IKOHS CREATE LIGHTCALM User manual

ENENGLISH
LIGHTCALM
CEILING FAN WITH LIGHT
ASSEMBLY MANUAL

4
LIGHTCALM
EN
To download this user guide in your language, visit our website:
www.ikohs.com/uk
ES
Para descargar el manual en su idioma, visite nuestra web:
www.ikohs.com/es
PT
Para baixar o manual no seu idiomas, visite nosso site:
www.ikohs.com/pt
FR
Pour télécharger le manuel dans votre langue, visitez notre site Web:
www.ikohs.com/fr
IT
Per scaricare il manuale nella sua lingua, visitare il nostro sito Web:
www.ikohs.com/it
DE
Um das Handbuch in Ihrer Sprachen herunterzuladen, besuchen Sie un-
sere Website:
www.ikohs.com/de
NL
Bezoek onze website om de handleiding in uw taal te downloaden:
www.ikohs.com/nl
PL
Aby pobrać instrukcję w swoim języku, odwiedź naszą stronę internetową:
www.ikohs.com/pl

5
LIGHTCALM
INDEX
THIS MANUAL IS FOR ALL LIGHTCALM MODELS
Box contents 6
Step 1. Wooden ceiling 7
Step 1. Concrete ceiling 8
Step 1. False ceiling 10
Step 2. Driver connection 11
Step 3. Ground connection 11
Step 4. Anchoring the motor to the ceiling 12
Step 5. Assembling the blades 13
Step 6. Decorative element installation 14
Step 7. Led plate connection 15
Step 8. Glass installation 16
Blade balancing kit 17

EN ENGLISH
A B
F G
D
E
H I J K
L
M N
BOX CONTENTS
(1) EXPANSION SCREWS
MOUNTING BRACKET
DECORATIVE ELEMENT
TERMINAL BLOCKS BALANCING KIT
BLADES GLASS
DRIVER
MOTOR SUPPORT
REMOTE CONTROL
SCREWS + WASHERS FOR
BLADES
LED PLATE
SCREWS FOR
SUPPORT + MOTOR
SCREWS FOR DECORATIVE
ELEMENT + MOTOR
(2) WOOD SCREWS
ATTENTION! Before starting the as-
sembly, remember to disconnect
the light from the electrical panel
so as not to suffer an electric shock.
C

ENENGLISH
STEP 1. WOODEN CEILING
+ +
(2) WOOD SCREWS
OPTIONAL ACCORDING TO
CEILING TYPE
E
4
1
3
5
4
If necessary, depending on the type of
ceiling, you will need to use a drill to
make the holes in the wood.
Repeat this step for the remaining 3
holes.
Place the washer and then the screw E2
with the help of the screwdriver.
Make sure that piece Ais perfectly hooked to the ceiling with the screws well tightened.
Mark with a pencil the 4 holes of piece
Aon the ceiling.
A
PARTS AND TOOLS
E2
A
NOT INCLUDED
2

EN ENGLISH
STEP 1. CONCRETE CEILING
(1) EXPANSION SCREWS
Using a drill, make the two correspond-
ing holes with a Ø8 mm drill bit.
Insert the pieces E1 in the holes of the
ceiling.
Place piece Amatching its holes with
the screws E. Make sure the ceiling ca-
bles pass through the center hole of
piece A.
Mark 2 parallel holes on the ceiling with
a pencil using piece Aas a guide.
A
E1
E1 E2 E3 E4
Disassemble piece Eseparating it into pieces.
E
A
EA
PARTS AND TOOLS
Ø8 mm
1
3
2
4
+ +
NOT INCLUDED

ENENGLISH
Insert piece E2, E3 and the nut E4 fol-
lowing this order.
Tighten piece E4 with a number 10

Make sure that piece A is perfectly hooked to the ceiling.
E4
E2
E3
E4
5 6
7

EN ENGLISH
+ ++
PIECES AND TOOLS
STEP 1. FALSE CEILING
FIXING SCREWS
WITH SPRING LEVER
NOT INCLUDED
Make sure that piece Ais perfectly attached to the ceiling.
A
With the help of a drill, make the two
corresponding holes.
Insert the set screws into the holes and
make sure the lever opens.
Place piece A    
screws to the false ceiling.
Mark 2 parallel holes on the ceiling with
a pencil using piece Aas a guide.
A
X
1
3
5
4
2

