IEI Technology gKINO-DMF-421-R10 User manual

gKINO-DMF SBC
Page I
User Manual
gKINO-DMF
MODEL:
Mini-ITX SBC with AMD Embedded R-Series On-board SoC,
DisplayPort++, Dual PCIe GbE, USB 3.0, PCIe Mini, M.2, PCIe x8,
SATA 6Gb/s, RS-232/422/485, ccTalk, Audio, TPM and RoHS
Rev. 1.00 - June 29, 2017
gKINO-DMF CPU Card

gKINO-DMF SBC
Page II
Revision
Date Version Changes
June 29, 2017 1.00 Initial release

gKINO-DMF SBC
Page III
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

gKINO-DMF SBC
Page IV
Manual Conventions
WARNING
Warnings appear where overlooked details may cause damage to the
equipment or result in personal injury. Warnings should be taken
seriously.
CAUTION
Cautionary messages should be heeded to help reduce the chance of
losing data or damaging the product.
NOTE
These messages inform the reader of essential but non-critical
information. These messages should be read carefully as any directions
or instructions contained therein can help avoid making mistakes.
HOT SURFACE
This symbol indicates a hot surface that should not be touched without
taking care.

gKINO-DMF SBC
Page V
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 INTRODUCTION........................................................................................................... 2
1.2 MODEL VARIATIONS ................................................................................................... 3
1.3 FEATURES................................................................................................................... 3
1.4 CONNECTORS ............................................................................................................. 4
1.5 DIMENSIONS............................................................................................................... 6
1.6 DATA FLOW................................................................................................................ 7
1.7 TECHNICAL SPECIFICATIONS ...................................................................................... 8
2 UNPACKING................................................................................................................11
2.1ANTI-STATIC PRECAUTIONS...................................................................................... 12
2.2 UNPACKING PRECAUTIONS....................................................................................... 12
2.3 PACKING LIST........................................................................................................... 13
2.4 OPTIONAL ITEMS...................................................................................................... 14
3 CONNECTORS ........................................................................................................... 15
3.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 16
3.1.1 gKINO-DMF Layout........................................................................................ 16
3.1.2 Peripheral Interface Connectors ..................................................................... 18
3.1.3 External Interface Panel Connectors............................................................... 19
3.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 20
3.2.1 12 V DC-IN Power Connector......................................................................... 20
3.2.2 Audio Connector .............................................................................................. 21
3.2.3 Battery Connector............................................................................................ 22
3.2.4 ccTalk Connectors............................................................................................ 23
3.2.5 Chassis Intrusion Connector............................................................................ 24
3.2.6 Digital I/O Connector...................................................................................... 25
3.2.7 Fan Connectors................................................................................................ 26
3.2.8 Front Panel Connector .................................................................................... 27
3.2.9 I2C Connector .................................................................................................. 28
3.2.10 LAN LED Connectors.................................................................................... 29

gKINO-DMF SBC
Page VI
3.2.11 M.2 Slot .......................................................................................................... 30
3.2.12 microSD Slot .................................................................................................. 31
3.2.13 PCIe Mini Card Slot ...................................................................................... 31
3.2.14 PCIe x8 Card Slot.......................................................................................... 33
3.2.15 RS-232 Serial Port Connectors...................................................................... 34
3.2.16 RS-232/422/485 Serial Port Connectors ....................................................... 35
3.2.17 SATA 6Gb/s Drive Connectors....................................................................... 36
3.2.18 SATA Power Connectors................................................................................ 37
3.2.19 SMBus Connector .......................................................................................... 38
3.2.20 SPI Flash Connector, BIOS............................................................................ 39
3.2.21 SPI Flash Connector, EC............................................................................... 40
3.2.22 TPM Connector.............................................................................................. 41
3.2.23 USB 2.0 Connectors....................................................................................... 42
3.3 EXTERNAL PERIPHERAL INTERFACE CONNECTOR PANEL ......................................... 43
3.3.1 Audio Jacks...................................................................................................... 43
3.3.2 DisplayPort++ Connector............................................................................... 44
3.3.3 HDMI Connectors............................................................................................ 45
3.3.4 LAN and USB 3.0 Combo Connectors............................................................. 46
3.3.5 Power Connector............................................................................................. 48
3.3.6 USB 2.0 Connector .......................................................................................... 48
4 INSTALLATION ......................................................................................................... 49
4.1ANTI-STATIC PRECAUTIONS...................................................................................... 50
4.2 INSTALLATION CONSIDERATIONS.............................................................................. 50
4.3 SO-DIMM INSTALLATION ....................................................................................... 52
4.4 M.2 MODULE INSTALLATION.................................................................................... 53
4.5 PCIE MINI CARD INSTALLATION .............................................................................. 53
4.5.1 Full-size PCIe Mini Card Installation............................................................. 53
4.5.2 Half-size PCIe Mini Card Installation............................................................. 55
4.6 SYSTEM CONFIGURATION......................................................................................... 58
4.6.1 AT/ATX Mode Select Switch............................................................................. 58
4.6.2 Clear CMOS Button......................................................................................... 59
4.6.3 M.2 and SATA2 Select Jumper......................................................................... 59
4.7 CHASSIS INSTALLATION............................................................................................ 60
4.7.1 Airflow.............................................................................................................. 60

