IKC HW00502 User manual

IKC | HQ EUROPE
Dronten | The Netherlands
[phone]
[e-mail]
www.ikcplay.com
All our products are inspected, tested
and certied by SGS and TÜV.
European standard EN 71 species
safety requirements for toys.
Compliance with the standard is legally
required for all toys sold in
the European Union.
All our products only use FSC
certied wood, so eco- and
environment friendly!
Our products are conform with
health, safety and environmental
protection standards for products
sold within the EU.
IKC | HQ ASIA
Shanghai | China
[phone]
[e-mail]
www.ikcplay.com.cn
Fencing | Fence monster play module
Fence monster play module is a play panel
that allows you to easily attach any square
Playmodule from the Monster collection.
By adding play value to the panel, you give
children the chance to discover a playful
surprise around every corner of the play area.
Fence monster
play module
Article no. Size HxWxD Mounting
HW00502 101,5x75,5x18 cm oor mount 6,5 KG MDF
FENCESIKC PRODUCTS
Corner piece colours Pantone no. and RAL
543C 375C RAL 9003

Required tools
4mm
TOOLS OVERVIEWINSTALLATION MANUAL
Drill
2x
High Pole
Low Pole
Screws Screws Wallmount
Screws
Floormount
BP
1x
LP
1x
MP
2x
CP
3x
BP
1x
LP
1x
MP
1x
CP
2x
S16
60
6x
3x
Ø10
95
S31
Not included
HP
1x
HP
1x
S11
40
6x
S19
40
10x
35
S9
4x
FP
1x

INSTALLATION MANUAL
To ensure a stable product we recommend using a 90 degree angle every two
panels (1).
A beadstree table or dashboard panel is also a good way to ensure stability. (2)
(1)
(2)

INSTALLATION MANUAL
BP
1x
LP
1x
MP
2x
HP
1x
CP
3x
BP
1x
LP
1x
MP
1x
HP
1x
CP
2x
High Pole
Low Pole

INSTALLATION MANUAL
S9
4x
S19
4x

INSTALLATION MANUAL
S11
6x
S19
6x

INSTALLATION MANUAL

INSTALLATION MANUAL
To ensure the product does not
move, bolt it to the ground.
To ensure the product does not
move, screw it into the wall.
S16
6x
S31
6x
60MM
No gap between wall and panel
Drill new hole
