IEI Technology tKINO-BW Series User manual

tKINO-BW SBC
Page I
User Manual
tKINO-BW
MODEL:
Mini-ITX SBC with 14nm Intel® Pentium® or Celeron® On-board SoC,
VGA, LVDS, HDMI/DP, Dual PCIe GbE, USB 3.0, PCIe Mini, mSATA,
PCIe x1, SATA 6Gb/s, RS-232/422/485, Audio, TPM and RoHS
Rev. 2.01 - January 7, 2019
tKINO-BW CPU Card

tKINO-BW SBC
Page II
Revision
Date Version Changes
January 7, 2019 2.01 Added a note in Section 4.3.
April 2, 2018 2.00 Updated for R20 version.
August 17, 2016 1.01 Changed supported power input voltage from 12 V to 9 V~30V.
Added notes regarding the DDR3L 1333 MHz memory module in
Section 1.7 and Section 4.3.
March 18, 2016 1.00 Initial release

tKINO-BW SBC
Page III
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

tKINO-BW SBC
Page IV
Manual Conventions
WARNING
Warnings appear where overlooked details may cause damage to the
equipment or result in personal injury. Warnings should be taken
seriously.
CAUTION
Cautionary messages should be heeded to help reduce the chance of
losing data or damaging the product.
NOTE
These messages inform the reader of essential but non-critical
information. These messages should be read carefully as any directions
or instructions contained therein can help avoid making mistakes.
HOT SURFACE
This symbol indicates a hot surface that should not be touched without
taking care.

tKINO-BW SBC
Page V
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 INTRODUCTION........................................................................................................... 2
1.2 MODEL VARIATIONS ................................................................................................... 3
1.3 FEATURES................................................................................................................... 3
1.4 CONNECTORS ............................................................................................................. 4
1.5 DIMENSIONS............................................................................................................... 5
1.6 DATA FLOW................................................................................................................ 6
1.7 TECHNICAL SPECIFICATIONS ...................................................................................... 7
2 UNPACKING............................................................................................................... 10
2.1ANTI-STATIC PRECAUTIONS.......................................................................................11
2.2 UNPACKING PRECAUTIONS........................................................................................11
2.3 PACKING LIST........................................................................................................... 12
2.4 OPTIONAL ITEMS...................................................................................................... 13
3 CONNECTORS ........................................................................................................... 14
3.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 15
3.1.1 tKINO-BW Layout............................................................................................ 15
3.1.2 Peripheral Interface Connectors ..................................................................... 16
3.1.3 External Interface Panel Connectors............................................................... 17
3.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 18
3.2.1 9 V~ 30 V DC-IN Power Connector ................................................................ 18
3.2.2 Audio Connector.............................................................................................. 18
3.2.3 Battery Connector............................................................................................ 19
3.2.4 Chassis Intrusion Connector............................................................................ 21
3.2.5 Digital I/O Connector...................................................................................... 22
3.2.6 Fan Connectors................................................................................................ 23
3.2.7 Front Panel Connector .................................................................................... 24
3.2.8 I2C Connector .................................................................................................. 25
3.2.9 Keyboard and Mouse Connector ..................................................................... 26
3.2.10 LVDS Backlight Inverter Connector.............................................................. 27

