iHome IH-M155WB User manual

user manual
IH-M155WB
5-button wireless optical
notebook mouse Congratulations on the purchase of your
new 5-button wireless optical notebook
mouse. This product comes with a limited
lifetime warranty.
Before using your product, please thoroughly
read and follow the instructions inside this
manual.
If you still need help, see the back page for
other support options.
If you want to know more about our
products, visit us online at
www.life-works.com.
system requirements
Windows• ®2000, XP or Windows Vista®
USB port•
CD-ROM drive•

your package should contain
2
5-button wireless
optical notebook mouse
user manual
(in your hands right now)
installation CD
IMPORTANT! Do not use the enclosed mini CD
with slot loading or trayless-style CD drives, or with
a sideways mounted CD drive. The mini CD may
become jammed. Instead, download the software
at www.life-works.com/drivers.
user manual contents
features•2
yournewmouse•3
connecthardware•3
installsoftware•4
to customize the mouse
buttons•5
to customize the mouse scroll
wheel•5
productoperatingtips•6
troubleshooting•6
2 AAA DURACELL®
batteries
user manual
.
mini USB
receiver travel pouch
features
plug-n-play—no synching needed•
programmable buttons•
low battery indicator•
rubberized nish•
travel pouch included•

3
your new mouse
programmable
buttons
programmable
buttons
scroll wheel and
low battery
indicator
battery
compartment
cover
connect hardware
Gently squeeze the sides of the battery cover and slide it1.
off to access the battery compartment.
a. squeeze
gently
a. squeeze
gently b. slide
Insert 2 AAA batteries into the mouse battery compartment2.
and replace the battery compartment cover.
Connect the mini USB receiver to an available USB port3.
on your computer. The mouse automatically connects to
the mini USB receiver.
plug in to
USB port
on computer
Start using your mouse.4.
Your mouse is plug-n-play—no synching needed.
notef
However, in the unlikely event that your mouse should
ever have a problem connecting, press the connect
button on the mini USB receiver and the ID button on the
bottom of the mouse.
To set up the advanced functions of your mouse, install the
supplied software.
connect
button

4
install software
Insert the installation CD into your computer.1.
On the screen that appears, click2. install.
5-button wireless
optical notebook mouse
www.life-works.com
2008© LifeWorks Technology Group LLC
iHome™ is a trademark of SDI Technologies Inc.
used under license.
Model # IH-M155WB
exitinstall
The3. InstallShield Wizard dialog box displays. Click
Next.
click
click
The4. Choose Destination Location dialog box displays.
Click Next to accept the default installation location.
The5. InstallShield Wizard Complete dialog box displays.
Select the option to restart your computer now and click
Finish.
With the software installed, you can customize allnotef
mouse buttons or change settings for the scroll wheel.
b. click
a. select

5
to customize the mouse buttons
Double-click the1. mouse icon in the system tray.
This opens a dialog box.
Select the2. Cong of mouse button tab.
Click the drop-down list to select an action for each3.
button.
Click4. OK to accept the changes and exit.
click to select an
action
to customize the mouse scroll wheel
Double-click the1. mouse icon in the system tray.
Select the2. Cong of the mouse wheel tab.
Select3. Speed of wheel scroll and choose how many
lines should scroll when the wheel is rotated one click, or
select For Pages to scroll a whole page with each click.
To set the mouse wheel to adjust the audio volume
instead, select Adjust of the volume, and adjust the slider
to determine how fast the volume changes when you turn
the wheel.
Click4. OK to accept the changes and exit.
audio volume
option
scroll options

6
product operating tips
Your mouse will operate from as far away as 20 ft. (7 m)•
from your computer.
Customize the programmable keys on your mouse for•
greater functionality.
The scroll wheel is also a button. Press the scroll wheel•
(without rolling it) to automatically scroll a document or
web page, then move your mouse up or down to set the
automatic scroll speed.
troubleshooting
situation try this
mouse does
not work at
setup
Ensure the mini USB receiver is connected.•
Connect the mini USB receiver to a different•
USB port.
Check that batteries are inserted correctly•
into the battery compartment.
Move the mouse closer to the mini USB•
receiver.
Disconnect the mini USB receiver, then•
reconnect it.
Connect the mini USB receiver to a different•
USB port. Try a USB port on the computer,
not a USB hub.
mouse has
stopped
working
Check that the batteries are good. If•
necessary, replace the batteries.
Ensure the optical sensor on the mouse is•
clean.
Press the connect button on the mini USB•
receiver and the ID button on the bottom of
the mouse.
low battery
indicator
continues to
blink
Install fresh batteries.•

