IEI Technology IMB-H810-i2 User manual

1
Micro ATX Motherboard supports 22nm LGA1150 Intel® Core™
i7/i5/i3/Pentium® and Celeron® CPU per Intel® H81, DDR3,
VGA, Dual Intel® PCIe GbE, USB 2.0, PCI, COM, LPT,
SATA 6Gb/s, HD Audio, iRIS-2400 and RoHS
IMB-H810-i2
Quick Installation Guide
Version 1.1
Sep. 08, 2015.
Package List
IMB-H810-i2 package includes the following items:
1 x IMB-H810-i2 single board computer
1 x I/O shielding
2 x SATA cable
1 x Utility CD
1 x QIG (Quick Installation Guide)
©2006 Copyright by IEI Integration corp.
All rights reserved.

2
Specifications
CPU:
LGA1150 Intel® 4th generation Core™ i7/i5/i3/Pentium®/
Celeron® processor supported
System Chipset: Intel® H81
Memory:
Two 240-pin 1333/1066MHz dual-channel DDR3 SDRAM
unbuffered DIMMs supported (system max. 16GB)
BIOS: UEFI BIOS
Graphic Engine:
Intel® HD Graphics Gen 7.5 support for DX11.1 and OpenCL
1.2, OpenGL 3.2 Full MPEG2, VC1, AVC Decode
Display Output:
VGA1 (Up to 1920x1200 @ 60 Hz)
VGA2 (Up to 1920x1200 @ 60 Hz)
iDP interface for HDMI, LVDS, VGA, DVI, DP
(Up to 3840x2160 @60 Hz)
Ethernet:
LAN1: Intel® I210 PCIe controller
LAN2: Intel® I211 PCIe controller
Super IO: Fintek F81866
PCIE-PCI Bridge: ITE IT8892E
EC: iWDD
Audio:
Realtek ALC662 HD Audio codec
Line-in, Line-out, Mic
Audio Jack:
Line-in, Line-out (with 3.5W +3.5W audio amplifier), Mic
I/O Interface:
2 x RS-232 (Rear IO)
8 x RS-232 (3-6 ports, 7-10 ports)
1 X RS-422/485 by s/w selection (Colay COM10)

3
1 x LPT
1 x PS/2 KB/MS
4 x USB 2.0 (4 by pin header)
2 x USB 3.0 (Rear IO)
6 x USB 2.0 (2 by Rear IO, 4 by pin header)
4 x SATA 6Gb/s
Watchdog Timer:
Software programmable support 1~255 sec. system reset
FAN:
1 x 4-pin CPU fan connector
1 x 4-pin NB/system fan connector
Front Panel:
1 x Front Panel (Power LED, HDD LED, Speaker (Buzzer),
Power Button, Reset Button)
TPM: 1 x 20-pin (2x10) header
SMBus: 1 x 4-pin (1x4) wafer
I2C: 1 x 4-pin (1x4) wafer
IPMI: 1 x DDR3 SO-DIMM slot supports iRIS-2400
Expansion:
1 x PCIe x16 slot
1 x PCIe x1 slot
2 x PCI slots
Power supply: ATX/AT power supply
Operation Temperature: -10°C ~ 60°C
Operation Humidity: 5% ~ 95%, non-condensing
Dimensions: 244mm x 244mm
Weight GW/NW: 1200g / 680g

4
Ordering Information
IMB-H810-i2-R11:
Micro ATX motherboard supports 22nm LGA1150 Intel® Core™
i7/i5/i3/Pentium® and Celeron® CPU per Intel® H81, DDR3,
VGA, Dual Intel® PCIe GbE, USB 2.0, PCI, COM, SATA 6Gb/s,
LPT, HD Audio, iRIS-2400 and RoHS
32205-001203-100-RS: RS-232 cable, 40 pin to 4 x D-SUB 9 pin
19800-003100-200-RS: Dual ports USB cable with bracket
19800-010500-100-RS: USB 3.0 cable with bracket
32205-003800-100-RS: RS-232 cable, 230mm (P=2.54)
32102-000100-200-RS:
SATA power cable, MOLEX 5264-4P to SATA15P
19800-000075-RS: PS/2 KB/MS Y-cable with bracket, 220mm
19800-000049-RS: LPT cable
CF-1156A-RS-R11:
High performance LGA1155/LGA1156 cooler kit, 1U chassis
compatible, 73W
CF-1156E-R11:
High performance LGA1155/LGA1156 cooler kit, 95W
DP-LVDS-R10:
DisplayPort to 24 bit dual channel LVDS converter board
(For iEi IDP connector)
DP-HDMI-R10:
DisplayPort to HDMI converter board (For iEi IDP connector)
DP-DVI-R10:
DisplayPort to DVI-D converter board (For iEi IDP connector)
DP-VGA-R10:
DisplayPort to VGA converter board (For iEi IDP connector)
DP-DP-R10:
DisplayPort to DisplayPort converter board (For iEi IDP connector)
TPM-IN01-R11: 20-Pin Infineon TPM module, software management
tool, firmware V3.17