tKINO-BW SBC
Page VI
3.2.11 LVDS LCD Connector.................................................................................... 28
3.2.12 LAN LED Connectors.................................................................................... 29
3.2.13 microSD Slot .................................................................................................. 30
3.2.14 mSATA Module Slot........................................................................................ 30
3.2.15 PCIe Mini Card Slot ...................................................................................... 32
3.2.16 PCIe x1 Card Slot .......................................................................................... 33
3.2.17 RS-232 Serial Port Connector....................................................................... 35
3.2.18 RS-232/422/485 Serial Port Connector......................................................... 36
3.2.19 SATA 6Gb/s Drive Connectors....................................................................... 37
3.2.20 SATA Power Connectors................................................................................ 38
3.2.21 SMBus Connector .......................................................................................... 39
3.2.22 SPI Flash Connector, BIOS............................................................................ 40
3.2.23 SPI Flash Connector, EC............................................................................... 41
3.2.24 TPM Connector.............................................................................................. 42
3.2.25 USB Connector .............................................................................................. 43
3.3 EXTERNAL PERIPHERAL INTERFACE CONNECTOR PANEL ......................................... 44
3.3.1 Audio Line-out Connector................................................................................ 44
3.3.2 HDMI Connector............................................................................................. 45
3.3.3 LAN Connectors............................................................................................... 46
3.3.4 USB Connectors............................................................................................... 46
3.3.5 VGA Connector................................................................................................ 47
4 INSTALLATION ......................................................................................................... 48
4.1ANTI-STATIC PRECAUTIONS...................................................................................... 49
4.2 INSTALLATION CONSIDERATIONS.............................................................................. 49
4.3 SO-DIMM INSTALLATION ....................................................................................... 51
4.4 MICROSD CARD INSTALLATION................................................................................ 52
4.5 MSATA MODULE INSTALLATION.............................................................................. 53
4.5.1 Full-size mSATA Module Installation .............................................................. 53
4.5.2 Half-size mSATA Module Installation.............................................................. 55
4.6 PCIE MINI CARD INSTALLATION .............................................................................. 57
4.6.1 Full-size PCIe Mini Card Installation............................................................. 57
4.6.2 Half-size PCIe Mini Card Installation............................................................. 59
4.7 SYSTEM CONFIGURATION......................................................................................... 61
4.7.1 AT/ATX Mode Select Switch............................................................................. 61

tKINO-BW SBC
Page VII
4.7.2 Clear CMOS Button......................................................................................... 62
4.7.3 HDMI/DP Select Switch................................................................................... 63
4.7.4 LVDS Panel Resolution Select Switch ............................................................. 64
4.7.5 LVDS Voltage Select Jumper............................................................................ 65
4.7.6 mSATA and SATA2 Select Jumper.................................................................... 66
4.8 CHASSIS INSTALLATION............................................................................................ 67
4.8.1 Airflow.............................................................................................................. 67
4.8.2 Motherboard Installation................................................................................. 67
4.9 SATA DRIVE CONNECTION ...................................................................................... 68
4.10 SOFTWARE INSTALLATION ...................................................................................... 69
4.10.1 Driver Download........................................................................................... 70
5 BIOS.............................................................................................................................. 72
5.1 INTRODUCTION......................................................................................................... 73
5.1.1 Starting Setup................................................................................................... 73
5.1.2 Using Setup...................................................................................................... 73
5.1.3 Getting Help..................................................................................................... 74
5.1.4 Unable to Reboot after Configuration Changes.............................................. 74
5.1.5 BIOS Menu Bar................................................................................................ 74
5.2 MAIN........................................................................................................................ 75
5.3ADVANCED............................................................................................................... 76
5.3.1 ACPI Settings................................................................................................... 77
5.3.2 RTC Wake Settings........................................................................................... 78
5.3.3 Trusted Computing........................................................................................... 79
5.3.4 CPU Configuration.......................................................................................... 80
5.3.5 SATA Configuration ......................................................................................... 81
5.3.6 USB Configuration........................................................................................... 82
5.3.7 NVMe Configuration........................................................................................ 83
5.3.8 F81866 Super IO Configuration...................................................................... 84
5.3.8.1 Serial Port n Configuration....................................................................... 84
5.3.8.1.1 Serial Port 1 Configuration................................................................ 85
5.3.8.1.2 Serial Port 2 Configuration................................................................ 86
5.3.8.1.3 Serial Port 3 Configuration................................................................ 87
5.3.8.1.4 Serial Port 4 Configuration................................................................ 88
5.3.8.1.5 Serial Port 5 Configuration................................................................ 89

