IEI Technology MODAT-550A Series User manual

MODAT-550A Mobile Data Collector
Page i
User Manual
5.5” Mobile Data Collector with Octa-Core ARM® Cortex®-A53
1.5 GHz CPU, Android 7.0 OS, Capacitive Touchscreen,
Bluetooth 4.0 LE, 802.11a/b/g/n Wi-Fi, 1D/2D Barcode Scanner,
GPS, NFC, 13-Megapixel Camera, IP 65, RoHS Compliant
Rev. 1.00 – September 11, 2018
MODEL:
MODAT-550A

MODAT-550A Mobile Data Collector
Page ii
Revision
Date Version Changes
September 11, 2018 1.00 Initial release

MODAT-550A Mobile Data Collector
Page iii
Copyright
COPYRIGHT NOTICE
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

MODAT-550A Mobile Data Collector
Page iv
Manual Conventions
WARNING
Warnings appear where overlooked details may cause damage to the
equipment or result in personal injury. Warnings should be taken
seriously.
CAUTION
Cautionary messages should be heeded to help reduce the chance of
losing data or damaging the product.
NOTE
These messages inform the reader of essential but non-critical
information. These messages should be read carefully as any directions
or instructions contained therein can help avoid making mistakes.
HOT SURFACE
This symbol indicates a hot surface that should not be touched without
taking care.

MODAT-550A Mobile Data Collector
Page v
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 OVERVIEW.................................................................................................................. 2
1.2 MODEL VARIATIONS ................................................................................................... 2
1.3 FEATURES................................................................................................................... 3
1.4 FRONT PANEL............................................................................................................. 3
1.5 REAR PANEL............................................................................................................... 4
1.6 SIDE PANELS .............................................................................................................. 5
1.7 TOP PANEL ................................................................................................................. 5
1.8 BOTTOM PANEL.......................................................................................................... 6
1.9 TECHNICAL SPECIFICATIONS ...................................................................................... 6
1.10 DIMENSIONS............................................................................................................. 8
2 UNPACKING................................................................................................................. 9
2.1 PACKING LIST........................................................................................................... 10
2.2 OPTIONAL ITEMS.......................................................................................................11
3 INSTALLATION ......................................................................................................... 12
3.1ANTI-STATIC PRECAUTIONS...................................................................................... 13
3.2 INSTALLATION PRECAUTIONS................................................................................... 13
3.3 CHARGING THE SYSTEM........................................................................................... 14
3.4 SIM CARD INSTALLATION........................................................................................ 16
3.5 MICROSD CARD INSTALLATION................................................................................ 18
3.6 I/O CONNECTORS..................................................................................................... 19
3.6.1 Headset Jack.................................................................................................... 19
3.6.2 Micro USB Connector...................................................................................... 19
3.7 SYSTEM MAINTENANCE ........................................................................................... 21
4 USING THE MODAT-550A........................................................................................ 22
4.1 POWERING ON/OFF .................................................................................................. 23
4.2 HOME SCREEN ......................................................................................................... 24
4.2.1 Adding a Home Screen..................................................................................... 24

MODAT-550A Mobile Data Collector
Page vi
4.2.2 Switching between Home Screens.................................................................... 25
4.2.3 Favorites Tray.................................................................................................. 26
4.2.4 Adding Shortcuts.............................................................................................. 27
4.2.5 Arranging the Home Screen............................................................................. 28
4.3 NAVIGATION BUTTONS............................................................................................. 29
4.4 STATUS BAR ............................................................................................................. 30
4.5 SETTINGS ................................................................................................................. 32
4.5.1 Wireless & Networks........................................................................................ 32
4.5.1.1 More Settings............................................................................................ 33
4.5.2 Barcode............................................................................................................ 35
4.5.3 Display............................................................................................................. 36
4.5.4 Notifications..................................................................................................... 38
4.5.1 Sound................................................................................................................ 39
4.5.2 Apps.................................................................................................................. 40
4.5.3 Storage............................................................................................................. 41
4.5.4 Battery.............................................................................................................. 42
4.5.5 Memory............................................................................................................ 43
4.5.6 Users................................................................................................................ 44
4.5.7 DuraSpeed........................................................................................................ 45
4.5.8 Location ........................................................................................................... 46
4.5.9 Security ............................................................................................................ 47
4.5.10 Accounts......................................................................................................... 49
4.5.11 Language & Input .......................................................................................... 50
4.5.12 Backup & Reset.............................................................................................. 51
4.5.13 Date & Time................................................................................................... 52
4.5.14 Accessibility ................................................................................................... 53
4.5.15 Printing.......................................................................................................... 55
4.5.1 Scheduled Power On & Off.............................................................................. 56
4.5.2 About Phone..................................................................................................... 57
4.6 CAMERA................................................................................................................... 59
A REGULATORY COMPLIANCE.............................................................................. 60
B SAFETY PRECAUTIONS......................................................................................... 62
B.1 SAFETY PRECAUTIONS............................................................................................. 63
B.1.1 General Safety Precautions............................................................................. 63