5
Jumpers setting and connectors
LABEL FUNCTION
J_ATX_AT1 AT/ATX mode select switch
J_CMOS1 Clear CMOS button
JP3 COM10 RS232/RS422 or RS485 type selection
USB SW1, USB SW2 USB power setting
CPU_FAN1 CPU fan connector
CPU12V1 +12V power source connector
ATX1 24-pin ATX power source connector
ATXPWR1 PCI-E power connector
CHA_DIMM1, CHB_DIMM1
DDR3 DIMM slots
DP1 Display port connector
CN3 EC Debug Port Connector
JSPI1 Flash SPI ROM
JSPI2 Flash EC ROM
F_PANEL1 PWR & RST buttons and indicators
LPT1 Parallel port connector
IPMI1 Collocation IPMI module(iRIS-2400)
CN5 I2C connector
COM3-6, COM7-10 Internal RS-232 serial port connectors
CN10 Internal RS-422/485 serial port connector
SATA1, SATA2
SATA3, SATA4 Serial ATA 3.0 connectors
CN1 SMBUS connector
SYS_FAN1, SYS_FAN2 System fan connector
TPM1 TPM connector
USB3 ~ 6 Internal USB 2.0 connectors
AUDIO_CV1 HD audio connector
COM1, COM2 External RS-232 serial port connector
LAN1_USB1 RJ45 LAN and USB 3.0 connectors
LAN2_USB2 RJ45 LAN and USB 2.0 connectors
KBMS1 PS/2 Keyboard and mouse connector
VGA1, VGA2 VGA connectors
FP_AUDIO1 Front panel audio connector

6
JP3: COM10 RS232/RS422 or RS485 type selection
PIN NO. DESCRIPTION
Short 1 - 2 RS232 (default)
Short 2 - 3 RS422 or RS485
USB SW1, USB SW2: USB power setting
USB SW1 DESCRIPTION
+5V DUAL +5V DUAL(default)
+5V +5V
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Chipset
Auto Power Button Status [Disabled(ATX)]
Restore AC Power Loss [Last State]
> PCI Express Configuration
> PCI Azalia Configuration
Power Saving Function(ERP) [Disabled]
PCIEX16 Power [1 x16 PCIE]
USB SW1 [+5V DUAL]
USB SW2 [+5V DUAL]
------------------
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
J_CMOS1: Clear CMOS button
PIN NO. DESCRIPTION
NC (default)
Keep CMOS Setup
(Normal Operation)
Press button Clear CMOS Setup
J_ATX_AT1: AT/ATX mode select switch
PIN NO. DESCRIPTION
Short 1 - 2 ATX Mode (default)
Short 2 - 3 AT Mode

7
ATXPWR1: PCI-E power connector
PIN NO.
DESCRIPTION PIN NO.
DESCRIPTION
1 +5V 2 GND
3 GND 4 +12V
ATX1: 24-pin ATX power source connector
PIN NO.
DESCRIPTION PIN NO.
DESCRIPTION
1 +3.3V 13 +3.3V
2 +3.3V 14 -12V
3 GND 15 GND
4 +5V 16 PS_ON
5 GND 17 GND
6 +5V 18 GND
7 GND 19 GND
8 Power good 20 -5V
9 5VSB 21 +5V
10 +12V 22 +5V
11 +12V 23 +5V
12 +3.3V 24 GND
CPU12V1: +12V power source connector
PIN NO.
DESCRIPTION PIN NO.
DESCRIPTION
1 GND 2 GND
3 +12V 4 +12V
CPU_FAN1: CPU fan connector
PIN NO. DESCRIPTION
PIN NO. DESCRIPTION
1 GND 2 +12V
3 FANIO 4 PWM