tKINO-BW SBC
Page VIII
5.3.8.1.6 Serial Port 6 Configuration................................................................ 90
5.3.9 iWDD H/W Monitor......................................................................................... 91
5.3.9.1 Smart Fan Mode Configuration................................................................ 92
5.3.10 Serial Port Console Redirection .................................................................... 95
5.3.10.1 Console Redirection Settings.................................................................. 96
5.3.11 IEI Feature..................................................................................................... 98
5.4 CHIPSET ................................................................................................................... 99
5.4.1 North Bridge Configuration........................................................................... 100
5.4.1.1 Intel IGD Configuration.......................................................................... 100
5.4.2 South Bridge Configuration........................................................................... 103
5.4.2.1 PCI Express Configuration..................................................................... 104
5.5 SECURITY............................................................................................................... 105
5.6 BOOT...................................................................................................................... 106
5.7 EXIT....................................................................................................................... 108
A REGULATORY COMPLIANCE.............................................................................110
B BIOS MENU OPTIONS............................................................................................112
C TERMINOLOGY ......................................................................................................115
D DIGITAL I/O INTERFACE..................................................................................... 120
D.1 INTRODUCTION...................................................................................................... 121
D.2ASSEMBLY LANGUAGE SAMPLE 1.......................................................................... 122
D.3ASSEMBLY LANGUAGE SAMPLE 2.......................................................................... 122
E WATCHDOG TIMER............................................................................................... 123
F HAZARDOUS MATERIALS DISCLOSURE........................................................ 126
F.1 HAZARDOUS MATERIAL DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS ROHS
COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY ................................................ 127

tKINO-BW SBC
Page IX
List of Figures
Figure 1-1: tKINO-BW.....................................................................................................................2
Figure 1-2: Connectors ..................................................................................................................4
Figure 1-3: Dimensions (mm)........................................................................................................5
Figure 1-4: Data Flow Diagram......................................................................................................6
Figure 3-1: Connector and Jumper Locations...........................................................................15
Figure 3-2: DC-IN Power Connector Location...........................................................................18
Figure 3-3: Audio Connector Location.......................................................................................19
Figure 3-4: Battery Connector Location.....................................................................................20
Figure 3-5: Chassis Intrusion Connector Location...................................................................21
Figure 3-6: Digital I/O Connector Location................................................................................22
Figure 3-7: Fan Connector Locations.........................................................................................23
Figure 3-8: Front Panel Connector Location.............................................................................24
Figure 3-9: I2C Connector Location............................................................................................25
Figure 3-10: Keyboard and Mouse Connector Location...........................................................26
Figure 3-11: Backlight Inverter Connector Location.................................................................27
Figure 3-12: LVDS Connector Location......................................................................................28
Figure 3-13: LAN LED Connector Locations .............................................................................29
Figure 3-14: microSD Card Slot Location ..................................................................................30
Figure 3-15: mSATA Module Slot Location................................................................................31
Figure 3-16: PCIe Mini Card Slot Location.................................................................................32
Figure 3-17: PCIe x1 Slot Location .............................................................................................34
Figure 3-18: RS-232 Serial Port Connector Locations..............................................................35
Figure 3-19: RS-232/422/485 Connector Locations...................................................................36
Figure 3-20: SATA 6Gb/s Drive Connectors Locations............................................................37
Figure 3-21: SATA Power Connector Locations .......................................................................38
Figure 3-22: SMBUS Connector Location..................................................................................39
Figure 3-23: SPI Flash Connector Location...............................................................................40
Figure 3-24: SPI Flash Connector Location...............................................................................41
Figure 3-25: TPM Connector Location........................................................................................42
Figure 3-26: USB Connector Location........................................................................................43
Figure 3-27: External Peripheral Interface Connector..............................................................44

tKINO-BW SBC
Page X
Figure 3-28: Audio Line-out Connector......................................................................................44
Figure 3-29: DP/HDMI Connector Pinout Locations..................................................................45
Figure 3-30: LAN Connector........................................................................................................46
Figure 3-31: VGA Connector .......................................................................................................47
Figure 4-1: SO-DIMM Installation ................................................................................................51
Figure 4-2: microSD Card Installation........................................................................................52
Figure 4-3: Removing the Retention Screw...............................................................................53
Figure 4-4: Inserting the Full-size mSATA Module into the Slot at an Angle.........................54
Figure 4-5: Securing the mSATA Module...................................................................................54
Figure 4-6: Removing the Retention Screw...............................................................................55
Figure 4-7: Removing the Standoff.............................................................................................55
Figure 4-8: Installing the Standoff ..............................................................................................56
Figure 4-9: Inserting the Half-size mSATA Module into the Slot at an Angle.........................56
Figure 4-10: Securing the Half-size mSATA Module.................................................................57
Figure 4-11: Removing the Retention Screws...........................................................................57
Figure 4-12: Inserting the Full-size PCIe Mini Card into the Slot at an Angle........................58
Figure 4-13: Securing the Full-size PCIe Mini Card ..................................................................58
Figure 4-14: Removing Retention Screw and Standoff ............................................................59
Figure 4-15: Installing the Standoff ............................................................................................60
Figure 4-16: Inserting the Half-size PCIe Mini Card into the Slot at an Angle........................60
Figure 4-17: Securing the Half-size PCIe Mini Card..................................................................61
Figure 4-18: AT/ATX Mode Select Switch Location ..................................................................62
Figure 4-19: Clear CMOS Button Location.................................................................................62
Figure 4-20: HDMI/DP Select Switch Location...........................................................................63
Figure 4-21: LVDS Panel Resolution Select Switch Location..................................................65
Figure 4-22: LVDS Voltage Select Jumper Location.................................................................66
Figure 4-23: mSATA and SATA2 Select Jumper Location.......................................................67
Figure 4-24: SATA Drive Cable Connection...............................................................................68
Figure 4-25: IEI Resource Download Center..............................................................................69

