iHome iHSI-W400BT-PR-BLK User manual

1
Waterproof Mountable Outdoor Bluetooth® Speakers
BLACK
iHSI-W400BT-PR-BLK
iHSI-W525BT-PR-BLK
iHSI-W650BT-PR-BLK
WHITE
iHSI-W400BT-PR-WHT
iHSI-W525BT-PR-WHT
iHSI-W650BT-PR-WHT

2
INDEX
What’s Included
Please ensure that you find these accessories with your iHSI Bluetooth Speakers
(1) Active Speaker with Bracket
(1) Passive Speaker with Bracket
(1) AC Adapter
(1) Speaker Cable

3
PRECAUTIONS
PLEASE READ THESE INSTRUCTIONS GIVEN IN THIS MANUAL AND
THOSE MARKED ON THE UNIT
This set has been designed and manufactured to assure personal
safety. Improper use can result in electric shock or fire hazard. The
safeguards incorporated in this unit will protect you if you observe the
following procedures for installation, use and servicing. This unit is fully
transistorized and does not contain any parts that can be repaired by
the user.
WARNINGS
Fire and Electric Shock Hazard
1 - Do not place any open flame sources, such as lighted candles, on or
near the apparatus.
2 - Do not attempt to service the apparatus yourself.
3 - Opening or removing covers may expose you to dangerous voltages
or other hazards and will void the manufacturer’s warranty.
4 - To prevent risk of fire or electric shock, avoid overloading wall
outlets, extension cords, or integral convenience receptacles.
5 - Lightning storms Unplug this apparatus during lightning storms.
6- Object and liquid entry: Never insert objects of any kind through the
openings of this apparatus, as it may touch dangerous voltage points
or short-circuit parts that could result in a fire or electric shock. Care
should be taken so that objects do not fall and liquids are not spilled
into the apparatus through openings in the enclosure

4
FEATURES
The ultimate solution for your outdoor Bluetooth® audio needs. These
mountable speakers are ideal for Backyards and Patios, whether for
home or business use. You can even install these speakers on a boat!
With a waterproof rating of IP44, you won’t have to worry about leaving
your speakers installed outside in the elements, they are safe from water
and dust. Adjustable mounting brackets make for easy installation and
allow for optimal sound dispersion. The iHSI Series Outdoor Speakers
pair to your Bluetooth device with ease and the wireless remote puts the
control in your hands. These speakers are specifically tuned for outdoor
use, resulting in huge sound from a compact package so you can fill your
Pool Parties, BBQs or any other outdoor event with unrivaled sound, sure
to impress your guests
ALL WEATHER OUTDOOR SPEAKER
With a rating of IP44, the iHSI Series is water and dust resistant, specially designed to
withstand most environments.
ACTIVE/PASSIVE SPEAKER PAIR
Includes one active speaker and one passive speaker, connect with included speaker
wire. Only the active speaker will need to be connected to power.
BLUETOOTH®
Super simple wireless connection. Once you connect your preferred device via
Bluetooth®, it will automatically connect in the future. LED indicator displays
connection status.
REMOTE CONTROL
The included wireless remote puts the control in your hands. Remote allows you to
Power on/off, Pair, Mute and adjust Volume, EQ and Playback controls.
BIG SOUND, COMPACT PACKAGE
D Class amplifier specifically tuned for outdoor use and custom cabinet tooling
design.

5
SPEAKER INSTALLATION
These indoor/outdoor weatherproof
speakers are manufactured to resist a
variety of weather conditions including
Snow, rain and sun (but not to be
submerged under water.) For durability /
longevity, we recommend removing the
speakers from the brackets and storing
indoors during extended extreme
temperatures over 120° F and below 0° F.
The most ideal place to install these
speakers is under overhangs, as they
provide the best protection. Like all
speakers, they sound the best when
placed no more than eight feet apart
from each other, and slightly higher than
ear level. When choosing the speaker
placement - consider the location of the
power source. The powered speaker
should be placed near the power source.
The passive speaker may be placed
further away and should be connected to
the powered speaker with included wire.
1: LED INDICATOR
2: POWER PORT
3: SPEAKER OUTPUT
4: ON/OFF SWITCH
WIRING
When connecting the speakers, it is very
important to connect with correct polarity. This
means that the wire attached to the Red /
Positive (+) terminal on one component must be
attached to the Red / Positive (+) terminal on the
corresponding component speaker terminal.
Similarly, the Black / Negative / Ground (-)
terminals must connect to the respective Black /
Negative / Ground (-) terminals. This is easy to do
by locating the (+) & (-) labels that appear on the
included speaker wire. If longer wire run is
needed, use 16-gauge weatherproof wire up to
50 feet.