MODAT-550A Mobile Data Collector
Page vii
B.1.2 Anti-static Precautions .................................................................................... 64
B.1.3 Product Disposal............................................................................................. 65
B.2 MAINTENANCE AND CLEANING PRECAUTIONS ........................................................ 65
B.2.1 Maintenance and Cleaning.............................................................................. 66
B.2.2 Cleaning Tools................................................................................................. 66
C HAZARDOUS MATERIALS DISCLOSURE......................................................... 67

MODAT-550A Mobile Data Collector
Page viii
List of Figures
Figure 1-1: MODAT-550A ...............................................................................................................2
Figure 1-2: Front Panel ..................................................................................................................3
Figure 1-3: Rear Panel....................................................................................................................4
Figure 1-4: Side Panels..................................................................................................................5
Figure 1-5: Top Panel.....................................................................................................................5
Figure 1-6: Bottom Panel...............................................................................................................6
Figure 1-7: Dimensions (units in mm)..........................................................................................8
Figure 3-1: Connecting the Micro USB Cable to the MODAT-550A.........................................14
Figure 3-2: Connecting the Power Plug .....................................................................................15
Figure 3-3: Connecting the MODAT-550A to the Power Adapter ............................................15
Figure 3-4: Battery Cover Retention Screws .............................................................................16
Figure 3-5: Removing the Battery...............................................................................................17
Figure 3-6: SIM Card Installation.................................................................................................17
Figure 3-7: microSD Card Slot ....................................................................................................18
Figure 3-8: MODAT-550A Headset Jack.....................................................................................19
Figure 3-9: USB for File Transfer................................................................................................20
Figure 3-10: USB Connection Option Screen............................................................................21
Figure 4-1: Power Button.............................................................................................................23
Figure 4-2: Power Off Menu.........................................................................................................23
Figure 4-3: Adding a Home Screen.............................................................................................24
Figure 4-4: Multiple Home Screens.............................................................................................25
Figure 4-5: Favorites Tray............................................................................................................26
Figure 4-6: All Apps/WIDGETS Page..........................................................................................27
Figure 4-7: Trash an Item on Home Screen...............................................................................28
Figure 4-8: Navigation Buttons...................................................................................................29
Figure 4-9: Status Bar ..................................................................................................................30
Figure 4-10: Notification List and System Status......................................................................31
Figure 4-11: Wireless and Networks Settings ...........................................................................32
Figure 4-12: More Settings Menu................................................................................................33
Figure 4-13: Barcode Menu .........................................................................................................35
Figure 4-14: Display Menu...........................................................................................................36

MODAT-550A Mobile Data Collector
Page ix
Figure 4-15: Notifications Menu..................................................................................................38
Figure 4-16: Sound Menu.............................................................................................................39
Figure 4-17: Apps Menu...............................................................................................................40
Figure 4-18: Storage Menu ..........................................................................................................41
Figure 4-19: Battery Menu ...........................................................................................................42
Figure 4-20: Memory Menu..........................................................................................................43
Figure 4-21: Users Menu..............................................................................................................44
Figure 4-22: DuraSpeed Menu.....................................................................................................45
Figure 4-23: Location Menu.........................................................................................................46
Figure 4-24: Security Menu..........................................................................................................47
Figure 4-25: Accounts Menu .......................................................................................................49
Figure 4-26: Language & Input Menu .........................................................................................50
Figure 4-27: Backup & Reset Menu ............................................................................................51
Figure 4-28: Date & Time Menu...................................................................................................52
Figure 4-29: Accessibility Menu..................................................................................................53
Figure 4-30: Printing Menu ..........................................................................................................55
Figure 4-31: Scheduled Power On & Off Menu..........................................................................56
Figure 4-32: About Phone Menu .................................................................................................57
Figure 4-33: Camera Application ................................................................................................59

MODAT-550A Mobile Data Collector
Page x
List of Tables
Table 1-1: Model Variations...........................................................................................................2
Table 1-2: Technical Specifications..............................................................................................7
Table 2-1: Packing List.................................................................................................................11
Table 2-2: Optional Items.............................................................................................................11
Table 4-1: Navigation Buttons.....................................................................................................29

MODAT-550A Mobile Data Collector
Page 1
Chapter
1
1 Introduction

MODAT-550A Mobile Data Collector
Page 2
1.1 Overview
Figure 1-1: MODAT-550A
The MODAT-550A is an Android-based mobile data collector with a 5.5” touchscreen. At
the heart of the system is the octa-core ARM®Cortex®-A53 1.5 GHz CPU. Wireless
communication technologies include 802.11a/b/g/n Wi-Fi, Bluetooth 4.0 LE and 4G. Other
peripherals include a 13-megapixel camera, a 1D/2D barcode scanner, a microSD card
slot, a Micro USB port, a headset jack and a speaker.
1.2 Model Variations
Model System Barcode Scanner
MODAT-550A-OA53 Octa-core 64-bitARM®
Cortex®-A53 1.5 GHz CPU,
2 GB LPDDR3, 16 GB eMMC
1D/2D imager scan engine
MODAT-550A-OA53-ET No
Table 1-1: Model Variations