gKINO-DMF SBC
Page VII
4.7.2 Motherboard Installation................................................................................. 60
4.8 SATADRIVE CONNECTION ...................................................................................... 61
5 BIOS.............................................................................................................................. 63
5.1 INTRODUCTION......................................................................................................... 64
5.1.1 Starting Setup................................................................................................... 64
5.1.2 Using Setup...................................................................................................... 64
5.1.3 Getting Help..................................................................................................... 65
5.1.4 Unable to Reboot after Configuration Changes.............................................. 65
5.1.5 BIOS Menu Bar................................................................................................ 65
5.2 MAIN........................................................................................................................ 66
5.3ADVANCED............................................................................................................... 67
5.3.1 Trusted Computing........................................................................................... 68
5.3.2 ACPI Settings................................................................................................... 69
5.3.3 IDE Configuration........................................................................................... 70
5.3.4 F81866 Super IO Configuration...................................................................... 71
5.3.4.1 Serial Port n Configuration....................................................................... 71
5.3.4.1.1 Serial Port 1 Configuration................................................................ 72
5.3.4.1.2 Serial Port 2 Configuration................................................................ 73
5.3.4.1.3 Serial Port 3 Configuration................................................................ 74
5.3.4.1.4 Serial Port 4 Configuration................................................................ 75
5.3.4.1.5 Serial Port 5 Configuration................................................................ 76
5.3.4.1.6 Serial Port 6 Configuration................................................................ 77
5.3.5 iWDD H/W Monitor......................................................................................... 79
5.3.5.1 Smart Fan Mode Configuration................................................................ 80
5.3.6 RTC Wake Settings........................................................................................... 82
5.3.7 Power Saving Configuration............................................................................ 83
5.3.8 CPU Configuration.......................................................................................... 85
5.3.8.1 Node 0 Information................................................................................... 86
5.3.9 NVMe Configuration........................................................................................ 86
5.3.10 USB Configuration......................................................................................... 87
5.4 CHIPSET ................................................................................................................... 88
5.4.1 South Bridge..................................................................................................... 89
5.4.1.1 SB SATA Configuration............................................................................ 90
5.4.2 GFX Configuration.......................................................................................... 91

gKINO-DMF SBC
Page VIII
5.4.3 North Bridge .................................................................................................... 92
5.5 SECURITY................................................................................................................. 93
5.6 BOOT........................................................................................................................ 94
5.7 SAVE &EXIT............................................................................................................ 96
6 SOFTWARE DRIVERS.............................................................................................. 98
6.1 SOFTWARE INSTALLATION ........................................................................................ 99
6.2AVAILABLE SOFTWARE DRIVERS ............................................................................ 100
A REGULATORY COMPLIANCE............................................................................ 101
B PRODUCT DISPOSAL............................................................................................ 103
C BIOS MENU OPTIONS........................................................................................... 105
D TERMINOLOGY ..................................................................................................... 108
E DIGITAL I/O INTERFACE......................................................................................112
F WATCHDOG TIMER................................................................................................115
G HAZARDOUS MATERIALS DISCLOSURE........................................................118

