IDX IA-60a User manual

12.8V～14.8V
12.8V～14.8V
IA-60a
60W ACアダプター
ASMK100581

INSTRUCTION MANUAL
IA-60a
60W AC Adapter Power Supply
A. Connect AC power cord firmly.
B. Switch the power switch ON.
C. Basic Operation:
The IA-60a is a camera AC Adapter. By connecting the 4P male XLR connector end of a DC
power cable to the IA-60a’s 4P female XLR connector, the user will be able to power a range of
equipment with power consumption equal to or less than 60W. Connect the cables 4P female XLR
connector to the 4P male XLR connector of the camera, light, or other equipment.
D. Included in the IA-60a box should be the following: one IA-60a, one AC power cord.
OPERATING INSTRUCTIONS
During use the unit may get a little warm, this is normal.
Do not rest any object on the unit, or block the ventilation holes during operation.
When in use, use in a horizontal position with the 4 rubber feet facing down and on a flat surface.
Do not expose the unit to direct sunlight; use in well ventilated place.
If the unit’s power fails to come on, contact your supplier or the IDX office listed below.
For repair or replacement, please contact the IDX office below or our authorized representative.
OPERATION PRECAUTIONS
Weight............................... 0.9Kg(1.7 lbs) Approx.
Dimensions ....................... 90(W) x 50(H) x 190(D)mm Approx.
3.5(W) x 2.0(H) x 7.5(D)inches Approx.
DC Output........................ MAX 60W (13.8V*/4.3A) *12.8V-14.8V adjustable
DC Output Connector..... 4P XLR Connector Female (Pin 1:Minus Pin 4:Plus)
Power Consumption ........ MAX 161VA (132VA:100V / 161VA:240V)
Input Voltage ................... 100~240VAC 50/60 Hz (Automatic)
SPECIFICATIONS
FOR SALES AND SERVICE CALL
In Japan/Asia
IDX Company, Ltd.
6-28-11 Shukugawara,
Tama-ku, Kawasaki-Shi,
Kanagawa-ken 214-0021 Japan
Sales and Service
Phone [phone]
Fax [phone]
E-mail [email protected]
In the United States
IDX System Technology, Inc.
19001 Harborgate Way,
Suite 105, Torrance,
CA 90501 USA
Sales and Service
Phone [phone]
Fax [phone]
E-mail [email protected]
In Europe/Middle East
IDX Technology Europe, Ltd.
Unit 9, Langley Park,
Waterside Drive, Langley,
Berkshire SL3 6EZ England
Sales and Service
Phone [phone]
Fax [phone]
E-mail [email protected] 2011.04
IDX wants to thank you for purchasing the IA-60a, our most compact Camera AC Adapter, and hopes that its robust and
careful design will satisfy all your power needs. Please utilize this Operation Manual or help on how to use the IA-60a.
If you have any additional questions, please contact the appropriate IDX office, listed below.
FEATURES
Universal Power Supply – the IA-60a can accept AC power ranging from 100~240VAC.
The power supply is automatic and does not need to be manually switched.
Compact & Lightweight – with a weight of 0.9Kg (1.7lbs) and extremely compact design,
theIA-60a’s robust design will help customers use it in a wide range of applications.
