SAMOS DEEP
Refrigerated
serve-over counter

1
SAMOS DEEP LINE ASSEMBLY INSTRUCTIONS
IGLOO Stary Wiśnicz 289, 32-720 Nowy Wiśnicz, Tel. [phone] / Fax: [phone] [email protected] / www.igloo.pl
en
ORIGINAL MANUAL 22.05.2019
READ CAREFULLY BEFORE USE
KEEP FOR FUTURE REFERENCE
LINE ASSEMBLY INSTRUCTIONS REVISION
PAGE: 1/10TYPE: SAMOS DEEP NO. DATE NO. DATE
DOCUMENTATION NO.: A D
NO.: 0 B E DATE of 1st issue:
26.05.2019
TABLE OF CONTENTS C F
NO. SECTION PAGE REV.
STATUS
DOCUMENTA-
TION NO.
0TABLE OF CONTENTS 1 - x
1Unpack 2 - x
2Prepare the fasteners delivered with the counter 2 - x
3Prepare necessary assembly tools 2 - x
4Prepare for line assembly 3 - x
4.1 Unpack the shelves, screens and worktops 3 - x
4.2 Remove the louvre 3 - x
4.3 Remove the fans 3 - x
4.4 Remove the ventilation grilles 3 - x
5Apply the sealant mastic 4 - x
6Remove the socket head cap screw near the top lamp 4 - x
7Place the modules (single counters) in line 4 - x
8Align all installation holes 5 - x
9Place the modules app. 5 mm apart 5 - x
10 Join the modules using delivered fasteners 5 - x
11 Level the set using the spirit levels 5 - x
12 Install the fans 6 - x
13 Install the louvre 6 - x
14 Install the worktops 6 - x
14.1 Place the worktops on the set 6 - x
14.2 Glue the worktops 6 - x
14.3 Seal the worktops 7 - x
14.4 Remove the lm from the two-sided prole of night covers 7 - x
14.5 Apply adhesive on the prole 7 - x
14.6 Install the prole on the granite worktop 7 - x
15 Adjust front glass panels 8 - x
16 Apply sealant on the modules joints 8 - x
17 Place the shelves 8 - x
18 Place the screens 9 - x
19 Install the partitions (if any) 9 - x
20 Install the client shelf (if any) 9 - x
21 Install the night covers 9 - x
22 After the line assembly and before the start-up, connect all plugs between
the modules 10 - x
23 Have the counters connected to the cooling and power infrastructure by
an authorized sta󰀨 indicated by the customer 10 - x
KEY:
-First issue
A, B, ... Rev. index
XNo. of section corresponding to documentation No.

2
SAMOS DEEP LINE ASSEMBLY INSTRUCTIONS
IGLOO Stary Wiśnicz 289, 32-720 Nowy Wiśnicz, Tel. [phone] / Fax: [phone] [email protected] / www.igloo.pl
en
LINE ASSEMBLY INSTRUCTIONS REVISION
PAGE: 2/10TYPE: SAMOS DEEP NO. DATE NO. DATE
DOCUMENTATION NO.: A D
NO: 1,2,3 BEDATE of 1st issue:
26.05.2019
C F
Unpack
Prepare necessary assembly tools
Prepare the fasteners delivered with the
counter
2x at spanner No. 13
Hex key No. 4
Star screwdriver
2 spirit levels: 2 m long and 0.5 m long
1 2
3

3
SAMOS DEEP LINE ASSEMBLY INSTRUCTIONS
IGLOO Stary Wiśnicz 289, 32-720 Nowy Wiśnicz, Tel. [phone] / Fax: [phone] [email protected] / www.igloo.pl
en
PREPARE FOR LINE ASSEMBLY
Unpack the shelves, screens and worktops
Remove the fans
Remove the louvre
Remove the ventilation grilles
• Place the counters in line according to the nal conguration leaving at least 20 cm gap between them.
• Remove all subassemblies from the inside such as lamps, glass sides, shelves, etc.
• Remove the feet slightly raising the counter at the front side, remove the base board, and screw in the feet
again. Remove the rear base board in the same way.
LINE ASSEMBLY INSTRUCTIONS REVISION
PAGE: 3/10TYPE: SAMOS DEEP NO. DATE NO. DATE
DOCUMENTATION NO.: A D
NO: 4,4.1,4.2,4.3,4.4BEDATE of 1st issue:
26.05.2019
C F
4
4.1
4.3
4.2
4.4

4
SAMOS DEEP LINE ASSEMBLY INSTRUCTIONS
IGLOO Stary Wiśnicz 289, 32-720 Nowy Wiśnicz, Tel. [phone] / Fax: [phone] [email protected] / www.igloo.pl
en
LINE ASSEMBLY INSTRUCTIONS REVISION
PAGE: 4/10TYPE: SAMOS DEEP NO. DATE NO. DATE
DOCUMENTATION NO.: A D
NO: 5,6,7 BEDATE of 1st issue:
26.05.2019
C F
Apply the sealant mastic
The space betweenb the counters is sealed by means
of mastic formed into rolls placed on the tape. Apply
the sealant mastic on one counter only.
• Gently tear o󰀨 one roll from the tape, remove the
paper cover and glue in the place shown in the
photograph. In order to glue, press the mastic with
your ngers to the counter body via the tape, and
later tear o󰀨 the tape. Apply the sealant mastic only
on the lateral prole of the sheet which is the body
interior. Do not apply the sealant mastic on the
wooden body reinforcements.
ATTENTION! Imprecise sealing of the counters will not
ensure tightness of the line.
Place the modules (single counters)
in line
Remove the socket head cap screw near
the top lamp
5
6 7

