iGenix IG2084 User manual

Please read these instructions carefully before use and retain for future reference
Before switching on your appliance,
always check for any damage which may have been caused in transit
Batch code:
USER MANUAL
IG2084
800W 20L Manual Microwave - Stainless Steel

2
CONTENTS
Important Safety Instructions...............................................3-5
Appliance Overview...............................................................6-7
Installation.................................................................................7-8
Operating Instructions...............................................................8
Container Guidelines .................................................................9
Cooking Tips ............................................................................. 10
Cleaning & Maintenance ......................................................... 11
Trouble Shooting Guide.......................................................... 12
Fuse Replacement.................................................................... 13
Disposal Information............................................................... 13
Terms and Conditions and Warranty Information...... 14-15

3
IMPORTANT SAFETY INSTRUCTIONS
The following basic precautions should always be followed when using this
electrical appliance:
• Carefully read all instructions before operating and save for future
reference.
• This appliance is for normal domestic use only.
• Make sure the voltage in the intended location corresponds to the one
shown on the rating label of the appliance.
• To reduce the risk of re in the microwave cavity ensure the following:
- Do not cook the food for longer than recommended.
- Remove wire twist-ties before placing bags in the microwave.
- Do not heat oil or fat for deep frying as the temperature of the oil
cannot be controlled.
- After use wipe the waveguide cover with a damp cloth, followed by
a dry cloth to remove any food splashes and grease. Built-up grease
may overheat and begin to cause smoke or catch re.
- If materials inside the microwave should smoke or ignite, keep the
microwave door closed, turn the microwave off at the wall socket
and disconnect the plug from the wall socket.
- When heating food in plastic containers, do not leave unattended
due to the possibility of ignition.
• To reduce the risk of explosion and sudden boiling:
Liquids and other foods must not be heated in sealed containers
since they are liable to explode; baby bottles tted
with a screw cap or teat are considered to be sealed containers.
- Use a wide-mouthed container to cook liquids and ensure the
cooked liquid is allowed to stand and is not removed immediately-
This is to avoid possible hazards such as explosion caused by delayed
boiling of liquids.
- Potatoes, sausages and chestnuts should be peeled or pierced before
cooking. Eggs in their shell should not be heated in microwaves since
they may explode, even after microwave heating has ended.

4
- The contents of feeding bottles and baby food jars should be stirred
or shaken and the temperature should be checked before
consumption, in order to avoid burns from uneven heating.
• If the supply cord is damaged, it must be replaced before further use
by the manufacturer, a service agent or a qualied electrician in order
to avoid a hazard.
• After cooking, the container will be very hot. Use sufcient protection
such as gloves to remove the food and avoid steam burns by directing
steam away from the face and hands.
• Slowly lift the furthest edge of dish covers and microwave plastic wrap
and carefully open popcorn and microwave cooking bags away from
the face to avoid risk of burns from escaping steam.
• To prevent the turntable from breaking:
- Let the turntable cool down before cleaning.
- Do not place hot foods or containers on the cold turntable.
- Do not place frozen foods or containers on the hot turntable.
• Make sure the containers do not touch the interior walls during
cooking.
• Only use containers that are marked as “microwave safe”.
• Do not store food or any other object inside the microwave.
• Do not operate the microwave without any liquid or food inside the
microwave.This could damage the microwave.
• Any accessories not recommended by the manufacturer may cause
injuries.
• Do not use outdoors.
• Retain these instructions for future reference.
If the door or door seals are damaged or the microwave has
malfunctioned, the microwave must not be operated until it has been
repaired by a qualied electrician.
WARNING: It is hazardous for anyone other than a qualied
electrician to carry out any service or repair operation that involves
the removal of a cover which gives protection against exposure to
microwave energy.
• If smoke is emitted, switch off and then unplug the appliance and keep
the door closed in order to contain any ames.

5
• Microwave heating of beverages can result in delayed boiling and the
possibility of overowing; therefore care must be taken when handling
the container.
• Do not use harsh abrasive cleaners or sharp metal scrapers to clean
the microwave door glass since they can scratch the surface, which
may result in shattering of the glass.
• The lamp of the microwave oven is not intended for other purposes.
• The appliances are not intended to be operated by means of an
external timer or separate remote -control system.
• This microwave oven is intended for heating food and beverages.
Drying of food or clothing and heating of warming pads, slippers, sponges,
damp cloth and similar may lead to risk of injury, ignition or re.
• This appliance should only be used by adults.
• Children shall not play with the appliance.
• Cleaning and user maintenance shall not be made by children.
• Keep the appliance and its cord out of reach of children.
• This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge.
• A steam cleaner is not to be used on any part of this product.
• The door or the outer surface may get hot when the appliance is
operating.
WARNING: Accessible parts may become hot during use.Young
children should be kept away.
During use the appliance becomes hot. Care should be taken to avoid
touching heating elements inside the microwave.
CAUTION: Hot surface