MODAT-550A Mobile Data Collector
Page 3
1.3 Features
Some of the MODAT-550A features include:
5.5” LCD with capacitive touchscreen
Octa-core ARM® Cortex®-A53 1.5 GHz CPU
Android 7.0 OS
13-megapixel camera with flashlight
Bluetooth 4.0 LE, 802.11a/b/g/n Wi-Fi and 4G wireless communication
technologies
Built-in GPS with internal antenna
Optional 1D/2D barcode scanner
IP 65 protection
RoHS compliant
1.4 Front Panel
The front panel of the MODAT-550A has a 5.5” LCD with capacitive touchscreen, a
receiver, a microphone and a LED indicator.
Figure 1-2: Front Panel

MODAT-550A Mobile Data Collector
Page 4
1.5 Rear Panel
The rear panel consists of a 13-megapixel camera with flashlight, a speaker, a
microphone and the NFC area.
Figure 1-3: Rear Panel

MODAT-550A Mobile Data Collector
Page 5
1.6 Side Panels
The side panels contain a power button, two barcode trigger buttons and a Micro USB
port.
Figure 1-4: Side Panels
1.7 Top Panel
The top panel contains a 1D/2D barcode scanner and a headset jack.
Figure 1-5: Top Panel

MODAT-550A Mobile Data Collector
Page 6
1.8 Bottom Panel
The bottom panel has a docking connector.
Figure 1-6: Bottom Panel
1.9 Technical Specifications
The MODAT-550A technical specifications are listed in the table below.
Display
LCD Size 5.5”
Brightness (cd/m2) 300
Max. Resolution 1080 (H) x 1920 (V)
Viewing Angle 80/80/80/80 degree
Touchscreen 5-point capacitive
System
CPU Octa-core 64-bit ARM® Cortex®-A53 1.5 GHz
Operating System Android 7.0
Memory 16 GB eMMC
2 GB LPDDR3
Storage 1 x microSD card slot
Communication
Wi-Fi 802.11a/b/g/n
Bluetooth Bluetooth 4.0 LE
GPS GPS/GLONASS

MODAT-550A Mobile Data Collector
Page 7
Modem (Optional)
GSM (850, 900, 1800, 1900)
WCDMA (Band 1, 2, 5, 8)
TDS-CDMA (Band 34, 39)
LTE FDD (Band 1, 2, 3, 4, 5, 7, 8, 20)
TDD (Band 38, 39, 40, 41b)
Data Collection
Barcode 1D/2D imager scan engine (MODAT-550A-OA53 only)
Camera 13-megapixel AF rear camera
NFC Yes
Indicator and Buttons
LED Indicator Green/red
Buttons Power button
2 x Barcode trigger buttons
I/O Interface
Audio
1 x Headset jack
2 x Microphone
1 x Receiver
1 x Speaker (0.5 W)
USB 1 x High-speed Micro USB 2.0 port
Power
Power Adapter 5V, 3A
Battery 4000 mAh
Environment
Operating Temperature -10ºC ~ 50ºC
Storage Temperature -20ºC ~ 60ºC
Humidity 10% ~ 95%, non-condensing
Drop Survival 1.5 m
Environment Protection IP 65
Physical Characteristics
Dimensions (LxWxH) 160.9 mm x 85.4 mm x 28.85 mm
Weight 380 g
Table 1-2: Technical Specifications

MODAT-550A Mobile Data Collector
Page 8
1.10 Dimensions
Figure 1-7: Dimensions (units in mm)

MODAT-550A Mobile Data Collector
Page 9
Chapter
2
2 Unpacking

MODAT-550A Mobile Data Collector
Page 10
To unpack the MODAT-550A, follow the steps below:
WARNING!
Only remove the protective plastic cover stuck to the front screen after
installation. The plastic layer protects the monitor surface during
installation process.
Step 1: Carefully cut the tape sealing the box. Only cut deep enough to break the tape.
Step 2: Open the box.
Step 3: Lift the MODAT-550A out of the box.
Step 4: Make sure all the components listed in the packing list are present. Step0:
2.1 Packing List
NOTE:
If any of the components listed in the checklist below are missing, do
not proceed with the installation. Contact the IEI reseller or vendor the
MODAT-550A
was purchased from or contact an IEI sales
representative directly by sending an email to [e-mail].
The MODAT-550A is shipped with the following components:
Quantity Item Image
1 MODAT-550A
