USER MANUAL
X-MONITOR

X-MONITOR
Contents
2
Table of Contents
Contents 2
License Agreement 4
1 – Introduction 10
2 – Remote control on X-MONITOR UI 11
2.1 – How the remote works 11
2.2 – Remote view 13
3 – Main view 14
3.1 – USB Connection 14
3.2 – Startup, monitor association and Identify button 15
3.3 – Firmware update 16
3.4 – Recovery mode 18
3.5 – Controls 19
3.5.1 – Settings 19
3.5.2 – Alert notifications 21
3.6 – Speakers link 22
3.7 – Standby timer setting 23
3.8 – Additional delay setting 23
3.9 – Contour view 24
3.10 – Speaker connection monitor 25
4 – Calibration 26
4.1 – Position the microphone 26
4.2 – Welcome to iLoud Precision calibration 27
4.3 – Hardware setup 28
4.4 – Room analysis 29
4.5 – DONE! 32
5 – Voice Menu 33
6 – ARC curves 35
6.1 – ARC curves graphic 35
7 – Contour view 36
7.1– Frequency sliders 38
7.2 – Contour presets 39
7.3 – Contour and ARC interaction 40

X-MONITOR
Contents
3
Support 41
User Area 41

X-MONITOR
License Agreement
4
License Agreement
End-User License Agreement for IK Multimedia Computer Related Software
Please read this document carefully before installing the IK Multimedia Production Srl (hereafter: IK Multimedia)
software on your computer.
This agreement licenses the enclosed software to you (hereafter: Licensee) and contains warranty and liability
disclaimers. By installing the IK Multimedia software on your computer, you are confirming to have taken notice
of terms and conditions of this agreement and you acknowledge your acceptance of the software as well as
your acceptance of the terms of this agreement.
If you do not wish to do so, do not install the software. Instead, provided you purchased a boxed product,
promptly return the entire package, to the dealer from whom you have obtained it, for a full refund. If you
purchased a product from the IK Multimedia Online Shop, please contact IK Multimedia at
www.ikmultimedia.com/contact-us.
1) DEFINITIONS
“End-User License Agreement” (hereafter: “EULA”), means the contractual conditions between you and IK
Multimedia for the use of the “IK Multimedia Product” and means the right to use this non-exclusive license
agreement.
“IK Multimedia Product” (hereafter: “Product”) means the software program, the related documentation, models,
multimedia content (such as animation, sound and graphics) and all related updates supplied by IK Multimedia.
“Not For Resale” (hereafter: “NFR”) means a version of the Product, so identified, intended for review and
evaluation purposes only.
“Intellectual Property Rights” means worldwide common law and statutory rights associated with (i) patents and
patent applications; (ii) works of authorship, including copyrights, copyright applications, copyright registrations
and “moral” rights; (iii) the protection of trade and industrial secrets and confidential information; (iv) other
proprietary rights relating to intangible intellectual property (specifically excluding trademarks, trade names
and service marks); (v) analogous rights to those set forth above; and (vi) divisions, continuations, renewals,
reissuances and extensions of the foregoing (as applicable) now existing or hereafter filed, issued or acquired.
2) LICENSE
The Product is protected by copyright laws and international copyright treaties, as well as other intellectual
property laws and treaties. The Product is licensed only. The intellectual property of the Product remains at IK
Multimedia.

X-MONITOR
License Agreement
5
This EULA grants you the non-exclusive right to use the Product for a maximum period of 30 (thirty) years. All
other actions and means of usage are reserved to the written permission of the right holder IK Multimedia.
The Product is only for your personal (individual) use.
You may install and use the Product, or any prior version thereof for the same operating system, on up to three
(3) computers, provided that (a) each computer is owned by (or leased to) and under the exclusive control of the
Licensee; (b) the Product shall NOT be used simultaneously on more than one machine, and (c) any computer(s)
with the Product installed shall not be sold, rented, leased, loaned or otherwise be removed from the Licensee’s
possession without first removing (uninstalling) the Product, except as provided in Paragraph 4.5 (below)
pertaining to “Software Transfer”.
You may also store or install a copy of the Product on a storage device, such as a network server, used only
to install or run the Product on your other computers over an internal network; however, you must acquire and
dedicate a distinct license for each user of the Product from the storage device.
Any given license for the Product may not be shared or used concurrently or otherwise on different computers
or by different users in a given organization.
3) AUTHORIZATION
The Product only functions upon completing the registration and authorization procedure described in the
accompanying user documentation.
The registration and authorization procedure requires to create a user account on the IK Multimedia website
and to provide the requested information about yourself, in accordance with IK Multimedia privacy policy (www.
ikmultimedia.com/privacy).
If you provide any information that is not correct or incomplete, or IK Multimedia has reasonable grounds to
suspect that such information is not correct or incomplete, IK Multimedia has the right to suspend or to revoke
the license.
The termination of the license shall be without prejudice to any other rights, whatsoever, of IK Multimedia.
Once the Product is registered it is associated with your user account and it can not be returned or transferred
to any third party without obtaining the prior written consent of IK Multimedia.