5
SAMOS DEEP LINE ASSEMBLY INSTRUCTIONS
IGLOO Stary Wiśnicz 289, 32-720 Nowy Wiśnicz, Tel. [phone] / Fax: [phone] [email protected] / www.igloo.pl
en
LINE ASSEMBLY INSTRUCTIONS REVISION
PAGE: 5/10TYPE: SAMOS DEEP NO. DATE NO. DATE
DOCUMENTATION NO.: A D
NO: 8,9,10,11 BEDATE of 1st issue:
26.05.2019
C F
Place the modules app. 5 mm apartAlign all installation holes
8 9
Join the modules using delivered
fasteners
10
Level the set using the spirit levels
11
• At the joint, level the height at the front and rear by
turning the feet in or out.
• Level each module placing the spirit level as shown
on the photo.

6
SAMOS DEEP LINE ASSEMBLY INSTRUCTIONS
IGLOO Stary Wiśnicz 289, 32-720 Nowy Wiśnicz, Tel. [phone] / Fax: [phone] [email protected] / www.igloo.pl
en
LINE ASSEMBLY INSTRUCTIONS REVISION
PAGE: 6/10TYPE: SAMOS DEEP NO. DATE NO. DATE
DOCUMENTATION NO.: A D
NO: 12,13,14,14.1,14.2BEDATE of 1st issue:
26.05.2019
C F
Glue the worktops
Place the worktops on the set
Install the fans Install the louvre
1312
Install granite worktops It is not necessary to install metal worktops
14
14.114.2

7
SAMOS DEEP LINE ASSEMBLY INSTRUCTIONS
IGLOO Stary Wiśnicz 289, 32-720 Nowy Wiśnicz, Tel. [phone] / Fax: [phone] [email protected] / www.igloo.pl
en
LINE ASSEMBLY INSTRUCTIONS REVISION
PAGE: 7/10TYPE: SAMOS DEEP NO. DATE NO. DATE
DOCUMENTATION NO.: A D
NO: 14.3, 14.4, 14.5, 14.6BEDATE of 1st issue:
26.05.2019
C F
Seal the worktops
14.3
Apply adhesive on the prole
14.5
Install the prole on the granite worktop
14.6
Remove the lm from the two-sided prole
of night covers
14.4

8
SAMOS DEEP LINE ASSEMBLY INSTRUCTIONS
IGLOO Stary Wiśnicz 289, 32-720 Nowy Wiśnicz, Tel. [phone] / Fax: [phone] [email protected] / www.igloo.pl
en
LINE ASSEMBLY INSTRUCTIONS REVISION
PAGE: 8/10TYPE: SAMOS DEEP NO. DATE NO. DATE
DOCUMENTATION NO.: G003_01PG A D
NO: 15,16,17 BEDATE of 1st issue:
26.05.2019
C F
Adjust front glass panels
Place the shelves
Apply sealant on the modules joints
Display shelves consist of three part types:
- Display shelve 305 [detail 23]
- Fit part [detail 24]
- Connector [detail 25]
• Start installing the shelves on the right-hand side.
• First install the shelve 305 [detail 26]. Install the
next shelves 305 on the so-called n of the previous
shelf [detail 27]. Finally install the t part suitable
for the module length.
• Place the connector [detail 28] under the t part of
the previous module [detail 29] and shelf 305 of the
next module [detail 30]
15
17
16

9
SAMOS DEEP LINE ASSEMBLY INSTRUCTIONS
IGLOO Stary Wiśnicz 289, 32-720 Nowy Wiśnicz, Tel. [phone] / Fax: [phone] [email protected] / www.igloo.pl
en
LINE ASSEMBLY INSTRUCTIONS REVISION
PAGE: 9/10TYPE: SAMOS DEEP NO. DATE NO. DATE
DOCUMENTATION NO.: A D
NO: 18,19,20,21 BEDATE of 1st issue:
26.05.2019
KONSERWACJA C F
Place the screens
Install the client shelf (if any)
Install the partitions (if any)
1. First install the bottom
cover (the shortger
one)
2. Then, install the top
cover (the longer one)
18 19
20
Install the night covers
21
2
1

10
SAMOS DEEP LINE ASSEMBLY INSTRUCTIONS
IGLOO Stary Wiśnicz 289, 32-720 Nowy Wiśnicz, Tel. [phone] / Fax: [phone] [email protected] / www.igloo.pl
en
LINE ASSEMBLY INSTRUCTIONS REVISION
PAGE: 10/10TYPE: SAMOS DEEP NO. DATE NO. DATE
DOCUMENTATION NO.: A D
NO: 22,23 BEDATE of 1st issue:
26.05.2019
C F
After the line assembly and before the
start-up, connect all plugs between the
modules
Have the counters connected to the
cooling and power infrastructure by an
authorized sta󰀨 indicated by the customer
22 23