ENENGLISH
STEP 2. DRIVER CONNECTION
STEP 3. GROUND CONNECTION
B
B
I
I
+
+
With the help of the screwdriver, you need to lay the wires of piece I into piece B, so
that the colors of the cables coincide with those represented in the driver.
Ain a hole in piece Iso that the motor is hanging
to facilitate the connection of the cables.
I
AA
II
I
I
B
B
B
M
1
32
1 2 3

EN ENGLISH
STEP 4. ANCHORING THE MOTOR TO THE CEILING
+
Connect the grounding wire in piece Ato the piece I.
Also, if your electrical installation has its own grounding
wire, also connect it to that of piece Aand piece I.
Once connected, place
piece Mscrewing it in until
it is secured.
Connect the line and
neutral wires to piece B.
After connecting the wires, insert piece Binside piece I.
Use 2 screws Kand screw them loosely into the parallel
holes in piece A.
Remove piece Ifrom the
hook and snap it into piece
Awithout pinching any wire.
A
AAA
K
K
B
I
I
I
B
I
M
A
I
K
4
7
1
5
8
2
6
9
3

ENENGLISH
Once docked in the hole, turn piece I to the right and check that it is properly seated
without pinching any wires.
Once piece I Kinto the remaining holes by tightening them

With the motor well posi-
tioned, we will begin the
assembly of the blades F.
    Fsecuring it with the washers and
screws Jwith the help of the screwdriver, without tighten-
ing them too much, to be able to put the rest of the blades.
STEP 5. ASSEMBLING THE BLADES
F J
A replacement
screw is included
+
F F
JJ
4
7
1
5
8
2
6
9
3
I

EN ENGLISH
To place piece Hpass the fan cables through the central hole, matching the 2 holes
with those in the central bracket.
STEP 6. DECORATIVE ELEMENT INSTALLATION
H L
Follow the same step with the second and third blades F. Remember not to screw in
the screws completely.
Once all the blades Fare in place, screw all the screws Jtightly so that the blades
are well attached.
+
H
4
7
1
5
8
2
6
9
3

ENENGLISH
Screw in the screws Lin the two large holes of piece Hnot too tight. Then turn piece
Hclockwise so that it is perfectly seated and aligned with the third hole.
Connect piece Dcables to those of the fan joining the connections, each with the
same color.
Once piece His attached, screw the last screw L and tighten the rest so that the piece
is attached to the fan.
LL
L
D
STEP 7. LED PLATE CONNECTION
D
4
1
7
5
2
8
6

EN ENGLISH
Place piece G
Then attach piece Dto the fan with the magnets to hold it.
Do not forget to check that piece G-
tricity and enjoy your new fan with light.
1
4
2
5
3
G
STEP 8. GLASS INSTALLATION
G
4 53

ENENGLISH
BLADE BALANCING KIT
G
Your ceiling fan may have blade swing problems when in operation due to irregularities
in the blades or brackets. Also, incorrect system mounting or crooked bearings could
cause additional problems. The following procedure is recommended to remedy these
problems:
1. 
2. 
inclination of the blade mounts, they should all be the same.
3. Standing under the fan and looking up, check that none of the blade supports are
bent so that none of the blades are misplaced. You can correct the position of the
blade holders by gently bending them to the correct position.
4. You can check the height of the blades with a simple school ruler. Place the ruler
against the ceiling vertically and level with the outside of the blade tip. Check the
distance from the blade tip to the ceiling, carefully rotate the blades by hand and
check the rest of the blades. If the blades are not aligned, you can carefully bend
the blade holder up or down slightly to align with each other.
If the balance problem is not solved even by following the steps above, you must
perform a dynamic balance check using the kit provided. Follow the procedure below:
1. Turn on the fan and set the speed at which the most sway is created (usually this
occurs at the highest speed).
2. Turn off the fan. Select a blade and place the balancing clip, midway between the
bracket and the tip, on the rear edge of the blade.
3. Turn on the fan. Wait to see if the sway has improved or worsened. Turn the fan off
again and attach the clip to another blade to retest. Repeat this process with all the
blades and check which one has improved the most.
4. Place the clip on the blade that has improved the most. Move it in or out of the

roll improvement.
5. Then remove the clip and install a balancing weight on top of the blade on the
center line near the position where the clip was placed. Use a knife or blade if nec-
essary to separate the weights.
Caution: Stand at a safe distance from the blades. If for any reason the clip has not
been properly secured, you could be injured.