tKINO-BW SBC
Page XI
List of Tables
Table 1-1: tKINO-BW Model Variations.........................................................................................3
Table 1-2: Technical Specifications..............................................................................................9
Table 3-1: Peripheral Interface Connectors...............................................................................17
Table 3-2: Rear Panel Connectors..............................................................................................17
Table 3-3: DC-IN Power Connector Pinouts...............................................................................18
Table 3-4: Audio Connector Pinouts ..........................................................................................19
Table 3-5: Battery Connector Pinouts........................................................................................20
Table 3-6: Chassis Intrusion Connector Pinouts ......................................................................21
Table 3-7: Digital I/O Connector Pinouts....................................................................................22
Table 3-8: Fan Connector Pinouts..............................................................................................23
Table 3-9: Front Panel Connector Pinouts.................................................................................24
Table 3-10: I2C Connector Pinouts..............................................................................................25
Table 3-11: Keyboard and Mouse Connector Pinouts..............................................................26
Table 3-12: Backlight Inverter Connector Pinouts....................................................................27
Table 3-13: LVDS Connector Pinouts.........................................................................................29
Table 3-14: LAN LED Connector Pinouts...................................................................................29
Table 3-15: mSATA Module Slot Pinouts...................................................................................32
Table 3-16: PCIe Mini Card Slot Pinouts ....................................................................................33
Table 3-17: PCIe x1 Slot Pinouts.................................................................................................34
Table 3-18: RS-232 Serial Port Connector Pinouts...................................................................35
Table 3-19: RS-232/422/485 Connector Pinouts........................................................................36
Table 3-20: DB-9 RS-422/485 Pinouts.........................................................................................37
Table 3-21: SATA Power Connector Pinouts.............................................................................38
Table 3-22: SMBUS Connector Pinouts......................................................................................39
Table 3-23: SPI Flash Connector Pinouts..................................................................................40
Table 3-24: SPI Flash Connector Pinouts..................................................................................41
Table 3-25: TPM Connector Pinouts...........................................................................................42
Table 3-26: USB Connector Pinouts...........................................................................................43
Table 3-27: DP/HDMI Connector Pinouts ...................................................................................45
Table 3-28: LAN Pinouts ..............................................................................................................46
Table 3-29: USB 3.0 Port Pinouts................................................................................................47

tKINO-BW SBC
Page XII
Table 3-30: VGA Connector Pinouts...........................................................................................47
Table 4-1: AT/ATX Mode Select Switch Settings.......................................................................61
Table 4-2: HDMI/DP Select Switch Settings...............................................................................63
Table 4-3: LVDS Panel Resolution Selection.............................................................................64
Table 4-4: LVDS Voltage Select Jumper Settings .....................................................................65
Table 4-5: mSATA and SATA2 Select Jumper Settings............................................................66
Table 5-1: BIOS Navigation Keys................................................................................................74