gKINO-DMF SBC
Page IX
List of Figures
Figure 1-1: gKINO-DMF..................................................................................................................2
Figure 1-2: Connectors (Front Side).............................................................................................4
Figure 1-3: Connectors (Solder Side)...........................................................................................5
Figure 1-4: Dimensions (mm)........................................................................................................6
Figure 1-5: Data Flow Diagram......................................................................................................7
Figure 3-1: Connector and Jumper Locations (Front)..............................................................16
Figure 3-1: Connector and Jumper Locations (Rear)...............................................................17
Figure 3-2: DC-IN Power Connector Location ...........................................................................20
Figure 3-3: Audio Connector Location.......................................................................................21
Figure 3-4: Battery Connector Location.....................................................................................22
Figure 3-5: ccTalk Connector Locations....................................................................................23
Figure 3-6: Chassis Intrusion Connector Location...................................................................24
Figure 3-7: Digital I/O Connector Location ................................................................................25
Figure 3-8: Fan Connector Locations.........................................................................................26
Figure 3-9: Front Panel Connector Location .............................................................................27
Figure 3-10: I2C Connector Location ..........................................................................................28
Figure 3-11: LAN LED Connector Locations .............................................................................29
Figure 3-12: M.2 Slot Location ....................................................................................................30
Figure 3-13: microSD Card Slot Location..................................................................................31
Figure 3-14: PCIe Mini Card Slot Location.................................................................................32
Figure 3-15: PCIe x1 Slot Location .............................................................................................33
Figure 3-16: RS-232 Serial Port Connector Locations..............................................................34
Figure 3-17: RS-232/422/485 Connector Locations...................................................................35
Figure 3-18: SATA 6Gb/s Drive Connectors Locations............................................................36
Figure 3-19: SATA Power Connector Locations .......................................................................37
Figure 3-20: SMBus Connector Location...................................................................................38
Figure 3-21: SPI Flash Connector Location...............................................................................39
Figure 3-22: SPI Flash Connector Location...............................................................................40
Figure 3-23: TPM Connector Location........................................................................................41
Figure 3-24: USB Connector Locations......................................................................................42
Figure 3-25: External Peripheral Interface Connector..............................................................43

gKINO-DMF SBC
Page X
Figure 3-26: Audio Connector.....................................................................................................44
Figure 3-27: DisplayPort++ Connector Pinout Locations.........................................................45
Figure 3-28: HDMI Connector......................................................................................................46
Figure 3-29: Ethernet Connector.................................................................................................46
Figure 3-30: Power Connector ....................................................................................................48
Figure 4-1: SO-DIMM Installation (DDR4)...................................................................................52
Figure 4-2: Removing the Retention Screw...............................................................................54
Figure 4-3: Inserting the Full-size PCIe Mini Card into the Slot at an Angle..........................54
Figure 4-4: Securing the Full-size PCIe Mini Card ....................................................................55
Figure 4-5: Removing Retention Screw and Standoff ..............................................................56
Figure 4-6: Installing the Standoff ..............................................................................................56
Figure 4-7: Inserting the Half-size PCIe Mini Card into the Slot at an Angle..........................57
Figure 4-8: Securing the Half-size PCIe Mini Card....................................................................57
Figure 4-9: AT/ATX Mode Select Switch Location ....................................................................58
Figure 4-10: Clear CMOS Button Location.................................................................................59
Figure 4-11: M.2 and SATA2 Select Switch Location................................................................60
Figure 4-12: SATA Drive Cable Connection...............................................................................61
Figure 4-13: SATA Power Drive Connection..............................................................................62
Figure 6-1: Available Drivers.......................................................................................................99

gKINO-DMF SBC
Page XI
List of Tables
Table 1-1: gKINO-DMF Model Variations......................................................................................3
Table 1-2: Technical Specifications............................................................................................10
Table 3-1: Peripheral Interface Connectors...............................................................................19
Table 3-2: Rear Panel Connectors..............................................................................................19
Table 3-3: DC-IN Power Connector Pinouts...............................................................................20
Table 3-4: Audio Connector Pinouts ..........................................................................................21
Table 3-5: Battery Connector Pinouts........................................................................................22
Table 3-6: ccTalk Connector Pinouts .........................................................................................23
Table 3-7: Chassis Intrusion Connector Pinouts......................................................................24
Table 3-8: Digital I/O Connector Pinouts....................................................................................25
Table 3-9: Fan Connector Pinouts..............................................................................................26
Table 3-10: Front Panel Connector Pinouts...............................................................................27
Table 3-11: I2C Connector Pinouts..............................................................................................28
Table 3-12: LAN LED Connector Pinouts...................................................................................29
Table 3-13: PCIe Mini Card Slot Pinouts ....................................................................................33
Table 3-14: RS-232 Serial Port Connector Pinouts...................................................................34
Table 3-15: RS-232/422/485 Connector Pinouts........................................................................35
Table 3-16: DB-9 RS-422/485 Pinouts.........................................................................................36
Table 3-17: SATA Power Connector Pinouts.............................................................................37
Table 3-18: SMBus Connector Pinouts ......................................................................................38
Table 3-19: SPI Flash Connector Pinouts ..................................................................................39
Table 3-20: SPI Flash Connector Pinouts ..................................................................................40
Table 3-21: TPM Connector Pinouts...........................................................................................41
Table 3-22: USB Connector Pinouts...........................................................................................42
Table 3-23: DisplayPort++ Connector Pinouts ..........................................................................45
Table 3-24: HDMI Connector Pinouts .........................................................................................45
Table 3-25: LAN1 Ethernet Connector Pinouts .........................................................................46
Table 3-26: Connector LEDs........................................................................................................47
Table 3-27: USB 3.0 Port Pinouts................................................................................................47
Table 3-28: USB 2.0 Port Pinouts................................................................................................48
Table 4-1: AT/ATX Mode Select Switch Settings.......................................................................58

