Idis DC-T6224HRXL User manual

Network
Camera
Quick Guide
Powered by
DC-T6223HRL
DC-T6224HRXL
DC-T6223HRL-A
DC-T6224HRXL-A

2
Safety Precautions
1. Read Instructions
All the safety and operating instructions should be read before the
appliance is operated.
2. Retain Instructions
The safety and operating instructions should be retained for future
reference.
3. Cleaning
Unplug this equipment from the wall outlet before cleaning it. Do
not use liquid aerosol cleaners. Use a damp soft cloth for cleaning.
4. Attachments
Never add any attachments and/or equipment without the
approval of the manufacturer as such additions may result in the
risk of re, electric shock or other personal injury.
5. Water and/or Moisture
Do not use this equipment near water or in contact with water.
6. Placing and Accessories
Do not place this equipment on an wall or ceiling
that is not strong enough to sustain the camera. The
equipment may fall, causing serious injury to a child
or adult, and serious damage to the equipment. Wall
or shelf mounting should follow the manufacturer’s
instructions, and should use a mounting kit approved by
the manufacturer.
This equipment and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may cause the
equipment and cart combination to overturn.
Do not place this equipment in an enclosed space. Sucient
ventilation is required to prevent an increase in ambient
temperature which can cause malfunction or the risk of re.
7. Power Sources
This equipment should be operated only from the type of power
source indicated on the marking label. If you are not sure of the
type of power, please consult your equipment dealer or local
power company.
You may want to install a UPS (Uninterruptible Power Supply)
system for safe operation in order to prevent damage caused by
an unexpected power stoppage. Any questions concerning UPS,
consult your UPS retailer.
This equipment should be remain readily operable.
8. Power Cord
Operator or installer must remove power and TNT connections
before handling the equipment.
9. Lightning
For added protection for this equipment during a lightning storm,
or when it is left unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the antenna or
cable system. This will prevent damage to the equipment due to
lightning and power-line surges. If thunder or lightning is common
where the equipment is installed, use a surge protection device.
10. Overloading
Do not overload wall outlets and extension cords as this can result
in the risk of re or electric shock.
11. Objects and Liquids
Never push objects of any kind through openings of this
equipment as they may touch dangerous voltage points or short
out parts that could result in a re or electric shock. Never spill
liquid of any kind on the equipment.
12. Servicing
Do not attempt to service this equipment yourself. Refer all
servicing to qualied service personnel.
13. Damage requiring Service
Unplug this equipment from the wall outlet and refer servicing to
qualied service personnel under the following conditions:
A. When the power-supply cord or the plug has been damaged.
B. If liquid is spilled, or objects have hit the equipment.
C. If the equipment has been exposed to rain or water.
D. If the equipment does not operate normally by following
the operating instructions, adjust only those controls that
are covered by the operating instructions as an improper
adjustment of other controls may result in damage and will
often require extensive work by a qualied technician to restore
the equipment to its normal operation.
E. If the equipment has been dropped, or the cabinet damaged.
F. When the equipment exhibits a distinct change in performance
— this indicates a need for service.
14. Replacement Parts
When replacement parts are required, be sure the service
technician has used replacement parts specied by the
manufacturer or that have the same characteristics as the original
part. Unauthorized substitutions may result in re, electric shock
or other hazards.
15. Safety Check
Upon completion of any service or repairs to this equipment, ask
the service technician to perform safety checks to determine that
the equipment is in proper operating condition.
16. Field Installation
This installation should be made by a qualied service person and
should conform to all local codes.
17. Correct Batteries
Warning: Risk of explosion if battery is replaced by an incorrect
type. Replace only with the same or equivalent type. Dispose of
used batteries according to the instructions. The battery shall not
be exposed to excessive heat such as sunshine, re or the like.
18. Tmra
A manufacturer’s maximum recommended ambient temperature
(Tmra) for the equipment must be specied so that the customer
and installer may determine a suitable maximum operating
environment for the equipment.
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Important Safeguards

