ProLite X2485WS
The ProLite X2485WS is a high-end 24” LED backlit LCD Screen featuring
IPS Panel technology which is considered to be the best all-round panel
type. It offers accurate and consistent colour reproduction with wide
viewing angles (178°/178°) and great response time (5ms). The ProLite
X2485WS features 1920 x 1200 native screen resolution, has a 5
000,000:1 Advanced Contrast Ratio and 300 cd/m² brightness offering the
user clear and vivid images. An array of inputs including Display Port, DVI
and VGA connections ensure compatibility across a range of devices
including games consoles and work stations. It also has two integrated
stereo speakers and is VESA mount compatible. It will provide both
excellent performance for photographic design and web-design and is
also an excellent choice for Universities, Corporate and Financial
Markets, as well as the rapidly expanding demand for Multi Monitor
applications.
DISPLAY CHARACTERISTICS
Diagonal 24.1"
Panel IPS, LED-Backlit
Display area h x w 324 x 518.4 mm; 12.8" x 20.4"
Response time 5 ms
Contrast 1000 : 1 typical
Contrast 5 000 000 : 1 ACR
Brightness 300 cd/m² typical
Viewing zone horizontal/vertical: 178°/ 178°; right/left:
89°/ 89°; up/down: 89°/ 89°
Display colour 16.77 million
Pixel pitch h x v 0.27 x 0.27 mm
Native resolution 1920 x 1200 ( 2.3 megapixel)
Horizontal sync 30 - 94 KHz
Vertical sync 50 - 75 Hz
Synchronization Separate sync
Aspect ratio 16 : 10
POWER MANAGEMENT
Power supply AC100~240V 50/60Hz
Power Supply Unit internal
Power usage 36 W typical; max. 0.5 W in Power
management mode
Power management VESA DPMS, ENERGY STAR®
DIMENSIONS & WEIGHT
Dimensions w x h x d 561 x 449 x 216.5 mm
Weight 4.6 kg
INTERFACES CONNECTORS
Analog input connector VGA (D-Sub)
Digital input connector DVI-D, DisplayPort
HDCP yes
Headphone connector Yes
Output connector headphone connector
D-Sub, DVI-D, DisplayPort
SPECIAL FEATURES
Apple - Mac All iiyama monitors are compatible with
Apple-Macintosh computers.
Plug & Play VESA DDC2B™
Controls Via OSD in 9 languages (EN, DE, FR, ES,
IT, NL, Chinese, RU, JP) and 5 front controls
(Power, Menu, +/ Volume, -/ ECO, Auto)
User controls picture (brightness, contrast, H.position,
V.position, phase, clock, colour temp., sRGB,
auto adjust), OSD (H.position, V.position,
OSD timeout, transparency), display (display
mode, i-style Colour, ACR, ECO, sharpness,
OD, gamma), audio (volume, mute, audio
input), miscellaneous (language, input select,
opening logo, after AC cut, reset), information
Speakers 2 x 1.5 W (Stereo)
Anti-theft-device Kensington-lock™ prepared
Ergonomics CE, TUV-GS, VCCI-B, TCO 6, CU
Tilt angle 22° up; 5° down
VESA mounting 100 x 100 mm
Colour Black
ACCESSORIES
Driver Windows 95 / 98 / 2000 / ME / XP / Vista / 7 /
8
Included accessories power cable, VGA (D-Sub) cable, DVI-D
cable, audio cable, stand, quick start guide,
safety guide
Powered by TCPDF (www.tcpdf.org)
All trademarks and registered trademarks acknowledged. E & O E. Specification subject to change without notice. All LCD's comply with ISO-9241-307:2008 in connection with pixel defects.
www.iiyama.com 2013-07-06T21:29:49+02:001/1
