IKER ZBS-20A User manual

Instruction Manual
Ice Maker & Shaver ZBS-20A
Thank you for choosing our ice maker
Please read this Instruction Manual carefully before using this product so as to ensure proper use.
After reading this manual, please keep it in a safe place and refer to it when necessary.

Description
1
Front top lid
14
Ice full sensor
2
Viewing window
15
Water buoy
3
Evaporator
16
Water suction hole
4
Ice basket
17
Drain plug
5
Back top lid
18
Max water filling line
6
Control Panel
19
Back cover
7
Middle Frame
20
Water Inlet Hole
8
Handle
21
Shaved ice bowl
9
Housing
22
Shaving paddle
10
Decoration door
23
Knife
11
Fan Cover
24
Bowl cap
12
Shaved ice outlet
25
Power Cord and Plug
13
Ice shovel
Specifications
Daily Ice Output：15-20kg/24h
Ice Storage Capacity：3kgs
Water Reservoir Capacity：3L
Refrigerant：R600a / R290
Ice Shape：Bullet
Dimension：378*398*420mm

Before/First Use of Your Ice Maker
1.During transportation, the incline angle of the cabinet should not be over 45°.Do not turn the Ice
maker upside down. As this may damage the compressor and sealed system.
2.Remove all packing material and carefully check your ice maker to ensure it is in good condition and
that there is no damage to the ice maker or power cord and plug.
3.The Ice maker should be placed horizontally on a level surface.To ensure proper ventilation for your
Ice maker allow 150mm of space at the top, the back and on each side. Do not install the Ice maker
near an oven, radiator, or any other heat source.
4.Before using the Ice maker for the first time, please wait 2 hours after positioning it, and keep the front
lid open for at least 2hours
5.Ensure that the voltage indicated on the ice maker corresponds with the voltage in your home.
6.Pure water is not allowed to be used on this unit, spring water is recommended.
7.Please always keep the viewing window close during ice making.
Control Panel Operation
Button/Indicator
Explanation
Press this button to shaved ice.
Before the press of this button,please put enough ice into the bowl and covers the
bowl cover well.
Unit under ice making process if it lights up without flash
It lights up when the ice in ice basket is full
It lights up when the water in water tank is not enough
Press it to start the ice making.

Operating Instructions
Step 1.
Shaved ice may melt,so it is strongly recommended that a drain hose at bottom of unit be connected.
The steps are as follows.
drain pipe
Sketch for step 1
Step 2.
Open the lid,take out of the ice basket and fill the water reservoir with water.
Note: Make sure the water is not over the bottom of the ice collecting tray.
If you prefer to fill the water automatically,then insert the water pipe into the socket at back of the unit as
below.
STEPS TO HOOK IT UP TO A TAP
Step 2.1
Insert the brackets at the
back of the machine
Step 2.2
Remove the lids on both
sides of the filter
Step 2.3
Install the filer connectors on
both sides, which should be
bound with raw tape,
otherwise it will result in
leakage

Step 2.4
Stick the filter between the
buckles(the end of the filter
with an arrow should be
placed towards the left).
Step 2.5
Insert the water pipes to both
sides to the filter .But do not
connect them to the machine
in advance.
Step 2.6
Unscrew the water tap and
instead screw the tap
interface(the metal) first,and
then screw the water tap to
the tap interface.
Step 2.7
Connect the blue water tap
with tap interface to the right
pipe of the filter.(Note:it’s not
the time yet for the left pipe to
be connected to the water
inlet hole),and turn on the tap
for at least 10seconds to
drain water. Once the water
becomes clear, turn off the
tap. Then connect the left
pipe to the water inlet hole
and turn on the tap again.