3
FCC Compliance Statement
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15
OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE
EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN RADIATE RADIO FREQUENCY
ENERGY AND IF NOT INSTALLED AND USED IN ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL INTERFERENCE
TO RADIO COMMUNICATIONS. OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE HARMFUL INTERFERENCE, IN
WHICH CASE USERS WILL BE REQUIRED TO CORRECT THE INTERFERENCE AT THEIR OWN EXPENSE.
WARNING: CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE COULD VOID THE
USER’S AUTHORITY TO OPERATE THE EQUIPMENT. THIS CLASS OF DIGITAL APPARATUS MEETS ALL REQUIREMENTS OF THE CANADIAN
INTERFERENCE CAUSING EQUIPMENT REGULATIONS.
WEEE (Waste Electrical & Electronic Equipment)
Correct Disposal of This Product
(Applicable in the European Union and other European countries with separate collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed with other household
wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled
waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable
reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government oce,
for details of where and how they can take this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product
should not be mixed with other commercial wastes for disposal.
Copyright
© 2022 IDIS Co., Ltd.
IDIS Co., Ltd. reserves all rights concerning this document.
Use or duplication of this document in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited.
Contents of this document are subject to change without prior notice for reasons such as functionality enhancements.
Registered Trademarks
IDIS is a registered trademark of IDIS Co., Ltd.
Other company and product names are registered trademarks of their respective owners.
The information in this manual is believed to be accurate as of the date of publication even though explanation about some functions
may not be incorporated. We are not responsible for any problems resulting from the use thereof. The information contained herein is
subject to change without notice. Revisions or new editions to this publication may be issued to incorporate such changes.
This product contains software built partially on open-source content. You may obtain the complete corresponding source code
depending on whether or not the source is publicly available under a license policy. For more information, refer to System > General
page. This product includes software developed by the University of California, Berkeley and its contributors, and software developed
by the OpenSSL Project for use in the OpenSSL Toolkit (http://www.openssl.org/). Also, this product includes cryptographic software
written by Eric Young ([email protected]).
Covered by one or more claims of the patents listed at patentlist.accessadvance.com.
Accessories
Upon purchasing the product, check inside the box to make sure all the following accessories are included. Some parts may dier
depending on the situation.
Item
Network Camera
Quick Guide
Screws (6ea)
Sunshield
Desiccant, double-sided tape
Please download software (IDIS Discovery, IDIS Center, IDIS Solution Suite Compact) and product manual from this link :
-IDIS Website (www.idisglobal.com)
-Search IDIS Discovery, IDIS Center, IDIS Solution Suite Compact.

4
Overview
• Product color and design may vary depending on the model.
• For more details on each part name, refer to the manual.
Outside
1
2
1IR LED 2Sunshield
Inside
1
2
3
7
6
4
5
1Lens 5Fastening Clasp
2Camera Body 6Power
3Control Board 7Power Connection
Terminal
4Fan
Back
97 8
2 3
4
5
6
1
0! @
1SD Memory Card Slot 7Photo Sensor Power,
Photo Sensor In
2ABF(Auto Back Focus) 8Alarm I/O
3Factory Reset Switch 9RS485 Port
4Network LED 0Audio I/O
5Network Port !IR Control Port
6Power LED @Power

5
Camera Installation
Installation
1 Attach the double-sided tape to the desiccant
rst, and attach it to the specied position inside
the dome cover as shown below.
To prevent leakage inside the product, close the
cable grand before use.
It is designed to connect the cable through the
connection part (compression tting) on the
bottom of the housing. Loosen the compression
tting nut on the back of the housing and insert
the power cable and network cable as their size
from the outside of the housing to the inside.
2 Connect the AC power and the network cable.
When installing the bracket, use the appropriate
xing screw to x it according to the situation.
3 Calculate the horizontal distance, angle, and
height of the camera taking into account the
recognition distance. (LED maximum recognition
distance: 20m)
Recognition distance
Height
Horizontal distance
수직각도
0~30°
수평각도
0~15°
• Focus on the angle of view and focus by
referring to the conditions below for accurate
number recognition.
– Installation angle: vertical (top and bottom)
0~30°, horizontal (left and right) 0~15°
– License plate height: Adjusted to be
singleline license plate (minimum 30
pixels, recommended 60 pixels or more),
doubleline license plate (minimum 60
pixels, recommended 90 pixels or more)
• Adjust the height and angle so that the
vehicle's lights do not shine directly on the
camera.
• Be sure to press the hook of the connector
rmly when connecting or disconnecting a
cable. It may be damaged.
4 Focus on angle of view. Press the ABF button for
precise auto-adjustment.
Rotate the lens' iris ring and then adjust
accordingly.

6
Specications
Exterior Dimensions (W x H x D) 166.5mm x 129.5mm x 540mm (6.55”x 5.09” x 21.25”)
Weight (Main Unit) 4.65kg (10.25lb)
Working Temperature -40°C ~ +60°C (-40°F ~ +140°F) [Starting Temperature: -20°C ~ +60˚C (-4°F ~ +140˚F)]
Operating Humidity 0% ~ 90%
Power 100-240V~, 50/60Hz, 1.0-0.5A
Power Consumption 100-240V~, 50/60Hz, 1.0-0.5A, 50W
External Storage* (Optional)
(MicroSD (SDHC/SDXC) Memory Card (Class 6 or above, up to 512 GB))
Certications FCC, CE, IP66
* An SLC (Single Level Cell) or MLC (Multi Level Cell) card by SanDisk or Transcend is recommended to ensu re stable recording
performance.
* An SD memory card is a consumable product with a nite service life. Prolonged use will damage the card’s memory sectors
and result in data loss or memory card failure. Test the SD memory card regularly and replace it whenever necessary.
* microSD Logo is a trademark of SD-3C, LLC.
•DirectIP NVR makes it easy to use cameras without extra network congurations.
Each camera can be controlled via the DirectIP™ NVR setup menu, without any PC.
– For detailed camera settings, please see the camera setting pages of DirectIP™ NVR manual.
•To use your camera with non-DirectIP system (e.g. other NVR or VMS), refer to the camera
manual and it can be downloaded from our website: www.idisglobal.com.
V1.0

Memo

Memo

Memo

Memo

Memo

IDIS Co., Ltd.
For more information, please visit
www.idisglobal.com