6
Placing Speakers
If your application requires the speaker to be mounted,
please follow these directions. Using the appropriate
screws (not included) mount the bracket. Attach the
speakers to the brackets using the large plastic knobs
supplied.
Mounting
To install the bracket on the speaker. Screw
the bracket knobs into the cabinet. Point the
speaker toward the listening area. Once the
direction of the speaker has been
determined tighten the bracket knobs
securely. When possible, tilt the speakers
down to increase longevity and prevent from
the weather elements.
Initial Setup
• Turn ON Bluetooth Device
• Open the Bluetooth Settings
• Select appropriate Bluetooth ID for connection
(You will hear Voice Prompt confirmation)
• You can now play Audio from your paired device
• Control Volume via Bluetooth Device or Remote
For subsequent pairings, Bluetooth will connect automatically when your
Device is nearby with Bluetooth turned ON.
To connect another device, turn Bluetooth OFF on your original device.

7
STANDBY
After 10 minutes with no audio signal, speaker will automatically enter standby mode. Press
the power button of remote to turn back on. Speaker will automatically reconnect to the last
device in memory.
REMOTE
VOICE PROMPTS WORDS:
• Power On
• Connected
• Disconnected

8
SPECIFICATIONS
SPECIFICATIONS
Indoor/Outdoor Weatherproof Loudspeaker
PART NUMBER:
IHSI-W400BT-PR-BLK / IHSI-W400BT-PR-WHT
BLUETOOTH:
PROTOCOL:
Bluetooth Specification 4.1+A2DP
AUDIO INPUTS:
Bluetooth Compatible Devices
ACOUSTIC OUTPUT:
POWER:
2 x 12W RMS / 24W Music Power
AUDIO POWER:
AC100-240V
WOOFER:
4” Injection Molded PP Cone Butyl Rubber Surround
TWEETER:
1” PET Dome
PACK DIMENSIONS:
36.7X25.8X22.2cm (pair)
PACK WEIGHT:
4.6kgs (pair)
COLOR:
Black/White
SPECIFICATIONS
Indoor/Outdoor Weatherproof Loudspeaker
PART NUMBER:
IHSI-W525BT-PR-BLK / IHSI-W525BT-PR-WHT
BLUETOOTH:
PROTOCOL:
Bluetooth Specification 4.1+A2DP
AUDIO INPUTS:
Bluetooth Compatible Devices
ACOUSTIC OUTPUT:
POWER:
2 x 15W RMS / 30W Music Power
AUDIO POWER:
AC100-240V
WOOFER:
5.25” Injection Molded PP Cone Butyl Rubber Surround
TWEETER:
0.75” PET Dome
PACK DIMENSIONS:
40.5X28X23.5cm (pair)
PACK WEIGHT:
5.26kgs (pair)
COLOR:
Black/White
SPECIFICATIONS
Indoor/Outdoor Weatherproof Loudspeaker
PART NUMBER:
IHSI-W650BT-PR-BLK / IHSI-W650BT-PR-WHT
BLUETOOTH:
PROTOCOL:
Bluetooth Specification 4.1+A2DP
AUDIO INPUTS:
Bluetooth Compatible Devices
ACOUSTIC OUTPUT
POWER:
2 x 20W RMS / 40W Music Power
AUDIO POWER:
AC100-240V
WOOFER:
6.50” Injection Molded PP Cone Butyl Rubber Surround
TWEETER:
1” PET Dome
PACK DIMENSIONS:
46X33X25cm (pair)
PACK WEIGHT:
7.0kgs (pair)
COLOR:
White/Black

