3.5" SBC with Intel® 14nm Celeron® Braswell on-board SoC with Dual
HDMI and LVDS, Dual PCIe GbE, USB 3.1 Gen1, PCIe Mini,
SATA 6Gb/s, mSATA , COM, Audio and RoHS
WAFER-BW
Quick Installation Guide
Version 2.0
Feb 18, 2019.
Package List
WAFER-BW package includes the following items:
1 x WAFER-BW single board computer
1 x Audio cable
1 x Power cable
1 x RS-232/422/485 cable
2 x SATA with power cable kit
1 x QIG (Quick Installation Guide)
©2019 Copyright by IEI Integration corp.
All rights reserved.

2
Specifications
SoC:
Intel® Pentium® N3710 on-board SoC
(up to 2.56GHz, quad-core, 2MB cache, TDP=6W)
Intel® Celeron® N3160 on-board SoC
(up to 2.24GHz, quad-core, 2MB cache, TDP=6W)
Intel® Celeron® N3060 on-board SoC
(up to 2.48GHz, dual-core, 2MB cache, TDP=6W)
Intel® Celeron® N3010 on-board SoC
(up to 2.24GHz, dual-core, 2MB cache, TDP=4W)
BIOS:AMI UEFI BIOS
Memory:
One 204-pin 1333/1600 MHz single-channel DDR3L SDRAM
unbuffered SO-DIMM slot supports up to 8 GB
Graphics Engine:
Intel® HD Graphics Gen 8 Engine with 16 low-power execution
units, supporting DX11.1, OpenGL 4.2 and OpenCL1.2
Display Output:
Triple independent display
2 x HDMI (up to 3840x2160@30Hz)
1 x 18/24-bit dual-channel LVDS by CH7511B DP to LVDS
converter (up to 1920x1200@60Hz)
Ethernet:
LAN1: Realtek RTL8111GN controller
LAN2: Realtek RTL8111GN controller
External I/O Interfaces:
1 x RS-232
2 x USB 3.0 (on rear I/O)
Internal I/O Interfaces:
1 x 8 GB eMMC (optional)
2 x SATA 6G/s with 5V SATA power connector (no RAID)
1 x KB/MS (1x6 pin)

3
3 x RS-232 (1x9 pin, P=1.25)
1 x mSATA
4 x USB 2.0 (2x4 pin, P=2.0)
2 x RS-232/422/485 (2 by pin header) (1x9 pin, P=1.25)
SMBus: 1 x SMBus (1x4 pin)
I²C: 1 x I²C (1x4 pin)
Audio:
Realtek ALC662 HD codec
1 x Analog audio (2x5 pin)
Front Panel:
1 x Power LED & HDD LED (1x6 pin)
1 x Power button (1x2 pin)
1 x Reset button (1x2 pin)
LAN LED: 2 x LAN LED (1x2 pin)
Expansion :
2 x Full/Half-size PCIe Mini card slot (1 w/ SIM holder) (1 w/
mSATA support: share SATA signal from SATA2)
Digital I/O: 1 x 8-bit digital I/O (1x10 pin, P=1.25)
Fan Connector:
1 x Smart fan connector (1x4 pin)
Power supply:
12V only DC input
1 x Internal power connector (2x2 pin)
Support AT/ATX mode
Power Consumption:
[email protected] (Intel® Pentium® processor N3710 with 8 GB
1600 MHz DDR3L memory)
Watchdog Timer:
Software programmable supports 1~255 sec. system reset
Operating Temperature: -20°C ~ 60°C
Storage Temperature: -30°C ~ 70°C
Operation Humidity: 5% ~ 95%, non-condensing

