ANRÄTTA
AU

ENGLISH 4
Please refer to the last page
of this manual for the full list
of IKEA appointed Authorized
Service Centre and relative
national phone numbers.

ENGLISH 4
Before using the appliance, read
these safety instructions. Keep
them nearby for future reference.
These instructions and the
appliance itself provide important
safety warnings, to be observed
at all times. The manufacturer
declines any liability for failure to
observe these safety instructions,
for inappropriate use of the
appliance or incorrect setting of
controls.
SAFETY WARNINGS
Very young children (0-3
years) should be kept away from
the appliance. Young children
(3-8 years) should be kept
away from the appliance unless
continuously supervised.
Children from 8 years old
and above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge can
use this appliance only if they
are supervised or have been
given instructions on safe use and
understand the hazards involved.
Children must not play with the
appliance.
Safety Information
Table of contents
Cleaning and user maintenance
must not be carried out by
children without supervision.
WARNING!: The appliance
and its accessible parts become
hot during use.
WARNING!: Avoid touching
heating elements or interior
surface during and after use - risk
of burns.
WARNING!: Never leave the
appliance unattended during
food drying. If the appliance
is suitable for probe usage,
only use a temperature probe
recommended for this oven - risk
of re.
Keep clothes or other
ammable materials away
from the appliance, until all the
components have cooled down
completely - risk of re.
Always be vigilant when cooking
foods rich in fat, oil or when
adding alcoholic beverages - risk
of re. Use oven gloves to remove
pans and accessories. At the end
of cooking, open the door with
caution: allowing hot air or steam
Safety Information 4
Product description 8
Control panel 9
First use 9
Daily use 10
Cooking tables 14
Cleaning and maintenance 15
What to do if ... 16
Technical data 17
Installation 17
Electrical connection 18
Environmental concerns 19
IKEA GUARANTEE 20

ENGLISH 5
to exit gradually before accessing
the cavity - risk of burns. Do not
obstruct hot air vents at the front
of the oven - risk of re.
Exercise caution when the
oven door is in the open or down
position, to avoid hitting the door.
WARNING!: If the door or
door seals are damaged, the
oven must not be operated until it
has been repaired – risk of injury.
WARNING!: Liquids and foods
must not be heated in sealed
containers – risk of explosion,
heating of beverages can result
in delayed eruptive boiling, care
must be taken when handling the
container – risk of burn.
Do not dry food or cloathing
or heat warming pads, slippers,
sponges and similar - risk of re.
When heating food in plastic or
paper containers, remains vigilant
on the oven - risk of re.
Contents of feeding bottles
and baby food jars shall be
stirred or shaken and temperature
checked - risk of burn. Do not
heat eggs in their shell and
shole hard-boiled eggs - risk of
explosion
Only use utensils suitable
for microwave oven. Do not use
metallic containers - risk of injury
Only use a temperature probe
recommended for this oven - risk
of re.
If smoke is emitted switch off
or unplug the appliance and
keep the door closed in order to
stie any ames.
If appliance is installed
above 850 cm heigh from oor,
care should be taken not to
displace turntable while removing
container - risk of injury.
Do not use your microwave
oven for deep-frying, because
the oil temperature cannot be
controlled.
PERMITTED USE
This appliance is intended to
be used in household and similar
applications such as:
Staff kitchen areas in shops,
ofces and other working
environments; Farm houses; By
clients in hotels, motels and other
residential environments; Bed and
breakfast type environments.
CAUTION: the appliance is
not intended to be operated by
means of an external switching
device, such as a timer, or
separate remote controlled
system.
This appliance is intended
to be used in household and
similar applications such as: staff
kitchen areas in shops, ofces
and other working environments;
farm houses; by clients in hotels,
motels, bed & breakfast and
other residential environments.