tKINO-BW SBC
Page XIII
List of BIOS Menus
BIOS Menu 1: Main.......................................................................................................................75
BIOS Menu 2: Advanced..............................................................................................................76
BIOS Menu 3: ACPI Settings .......................................................................................................77
BIOS Menu 4: RTC Wake Settings..............................................................................................78
BIOS Menu 5: Trusted Computing..............................................................................................79
BIOS Menu 6: CPU Configuration...............................................................................................80
BIOS Menu 7: SATA Configuration.............................................................................................81
BIOS Menu 8: USB Configuration...............................................................................................82
BIOS Menu 9: NVMe Configuration.............................................................................................83
BIOS Menu 10: F81866 Super IO Configuration ........................................................................84
BIOS Menu 11: Serial Port n Configuration ...............................................................................84
BIOS Menu 12: iWDD H/W Monitor .............................................................................................91
BIOS Menu 13: Smart Fan Mode Configuration ........................................................................92
BIOS Menu 14: Serial Port Console Redirection.......................................................................95
BIOS Menu 15: Console Redirection Settings...........................................................................96
BIOS Menu 16: IEI Feature...........................................................................................................98
BIOS Menu 17: Chipset................................................................................................................99
BIOS Menu 18: North Bridge Configuration ............................................................................100
BIOS Menu 19: Intel IGD Configuration....................................................................................101
BIOS Menu 20: South Bridge Configuration............................................................................103
BIOS Menu 21: PCI Express Configuration .............................................................................104
BIOS Menu 22: Security.............................................................................................................105
BIOS Menu 23: Boot...................................................................................................................106
BIOS Menu 24: Exit.....................................................................................................................108

tKINO-BW SBC
Page 1
Chapter
1
1 Introduction

tKINO-BW SBC
Page 2
1.1 Introduction
Figure 1-1: tKINO-BW
The tKINO-BW series is a Mini-ITX form factor single bard computer. It has an on-board
14nm Intel®Pentium®or Celeron®processor, and supports two 204-pin 1600/1333 MHz
single-channel unbuffered DDR3 Low Voltage (DDR3L) SDRAM SO-DIMM slots with up
to 8.0 GB of memory.
The tKINO-BW series includes a VGA connector, a HDMI/DisplayPort connector and an
18-/24-bit LVDS connector for triple independent display.
Expansion and I/O include one PCIe x1 slot, one PCIe Mini slot supporting mSATA
modules, one PCIe Mini slot for expansion, four USB 3.0 connectors on the rear panel,
two USB 2.0 connectors by pin header and two SATA 6Gb/s connectors. Serial device
connectivity is provided by four internal RS-232 connectors and two internal
RS-232/422/485 connectors. Two RJ-45 GbE connectors provide the system with smooth
connections to an external LAN.

tKINO-BW SBC
Page 3
1.2 Model Variations
The model variations of the tKINO-BW series are listed below.
Model No. SoC
tKINO-BW-N4-R10 Intel®Pentium®N3710 on-board SoC
(2.56 GHz, quad-core, 2 MB cache, TDP=6 W)
tKINO-BW-N3-R10 Intel®Celeron®N3160 on-board SoC
(2.24 GHz, quad-core, 2 MB cache, TDP=6 W)
tKINO-BW-N2-R10 Intel®Celeron®N3060 on-board SoC
(2.48 GHz, dual-core, 2 MB cache, TDP=6 W)
tKINO-BW-N1-R10* Intel®Celeron®N3010 on-board SoC
(2.24 GHz, dual-core, 2 MB cache, TDP=4 W)
*By order production, MOQ 100
Table 1-1: tKINO-BW Model Variations
1.3 Features
Some of the tKINO-BW motherboard features are listed below:
Thin Mini-ITX motherboard supports 14nm Intel®Pentium®/Celeron®on-board
SoC
Triple independent display supporting 4K resolution
Two 1600/1333 MHz DDR3L SO-DIMM slots support up to 8 GB of memory
Two SATA 6Gb/s connectors with 5 V / 12 V power output
9 V ~ 30 V wide voltage power input
Four USB 3.0 external connectors
Four RS-232 connectors and two RS-232/422/485 connectors
One microSD card socket on board
Full-size/half-size PCIe Mini card slots for expansion
Support mSATA modules
IEI One Key Recovery solution allows you to create rapid OS backup and
recovery

tKINO-BW SBC
Page 4
1.4 Connectors
The connectors on the tKINO-BW are shown in the figure below.
Figure 1-2: Connectors

tKINO-BW SBC
Page 5
1.5 Dimensions
The dimensions of the board are listed below:
Figure 1-3: Dimensions (mm)

tKINO-BW SBC
Page 6
1.6 Data Flow
Figure 1-4 shows the data flow between the system chipset, the CPU and other
components installed on the motherboard.
Figure 1-4: Data Flow Diagram