9
Responsible Party Name:
Innovative Concepts & Design LLC
Company address:
458 Florida Grove Road
Perth Amboy, NJ, 08861 USA
FCC Compliance Statement
This device complies with Part 15 of the FCC Rules. The operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a
class B digital device, pursuant to Part 15 of the FCC Rules. This equipment
generates, uses and can radiate radio frequency energy and if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause interference to radio or
television reception, which can be determined by turning the equipment off and
then on, the user is encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to a different outlet so that the equipment and
receiver are on different branch circuits.
• Consult the dealer or an experienced radio/TV technician for help.
FCC ID: 2AWFXIHSI650BT

10
LEGALITY & SAFETY
The device is not intended for use by people (including children) with reduced physical,
sensory or mental capacity. People who have not read the manual, unless they have
received an explanation by someone responsible for their safety, should not use this unit.
Children should be monitored to ensure that they do not play with the device. The device
should always be readily accessible. The device should not be exposed to water. No
objects filled with liquids, such as vases, shall be placed on the device. Always leave a
minimum distance of 10 cm around the unit to ensure sufficient ventilation. Open flame
sources, such as candles, should not be placed on top of the device. The device is intended
for use only in a temperate climate. At full volume, prolonged listening may damage your
hearing and cause temporary or permanent deafness, hearing drone, tinnitus, or
hyperacusis. Listening at high volume is not recommended. One hour per day is not
recommend either. Danger of explosion if battery is incorrectly replaced or not replaced
by the same type or equivalent. The battery should not be exposed to excessive heat such
as sunshine or fire. Different types of batteries, or new and used batteries, should not be
mixed. The battery must be installed according to its polarity. If the battery is worn, it
must be removed from the product. The battery must be disposed of safely. Always use
collection bins to protect the environment. The battery can only be replaced by the maker
of this product, the sales department, or a qualified person. Switch the device off where
the use of the device is not allowed or where there is a risk of causing interference or
danger - for examples: on an aircraft, or near medical equipment, fuel, chemicals or
blasting sites. Check the current laws and regulations regarding the use of this device in
the areas where you drive. Do not handle the device when driving. Concentrate fully on
driving. All wireless devices are susceptible to interference which may affect their
performance. All our devices conform to international/national standards and
regulations, and we aim to limit user exposure to electromagnetic fields. These standards
and regulations were adopted after the completion of extensive scientific research. This
research established no link between the use of the mobile headset and any adverse
effects on health if the device is used in accordance with standard practices. Only qualified
people are authorized to install or repair this product. Only use batteries, chargers and
other accessories which are compatible with this equipment. Do not connect
incompatible products. This equipment is not waterproof. Keep it dry. Keep your device
in a safe place, out of the reach of young children. The device contains small parts which
may present a choking hazard to kids.

11
WARRANTY AND REPAIR:
All Innovative Concepts & Design LLC products are designed and manufactured to the highest
standards in the industry. With proper care and maintenance, your product will provide years
of reliable service.
LIMITED WARRANTY
A. Innovative Concepts & Design LLC guarantees its products to be free from defects in
materials and workmanship for one (1) year from the original purchase date. Exceptions: Laser
assemblies on CD Players, cartridges, and crossfaders are covered for 90 days.
B. This limited warranty does not cover damage or failure caused by abuse, misuse, abnormal
use, faulty installation, improper maintenance or any repairs other than those provided by an
authorized Innovative Concepts & Design LLC Service Center.
C. There are no obligations of liability on the part of Innovative Concepts & Design LLC for
consequential damages arising out of or in connection with the use or performance of the
product or other indirect damages with respect to loss of property, revenues, of profit, or costs
of removal, installation, or reinstallation. All implied warranties for Innovative Concepts &
Design LLC, including implied warranties for fitness, are limited in duration to one (1) year from
the original date of purchase, unless otherwise mandated by local statutes.
RETURN/REPAIR
A. In the U.S.A., please call our helpful Customer Service Representatives at (732) 346-0061,
and they will be happy to give you a Return Authorization Number (RA#) and the address of an
authorized service center closest to you.
B. After receiving an RA#, include a copy of the original sales receipt, with defective product
and a description of the defect. Send by insured freight to: Innovative Concepts & Design LLC
and use the address provided by your customer service representative. Your RA# must be
written on the outside of the package, or processing will be delayed indefinitely!
C. Service covered under warranty will be paid for by Innovative Concepts & Design LLC and
returned to you. For non-warrantied products, Innovative Concepts & Design LLC will repair
your unit after payment is received. Repair charges do not include return freight. Freight
charges will be added to the repair charges.
D. On warranty service, you pay for shipping to Innovative Concepts & Design LLC, we pay for
return shipping within the continental United States. Alaska, Hawaii, Puerto Rico, Canada,
Bahamas, and the Virgin Islands will be charged for freight.
E. Please allow 2-3 weeks for return of your product.
Under normal circumstances your product will spend no more than 10 working days at
Innovative Concepts & Design LLC. We are not responsible for shipping times.