8
JSPI1: Flash SPI ROM connector
PIN NO.
DESCRIPTION PIN NO.
DESCRIPTION
1 +3.3V 2 SPI_CS#
3 SPI_SO 4 NC
5 GND 6 SPI_CLK
7 SPI_SI 8 NC
CN3: EC debug connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 EC_EPP_STB#
2 EC_EPP_AFD#
3 EC_EPP_PD0 4 NC
5 EC_EPP_PD1 6 EC_EPP_INIT#
7 EC_EPP_PD2 8 EC_EPP_SLIN#
9 EC_EPP_PD3 10 GND
11 EC_EPP_PD4 12 NC
13 EC_EPP_PD5 14 EC_EPP_BUSY
15 EC_EPP_PD6 16 EC_EPP_KSI5
17 EC_EPP_PD7 18 EC_EPP_KSI4
DP1: Display port connector
PIN NO.
DESCRIPTION PIN NO.
DESCRIPTION
1 +5V 2 LANE1N
3 LANE1P 4 GND
5 LANE3N 6 LANE3P
7 GND 8 AUX_CTRL_DET_D
9 GND 10 HPD
11 AUXP 12 AUXN
13 GND 14 LANE2P
15 LANE2N 16 GND
17 LANE0P 18 LANE0N
19 +3.3V 20 NC

9
LPT1: Parallel Port Connector
PIN
DESCRIPTION PIN
DESCRIPTION
1 STROBE# 2 DATA 0
3 DATA 1 4 DATA 2
5 DATA 3 6 DATA 4
7 DATA 5 8 DATA 6
9 DATA 7 10 ACKNOWLEDGE
11 BUSY 12 PAPER EMPTY
13 PRINTER SELECT 14 AUTO FORM FEED #
15 ERROR# 16 INITIALIZE
17 PRINTER SELECT LN# 18 GROUND
19 GROUND 20 GROUND
21 GROUND 22 GROUND
23 GROUND 24 GROUND
25 GROUND 26 NC
JSPI2: Flash EC ROM connector
PIN NO.
DESCRIPTION PIN NO.
DESCRIPTION
1 +3.3V 2 SPI_CS#
3 SPI_SO 4 NC
5 GND 6 SPI_CLK
7 SPI_SI 8 NC
F_PANEL1: PWR & RST buttons and indicators
PIN
DESCRIPTION PIN
DESCRIPTION
PWR
LED
1 +5V 2 BEEP_PWR
SPKR
3 NC 4 NC
5 GND 6 NC
PWR
BTN
7 PWRBTN_SW# 8 PC_BEEP
9 GND 10 NC
HDD
LED
11 +5V 12 EXTRST- RESET
13 SATA_LED# 14 GND

10
CN5: I2C connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1
GND 2 PCH_GP38
3
PCH_GP39 4 +5V
COM3-6: Internal RS-232 serial port connectors
Function PIN DESCRIPTION
PIN DESCRIPTION
COM3
1 DCD 2 DSR
3 RXD 4 RST
5 TXD 6 CTS
7 DTR 8 RI
9 GND 10 GND
COM4
11 DCD 12 DSR
13 RXD 14 RST
15 TXD 16 CTS
17 DTR 18 RI
19 GND 20 GND
COM5
21 DCD 22 DSR
23 RXD 24 RST
25 TXD 26 CTS
27 DTR 28 RI
29 GND 30 GND
COM6
31 DCD 32 DSR
33 RXD 34 RST
35 TXD 36 CTS
37 DTR 38 RI
39 GND 40 GND

11
COM7-10: Internal RS-232 serial port connectors
Function PIN DESCRIPTION
PIN DESCRIPTION
COM7
1 DCD 2 DSR
3 RXD 4 RST
5 TXD 6 CTS
7 DTR 8 RI
9 GND 10 GND
COM8
11 DCD 12 DSR
13 RXD 14 RST
15 TXD 16 CTS
17 DTR 18 RI
19 GND 20 GND
COM9
21 DCD 22 DSR
23 RXD 24 RST
25 TXD 26 CTS
27 DTR 28 RI
29 GND 30 GND
COM10
31 DCD 32 DSR
33 RXD 34 RST
35 TXD 36 CTS
37 DTR 38 RI
39 GND 40 GND
CN10: RS-422/485 serial port connector (COM10)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1RXD485# 2 RXD485+
3TXD485+ 4 TXD485#