ENGLISH 6
Do not install the appliance
behind a decorative door - risk o
re.
This appliance is not for
professional use. Do not use the
appliance outdoors.
No other use is permitted (e.g.
heating rooms).
Do not store explosive or
ammable substances (e.g.
gasoline or aerosol cans) inside
or near the appliance - risk of
re.
INSTALLATION
The appliance must be
handled and installed by two or
more persons - risk of injury. Use
protective gloves to unpack and
install - risk of cuts.
Installation, including water
supply (if any) and electrical
connections, and repairs must
be carried out by a qualied
technician. Do not repair or
replace any part of the appliance
unless specically stated in the
user manual. Keep children
away from the installation site.
After unpacking the appliance,
make sure that it has not been
damaged during transport.
In the event of problems, contact
the dealer or your nearest
After-sales Service. Once
installed, packaging waste
(plastic, styrofoam parts etc.)
must be stored out of reach of
children - risk of suffocation. The
appliance must be disconnected
from the power supply before
any installation operation -
risk of electrical shock. During
installation, make sure the
appliance does not damage
the power cable - risk of re or
electrical shock. Only activate the
appliance when the installation
has been completed.
This appliance is intended
to be used built-in. Do not use
it freestanding or place into a
cabinet.
After unpacking the appliance,
make sure that the appliance
door closes properly.
In the event of problems, contact
the dealer or your nearest After-
sales Service.
Carry out all cabinet cutting
works before tting the appliance
in the furniture and remove all
wood chips and sawdust.
Do not obstruct the minimum gap
between the worktop and the
upper edge of the oven - risk of
burn.
Do not remove the oven from its
polystyrene foam base until the
time of installation.
After installation, the bottom
of the appliance must no longer
be accessible - risk of burn.
ELECTRICAL WARNINGS
The rating plate is on the front
edge of the oven (visible when
the door is open).

ENGLISH 7
It must be possible to
disconnect the appliance from
the power supply by unplugging
it if plug is accessible, or by
a multipole switch installed
upstream of the socket and the
appliance must be earthed, in
conformity with national electrical
safety standards.
Do not use extension leads,
multiple sockets or adapters.
The electrical components must
not be accessible to the user
after installation. Do not use the
appliance when you are wet or
barefoot. Do not operate this
appliance if it has a damaged
power cable or plug, if it is not
working properly, or if it has been
damaged or dropped.
If the supply cord is damaged,
it must be replaced with an
identical one by the manufacturer,
its service agent or similarly
qualied persons in order to
avoid a hazard - risk of electrical
shock.
In case of replacement
of power cable, contact an
authorized service center.

ENGLISH 8
Product description
1
2
3
4
1Control Panel
2Grill element (Quartz)
3Cavity Lamp
4Door
Accessories
Turntable support
1x
Glass turntable
1x
Crisp-plate
1x
Crisp handle
1x
General
There are a number of accessories available
on the market. Before you buy, ensure they are
suitable for microwave use.
Ensure that the utensils you use are oven proof
and allow microwaves to pass through them
before cooking.
When you put food and accessories in the
microwave oven, ensure that they do not come
in contact with the interior of the oven.
This is especially important with accessories
made of metal or metal parts.
If accessories containing metal come in contact
with the oven interior, while the oven is in
operation, sparking can occur and the oven
could be damaged.
Always ensure that the turntable is able to turn
freely before starting the oven.
All accessories are dishwasher safe with the
exception of the crisp plate.
The crisp plate should be cleaned using water
and a mild detergent. For stubborn dirt, rub
gently with a cloth. Always leave the crisp
plate to cool down before cleaning.
Aluminium foil can be used safely to shield
small areas of food as long as it does not
come in contact with the oven interior.
Turntable support
Fit rst the internal weel and then the external
part of the turntable support.
Use the turntable support under the Glass
turntable. Never put any other utensils on the
turntable support.
Glass turntable
Place the Glass turntable on the turntable
support.
Use the Glass turntable with all cooking
methods. It collects the dripping juices and
food particles that otherwise would stain and
soil the interior of the oven.
Crisp handle
Use the supplied special Crisp handle to
remove the hot Crisp plate from the oven.
Crisp-plate
Place the food directly on the Crisp-plate.
Always use the Glass turntable as support
when using the Crisp-plate.
Do not place any utensils on the Crisp-plate
since it will quickly become very hot and is
likely to cause damage to the utensil.

