VEHICLE WIRE REFERENCE CHART
T-Harness Wires Vehicle Wires
Wire
Tag
Wire
Color Speaker Wire Description Component
Position
LEFT FRONT 1 White Left Front Mid (+) 1
White/Black Left Front Mid (-)
LEFT FRONT 2 White Left Front Tweeter (+) 5
White/Red Left Front Tweeter (-)
RIGHT FRONT 1 Gray Right Front Mid (+) 2
Gray/Black Right Front Mid (-)
RIGHT FRONT 2 Gray Right Front Tweeter (+) 6
Gray/Red Right Front Tweeter (-)
LEFT REAR 1 Green Left Rear Mid (+) 12
Green/Black Left Rear Mid (-)
LEFT REAR 2 Green Subwoofer 1 (+) 16
Green/Red Subwoofer 1 (-)
RIGHT REAR 1 Purple Right Rear Mid (+) 13
Purple/Black Right Rear Mid (-)
RIGHT REAR 2 Purple Subwoofer 2 (+) 16
Purple/Red Subwoofer 2 (-)
CENTER 1 Orange Left Rear Tweeter (+) 8
Orange/Black Left Rear Tweeter (-)
SUB 1 Black n/a
Black/White n/a
SUB 2 Black Right Rear Tweeter (+) 9
Black/Red Right Rear Tweeter (-)
SUB 3 Black n/a
Black/Yellow n/a
Amplifier location: Right end of dash
Note: The amplifier output colors and labels on the AR-CH2 T-harness do not correspond to the vehicle. For vehicle specific wiring
designation, follow this wiring chart.