12
Altavoces Bluetooth® para exteriores impermeables y montables

13
Qué está incluido
Asegúrese de encontrar estos accesorios con sus altavoces Bluetooth IHSI
(1) Altavoz autoamplificado con soporte
(1) Altavoz pasivo con soporte
(1) Adaptador de CA
(1) Cable de altavoz
PRECAUCIONES
POR FAVOR LEA ESTAS INSTRUCCIONES DADAS EN ESTE MANUAL Y LAS MARCADAS EN LA UNIDAD
Este conjunto ha sido diseñado y fabricado para garantizar la seguridad personal.
El uso inadecuado puede provocar descargas eléctricas o peligro de incendio. Las
medidas de seguridad incorporadas en esta unidad lo protegerán si observa los
siguientes procedimientos de instalación, uso y servicio. Esta unidad está
completamente transistorizada y no contiene ninguna pieza que pueda ser
reparada por el usuario.
ADVERTENCIAS
Peligro de incendio y descarga eléctrica
1 - No coloque ninguna fuente de llama abierta, como velas encendidas, sobre o
cerca del aparato.
2 - No intente reparar el aparato usted mismo.
3 - Abrir o quitar las cubiertas puede exponerlo a voltajes peligrosos u otros
peligros y anulará la garantía del fabricante.
4 - Para evitar el riesgo de incendio o descarga eléctrica, evite sobrecargar los
tomacorrientes de pared, los cables de extensión o los receptáculos de
conveniencia integrales.
5 - Tormentas eléctricas Desenchufe este aparato durante tormentas eléctricas.
6- Entrada de objetos y líquidos: Nunca inserte objetos de ningún tipo a través de
las aberturas de este aparato, ya que pueden tocar puntos de voltaje peligrosos o
cortocircuitar partes que podrían resultar en un incendio o descarga eléctrica. Se
debe tener cuidado para que no caigan objetos y no se derramen líquidos dentro
del aparato a través de las aberturas de la carcasa.

