technology Inc. II
Revision History
Revision
Date
Remark
1.0
May 22, 2017
First version release

VEX-6225 User Manual
ICOP Technology Inc. III
Table of Contents
1General Information...........................................................................................1
1.1 Overview....................................................................................................................................... 1
1.2 Block diagram................................................................................................................................ 2
1.3 Specifications.................................................................................................................................4
1.4 Ordering Information.................................................................................................................... 6
1.4.1 VEX-6225 ............................................................................................................................... 6
1.4.3 SATA DOM............................................................................................................................ 6
2Hardware Information .......................................................................................7
2.1 Dimension..................................................................................................................................... 7
2.2 Board Outline................................................................................................................................ 9
2.3 Connector Location.....................................................................................................................10
2.4 Connector and Jumper Summary.................................................................................................12
2.5 Pin Assignments & Jumper Settings.............................................................................................13
J3: RS232/485 Switch .................................................................................................................... 13
J4: SATA DOM .............................................................................................................................13
J5: USB1 ........................................................................................................................................ 13
J6: SATA DOM POWER ..............................................................................................................13
J7: USB2 ........................................................................................................................................ 13
J9: CAN BUS................................................................................................................................. 13
J10: MiniPCI Express....................................................................................................................... 2
J12: MiniPCI Express....................................................................................................................... 2
J13: MiniPCI Express....................................................................................................................... 3
J14: I2C............................................................................................................................................ 3
J15: PS/2 Keyboard ......................................................................................................................... 3
J16: PS/2 Mouse .............................................................................................................................. 3

VEX-6225 User Manual
ICOP Technology Inc. IV
J17: ADC ......................................................................................................................................... 4
J18: VGA ......................................................................................................................................... 4
J19: LCD.......................................................................................................................................... 4
J20: LCD Backlight Control ............................................................................................................. 4
J22: Expansion I/O ......................................................................................................................... 5
J24: Power........................................................................................................................................ 5
J28: LCD Backlight .......................................................................................................................... 5
3Software Resources...........................................................................................16
3.1 ICOP Technical Resource Website .............................................................................................. 16
Technical Support Directly from ICOP................................................................17
User Manual Feedback .............................................................................................17
Warranty......................................................................................................................18

VEX-6225 User Manual
ICOP Technology Inc. 1
1 General Information
1.1 Overview
The VEX-6225 family of low-power x86 embedded controller is designed to
meet 3.5” specification with backward compatibility to provide migration
path for projects facing end-of-life challenges with their existing x86 based
3.5” controller.
In addition, the VEX-6225 family of controller is designed as a plug in
replacement, with backward compatibility to support legacy software to help
extend existing product life cycle without heavy re-engineering.
The VEX-6225 is suitable for broad range of data-acquisition, industrial
automation, process control, automotive controller, AVL, intelligent vehicle
management device, medical device, human machine interface, robotics,
machinery control and more

VEX-6225 User Manual
ICOP Technology Inc. 2
1.2 Block diagram
VEX-6225-43VE

VEX-6225 User Manual
ICOP Technology Inc. 3
VEX-6225-43EE

VEX-6225 User Manual
ICOP Technology Inc. 4
1.3 Specifications
Processor
DM&P SoC CPU Vortex86EX –400 MHz
L1: I/D-Cache 16/16KB, L2: 128KB
RAM
512MB DDR3 Onboard
BIOS
Coreboot BIOS
Bus
MiniPCI Express x3 (Optional)
Expansion I/O x1 [USB x3 + 8-GPIO x4] (Optional)
Display
Integrated 2D VGA chip
VGA and TFT Flat Panel Interface Support
VGA: Maximum resolution up to 1024 x 768 @ 60Hz
LCD: Maximum resolution up to 1024x768 @ 60Hz
LAN
Integrated 10/100Mbps Ethernet
Audio
None
PWM
None
Flash Disk
Support
SATA DOM
Micro SD
I/O Interface
SATA 7P connector x1
Micro SD slot x1
SIM Card slot x1
VGA port x1
LCD connector x1
8-CH 11-bit ADC port x1
USB port (Ver. 2.0) x2
RS232 port x1
RS232/485 port x1
CAN BUS port x1
I2C port x1

