Idview Digital IV-DV720LT User manual

Quick Start Guide
Item Number: IV-DV720LT
Thank you for purchasing our products.
Please read this Quick Start Guide carefully before operating.
Safety Precaution

Warning
To prevent fire or shock hazard, please do not submerge the camera in
water for an extended period of time.
Please make sure the adapter is consistent with product specifications,
otherwise there is risk of fire, electrical shock, or damage.
Please pay attention to the polarity of the adapter. Reversing the polarity
may damage the camera and poses risk of fire.
Please do not connect multiple cameras to the same adapter without
verifying the capacity of the adapter. Exceeding the adapter’s capacity
poses risk of fire.
The power supply must be firmly connected to avoid risk of fire.
If the device emits an abnormal smell or smoke, please disconnect the
power source immediately.
If the camera does not work properly, please do not dismantle /
disassemble it by yourself however please contact your local distributor or
an authorized dealer to avoid causing any damage which may void the
warranty.
* Please avoid getting water on the product components during maintenance.
Technical Specifications
Item Number: IV-DV720LT
Signal System: NTSC
Sensor CCD: Sony Effio-E
Horizontal Resolution: 700TV lines
Lens: 2.8-12mm
Minimum Illumination: 0 LUX (IR ON)
S/N Ratio: More than 48 dB
Distance: 65 feet
Video Output: 1Vp-p 75Ω . Y/C Separated
Connector video : BNC
Operation Temperature: -4°F to +122°F
Supplied Power: 24VAC/12VDC(+/-10%);

Installation
1. Connect the terminating wire of the cable directly to the DC power
source.
2. Connect the BNC end of the Camera Cable to an extension cable, or
directly to a DVR / Observation System or to a TV/Monitor.
3. Attach the base to the wall/ceiling, then mount the camera to the base.
4. Rotate the lens to the desired position then tighten screw to prevent
rotation.
5. Adjust the up and down position then tighten the screw to prevent lens
movement.
Troubleshooting
1.No picture or the picture is unstable:

1) Check the connection of the video line or power line
2. Blurred images:
1) Check the lens for debris then use a customized lens paper or cotton buds
drenched in alcohol for cleansing.
2)Check the focus length and OSD settings
3. Dim images:
1) Adjust the CNT of the monitor and iris
4. No motion detection frame or privacy shaded frame:
1) Check whether the ON/OFF option has been selected accurately or check the
menu parameters
5. Screen color cast in a special environment:
1) Adjust the WEB mode or direction
6. Glittering screen:
1) The camera might be facing the sun, TV set, or computer.
7. Functions are in disorder and not able to be adjusted:
1) Restore to default settings
8. The camera works abnormally; the surface is over-heating or has a peculiar smell,
smoke etc.
1) Please cut off the power supply immediately. Second, check the connection of
the power supply. Last, send the camera to professionals for maintenance
Accessory List
No.
Name
Quantity
Remark
1
CCTV Camera
1
2
User Manual
1
3
Screw
1