X-MONITOR
License Agreement
6
4) DESCRIPTION OF OTHER RIGHTS AND LIMITATIONS
4.1 Limitations on Reverse Engineering, Decompilation, and Disassembly
The Product is licensed as a single product. Its component parts may not be separated for use on more than
one computer.
You may not reverse engineer, decompile, or disassemble the Product, except and only to the extent that such
activity is expressly permitted by applicable law.
4.2 Sound License Agreement
In case a sound library is part of the Product, it is subject to the following terms in addition to the EULA:
All sounds and samples in the Product are licensed to you for commercial and non-commercial use in music
and audio production, public performance, broadcast or similar use.
Re-distribution of this Product, its sounds or their derivatives, through any means, including but not limited
to, re-sampling, mixing, filtering, processing, isolating, or embedding into software or hardware of any kind, is
strictly prohibited.
Furthermore all these sound and samples may not be repackaged in whole or in part as audio samples, sound
libraries, sound effects or on a stand alone basis.
4.3 Not For Resale
If the Product is labeled “NFR” or “Evaluation Copy”, then, notwithstanding other sections of this EULA, you
may not sell, or otherwise transfer the Product.
4.4 Rental
You may not rent, lease, or lend the Product to any party.
4.5 Software Transfer
You may transfer your rights as Licensee of the software or any IK Multimedia product, as licensed to you under
this agreement only with purchasing a license transfer on IK Multimedia official website. The above-mentioned
transfer license can be combined with a single “IK Multimedia Product”, and just only once.
IK Multimedia reserves the rights to:
I) delete or cancel, at its sole discretion, the necessary serial number for the registration, if purchased
fraudulently or, in any case, against the law.

X-MONITOR
License Agreement
7
II) forbid, at its sole discretion, any transfer of the necessary serial number for the registration, before the term of
90 days starting from the serial number or license transfer purchasing order.
The Product may be transferred or otherwise made available to any third party only with the prior written
consent of IK Multimedia and provided that (a) the original media and license(s) accompany the Product and (b)
the party transferring the Product does not retain a copy of the Product.
In addition the following may apply:
a) If the Product is part of a bundle of software, the whole bundle must be resold / transferred as a whole. Any
individual Product in a software-only bundle cannot be resold / transferred separately.
b) If the Product is part of a bundle of IK Multimedia software and hardware, only the hardware can be resold /
transferred. Any bundled software Product is considered NFR.
4.6 Third Party Rights
Some content included in the Product may belong to third parties and could be protected by copyright or other
intellectual property laws.
5) UPGRADES
If the Product is labeled or otherwise identified by IK Multimedia as an “upgrade” or “crossgrade”, you must be
properly licensed to use a product identified by IK Multimedia as being eligible for the upgrade or crossgrade in
order to use the Product.
A Product labeled or otherwise identified by IK Multimedia as an upgrade replaces and/or supplements the
product that formed the basis for your eligibility for such upgrade. You may use the resulting upgraded Product
only in accordance with the terms of this EULA.
If the Product is an upgrade of a component of a bundle of software programs, it may be used and transferred
only as part of the bundle and may not be separated for use on more than one computer.
6) DUAL-MEDIA SOFTWARE
You may receive the Product in more than one medium. You may not loan, rent, lease, or otherwise transfer the
other medium to another user, except as part of the permanent transfer (as provided above) of the Product.
7) LIMITED WARRANTY
IK Multimedia warrants to the original purchaser of the Product, for a period of ninety (90) days following the