6
APPLIANCE OVERVIEW
1. Door lock - Microwave door must be
properly closed in order for it to operate.
2. Viewing window - Allows user to see
the cooking status.
3. Rotating axis - The glass turntable sits
on the axis; the motor underneath it
drives the turntable to rotate.
4. Rotating ring - The glass turntable sits
on its wheels; it supports the turntable
and helps it to balance when rotating.
5. Turntable - The food sits on the turntable,
its rotation during operation helps to
cook food evenly.
CAUTION:
- Place the rotating ring in the
microwave rst.
- Fit the turntable onto the rotating axis
and make sure that it is located over the
gear mechanism.
6. Control panel - See control panel section for full details*.
7. Waveguide cover - It is inside the microwave, next to the wall of control panel.
WARNING: Never remove the waveguide cover
2.
5. 7.
3.
1. 6.
Waveguide
cover
*(the control panel is subject to change without prior notice).
CONTROL PANEL
1. Timer
- The max cooking time length that can be
set is 30 minutes.
- Each setting increment is 1 minute.
- A bell ring will be heard when the timer
times out and returns to Zero position.
2. Function/Power knob
1.
2.
4.

7
There are 6 power levels:
HIGH
(H)
M.HIGH
(M.H)
MED
(M)
M.LOW
(M.L)
DEFROST
(D)
LOW
(L)
100% power output
85% power output
66% power output
40% power output
37% power output
17% power output
(Quick cooking)
(Normal cooking)
(Slow cooking)
(Drinks or soup)
(Defrost)
(Keep warm)
The following table provides a reference defrost time length for various foods:
Meat
Poultry
Seafood
WEIGHT RANGE
0.1~1.0kg
0.2~1.0kg
0.1~0.9kg
DEFROST TIME (Minutes)
1:30~26:00
2:30~22:00
1:30~14:00
1. Take out all the packing. If there is a safety lm over the microwave, tear it
off before use. Check carefully for damage. If any damage is evident,
immediately notify dealer or send to the manufacturer’s service center.
2. Microwave ovens must be placed in dry and non-corrosive environments
and kept away from heat and humidity, such as gas burners or water tanks.
3. To ensure sufcient ventilation, the distance from the back of the microwave
to the wall should be at least 10cm, the side to the wall should be at least
5cm, the free distance above the top surface at least 20cm and the distance
from the microwave to the ground should be at least 85cm.
4. The position of the microwave should be such that it is located at least 5m
from any TVs, Radios or antenna as this can cause picture disturbance.
5. The appliance must be positioned so that the plug is accessible and must
ensure a good grounding in case of leakage.
6. The microwave must be operated with the door closed.
7. The microwave must not be placed in a cabinet.The microwave is intended
to be freestanding.
INSTALLATION

8
Plug the plug into the wall socket- Before connecting the cord, make sure the
timer is set to “0” position. Do not block the ventilation outlets.
• Place the food in a container and onto the glass turntable and close the
door.
• Select the desired power level.
• Set the timer:
If desired time is less than 10 minutes then turn the timer knob to the over
10 minutes position and then turn back to the desired time setting.
• Once the desired time is set cooking will begin. If pausing is required whilst
cooking then the door can be opened at any time by pressing the door
release button, this will pause the cooking- Closing the door again will
resume cooking.
• When the timer ends and cooking is nished, the microwave produces a bell
ring and the inside lamp will be automatically turned off.
If desired cooking level is reached and food is therefore removed before
the timer nishes then ensure the timer is reset to the “0” position to avoid
the microwave operating whilst empty when the door is closed again.
OPERATING INSTRUCTIONS
8. As there could be manufacturing residue or oil remaining in the microwave
cavity or on the heating element, it is normal for there to be an odor or
slight smoke upon initial use.This should not occur after the microwave
has been used several times. Keep the door and windows open to ensure
good ventilation. It is strongly recommended to place a cup of water on
the turntable, set the microwave to high power and operate for 2-3 minutes
to reduce the risk of residual odor before cooking food and beverages for
the rst time, repeating several times if necessary.

