Ikan ELE-EV3-FFSBP User manual

What’s Included
QUICKSTART GUIDE
1 x EV3 Baseplate
2 x 12" 15mm Aluminum Rods
1 x FG Follow Focus Cine-Kit (ELE-FGK)
ELE-EV3-FFSBP
EV3 DSLR Quick Release Baseplate & Follow Focus Kit
[email protected] © 2015 ikan Corporation. All rights Reserved
www.ikancorp.com 713.272.8822
CHECKED BY

Getting to know your Quick-Release Baseplate
EV3 Quick-Release Baseplate
The EV3 baseplate system enables you to
quickly and efficiently mount and dismount
your camera - Simply press one level and
the quick-release button.
Height Adjustable
Use the riser plate to adjust the
height of the baseplate to adapt
to different cameras.
Integrated Tripod Mount
Four ½-20"& four 3/8"-16 thread holes line
the bottom of the tripod mount for various
mounting options.
Anti-Rotation plate prevents your camera from
rotating out of alignment.
½"-20
Threaded Holes
3/8"-16
Threaded Holes

Getting to Know your Follow Focus
Reaching Out
The included 17"FG Follow Focus Whip
features vinyl covering and a crank
stability grip for smooth control.
Utilizing a standard ¾"square
connector, the FG Whip provides
leverage over distance and
smoother focus pulls all around.
Crank It Up
Our 2.3 FG Follow Focus Crank Knob provides
rapid focus, allowing you to move from focus
mark to focus mark at a high rate of speed.
Fitted with standard size square connector, the
FG Crank Knob offers fast and accurate control.
Get It In Gear
Also in the box is a pair of 2.5 to 4.25” diameter
adjustable zip lens gears. Complete with two
no-scuff, non-slip gear liners; your DSLR lens is
protected and ready to pull focus.

Getting Started
Adjust FG Follow Focus vertically to slide
away or towards the lens, depending on
the barrel width.
This is an example of the basic completed
Follow Focus application.

Rig Specifications
EV3 Baseplate Specifications
Weight 1.15 lbs
Baseplate Type Quick Release
Rod Compatibility 15 mm
Rod Spacing 60 mm
Tripod Mounting 4 x 1/4"-20 Threaded Holes
4 x 3/8"-16 Threaded Holes
1 x 1/4"-20 Threaded Screw
Camera Compatibility DSLR, Mirrorless DSLR, Micro 4/3, Small Camcorders
Material Aluminum
Rod Specifications 12 Inch
Rod Type Standard
Rod Diameter 15 mm
Rod Length 12 In.
Weight 0.14 lbs
Quantity 1
Material Aluminum
Follow Focus Specifications
Follow Focus Specifications
Dimensions 12.25 x 7 x 4.375 In.
Weight 1
Shipping Specifications
Shipping Dimensions 14 x 12 x 6 In.
Shipping Weight 4 lbs

Learn More
More dynamic information at official website: www.ikancorp.com
Support
Contact email: [email protected]
CONDITIONS OF WARRANTY SERVICE
• Free service for one year from the day of purchase if the problem is caused by manufacturing errors.
• The components and maintenance service fee will be charged if the warranty period is expired.
Free Service will not be Provided in the Following Situations:(*Even if the product is still within the warranty period.)
• Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company.
• Damage caused by natural disaster, abnormal voltage, and environmental factors, etc.
