Zeiss ZHE Cube Assembly Procedure
2/12
Step
Action
1.1
Disassemble Cube
1.1.1
The cube assembly has two filter retainer rings; one is located on the Exciter side
and one is on the Emitter side as shown below.
1.1.2
Remove both filter retainer rings from the cube assembly.
1.1.2.1
The supplied retaining rings for the ZHE cube are installed shoulder side inward.
Remove the rings by gently grasping the slots with your finger tips. Applying even
pressure to the retaining ring slots, turn the ring outward (counterclockwise) to
remove from the cube assembly.
Emitter Retaining Ring
Exciter Retaining Ring
Slots

Zeiss ZHE Cube Assembly Procedure
3/12
Step
Action
1.1.2.2
Note that there are two distinctly different sides to the retainer rings. One is the
“flat” Shoulder Side and one is the Open Side.
The Open Side ALWAYS faces into the cube assembly and is tightened against the
installed filter. The Shoulder Side faces outward. The two sides are shown below for
reference.
Open Side Shoulder Side

Zeiss ZHE Cube Assembly Procedure
4/12
Step
Action
1.2
Install the Semrock Filter Set
1.2.1
The diagram below illustrates a cross section of the Zeiss ZHE cube for use in
orienting and installing the Exciter, Dichroic and Emitter filters into the cube
assembly. The cross section is for reference only to illustrate filter position and
orientation.
Filter Positions
The Emitter is located at the top of the cube assembly. Notice it is mounted at a slight angle.
The Exciter is located at the left side and the Dichroic is
mounted diagonally at the center of the cube and shares the
Emitter half of the assembly.
Filter Orientation
The filters are oriented in the assembly as follows:
The Exciter is mounted with its arrow pointing inward.
The Dichroic reflective side is mounted facing the Exciter
The Emitter is mounted with its arrow pointing outward.
Light passes through the cube in the direction of the arrows.
The arrows point toward the Anti-Reflective coatings on the
Emitter and Exciter filters.
Note: The Dichroic Reflective coating must face the Exciter as
shown in the cross section diagram.
Step
Action
Dichroic
Emitter
Exciter
ZHE Filter Positions
Dichroic reflective coating faces the Exciter

Zeiss ZHE Cube Assembly Procedure
5/12
Step
Action
1.2.2
Remove the two Flat Head screws to separate the cube halves. Set the screws aside
for reassembly later.
1.2.3
Separate the cube halves to prepare for assembly of the Semrock filter set.
Note that there are two prongs used to locate and hinge the cube housing and a metal
spring clip that is used to position and secure the Dichroic filter during assembly.
Remove
Screws
Hinge
Spring Clip

Zeiss ZHE Cube Assembly Procedure
6/12
Step
Action
1.2.4
Assemble the Dichroic/Emitter half of the cube first. The Dichroic is positioned
over the spring clip between the upright flanges at either end of the spring. Note that
the clip locating tab is inserted into the notch at the side of the cube assembly.
Note: Ensure the spring clip flanges face UPWARD.
1.2.5
Reflective “Coated Side”: The filter edge is concealed by the reflective coating and
appears colored all the way to the edge.
Anti-Reflective “Uncoated Side”: The filter edge appears uncolored.
Reflective Side Anti-Reflective Side
Locating Tab
Dichroic Mounting Area
Flanges face Up

Zeiss ZHE Cube Assembly Procedure
7/12
Step
Action
1.2.6
Install the Dichroic over the spring clip with the Reflective coated side facing up.
Center the filter within the mounting area between the mounting flanges. Once the
Dichroic is centered, insert the prongs of the hinge into the Exciter half of the cube
and carefully fold the cube together keeping the Dichroic centered in its mounting
area. Apply gentle pressure to the cube halves during assembly to retain the Dichroic
within the flanges of the spring clip.
Note: The cube halves should fit together flush and without interference at either
mounting surface.
Note: DO NOT rest the cube assembly on the Dichroic filter during assembly.
1.2.7
Check the alignment of the Dichroic and spring clip through the slots on the cube
side. Ensure the spring clip locating tab is flush within the slotted opening and the
Dichroic is aligned within the spring clip flanges. The spring clip should not be
visible in the screw holes or interfere with screw placement.
Carefully fold the cube together while
keeping the Dichroic centered in the spring
clip.

Zeiss ZHE Cube Assembly Procedure
8/12
Step
Action
1.2.8
Fasten the cube halves together using the two flat head screws removed previously.
Alternately tighten the screws until they are snug. Once snug, further tighten ¼ turn.
1.2.9
Orient the Emitter with the arrow pointing away from the cube as shown below.

Zeiss ZHE Cube Assembly Procedure
9/12
Step
Action
1.2.10
Place the filter inside the Emitter mounting area with the arrow pointing up.
Note that the filter shoulder side faces outward.
1.2.11
Insert the filter retaining ring open side into the Emitter mounting area of the cube.
Note that the cube threads are at an angle. This will require careful installation of the
retaining ring to avoid cross threading.
Using your fingers, carefully turn the ring while observing its position in the threads.
Keep the ring level across the threaded area while allowing the ring to tilt as it
threads inward. If the ring will not turn, it is not threaded properly – slowly turn the
ring out and try again. Do not force thread the ring as it will turn freely if oriented
correctly. Turn the ring inward until it starts to resist finger tightening.
Note the angle of the retaining ring threads in the photo below.

Zeiss ZHE Cube Assembly Procedure
10/12
Step
Action
1.2.12
Locate the the THORLABS SPX602 Spanner Wrench. The spanner wrench blades
are shown below.
1.2.13
Insert the spanner wrench blades into the slots of the Emitter retaining ring. Tighten
the ring snug against the Emitter filter. Once snug, tighten slightly further to secure.
Spanner wrench blades

Zeiss ZHE Cube Assembly Procedure
11/12
Step
Action
1.2.14
Orient the Exciter with the arrow pointing into the cube as shown below.
1.2.15
Position the cube with the Exciter mounting area facing upward as shown below.
Place the filter inside the Exciter mounting area with the arrow pointing in. Note that
the filter shoulder side faces outward.

Zeiss ZHE Cube Assembly Procedure
12/12
Step
Action
1.2.16
Insert the retaining ring open side into the Exciter mounting area of the cube. Using
your finger tips, carefully rotate the retaining ring to avoid cross threading. If the
ring will not turn, it is not threaded properly – slowly turn the ring out and try again.
Do not force thread the ring as it will turn freely if oriented correctly.
Using the Spanner Wrench, tighten the ring snug against the Exciter filter. Once
snug, tighten slightly further to secure. In the photo below, note the retaining ring
shoulder side faces outward.
1.2.17
Completed Zeiss ZHE Cube Assembly.