4
Dimensions: 146mm x 102mm
Weight(GW/ NW): 600g/ 250g
Ordering Information
WAFER-BW-N4-R20:
3.5” SBC supports Intel® Pentium® quad-core processor N3710
up to 2.56GHz (6W) with dual HDMI and LVDS, Dual PCIe GbE,
PCIe Mini, USB 3.0, SATA 6Gb/s, mSATA, COM, Audio and RoHS
WAFER-BW-N3-R20:
3.5” SBC supports Intel® Celeron® quad-core processor N3160
up to 2.24GHz (6W) with dual HDMI and LVDS, Dual PCIe GbE,
PCIe Mini, USB 3.0, SATA 6Gb/s, mSATA, COM, Audio and RoHS
WAFER-BW-N2-R20:
3.5” SBC supports Intel® Celeron® dual-core processor N3060
up to 2.48GHz (6W) with dual HDMI and LVDS, Dual PCIe GbE,
PCIe Mini, USB 3.0, SATA 6Gb/s, mSATA, COM, Audio and RoHS
WAFER-BW-N1-R20**:
3.5” SBC supports Intel® Celeron® dual-core processor N3010
up to 2.24GHz (4W) with dual HDMI and LVDS, Dual PCIe GbE,
PCIe Mini, USB 3.0, SATA 6Gb/s, mSATA, COM, Audio and RoHS
**By order production, MOQ: 100
32000-070301-RS:Dual-port USB 2.0 cable, 210mm, P=2.0
32006-000300-100-RS:
PS/2 KB/MS Y-cable without bracket, 140mm/120mm
All the drivers and One Key Recovery
utility for the WAFER-BW are available
on IEI Resource Download Center. Type
WAFER-BW and press Enter to find all
the relevant software, utilities, and
documentation. To install software from
the downloaded ISO file, mount the file
as a virtual drive to view its content.
IEI Resource Download Center
https://download.ieiworld.com

5
Jumpers setting and connectors
LABEL
FUNCTION
J_ATX_AT1
Select ATX or AT mode
J_CMOS1
CMOS state setting
J_PW1
LVDS1 Voltage Selection
HDMI1
Dual HDMI Connector
LAN1
LAN1 Connector
LAN2
LAN2 Connector
USB1
External 2 Port USB3.0 Connectors
USB2
USB3
External 2 Port USB2.0 Connectors
COM1
External Serial Port Connector
COM2
COM3
COM4
COM5
COM6
Internal Serial Port Connectors
AUDIO1
HD Audio Connector
SATA1
SATA2
Serial ATA Connectors
SATA_PWR1
SATA_PWR2
SATA Power Connector
LVDS1
LVDS1 Panel Connector
INV1
LVDS1 Panel Backlight +12V Power Source
CN1
Power & HDD LED Connector
RST_BTN1
Reset Button Connector
PWR_BTN1
Power Button Connector
PWR1
Power Source Connector
MINI_PCIE1
MINI_PCIE2
Mini PCI-E Card Connector
DIO1
Digital I/O Connector
J_KB/MS1
KEYBOARD & MOUSE Connectors
J_I2C1/J_SMB1
I2C / SMBUS Connector
CPU_FAN1
CPU Fan Connector
SIM1
SIM Card Connector

6
USB2 & USB3: Internal USB Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
USB_VCC
2
GND
3
DATA-
4
DATA+
5
DATA+
6
DATA-
7
GND
8
USB_VCC
LAN1: RJ45 LAN Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
LAN1_MDI0+
7
LAN1_MDI2+
2
LAN1_MDI0-
8
LAN1_MDI2-
3
LAN1_MDI1+
9
LAN1_MDI3+
4
LAN1_MDI1-
10
LAN1_MDI3-
LAN2: RJ45 LAN Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
LAN1_MDI0+
7
LAN1_MDI2+
2
LAN1_MDI0-
8
LAN1_MDI2-
3
LAN1_MDI1+
9
LAN1_MDI3+
4
LAN1_MDI1-
10
LAN1_MDI3-
J_ATX_AT1: AT/ATX Power Mode Setting
PIN NO.
DESCRIPTION
Short 1 - 2
ATX Power Mode (default)
Short 2 - 3
AT Power Mode
J_PW1: LVDS1 Voltage Selection
PIN NO.
DESCRIPTION
Short 1 - 2
+3.3V LVDS (default)
Short 2 - 3
+5V LVDS
J_CMOS1: Clear CMOS Setup
PIN NO.
DESCRIPTION
Open
Normal Operation (Default)
Push
Clear CMOS Setup