VEX-6225 User Manual
ICOP Technology Inc. 5
Connectors
MiniPCI Express connector x3
1.2mm 6-pin wafer for I2C x1
2.0mm 56-pin female connector x1
2.0mm 10-pin box header for VGA x1
2.0mm 44-pin box header for LCD x1
2.0mm 10-pin header for ADC x1
2.54mm 3-pin header for CAN BUS x1
2.54mm 5-pin header for Mouse x1
2.54mm 2-pin header fro RS232/485 Switching x1
External D-Sub 9-pin male connector for RS232 x1
External D-Sub 9-pin male connector for RS232/485 x1
External RJ45 connector for Ethernet x1
2-pin power terminal connector x1
2-pin power connector for SATA DOM x1
7-pin SATA connector for SATA DOM x1
Power
Requirement
+12 to 24V DC Input
+12V DC Input @ 200mA (Typical)
Weight
165g
Dimensions
102mm x 146mm (4.01 x 5.75 inches)
Operating
Temperature.
-20℃~ +70℃
-40℃~ +85℃(Optional)
Operating
System Support
DOS, Windows CE6.0/Embedded Compact 7
X-Linux, Linux, QNX, VxWorks, FreeBSD

VEX-6225 User Manual
ICOP Technology Inc. 6
1.4 Ordering Information
1.4.1 VEX-6225
Product Name
VGA
LCD
MiniPCI Express
VEX-6225-43VE
V
V
VEX-6225-43EE
V
1.4.3 SATA DOM
Product Name
MLC
SLC
0℃~ +70℃
-40℃~ +85℃
SDM-SST-2G-H-M
V
V
SDM-SST-4G-H-M
V
V
SDM-SST-2G-H-S-X
V
V
SDM-SST-4G-H-S-X
V
V
SDM-SST-8G-H-S-X
V
V
ISATA-8G-H-M
V
V
ISATA-16G-H-M
V
V
ISATA-32G-H-M
V
V
ISATA-8G-H-M-X
V
V
ISATA-16G-H-M-X
V
V
ISATA-32G-H-M-X
V
V
ISATA-1G-H-S
V
V
ISATA-2G-H-S
V
V
ISATA-4G-H-S
V
V
ISATA-8G-H-S
V
V
ISATA-16G-H-S
V
V
ISATA-16G-H-S-X
V
V

VEX-6225 User Manual
ICOP Technology Inc. 7
2 Hardware Information
2.1 Dimension
Front

VEX-6225 User Manual
ICOP Technology Inc. 8
Back

VEX-6225 User Manual
ICOP Technology Inc. 9
2.2 Board Outline
SOM200EX Module
COM1
LCD
Connector
VGA
A/D
CAN Bus
I2C
PS/2 Mouse
PS/2 Keyboard
Extension I/O
(Optional)
SIM Card Slot
SATA DoM
Power Connector
SATA DoM Connector
RS232/485 Switch for COM2
MiniPCI Express (Optional)
+12~24V DC In
COM2
LAN
USB
Reset
MiniPCI Express (Optional)
Micro SD

VEX-6225 User Manual
ICOP Technology Inc. 10
2.3 Connector Location
Front
J3
J26A
J24
J25
J5
J7
J4
S1
J10
J20
J19
J28
8
J17
J19
J14
J15
J16
J22
J11
J12
J6
J18
J26B