14
CARACTERÍSTICAS
La solución definitiva para sus necesidades de audio Bluetooth® para exteriores.
Estos altavoces montables son ideales para patios y patios, ya sea para uso
doméstico o comercial. ¡Incluso puedes instalar estos altavoces en un barco! Con
una clasificación de resistencia al agua de IP44, no tendrá que preocuparse por
dejar los altavoces instalados en el exterior en los elementos, están a salvo del agua
y el polvo. Los soportes de montaje ajustables facilitan la instalación y permiten
una óptima dispersión del sonido. El IPHA-W400BT se empareja con su dispositivo
Bluetooth con facilidad y el control remoto inalámbrico pone el control en sus
manos. Estos parlantes están específicamente sintonizados para uso en exteriores,
lo que da como resultado un sonido enorme en un paquete compacto para que
pueda llenar sus fiestas en la piscina, barbacoas o cualquier otro evento al aire libre
con un sonido inigualable, que seguramente impresionará a sus invitados.
ALTAVOZ PARA TODO EL TIEMPO AL AIRE LIBRE
Con una clasificación de IP44, los iHSI es resistente al agua y al polvo,
especialmente diseñado para soportar la mayoría de los entornos.
PAR DE ALTAVOCES ACTIVOS / PASIVOS
Incluye un altavoz maestro activo y un altavoz esclavo pasivo, se conectan con el
cable de altavoz incluido. Solo el altavoz principal deberá estar conectado a la
alimentación.
BLUETOOTH®
Conexión inalámbrica súper simple. Una vez que conecte su dispositivo preferido
a través de Bluetooth®, se conectará automáticamente en el futuro. El indicador
LED muestra el estado de la conexión.
CONTROL REMOTO
El control remoto inalámbrico incluido pone el control en sus manos. El control
remoto le permite encender / apagar, emparejar, silenciar y ajustar los controles
de volumen, ecualización y reproducción.
GRAN SONIDO, PAQUETE COMPACTO
Amplificador de clase D sintonizado específicamente para uso en exteriores y
diseño de herramientas de gabinete personalizado.

15
Instalación de altavoces
Estos altavoces resistentes a la intemperie
para interiores y exteriores están fabricados
para resistir una variedad de condiciones
climáticas. Nieve, lluvia y sol (no sumergir
bajo el agua). Para mayor durabilidad /
longevidad, recomendamos quitar los
altavoces de los soportes y colocarlos en el
interior durante temperaturas extremas
prolongadas de más de 120 grados y menos
de 0 grados. El lugar más ideal para instalar
estos altavoces es debajo de los voladizos, ya
que brindan la mejor protección. Como todos
los altavoces, suenan mejor cuando se
colocan a no más de dos metros y medio de
distancia entre sí y un poco más altos que el
nivel de los oídos. Al elegir la ubicación de los
altavoces, tenga en cuenta la ubicación de la
fuente de alimentación. El altavoz
autoamplificado debe colocarse cerca de la
fuente de alimentación. El altavoz pasivo
puede colocarse más lejos y debe conectarse
al altavoz autoamplificado.
1: LED
2: DC IN (ALIMENTACIÓN)
3: SALIDA DE ALTAVOZ DERECHO
4: INTERRUPTOR DE ENCENDIDO
/ APAGADO
ALAMBRADO
Al conectar los altavoces, es muy importante observer
la polaridad correcta. Esto significa que el cable
conectado a los terminales (+), rojo o positivo de un
componente debe conectarse al terminal (+),rojo o
positivo de los terminales de salida de altavoz del
componente correspondiente. De manera similar, los
terminales (-), Negro, Negativo o de tierra deben
conectarse a los respectivos terminales (-), Negro,
Negativo o de tierra. Esto es fácil de hacer localizando
las franjas de color que aparecen en
el cable de altavoz incluido. Si se necesita untramo
de cable más largo, use cable resistente a la
intemperie de calibre 16 hasta 50 pies.

16
Metodo de uso
Colocación de altavoces
Si su aplicación requiere que se monte el
altavoz, siga estas instrucciones. Usando los
tornillos apropiados (no incluidos) monte el
soporte. Fije los altavoces a los soportes
utilizando las perillas de plástico grandes
suministradas.
Montaje
Para instalar el soporte en el altavoz.
Atornille las perillas del soporte en el
gabinete. Apunte el altavoz hacia el área
de audición. Una vez que se ha
determinado la dirección del altavoz,
apriete firmemente las perillas del
soporte. Cuando sea posible, incline los
altavoces hacia abajo para aumentar la
longevidad y evitar las inclemencias del
tiempo.
Configuración inicial
• Encienda el dispositivo Bluetooth
• Abra la configuración de Bluetooth
• Seleccione el ID de Bluetooth apropiado para la conexión
(Escuchará la confirmación del mensaje de voz)
• Ahora puede reproducir audio desde su dispositivo emparejado
• Control de volumen mediante dispositivo Bluetooth o control
remoto
Para emparejamientos posteriores, Bluetooth se conectará
automáticamente cuando su dispositivo esté cerca con Bluetooth
encendido. Para conectar otro dispositivo, apague Bluetooth en su
dispositivo original.