Step 2.8
If you want to take off the
pipe connected to the water
inlet hole, take off the blue
ring named as A(if any)first,
then press the white ring at
the outer side named as
B,and pull out the pipe
simultaneously
Step 3.
Connect to the power.
Step 4.
Press button to turn unit on. The ice maker begins to work.
Note: For the first three cycles,the ice may be small and irregular in size,or even no ice.
Step 5.
If indicator lights up,please take out the basket,then add water as per step 1，then press to
restart the ice maker
Step 6.
If indicator lights up,please take out the ice with the scoop.
Note: When the ice basket is full please remove the ice immediately, Do not allow
the ice collecting tray overfill.
Step 7.
Press button to shave ice.
Note: Before the press of this button,please put enough ice into the shaved ice bowl and cover
the bowl cap well.
Step 8.
Press button to stop the machine.
Step 9.
Put a tank in below the unit,then pull the unit a little forward, pull the drain plug at middle of the tank to
drain water.
Step 10.
If you want to take off the pipe,sketch as above,firstly take off the blue ring named as A(if any),then press
the white ring(lock) at the outer side named as B,At last take out the pipe

Caring
1.Clean the inner liner, ice collecting tray, water box, ice shovel and evaporator frequently. When
cleaning, unplug the unit and remove the ice cubes. Use a diluted solution of water and vinegar to
clean the inside and the outside surface of the Ice maker. Do not spray Ice maker with chemicals or
diluted agents such as acids, gasoline or oil. Rinse thoroughly before starting.
2.Keep ventilation openings in the appliance enclosure, or in the built-in structure, clear of obstruction.
Do not use mechanical devices or other means to accelerate the defrosting process, other than those
recommended by the manufacturer.
3.To ensure the cleanliness of the ice cubes, water in the water reservoir is suggested to be replaced
every 24 hours.
5.If the compressor stops for any reason such as water shortage, too much Ice, power off, etc... Do not
start the system right away, wait 3 minutes, and then re-start the Ice maker.
6.Always use fresh water before starting ice production either at initial installation or after a long shut-off
period.
7.This unit is for home use only,not for outdoor use,if it is necessary for use outside,please make sure
the view window is closed.
Safety Notice
In order to avoid any accidents, please refer to following operation:
1. Disconnect power before servicing.
2. Do not pull directly on wire when plugging or unplugging the unit.
3. If ice is abnormal, please call the seller.
4. It is normal for the compressor and condenser surface to reach temperatures between 70°C and 90°C
during operation and surrounding areas may be hot. Please don't touch it.
5. Due to fast freezing, ice cubes may appear “Cloudy”. This is trapped air in the water and it will not
affect quality or taste of ice.
6. When out of use, please open the drawer at least 2cm to allow for air circulation and avoid any
metallic components becoming rusted.
7. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a
similarly qualified person in order to avoid a hazard.
8. This appliance can be used by children aged from 8years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and understand the hazards
involved.
9.Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision
10. WARNING: fill with bottled or good quality tap water only. (Do not fill with fruit juices or other drink
types).
11. WARNING –Keep the air vents on the sides of the machine unblocked at all times.
12. WARNING –Do not use mechanical devices or other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
13. WARNING –Do not damage the refrigerant circuit.

14. WARNING –Do not use electrical appliances inside the food storage compartments of the appliance,
unless they are of the type recommended by the manufacturer.
Troubleshooting
1. Please note, if a power failure occurs due to disconnection of the power cord, or the off power button
has been pushed off during an ice making cycle, small ice chips may formed and lodge in the automatic
shovel causing it to jam. If this occurs, the ice chips may be removed by disconnecting the power cord
and gently pushing the shovel to the rear of the cabinet and removing the ice chips, then restarting.
2. Please restart the ice maker by pressing Stop and then Start. If the Ice shovel does not push the Ice
into the Ice collector after the formed Ice drops from the evaporator finger while at the same time the M
light is on, check to see if the water tray is horizontal or balanced. If not then adjust by pressing the Ice
shovel lightly with your finger. Then re-start the Ice maker.
The compressor works
abnormally with a
Buzzing noise
Reasons
The voltage is lower than recommended
Solutions
Stop the Ice maker and do not restart until the voltage is
normal.
Conditions for Ice making
Cycle are right but no ice
is made.
Reasons
Refrigerant leaks./ Sealed system is
blocked
Solutions
call for service
The lights of ice full and
add water come at in the
same time.
Water tray is
blocked by
ice cube.
Clear the ice cube under the ice shovel pull out the plug
and insert It again then press the button, 3 minutes
later the machine will restart automatically.
Machine keeps
running,but the water is
warmer than the normal
water.
The
magnetic
valve is
broken.
Replace the magnetic valve.