X-MONITOR
License Agreement
8
date of original purchase, that under normal use, the software program and the user documentation are free
from defects that will materially interfere with the operation of the program as described in the enclosed user
documentation.
In any case the concerning law is reserved, if applicable.
8) WARRANTY CLAIMS
To make a warranty claim under the above limited warranty, please contact IK Multimedia at the address
www.ikmultimedia.com/contact-us.
IK Multimedia or its authorized dealer will use reasonable commercial efforts to repair or replace the product and
return it to you or issue to you a credit equal to the purchase price, at its option
IK Multimedia or its authorized dealer will use reasonable commercial efforts to repair or replace the product and
return it to you or issue to you a credit equal to the purchase price, at its option.
9) LIMITATIONS ON WARRANTY
IK Multimedia warrants only that the Product will perform as described in the user documentation. No other
advertising, description or representation, whether made by an IK Multimedia dealer, distributor, agent or
employee, shall be binding upon IK Multimedia or shall change the terms of this warranty.
EXCEPT AS STATED ABOVE, IK MULTIMEDIA MAKES NO OTHER WARRANTY, EXPRESSED OR IMPLIED,
REGARDING THIS PRODUCT. IK MULTIMEDIA DISCLAIMS ANY WARRANTY THAT THE SOFTWARE IS FIT
FOR A PARTICULAR PURPOSE, AND ANY IMPLIED WARRANTY OF MERCHANTABILITY SHALL BE LIMITED
TO A NINETY (90) DAY DURATION OF THIS LIMITED EXPRESS WARRANTY AND IS OTHERWISE EXPRESSLY
AND SPECIFICALLY DISCLAIMED. IK MULTIMEDIA SHALL NOT BE LIABLE FOR SPECIAL, INCIDENTAL,
CONSEQUENTIAL OR OTHER DAMAGES, EVEN IF IK MULTIMEDIA IS ADVISED OF OR AWARE OF THE
POSSIBILITY OF SUCH DAMAGES. THIS MEANS THAT IK MULTIMEDIA SHALL NOT BE RESPONSIBLE OR
LIABLE FOR THE LOSS OF PROFITS OR REVENUES, OR FOR DAMAGES OR COSTS AS A RESULT OF
LOSS OF TIME, DATA OR USE OF THE SOFTWARE, OR FROM ANY OTHER CAUSE EXCEPT THE ACTUAL
COST OF THE PRODUCT. IN NO EVENT SHALL IK MULTIMEDIA LIABILITY EXCEED THE PURCHASE PRICE
OF THIS PRODUCT.
10) GOVERNING LAW, DISPUTES RESOLUTION
This Agreement shall be governed by and construed and interpreted in accordance with the laws of Italy. Any
dispute, controversy or claim arising under, out of, or relating to this EULA, including, without limitation, its
formation, content, validity, binding effect, interpretation, performance, breach or termination, as well as non-
contractual claims, shall be subject to the Court of Milano (Italy), having the complete and exclusive jurisdiction.

X-MONITOR
License Agreement
9
11) GENERAL
This Agreement contains the complete agreement between the parties with respect to the subject matter hereof,
and supersedes all prior or contemporaneous agreements or understandings, whether oral or written.
If any stipulations of this EULA become invalid, completely or in part, this not affect the validity of the remaining
stipulations.
All questions concerning this Agreement shall be directed to:
IK Multimedia Production Srl
Via dell’Industria 46
41122 Modena
Italy
Last update September 22nd, 2020

X-MONITOR
1 – Introduction
10
1 – Introduction
The iLoud Precision X-MONITOR control software is a macOS/Windows application that connects to the iLoud
Precision studio monitors via USB.
The main functionalities of the control software are:
• Remote control of all the monitor’s parameters and settings from a convenient user interface
• Assist the user in the ARC calibration process and visualize the frequency response of the system before
and after the calibration process
• Replicate the functionality of the iLoud Precision remote control onscreen through a minimized view

X-MONITOR
2 – Remote control on X-MONITOR UI
11
2 – Remote control on X-MONITOR UI
The remote view replicates the hardware remote control unit onscreen. You can assign any of these functions to
the four buttons:
• Any of the available X-MONITOR “voices”
• Mute or Dimming
• ARC calibration On/Off
2.1 – How the remote works
Function Selection/Association
Function assignment can be done on each one of the four buttons: these assignments will apply on both the
software and the hardware remote unit.
By default, the configuration for both the hardware and the software remote are:
• Button 1: Precision
• Button 2: High End 3-Way
• Button 3: Classic AMT 7
• Button4:White′90s

X-MONITOR
2 – Remote control on X-MONITOR UI
12
In order to assign functions to the remote control, proceed by right-clicking on the virtual remote buttons
displayed in the middle of X-MONITOR, a menu showing the assignable options will appear:
The functions are divided into different categories:
• X-MONITORVoice(i.e.HighEnd3-Way,White′90s)
• Speakers Mute
• Speakers Dim
• ARC On/Off
Please Note: in the Settings panel, you can save and recall the entire settings to and from a “session” file so that
the entire setup can be transferred from one system to another. (See paragraph 3.2.2)

X-MONITOR
2 – Remote control on X-MONITOR UI
13
2.2 – Remote view
The interface of the X-MONITOR control software can be used in Main view mode or in a convenient Remote
view. The Main view displays all the controls and features of the software, while the Remote view replicates the
iLoud Precision remote control and is designed to take up as little space as possible onscreen.
In order to switch between Main and Remote views, proceed by clicking on the following button:
A similar button is present on the Remote view, allowing you to switch back to the Main view.