17
APOYAR
Si no hay entrada de señal en 10 minutos, ingresará automáticamente al modo de espera. El
usuario puede presionar el botón de encendido del control remoto para regresarlo. se volverá a
conectar automáticamente al último dispositivo en la memoria.
REMOTO
PALABRAS DE AVISOS DE VOZ:
• “Power On” = Encendido
• “Connected” = Conectado
• “Dissconnected” = Desconectado

18
ESPECIFICACIONES
ESPECIFICACIONES
Altavoz resistente a la intemperie para interiores / exteriores
NÚMERO DE PIEZA:
IHSI-W400BT-PR-BLK / IHSI-W400BT-PR-WHT
PROTOCOLO BLUETOOTH:
Especificación Bluetooth 4.1 + A2DP ENTRADAS DE
AUDIO:
Dispositivos compatibles con Bluetooth
POTENCIA DE SALIDA
ACÚSTICA:
2 x 12W RMS / 24W Music Power
POTENCIA DE AUDIO:
AC100-240V
WOOFER:
Anillo de caucho butílico de cono de PP moldeado por inyección de 4 ”
TWEETER:
domo PET de 1 "
DIMENSIONES DEL PAQUETE
36.7X25.8X22.2cm (par)
PESO DEL PAQUETE
4.6 kgs (par)
COLOR:
Negro / Blanco
ESPECIFICACIONES
Altavoz resistente a la intemperie para interiores / exteriores
NÚMERO DE PIEZA:
IHSI-W525BT-PR-BLK / IHSI-W525BT-PR-WHT
PROTOCOLO BLUETOOTH:
Especificación Bluetooth 4.1 + A2DP ENTRADAS DE
AUDIO:
Dispositivos compatibles con Bluetooth
POTENCIA DE SALIDA
ACÚSTICA:
2 x 15W RMS / 30W Music Power
POTENCIA DE AUDIO:
AC100-240V
WOOFER:
Anillo de caucho butílico de cono de PP moldeado por inyección de 4 ”
TWEETER:
domo PET de 1 "
DIMENSIONES DEL PAQUETE
39.5X27X22.5cm (par)
PESO DEL PAQUETE
4.97 kgs (par)
COLOR:
Negro / Blanco
ESPECIFICACIONES
Altavoz resistente a la intemperie para interiores / exteriores
NÚMERO DE PIEZA:
IHSI-W650BT-PR-BLK / IHSI-W650BT-PR-WHT
PROTOCOLO BLUETOOTH:
Especificación Bluetooth 4.1 + A2DP ENTRADAS DE
AUDIO:
Dispositivos compatibles con Bluetooth
POTENCIA DE SALIDA
ACÚSTICA:
2 x 20W RMS / 40W Music Power
POTENCIA DE AUDIO:
AC100-240V
WOOFER:
Anillo de caucho butílico de cono de PP moldeado por inyección de 4 ”
TWEETER:
domo PET de 1 "
DIMENSIONES DEL PAQUETE
45X32.5X24.5cm (par)
PESO DEL PAQUETE
6.5 kgs (par)
COLOR:
Negro / Blanco