gKINO-DMF SBC
Page XII
Table 4-2: M.2 and SATA2 Select Switch Settings....................................................................59
Table 5-1: BIOS Navigation Keys................................................................................................65

gKINO-DMF SBC
Page XIII
List of BIOS Menus
BIOS Menu 1: Main.......................................................................................................................66
BIOS Menu 2: Advanced..............................................................................................................67
BIOS Menu 3: Trusted Computing..............................................................................................68
BIOS Menu 4: ACPI Settings .......................................................................................................69
BIOS Menu 5: IDE Configuration.................................................................................................70
BIOS Menu 6: F81866 Super IO Configuration ..........................................................................71
BIOS Menu 7: Serial Port n Configuration .................................................................................71
BIOS Menu 8: iWDD H/W Monitor ...............................................................................................79
BIOS Menu 9: Smart Fan Mode Configuration ..........................................................................80
BIOS Menu 10: RTC Wake Settings............................................................................................82
BIOS Menu 11: Power Saving Configuration.............................................................................83
BIOS Menu 12: CPU Configuration.............................................................................................85
BIOS Menu 13: Node 0 Information ............................................................................................86
BIOS Menu 14: NVMe Configuration...........................................................................................86
BIOS Menu 15: USB Configuration.............................................................................................87
BIOS Menu 16: Chipset................................................................................................................88
BIOS Menu 17: South Bridge.......................................................................................................89
BIOS Menu 18: SB SATA Configuration.....................................................................................90
BIOS Menu 19: GFX Configuration.............................................................................................91
BIOS Menu 20: North Bridge .......................................................................................................92
BIOS Menu 21: Security...............................................................................................................93
BIOS Menu 22: Boot.....................................................................................................................94
BIOS Menu 23: Save & Exit..........................................................................................................96

gKINO-DMF SBC
Page 1
Chapter
1
1 Introduction

gKINO-DMF SBC
Page 2
1.1 Introduction
Figure 1-1: gKINO-DMF
The gKINO-DMF series is a Mini-ITX form factor single bard computer. It has an on-board
AMD RX-421BD or RX-216GD processor, and supports two 260-pin 2400 MHz
dual-channel DDR4 ECC unbuffered SDRAM SO-DIMM slots with up to 64.0 GB of
memory.
The gKINO-DMF series includes two external HDMI 1.4 connectors and one external
Dual-mode DisplayPort (DisplayPort++) connector for triple independent display which
support up to 4K resolution.
Expansion and I/O include one PCIe x8 slot, one PCIe Mini slot, one M.2 B-key slot for
expansion, four USB 3.0 connectors on the rear panel, four USB 2.0 connectors by pin
header and two SATA 6Gb/s connectors. Serial device connectivity is provided by two
internal RS-232 connectors, two internal RS-232/422/485 connectors and two ccTalk
connectors. Two RJ-45 GbE connectors provide the system with smooth connections to
an external LAN.

gKINO-DMF SBC
Page 3
1.2 Model Variations
The model variations of the gKINO-DMF series are listed below.
Model No. SoC
gKINO-DMF-421-R10 AMD RX-421BD on-board SoC
(2.1 GHz, quad-core, 2 MB cache, TDP=35 W)
gKINO-DMF-216-R10 AMD RX-216GD on-board SoC
(1.6 GHz, quad-core, 1 MB cache, TDP=15 W)
Table 1-1: gKINO-DMF Model Variations
1.3 Features
Some of the gKINO-DMF motherboard features are listed below:
Mini-ITX motherboard supports AMD RX-421BD or RX-216GD on-board SoC
Triple independent display via HDMI 1.4 and DP++
Two 2400 MHz DDR4 SO-DIMM slots support up to 64 GB of memory
Two SATA 6Gb/s connectors with 5 V power output
Full-size/half-size PCIe Mini card slot for expansion
M.2 B-key modules supported
Support microSD card for data storage
One PCIe x8 slot for expansions
Four USB 3.0 external connectors
Two RS-232 connectors and two RS-232/422/485 connectors
IEI One Key Recovery solution allows you to create rapid OS backup and
recovery

gKINO-DMF SBC
Page 4
1.4 Connectors
The connectors on the gKINO-DMF are shown in the figures below.
Figure 1-2: Connectors (Front Side)

gKINO-DMF SBC
Page 5
Figure 1-3: Connectors (Solder Side)

gKINO-DMF SBC
Page 6
1.5 Dimensions
The dimensions of the board are listed below:
Figure 1-4: Dimensions (mm)