X-MONITOR
3 – Main view
14
3 – Main view
3.1 – USB Connection
To control and manage the iLoud Precision speakers via the X-MONITOR software, you need to connect them
both via USB to two separate and available ports of your computer or USB hub, as shown in the image below.

X-MONITOR
3 – Main view
15
3.2 – Startup, monitor association and Identify button
The first time X-MONITOR software is launched, you’ll need to manually select speakers using the “Left
Speaker” and “Right Speaker” select menus. The next time this will be saved in the session so that X-MONITOR
will recognize and automatically connect the speakers.
However, if the monitors are connected to USB (or turned ON) only after running the software, you’ll need to
manually select the monitors from the “Left Speaker” and “Right Speaker” select menus.
When no monitor is associated to the slots, all the onscreen controls are greyed out and inoperable except for
the “Left Speaker” and “Right Speaker” select menus, where the “None” option will be selected.
Identify button:
In order to recognize which speaker is which, click on the “Identify” button displayed next to both the “Left
Speaker” and the “Right Speaker” select menus. This will make the front LED on the speaker blink white for a
few seconds.

X-MONITOR
3 – Main view
16
3.3 – Firmware update
Each time X-MONITOR scans the USB ports for iLoud Precisions, the speaker’s firmware version will be
detected. If one or both speakers appear to have an outdated firmware version, the software will prompt you to
update the firmware:
Click on the “Update Firmware” button in order to proceed. A progress bar will appear indicating that the update
process is pending. During this firmware update process the speaker’s front LED will be steady blue.
DO NOT INTERRUPT FOR ANY REASON THIS PROCESS. DO NOT TURN SPEAKERS OR COMPUTER
OFF. DO NOT DISCONNECT THE USB CABLES OR QUIT THE X-MONITOR SOFTWARE WHILE THIS
PROCESS IS IN PROGRESS AS THIS MAY RESULT IN DAMAGE TO THE SPEAKERS.

X-MONITOR
3 – Main view
17
In the event the update fails, the process will be interrupted and the X-MONITOR controls will be greyed out
and the software will not recognize the speaker. In this case, please turn the speakers off and on again and try
the procedure again. If the problem persists, please contact our Support Team. (also see paragraph 3.4 for the
Recovery procedure)
When the update is correctly completed, X-MONITOR will display this info:
In some cases, the firmware version of the speakers may be newer than the software one. In this scenario, when
opening the X-MONITOR software, a dialog asking you to update the X-MONITOR software through the IK
Product Manager will appear.
Close the X-MONITOR software and open the IK Product Manager. Go in the Hardware tab and click on the
“Software” tab of the iLoud Precision product family. Click on the download button of the X-MONITOR software
in order to download the latest version of X-MONITOR.

X-MONITOR
3 – Main view
18
3.4 – Recovery mode
In some rare cases, the firmware upgrade process may fail and one or both speakers enter in DFU mode. DFU
mode can be recognized by the steady blue light on the speaker front panel. While in DFU mode, the speaker
controls on the X-MONITOR UI are greyed out and inoperable.
Please proceed as follows to try the Recovery procedure and upgrade the firmware version of the speaker:
• Open the Settings panel
• Click on the Recovery button
• Follow the onscreen instructions in order to upgrade the firmware
Please note: when doing a Recovery procedure, only one speaker in DFU mode must be connected to the USB
port. Please disconnect all the other speakers connected via USB before proceeding. If both speakers are in
DFU mode, follow the onscreen instructions and connect one speaker at a time via USB. If the Recovery mode
doesn’t fix the problem on the speaker, please contact technical support.
Please note: When executing a Recovery procedure, all previous saved settings on the speaker will be erased
and restored to factory default.

X-MONITOR
3 – Main view
19
3.5 – Controls
3.5.1 – Settings
Click on the toast icon in the top bar in order to open the settings pop-up window.
The Settings menu is divided into two tabs: Settings and Info.
Tab 1: SETTINGS
This tab allows you to load from and save to disk session files of the contour section, voice and Remote buttons
assignments, together with Delay and Standby timer controls. Once a session is loaded, all the controls in the
X-MONITOR software will be populated with the previously saved settings. Also, X-MONITOR will automatically
store the edits in the session, so that when closing and reopening the software, the settings are restored
according to the last change made.
Please note: Session saving does not include the ARC calibration.
Also, from this tab it is possible to launch the Recovery procedure (described in paragraph 3.4). If you want to
try forcing the firmware update, click on the “Force Update” button and select again the units from the “Left
Speaker” and “Right Speaker” select menus.

X-MONITOR
3 – Main view
20
Tab 2: INFO
This tab opens an info window regarding the Software and the iLoud Precision products.