19
FONCTIONNALITÉS
La solution ultime pour vos besoins audio Bluetooth® extérieurs. Ces haut-parleurs
montables sont idéaux pour les arrière-cours et les patios, que ce soit pour un
usage domestique ou professionnel. Vous pouvez même installer ces haut-parleurs
sur un bateau! Avec un indice d’étanchéité IP44, vous n’aurez pas à vous soucier
de laisser vos haut-parleurs installés à l’extérieur dans les éléments, ils sont à l’abri
de l’eau et de la poussière. Les supports de montage réglables facilitent
l’installation et permettent une dispersion optimale du son. Les haut-parleurs
extérieurs de la série iHSI s’associent facilement à votre appareil Bluetooth et la
télécommande sans fil met le contrôle entre vos mains. Ces haut-parleurs sont
spécialement réglés pour une utilisation en extérieur, ce qui donne un son énorme
à partir d’un ensemble compact afin que vous puissiez remplir vos fêtes à la piscine,
barbecues ou tout autre événement en plein air avec un son inégalé, sûr
d’impressionner vos invités
HAUT-PARLEUR EXTÉRIEUR PAR TOUS LES TEMPS
Avec un indice de protection IP44, la série iHSI est résistante à l’eau et à la poussière,
spécialement conçue pour résister à la plupart des environnements.
PAIRE DE HAUT-PARLEURS ACTIFS/PASSIFS
Comprend un haut-parleur actif et un haut-parleur passif, connectez-vous avec le fil
de haut-parleur inclus. Seul le haut-parleur actif devra être connecté à
l’alimentation.
BLUETOOTH®
Connexion sans fil super simple. Une fois que vous avez connecté votre appareil
préféré via Bluetooth®, il se connectera automatiquement à l’avenir. L’indicateur LED
affiche l’état de la connexion.
TÉLÉCOMMANDE
La télécommande sans fil incluse met le contrôle entre vos mains. La télécommande
vous permet d’allumer / éteindre, de coupler, de couper le son et de régler les
commandes de volume, d’égalisation et de lecture.
GROS SON, BOÎTIER COMPACT
Amplificateur de classe D spécialement réglé pour une utilisation en extérieur et une
conception d’outillage d’armoire personnalisée.

20
INSTALLATION DE HAUT-PARLEURS
Ces haut-parleurs résistants aux intempéries
intérieurs / extérieurs sont fabriqués pour
résister à une variété de conditions
météorologiques, y compris la neige, la pluie
et le soleil (mais pas pour être immergés
sous l’eau). Pour la durabilité / longévité,
nous vous recommandons de retirer les
haut-parleurs des supports et de les stocker
à l’intérieur pendant des températures
extrêmes prolongées supérieures à 120 ° F et
inférieures à 0 ° F. L’endroit le plus idéal pour
installer ces haut-parleurs est sous des
porte-à-faux, car ils offrent la meilleure
protection. Comme tous les haut-parleurs,
ils sonnent mieux lorsqu’ils ne sont pas
placés à plus de huit pieds les uns des autres
et légèrement plus haut que le niveau de
l’oreille. Lorsque vous choisissez
l’emplacement du haut-parleur, tenez
compte de l’emplacement de la source
d’alimentation. Le haut-parleur alimenté
doit être placé près de la source
d’alimentation. Le haut-parleur passif peut
être placé plus loin et doit être connecté au
haut-parleur alimenté avec le fil inclus.
1: INDICATEUR LED
2: PORT D’ALIMENTATION
3 : SORTIE HAUT-PARLEUR
4: INTERRUPTEUR MARCHE / ARRÊT
CÂBLAGE
Lors de la connexion des haut-parleurs, il est très
important de se connecter avec une polarité
correcte. Cela signifie que le fil attaché à la borne
Rouge / Positif (+) sur un composant doit être
attaché à la borne Rouge / Positif (+) sur la borne
de haut-parleur du composant correspondant.
De même, les bornes Noire / Négative / Terre (-)
doivent se connecter aux bornes Noire / Négative
/ Terre (-) respectives. Ceci est facile à faire en
localisant les étiquettes (+) et (-) qui apparaissent
sur le fil de haut-parleur inclus. Si un fil plus long
est nécessaire, utilisez un fil résistant aux
intempéries de calibre 16 jusqu’à 50 pieds.
This manual suits for next models
5
Table of contents
Other iHome Speakers manuals

iHome
iHome iBN27 Instruction Manual

iHome
iHome iHRK-400MOBC-PR User manual

iHome
iHome iBN16 User manual

iHome
iHome iBT374 User manual

iHome
iHome iDM15 User manual

iHome
iHome iBN24 User manual

iHome
iHome iBT75 User manual

iHome
iHome PLAYTOUGH X iBT300 User manual

iHome
iHome Split iBT11 User manual

iHome
iHome PLAYGLOW+ iBT820 User manual