FCC Statement
This device complies with part 15 of FCC Rules. Operation
is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device must
accept any interference received, including interference
that may cause undesired operation. This equipment has
been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of FCC Rules. These
limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a
residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and
used in accordance with the instruction guide, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
Reorient or relocate the receiving antenna.•
Increase the separation between the equipment and•
the receiver.
Connect the equipment into an outlet on a circuit•
different from that to which the receiver is connected.
Consult a service representative for help.
Properly shielded and grounded cables and connectors
must be used in order to comply with FCC emission limits.
LifeWorks is not responsible for any radio or television
interference caused by using other than recommended
cables and connectors or by unauthorized changes or
modications to this equipment. Unauthorized changes or
modications could void the user’s authority to operate the
equipment.
Responsible party:
LifeWorks Technology Group LLC
1412 Broadway
New York, NY 10018
Tested To Comply With FCC Standards
FOR HOME OR OFFICE USE
Warning
Improper setup, use and care of this product can increase
the risk of serious injury,death or device damage. Read
and keep this guide and all other printed guides for future
reference. For updated guides or replacements, go to
www.life-works.com
Do Not Attempt Repairs
Do not attempt to take apart, open, repair, service or
modify the device(s). Doing so may risk electric shock or
other hazard. Evidence of any attempt to open or modify
the device, including any peeling, puncture or removal of
labels, will void the Limited Lifetime Warranty.
Keyboard and Mouse Devices: Health Warning
Use of a keyboard or mouse may be linked to serious
injuries or disorders. As in many activities, when using
a computer you may experience occasional discomfort
in various parts of your body. However, do not ignore
symptoms such as persistent or recurring discomfort, pain,
throbbing, aching, tingling, numbness, burning sensation or
stiffness. Promptly see a qualied doctor, even if symptoms
occur when you are not working at your computer.
There is general consensus among researchers that
there may be many factors linked to the occurrence of
these symptoms, including overall health, stress, physical
condition and how a person positions and uses his or her
body during work and other activities (including the use of
a keyboard or mouse). The amount of time a person spends
performing an activity may also be a factor.
If you have questions about how your own lifestyle,
activities or physical condition may be related to these
symptoms, see a qualied health professional.
Battery-Powered Devices
Use of rechargeable or disposable batteries in an improper
manner may result in battery uid leakage, overheating
or explosion. Battery uid is corrosive,may be toxic, can
cause skin and eye burns, and is harmful if swallowed.
Keep batteries out of reach of children.•
Do not heat, open, puncture, mutilate or dispose of•
batteries in re.
Do not mix new and old batteries or batteries of•
different types (for example, carbon-zinc and alkaline
batteries).
Remove the batteries if they are worn out or before•
storing your device for an extended period of time.
Always remove old, weak or worn-out batteries•
promptly and recycle or dispose of them in accordance
with local and national disposal regulations.
If a battery leaks, remove all batteries, taking care to•
keep the leaked uid from touching your skin or clothes.
If uid from the battery comes into contact with your skin
or clothes, ush with water immediately. Before inserting
new batteries, thoroughly clean the battery compartment
with a damp paper towel, or follow the battery
manufacturer’s recommendations for cleanup.
Caution• Risk of explosion if battery is replaced with an
incorrect type. Use and replace with the correct size
and type (alkaline, zinc-carbon, or zinc-chloride) of
battery only.
Wireless Devices
Remove the batteries from any wireless device, or turn it
off, before boarding an aircraft or packing the device
in luggage that will be checked. Wireless devices can
transmit radio frequency (RF) energy whenever batteries are
installed and the device is turned on.
Radio Frequency Technical Specications:
2.4 GHz Devices
Non-specic short range device. RF output power meets all
SRD requirements.

technical support
for technical support please visit
www.life-works.com
or call (877) LIFE-540
(877-543-3540)
lifetime warranty
for warranty information, please visit
www.life-works.com/warranty
Printed in China
© 2008 LifeWorks Technology Group LLC.
iHome™ is a trademark of SDI Technologies Inc. used
under license.
Windows Vista®is a registered trademark or trademark of
Microsoft Corporation in the United States and/or other
countries.
All other brands and logos are trademarks of their
respective companies.
for model number
IH-M155WB
document version number 0811-0
