[ Dimensions ]
(unit:mm)
ืPIXIM 1/3" High Sensitivity Digital Sensor
ืHigh Resolution : 690TVL Effective (Color), 800TVL Effective (B/W)
ืMin. Illumination : 0Lux with IR LED
ืSens-Up (2x~64x)
ืVari-Focal Auto Iris Lens (2.8~10mm/F1.2, 5~50mm/F1.4)
ืPowerful WDR (Wide Dynamic Range)
ืDNR for saving storage
ืPrivate Masking (12 Zones)
ืMotion Detection
ืOSD remote control via RS-485 (optional)
ืOSD control by coaxial cable via pelco coaxitron
ืDigital Zoom (8x)
ืFocus, Viewing Angle & OSD menu adjustment externally
ืPhoto Sensor & IR LED (30pcs)
ืViewable Distance at Night : 25m
ืVBS-EXTRA for connection to LCD monitor
ืWeatherproof (IP67)
ืHeater optional (-40ȋC ~ +50ȋC)
ืUTC controller optional
[ Features ] [ Specifications ]
0Lux
IP67
690
HTVL
Effective
ITEM
Image Sensor
Effective Pixels
Dynamic Range
Horizontal Resolution
Min. Illumination
Day & Night
White Balance
WB Range
Shutter Speed
Sens-up
DNR
Privacy Masking
Remote Control
AGC
Image Flip
Camera ID
S/N Ratio
Video Output
OSD
Sync. System
Operating Humidity
Operating Temp.
Weight
PIXIM 1/3" High Sensitivity Digital Sensor
758(H) x 540(V)
120dB(Max), 102dB(Typical)
690TVL Effective(Color), 800TVL Effective (B/W)
0Lux with IR LED (30pcs)
COLOR / B/W / AUTO
Auto / AWB / Indoor / Outdoor / Manual
2000ȋK~11,000ȋK
1/25(f/1.2) ~ 1/30,720 sec.
Auto / Off (Selectable x2 ~ x64)
Low / Middle / High / Off
12 Zones
RS-485
Low / Middle / High / Off
Horizontal and Vertical
On / Off
More than 50dB
Composite video output 75ohm terminated
Built-in
Internal / Line Lock
30% ~ 90% RH
-10ȋC to 50ȋ
Approx. 1,130g
ISD-M71
12VDC Only (Max.500mA)
24VAC/12VDC (Max.400mA/Max.650mA)
Power Consumption
WDR Digital Sensor Bullet Camera
ISD-M71 Nightwolf
ISD-M71 ඖ
(Nightwolf)
100
(122.8)
162.5
146.4
85.7
(7.4)
(241.5)