12
USB3, USB4, USB5, USB6: Internal USB 2.0 connectors
PIN NO.
DESCRIPTION PIN NO.
DESCRIPTION
1 VCC 2 GND
3 USB_DATA- 4 USB_DATA+
5 USB_DATA+ 6 USB_DATA-
7 GND 8 VCC
SYS_FAN1, SYS_FAN2: System fan connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 FANIO 2 +12V (PWM)
3 GND
CN1: SMBUS connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 2 SMB_DATA
3 SMB_CLK 4 +5V
SATA1, SATA2, SATA3, SATA4: Serial ATA 3.0 connectors
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1GND 2 SATA_TX+
3SATA_TX- 4 GND
5 SATA_RX- 6 SATA RX+
7 GND
TPM1: TPM connector
PIN NO. DESCRIPTION PIN NO.
DESCRIPTION
1 LCLK 2 GND
3 LFRAME# 4 NC
5 LRERST# 6 +5V
7 LAD3 8 LAD2
9 +3.3V 10 LAD1
11 LAD0 12 GND
13 SCL 14 SDA
15 SB3V 16 SERIRQ
17 GND 18 GLKRUN#
19 LPCPD# 20 LDRQ#

13
COM2: External RS-232 serial port connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 DCD2 2 RXD2
3 TXD2 4 DTR2
5 GND2 6 DSR2
7 RTS2 8 CTS2
9 RI2
COM1: External RS-232 serial port connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 DCD1 2 RXD1
3 TXD1 4 DTR1
5 GND1 6 DSR1
7 RTS1 8 CTS1
9 RI1

14
LAN2_USB2: Ethernet and USB 2.0 connectors
USB2: External USB 2.0 connectors
PIN NO. DESCRIPTION PIN NO.
DESCRIPTION
1 VCC 5 VCC
2 USB_DATA- 6 USB_DATA-
3 USB_DATA+ 7 USB_DATA+
4 GND 8 GND
LAN2: RJ45 LAN connector
PIN NO. DESCRIPTION PIN NO.
DESCRIPTION
P2 TRD2P0 P6 TRD2P2
P3 TRD2N0 P7 TRD2N2
P4 TRD2P1 P8 TRD2P3
P5. TRD2N1 P9 TRD2N3
LAN1_USB1: Ethernet and USB 3.0 connectors
USB1: External USB 3.0 connectors
PIN NO. DESCRIPTION PIN NO.
DESCRIPTION
1 VCC 10 VCC
2 USB_DATA- 11 USB_DATA-
3 USB_DATA+ 12 USB_ DATA+
4 GND 13 GND
5 USB3_RX- 14 USB3_RX-
6 USB3_RX+ 15 USB3_ RX+
7 GND 16 GND
8 USB3_TX- 17 USB3_TX-
9 USB3_TX+ 18 USB3_TX+
LAN1: RJ45 LAN connector
PIN NO. DESCRIPTION PIN NO.
DESCRIPTION
20 LAN1_MDI0P 24 LAN1_MDI2P
21 LAN1_MDI0N 25 LAN1_MDI2N
22 LAN1_MDI1P 26 LAN1_MDI3P
23 LAN1_MDI1N 27 LAN1_MDI3N

15
FP_AUDIO1: Front panel audio connector
PIN NO. DESCRIPTION PIN NO.
DESCRIPTION
1 LMIC2_L 2
AUD_GND
3
LMIC2_R
4
F_PRESENCE#
5
LLINE2
-
R
6 MIC2-JD
7 F_SENSE 8
NC
9 LLINE2-L 10
AUD_GND
KBMS1: PS/2 Keyboard and mouse connector
KBMS1 (Purple): 6-pin Mini-DIN keyboard connector
PIN NO. DESCRIPTION PIN NO.
DESCRIPTION
1 Keyboard Data 2 NC
3 GND 4 VCC
5 Keyboard Clock 6 NC
KBMS1 (Green): 6-pin Mini-DIN Mouse Connector
PIN NO. DESCRIPTION PIN NO.
DESCRIPTION
1 Mouse Data 2 NC
3 GND 4 VCC
5 Mouse Clock 6 NC
VGA1, VGA2: VGA connectors
PIN NO. DESCRIPTION PIN NO.
DESCRIPTION
1 RED 2 GREEN
3 BLUE 4 NC
5 GND 6 GND
7 GND 8 GND
9 VCC 10 GND
11 NC 12 DDCDA
13 HSYNC 14 VSYNC
15 DDCCLK

16
Board Layout: Jumper and Connector Locations
(Unit: mm)