7
HDMI1: Dual 19-pin HDMI Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
A1 HDMI_A_DATA2P B1 HDMI_B_DATA2P
A2
GND
B2
GND
A3
HDMI_A_DATA2N
B3
HDMI_B_DATA2N
A4
HDMI_A_DATA1P
B4
HDMI_B_DATA1P
A5
GND
B5
GND
A6
HDMI_A_DATA1N
B6
HDMI_B_DATA1N
A7
HDMI_A_DATA0P
B7
HDMI_B_DATA0P
A8
GND
B8
GND
A9
HDMI_A_DATA0N
B9
HDMI_B_DATA0N
A10
HDMI_A_CLKP
B10
HDMI_B_CLKP
A11 GND B11 GND
A12
HDMI_A_CLKN
B12
HDMI_B_CLKN
A13
N/A
B13
N/A
A14
N/A
B14
N/A
A15
HDMI_A_SCL
B15
HDMI_B_SCL
A16
HDMI_A_SDA
B16
HDMI_B_SDA
A17
GND
B17
GND
A18
+5V
B18
+5V
A19
HDMI_A_HPD
B19
HDMI_B_HPD
USB1: External USB3.0 Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
USB_VCC
2
USB2_D0-
3
USB2_D0+
4
GND
5
USB3_RXD0-
6
USB3_RXD0+
7
GND
8
USB3_TXD0-
9
USB3_TXD0+
10
USB_VCC
11
USB2_D1-
12
USB2_D1+
13
GND
14
USB3_RXD1-
15
USB3_RXD1+
16
GND
17
USB3_TXD1-
18
USB3_TXD1+

8
COM4/6: Internal Serial Port Connector
Mode
RS232
RS422
RS485
PIN NO.
DESCRIPTION
DESCRIPTION
DESCRIPTION
1
DCD
TXD-
DATA-
2
DSR
N/A
N/A
3
RXD
TXD+
DATA+
4
RTS
N/A
N/A
5
TXD
RXD+
N/A
6
CTS
N/A
N/A
7
DTR
RXD-
N/A
8
RI
N/A
N/A
9
GND
N/A
N/A
COM2/3/5: Internal Serial Port Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
DCD
2
DSR
3
RXD
4
RTS
5
TXD
6
CTS
7
DTR
8
RI
9
GND
COM1: External Serial Port Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
DCD
2
RXD
3
TXD
4
DTR
5
GND
6
DSR
7
RTS
8
CTS
9
RI
AUDIO1: Audio Line-In/Out MIC Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
LINE-OUT_R
2
LINE-IN_R
3
AUD_GND
4
AUD_GND
5
LINE-OUT_L
6
LINE-IN_L
7
AUD_GND
8
AUD_GND
9
MIC1_R
10
MIC1_L

9
LVDS1: LVDS Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
GND
3
A_Y0
4
A_Y0#
5
A_Y1
6
A_Y1#
7
A_Y2
8
A_Y2#
9
A_CK
10
A_CK#
11
A_Y3
12
A_Y3#
13
GND
14
GND
15
B_Y0
16
B_Y0#
17
B_Y1
18
B_Y1#
19
B_Y2
20
B_Y2#
21
B_CK
22
B_CK#
23
B_Y3
24
B_Y3#
25
GND
26
GND
27
VCC/VCC3
28
VCC/VCC3
29
VCC/VCC3
30
VCC/VCC3
SATA1/2 : Serial ATA Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
5
RX-
2
TX+
6
RX+
3
TX-
7
GND
4
GND
8
N/C
INV1: 5-pin Header Inverter Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
LCD_BKLTCTL
2
GROUND
3
+12V
4
GROUND
5
BACKLIGHT ENABLE
SATA_PWR1/2: SATA Power Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
+5V
2
Ground

