Altronix SMP5 User manual

Overview:
SMP5 power supply/charger converts low voltage AC input into 6VDC, 12VDC or 24VDC @ 4 amp of continuous
supply current (see specifications). This general purpose power supply has a wide range of applications for
access control, security and CCTV system accessories that require additional power.
Specifications:
Input:
• 16VAC to 28VAC (see transformer selection table).
Output:
• 6VDC, 12VDC or 24VDC selectable output.
• 4 amp continuous supply current*.
• Thermal overload and short circuit protection.
• Filtered and electronically regulated output.
Battery Backup:
• Built-in charger for sealed lead acid or gel type batteries.
• Maximum charge current 300mA.
•Automatic switch over to stand-by battery.
• Battery short circuit protection (PTC).
Additional Features:
• AC input and DC output LED indicators.
•Extremelycompact design.
• Includes batteryleads.
• Snap Trac compatible (Altronix model #ST3).
• DIN Rail Mount version available (order Altronix model #DPS5).
Board Dimensions (approximate): 3.5”L x 2.75”W x 1.75”H
*Specified at 25˚ C ambient.
Voltage Output/Transformer Selection Table:
Output Voltage Switch Position Transformer Requirements
SW1 SW2 (Recommended Altronix Part #’s)
6VDC Closed/On Open/Off 16VAC / 40VA (TP1640)
12VDC Open/Off Open/Off 28VAC or 28VAC / 100VA (T2428100), or 16VAC / 100 VA (T16100)
24VDC Open/Off Closed/On 28VAC / 175VA (T2428175)
Note: Transformers with higher power (VA) ratings may be used for all output voltages selected above
provided the input voltage does not exceed 28V
AC or 45VDC.
Installation Instructions:
The SMP5 should be installed in accordance with The National Electrical Code and all applicable Local Regulations.
1. Mount the SMP5 in desired location / enclosure.
2. Set DC output voltage with switches (refer to Voltage Output/Transformer Selection Table).
3. Connect proper transformer to terminals marked [AC] (see Voltage Output/Transformer Selection Table).
Use 18 AWG or larger for all power connections (Battery, DC output).
4. Measure output voltage before connecting devices. This helps avoid potential damage.
5. Connect devices to be powered to terminals marked [+ DC ---].
6. When the use of stand-bybatteries are desired,theymust be lead acid or gel type.
Connect batteryto terminals marked [+ BAT---] (battery leads included).
Use two (2) 12VDC batteries connected in series for 24VDC operation.
Note: When batteries are not used a loss of AC will result in the loss of output voltage.
SMP5 - High Current Power Supply/Charger

LED Diagnostics:
Red (DC) Green (AC) Power Supply Status
ON ON Normal operating condition
ON OFF Loss of AC, Stand-by battery supplying power
OFF ON No DC output. Short circuit or thermal overload condition.
OFF OFF No DC output. Loss of AC. Discharged or no battery present.
Terminal Identification:
Terminal Function/Description
Legend
AC/AC Low voltage AC input (see voltage output/transformer selection table).
For 6VDC output use 16VAC or higher with 40VA power rating or higher.
For 12VDC output use 16V
ACor higher with 85VA power rating or higher.
For 24VDC output use 28VAC with 175VA power rating or higher.
Caution: Do not apply voltage above 28 VAC or 45VDC (maximum input rating).
+DC -- 6VDC,12VDC or 24VDC @ 4 amp continuous supply current.
+ BAT -- Stand-by battery connections. Maximum charge rate 300mA.
+DC -- + BAT -- AC AC
AC
DC
MADE IN U.S.A.
SW1
6V 12 V 24 V
SW1 CLSD OPEN OPEN
SW2 OPEN OPEN CLSD
SW2
Altronix is not responsible for any typographical errors. Product specifications are subject to change without notice.
140 58th Street, Brooklyn, NewYork 11220 USA, 718-567-8181, fax: [phone]
website: www.altronix.com, e-mail: [email protected], Lifetime Warranty, Made in U.S.A.
IISMP5 - Rev. 110606 K06F MEMBER