VEX-6225 User Manual
ICOP Technology Inc. 11
Back
J13
J8

VEX-6225 User Manual
ICOP Technology Inc. 12
2.4 Connector and Jumper Summary
Nbr.
Name
Type of Connections
Pin Nbr
J3
RS232/485 Switch
Pin Header, 2.54mm, 2x1
2
J4
SATA DOM
SATA 7P Connector, 7x1
7
J5
USB1
Type A USB connector
4
J6
SATA DOM Power
Box Header, 2.0mm, 1x2
2
J7
USB2
Type A USB connector
4
J8
Micro SD Slot
J9
CAN BUS
Pin Header, 2.54mm, 1x3
3
J10
MiniPCI Express
(for USB Form Factor
3G/4G Module Only)
Standard MiniPCI Express Connector
52
J11
SIM Card Slot
8
J12
MiniPCI Express
Standard MiniPCI Express Connector
52
J13
MiniPCI Express
Standard MiniPCI Express Connector
52
J14
I2C
Wafer, 1.25mm, 1x6
6
J15
PS/2 Keyboard
Box Header, 2.54mm, 1x5
5
J16
PS/2 Mouse
Box Header, 2.54mm, 1x5
5
J17
ADC
Pin Header, 2.0mm, 8x2
16
J18
VGA
Box Header, 2.0mm, 5x2
10
J19
LCD
Box Header, 2.0mm, 22x2
44
J20
LCD Back Light Control
J22
Expansion I/O
Box Header, 2.0mm, 28x2
56
J24
Power
Terminal Block, 2x1
2
J25
LAN
RJ45 Connector
J28
LCD Backlight
Pin Header, 2.0mm, 1x2
2

VEX-6225 User Manual
ICOP Technology Inc. 13
2.5 Pin Assignments & Jumper Settings
J3: RS232/485 Switch
Pin#
Single Name
1.
GND
2
RS485
OPEN: Enable RS232
CLOSE: Enable RS485
J4: SATA DOM
Pin#
Single Name
Pin #
Single Name
1.
GND
2
TX+
3
TX-
4
GND
5
RX-
6
RX+
7
GND
J5: USB1
Pin#
Single Name
Pin #
Single Name
1.
VCC
2
LUSBD1-
3
LUSBD1+
4
GND
5
NC
6
GND
7
GND
8
NC
J6: SATA DOM POWER
Pin#
Single Name
Pin #
Single Name
1.
VCC
2
GND
J7: USB2
Pin#
Single Name
Pin #
Single Name
1.
VCC
2
LUSBD3-
3
LUSBD3+
4
GND
5
NC
6
GND
7
GND
8
NC
J9: CAN BUS
Pin#
Single Name
1.
CAN_H
2
CAN_L
3
GND

VEX-6225 User Manual
ICOP Technology Inc. 2
J10: MiniPCI Express
Pin#
Single Name
Pin #
Single Name
1.
NC
2
+.3.3VAUX
3
NC
4
GND
5
NC
6
GPIO_0
7
NC
8
UIM_PWR
9
GND
10
UIM_DATA
11
REFCLK-
12
UIM_CLK
13
REFCLK+
14
UIM_RESET
15
GND
16
UIM_VPP
17
NC
18
GND
19
NC
20
W_DISABLE#
21
GND
22
PERST#
23
PERn0
24
+3.3VAUX
25
PERp0
26
GND
27
GND
28
+1.5V
29
GND
30
NC
31
PETn0
32
NC
33
PETp0
34
GND
35
GND
36
USB_D-
37
GND
38
USB_D+
39
+3.3VAUX
40
GND
41
+3.3VAUX
42
LED_WWAN#
43
GND
44
GPIO_1
45
CTS
46
GPIO_3
47
RTS
48
GPIO_2
49
RXD
50
GND
51
TXD
52
VDD3
J12: MiniPCI Express
Pin#
Single Name
Pin #
Single Name
1
NC
2
+3.3VAUX
3
NC
4
GND
5
NC
6
NC
7
NC
8
NC
9
GND
10
NC
11
REFCLK-
12
NC
13
REFCLK+
14
NC
15
GND
16
NC
17
NC
18
GND
19
NC
20
NC
21
GND
22
PERST#
23
PERn0
24
+3.3VAUX
25
PERp0
26
GND
27
GND
28
NC
29
GND
30
NC
31
PETn0
32
NC
33
PETp0
34
GND
35
GND
36
NC
37
GND
38
NC
39
+3.3VAUX
40
GND
41
+3.3VAUX
42
NC
43
GND
44
NC
45
NC
46
NC
47
NC
48
NC
49
NC
50
GND
51
NC
52
+3.3VAUX
(for USB Form Factor
3G/4G Module only)