10
SIM1: SIM Card Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
SIM_VCC
2
SIM_RST
3
SIM_Clock
5
GND
6
SIM_VPP
7
SIM_DATA
CPU_FAN1: CPU Fan Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
+V12S
3
Rotation Signal
4
PWM Control Signal
PWR1: +12V Power Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
GND
3
+12V
4
+12V
PWR_BTN1: Power Button Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
PWR_BTN+
2
PWR_BTN-
RST_BTN1: Reset Button Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
RESET+
2
RESET-
CN1: Power LED & HDD LED connector
PIN NO.
DESCRIPTION
+5V
1
VCC
2
GND
Power LED
3
PWR_LED+
4
PWR_LED-
HDD LED
5
HDD_LED+
6
HDD_LED-

11
MINI_PCIE1: Mini PCI-E Card Connector(Support SIM Card)
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
PCIE_WAKE#
2
VCC3
3
N/C
4
GND
5
N/C
6
1.5V
7
N/C
8
UIM_PWR
9
GND
10
UIM_DATA
11
PCIE_CLK#
12
UIM_CLK
13
PCIE_CLK
14
UIM_RST
15
GND
16
UIM_VPP
17
N/C
18
GND
19
N/C
20
N/C
21
GND
22
PCIRST#
23
PCIE_RXN
24
N/C
25
PCIE_RXP
26
GND
27
GND
28
1.5V
29
GND
30
SMBCLK
31
PCIE_TXN
32
SMBDATA
33
PCIE_TXP
34
GND
35
GND
36
USBD-
37
GND
38
USBD+
39
VCC3
40
GND
41
VCC3
42
N/C
43
GND
44
N/C
45
N/C
46
N/C
47
N/C
48
1.5V
49
N/C
50
GND
51
N/C
52
VCC3

12
MINI_PCIE2: Mini PCI-E Card Connector(Support mSATA)
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
PCIE_WAKE#
2
VCC3
3
N/C
4
GND
5
N/C
6
1.5V
7
N/C
8
N/C
9
GND
10
N/C
11
PCIE_CLK#
12
N/C
13
PCIE_CLK
14
N/C
15
GND
16
N/C
17
N/C
18
GND
19
N/C
20
N/C
21
GND
22
PCIRST#
23
PCIE_RXN(SATA_RX+)
24
N/C
25
PCIE_RXP(SATA_RX-)
26
GND
27
GND
28
1.5V
29
GND
30
SMBCLK
31
PCIE_TXN(SATA_TX-)
32
SMBDATA
33
PCIE_TXP(SATA_TX+)
34
GND
35
GND
36
USBD-
37
GND
38
USBD+
39
VCC3
40
GND
41
VCC3
42
N/C
43
GND
44
N/C
45
N/C
46
N/C
47
N/C
48
1.5V
49
N/C
50
GND
51
N/C
52
VCC3

13
J_I2C1/J_SMB1 : 4-pin Header SMBUS Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
SMBUS(I2C) DATA
3
SMBUS(I2C) CLK
4
+5V
J_KB/MS1: 6-pin header Keyboard/Mouse Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
VCC
2
Mouse Data
3
Mouse Clock
4
Keyboard Data
5
Keyboard Clock
6
GND
DIO1 : Digital Input / Output Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
Ground
2
+5V
3
Output 3
4
Output 2
5
Output 1
6
Output 0
7
Input 3
8
Input 2
9
Input 1
10
Input 0

14
Board Layout: Jumper and Connector Locations
(Unit: mm)