ENGLISH 9
Control panel
A
Selection push-push knob
B
Back button
C
Stop
D
Display
E
Start
F
Conrmation button
G
Adjust push-push knob
Retractable knobs
To use this type of knob,
press it in the middle.
The knob comes out.
Turn it to the required position.
Once cooking is over, turn the
knob to and press it again to
restore it to its original position.
A D GB CFE
Settings
When the appliance is rst plugged in it will
ask you to set the clock.
After a power failure the clock will ash and
needs to be reset.
Your microwave oven has a number of
functions which can be adjusted to your
personal taste.
GFA
1. Turn the Aknob until Setting is shown
(aprox. 3 sec).
2. Push the Gknob out and turn it to choose
one of the following settings to adjust:
Clock, Sound, ECO, Brightness
3. Press the Fbutton to exit the settings
function and save all your changes when
you are done.
• Clock
GF
1. Press the
F
button (the left-hand digits
hour’s icker).
2. Push the
G
knob out and turn it to set
hours.
First use
3. Press the
F
button (the two right hand
digits (minutes) icker).
4. Turn the
G
knob to set the minutes.
5. Press the
F
button again.
The clock is set and in operation.
• Sound
GF
1. Press the
F
button.
2. Push the
G
knob out, and turn it to turn
the buzzer ON or OFF.
3. Press the
F
button again to conrm the
change.
• Eco
GF
1. Press the
F
button.
2. Push the
G
knob out and turn it to turn
the ECO setting ON or OFF.
3. Press the
F
button again to conrm the
change.
When the ECO mode is on, the brightness
of the display will automatically switch to

ENGLISH 10
Start protection / Safety lock
This automatic safety function is activated
one minute after the oven has returned to
“stand by mode“. (The oven is in “stand by”
when the 24-hour clock is displayed or if the
clock has not been set, when the display is
blank).
Open and close the door, then press
F
to
start the function.
Cooling down
When a function is nished, the oven may
carry out a cooling procedure. This is normal.
After this procedure the oven switches off
automatically.
The cooling procedure can be interrupted
without any harm to the oven by opening the
door or pressing the
C
Button.
Setting the timer
Use this function when you need a kitchen
timer to measure exact time for various
purposes such as cooking eggs or letting the
dough rise before baking etc.
GFA
Daily use
1. Push the
A
knob out and turn it until zero
position.
2. Push the
G
knob out and turn it to set the
desired length of the timer.
3. Press the
F
button.
An acoustic signal will be heard when the
timer has nished to count down.
Pressing any button to turn off the acoustic
signal
WARNING : Overheating the liquid beyond
boiling point can occur without evidence
of bubbling. This could result in a sudden
boil over of the hot liquid. To prevent this
possibility the following steps should be
taken :
1. Avoid using straight-sided containers
with narrow necks.
2. Stir the liquid before placing the
container in the appliance and let the
teaspoon remain in the container.
3. After heating, allow standing for a short
time, stirring again before carefully
removing the container from the
appliance.
Jet start
This function is used for quick reheating of
food with a high water content such as; clear
soups, coffee or tea.
With the knob in the upright postion, press
Start button to switch on the Jet Start
function.
a lower level after 1 minute. If the ECO
mode is off, the brightness will switch to
the same lower level after 3 minutes. It
will automatically switch back to the set
brightness level when a button is pressed or
the door is opened.
• Brightness
GF
1. Press the
F
button.
2. Push the
G
knob out and turn it to set
the level of brightness suitable to your
preference.
3. Press the
F
button again to conrm the
change.