9
It is strongly recommended to use containers which are marked as microwave safe.
Generally speaking containers which are made of heat-resistant ceramic, glass or plastic
are suitable for microwave cooking. Never use metal containers for microwave cooking
as sparking is likely to occur. Use the below table for reference:
CONTAINER GUIDELINES
Heat-resistant
ceramic
Microwave
Ye s
Notes
Never use ceramics which are decorated with metal or glazed.
Container
Material
Heat-resistant
plastic Ye s Do not leave unattended due to the possibility of ignition.
Heat-resistant
glass Ye s Never use glass with metal parts.
Plastic lm Ye s Should not be used when cooking meat as the over-temperature
may do damage to the lm.
Grill rack No Should not be used in microwave. Microwave cannot penetrate
through metal.
Metal container No Should not be used in microwave. Microwave cannot penetrate
through metal.
Lacquer No Poor heat-resistance. Cannot be used for High-temperature
cooking.
Bamboo wood
and paper No Poor heat-resistance. Cannot be used for High-temperature cooking.

10
COOKING TIPS
The following factors may affect the cooking result:
Food arrangement
Place thicker areas towards the outside of the dish and the thinner part towards
the centre and spread evenly. Do not overlap if possible.
Cooking time
Start cooking with a short time setting, evaluate it after it times out and extend it
according to the actual need. Over cooking may result in smoke and burns.
Cooking food evenly
Food such as chicken, hamburgers or steak should be turned at least once during
cooking.
Depending on the type of food, if applicable remove it and stir it from outside to
centre of dish once or twice during cooking.
Allow standing time
After timer is nished, leave the food in the microwave for an adequate length
of time, this allows it to complete its cooking cycle and begin cooling down in a
gradual manner.
Whether the food is cooked
Color and hardness of food help to determine if it is done, these include:
- Steam coming out from all parts of food, not just the edge
- Joints of poultry can be moved easily
- Pork or poultry shows no signs of blood
- Fish is opaque and can be sliced easily with a fork
Microwave safe plastic wrap
When cooking food with high fat content, do not allow the plastic wrap to come
into contact with food as it may melt.
Microwave safe plastic cookware
Some microwave safe plastic cookware might not be suitable for cooking foods
with high fat and sugar content. The preheating time specied in the cooking
instructions of each food/beverage must not be exceeded.

11
CLEANING & MAINTENANCE
Microwave Oven Care
CAUTION: The microwave should be cleaned regularly and any food
deposits removed.
WARNING: Turn off the power at the wall socket and remove the
power cord from the wall socket before cleaning. Do not immerse
any part of the appliance in water or other uids when cleaning- except the
removable glass turntable and rotating ring.
• Failure to maintain the microwave in a clean condition could lead to
deterioration of the surfaces which could adversely affect the life of the
appliance and possibly result in a hazardous situation.
• Never use strong detergent, gasoline, abrasive powder or a metal brush to
clean any part of the appliance.
• Do not remove the waveguide cover (located on the inner walls as per the
diagram contained within the product instructions section of this manual).
Tips for Cleaning
Details for cleaning door seals, cavity and adjacent parts:
Exterior:
- Wipe the enclosure with a dampened soft cloth.
Door:
- Using a dampened soft cloth, wipe clean the door and window.
- Wipe the door seals and adjacent parts to remove any spill or spatter.
- Wipe the control panel with a slightly dampened soft cloth.
Interior walls:
- Wipe clean the cavity with a dampened soft cloth.
- Wipe clean the waveguide cover to remove any food splashed.
Turntable/ Rotation ring/ Rotation axis:
- Remove and wash with mild soapy water.
- Rinse with clean water and allow to dry thoroughly before replacing.

12
Fault Possible Cause Solution
The fridge does
not work.
Not properly plugged into the
mains wall socket.
Plug in rmly.
Not switched on. Make sure appliance is switched on.
No electricity in the mains wall socket. Check fuse.
Door not shut properly. Ensure nothing is blocking the door (if food
container is too large, use smaller container).
Food is not
cooked
Time or power setting is not correct
for required food/ beverage.
Ensure cooking instructions from packaging are
followed and appropriate setting and time is
selected.
Door is not closed. Ensure door is fully closed.
No electricity in the mains wall
socket.
Check fuse.
Food is over or
undercooked
Time or power setting is not correct
for required food/beverage.
Ensure cooking instructions from packaging are
followed and appropriate setting and time is
selected.
Sparking or
noises inside the
microwave
Container used is made of metal
components or unsuitable material
for microwaving.
Ensure any container used adheres to
guidelines in manual.
Metal utensil has been left in
container.
Ensure no metal utensils are left in containers.
Air ow to vents is blocked.Cooling fan is not
working
Ensure nothing is blocking the air vents and
that the microwave is situated as per the
installation instructions.
Turntable is
not rotating
Door is not properly closed. Ensure door is properly closed.
Container is touching the walls
and preventing turntable from
rotating.
Ensure container is not touching the walls
(if food container is too large, use smaller
container).
TROUBLE SHOOTING GUIDE
If you experience difculties with the appliance, please check the suggestions below
before contacting customer services on 01473 271272:
To test microwave is working before cooking food – DO NOT operate empty, instead
place one cup of water (approx.150ml) in a glass in the microwave and close the door
securely. Microwave lamp should go off if the door is closed properly. Let the microwave
work on full power for 1 min.

13
DISPOSAL INFORMATION
The European Directive 2012/19/EU on Waste Electrical and
Electronic Equipment (WEEE), requires that old household
electrical appliances must not be disposed of in normal unsorted
municipal waste.
Old appliances must be collected separately in order to optimise
the recovery and recycling of the materials they contain and reduce the impact
on human health and the environment.
The crossed out “wheeled bin” symbol on the product reminds you of your
obligation, that when you dispose of the appliance it must be separately collected.
Consumers should contact their local authority or retailer for information
concerning the correct disposal of their old appliance.
CAUTION- HIGH VOLTAGE WARNING
This appliance is equipped with an earthed plug for your protection against
possible shock hazards and should be connected to a properly earthed
power socket.
Do not operate this oven if the door is bent, warped or otherwise damaged and
does not close rmly.
Do not tamper with the door safety interlocks.
This device is to be serviced only by a qualied electrician.
Disconnect power plug from the mains before servicing.
MAINS PLUG FUSE REPLACEMENT Fuse Cover
Fuse Replacement (Class I)
This appliance must be earthed. Remove the fuse cover
with a small at head screw driver. Take out the fuse and
replace with a new fuse of the same Amp. Replace the
fuse cover and push back into place.

14
lgenix Warranty Terms & Conditions
This product is guaranteed for a period of 12 months as standard from the date of purchase
against mechanical and electrical defects.You can extend your warranty for a further 12 months by
registering your product.
Upon registration we will cover your product for a period of 24 months from the original purchase
date against any mechanical or electrical defects.
To qualify for the warranty, the product must be used for domestic household use only and in
accordance with the instructions in the user manual.Any misuse of the product will result in the
warranty being void.
The warranty does not cover accidental damage, misuse, neglect, tampering or incorrect adjustment
or installation.
The warranty will be rendered invalid if the product is resold, has had its serial number removed
(or has an invalid serial number), or if an unauthorised person has carried out any repairs or
alterations.
The warranty does not cover accessories or consumable parts that require replacement under
normal use. This includes shelving, dials, lters, belts and trays etc.
In the unlikely event of a breakdown please refer to the Troubleshooting guide in your user manual
and check all plugs, fuses and the electricity supply.
If you still require assistance please contact our Customer Service department on
01473 271 272 or write to us at the following address:
Customer Service Department
38 Bluestem Road, Ransomes Europark
Ipswich, IP3 9RR
Please quote the Product Code which begins ‘IG’ or ‘DF’ and the Batch Code on the front of the
manual, and give details of the exact fault.We will then decide whether to repair or replace the
item.
Before we arrange the repair or replacement you will be required to return a copy of your proof
of purchase. Please retain your original.
If an item is replaced within the agreed warranty period, the warranty for the replacement item will
be calculated from the purchase date of the original.
In the event that the product is inspected and no fault is found or the product is not within the
warranty period you will be charged for the repair and any carriage costs.

15
Thank you for choosing lgenix
As a valued customer we would like to offer you a FREE 2 year warranty to cover your product
against any electrical or mechanical defects.
This means that in the unlikely event you develop a fault or problem with your product we will
happily repair or replace the item free of charge.
To qualify for the 2 year warranty you must register your product within 30 days of purchase.The
full Terms & Conditions of our warranty policy are shown on the opposite page.They are also
available on our website. www.igenix.co.uk

38 Bluestem Road, Ransomes Europark, Ipswich, IP3 9RR
Tel. [phone]
Disclaimer: Igenix operate a policy of continual improvement and development.
We therefore reserve the right to change/alter the specication and appearance of our appliances without prior notice.
All diagrams and images shown in this manual are for illustration purposes only.
