Iluv I399 User manual

Stereo Audio System for Your iPod®

Instruction Manual

Model: i399/i398

Please read this manual carefully before operating and save it for future reference.

Have a question? Please visit http://www.i-Luv.com

Stereo Audio System for Your iPod V10M10_IM_EN_12072007

www.i-Luv.com- 1 -

USER SAFETY GUIDE

INSTRUCTIONS ON ENVIRONMENT PROTECTION

Do not dispose of this product in the usual household garbage at the end of its life cycle; bring it to a collection point for the recycling of

electrical and electronic appliances. This symbol on the product means the instructions for use or the packing will inform about the methods

for disposal. The materials are recyclable as mentioned in its marking. By recycling, material recycling, or other forms of re-utilization of old

appliances, you make an important contribution to protect the environment. Please inquire at your local community administration for the

authorized disposal location.

FCC RULES

This device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference.

Do not make changes or modify the device in any way. Changes or modifications not expressly approved by the party responsible for compliance

could void the user’s authority to operate the equipment.

IMPORTANT SAFETY WARNINGS

1. Before using the player, please ensure that your local AC voltage is suitable for this unit.

2. To prevent fire or electric shock, do not expose the unit to rain or moisture.

3. Never attempt to open the cabinet. Always refer servicing to a qualified technician.

IMPORTANT SAFETY INSTRUCTIONS

1. READ INSTRUCTIONS – All the safety and operating instructions should be read before the appliance is operated.

2. RETAIN INSTRUCTIONS – The safety and operating instructions should be retained in a secure place for future reference.

3. HEED WARNINGS – All warnings on the appliance and in the operating instructions should be observed.

4. FOLLOW INSTRUCTIONS – All operating and use instructions should be followed.

5. WATER AND MOISTURE – The appliance should not be used near water. For example: near a bathtub, kitchen sink, laundry tub, and/or swimming

pool.

6. HEAT – The appliance should be situated away from heat sources such as radiators, heat registers, stoves, or other appliances (including amplifiers)

that produce heat.

Stereo Audio System for Your iPod V10M10_IM_EN_12072007

www.i-Luv.com- 2 -

USER SAFETY GUIDE

IMPORTANT SAFETY INSTRUCTIONS – CONTINUED

7. POWER SOURCES – The appliance should be connected to a power supply only of the type described in the operating instructions or as marked on

the appliance itself.

8. CLEANING – The appliance should be cleaned with a dry cloth.

9. OBJECT AND LIQUID ENTRY – Care should be taken so that objects do not fall and liquids are not spilled into the device’s openings.

10. CARTS AND STANDS – The appliance should be used only with a cart or stand that is recommended by the manufacturer. An

appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the

appliance and cart combination to overturn.

11. DAMAGE REQUIRING SERVICE – The appliance should be serviced by qualified service professional when:

a. The power supply cord or plug has been damaged.

b. Objects have fallen into, or liquid has been spilled into the appliance’s apertures.

c. The appliance has been exposed to rain.

d. The appliance has been dropped and suffered damage.

e. The appliance does not appear to operate normally or exhibits a change in performance.

12. SERVICING – The user should not attempt to service the appliance beyond what is described in the user's operating instructions. All other servicing

should be referred to qualified service professional.

13. BATTERY USAGE – To prevent battery leakage, which may result in bodily injury, property damage or damage to the unit, follow these instructions:

a. Install all batteries correctly according to the polarity (+/-) as marked on the unit.

b. Do not mix old and new batteries, carbon and alkaline, etc.

c. Remove batteries from the unit when the device will not be used for an extended period of time.

14. LEAD AND MERCURY – This product may contain lead and/or mercury. Disposal of these materials may be regulated by your local authorities due to

environmental considerations. For more detailed disposal or recycling information, please contact your local authorities or the EIA (Electronic Industries

Alliance) – http://www.eiae.org

Stereo Audio System for Your iPod V10M10_IM_EN_12072007

www.i-Luv.com- 3 -

USER SAFETY GUIDE

FCC NOTICE (USA)

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the equipment and receiver.

3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4. Consult the dealer or an experienced radio/TV technician for help.

IC NOTICE (CANADA)

This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the Radio Interference Regulations of

Industry Canada. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment

generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television operation (which can be determined by turning the equipment off), the user is encouraged to try to correct the interference

by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

Stereo Audio System for Your iPod V10M10_IM_EN_12072007

www.i-Luv.com- 4 -

USER SAFETY GUIDE

About Electromagnetic Interference (EMI)

The term “EMI” is short for the electromagnetic interference caused by the electromagnetic field generated by electronic devices. In fact, most electrical

appliances and devices emit electric and magnetic fields, and most of modern electronic devices are susceptible to the EMI if they are inadequately shielded

or designed.

•If you use any personal medical device, such as a pacemaker, please consult the manufacture of your medical device to determine if it is adequately

shielded from EMI. Your physician might assist you in obtaining this information.

•Please turn off this device if you are instructed to do so, especially on an airplane or in a hospital.

•Please keep away from medical instruments in a hospital or medical unit while using this device.

IMPORTANT NOTES ON HEARING

Your hearing is very important to you and to us. We strongly recommend you to follow the guideline below in order to prevent possible damage to or loss of

hearing.

Hearing experts caution that listening to loud sounds can damage hearing over time. With continuous listening to loud sounds, hearing adapts and will give

the impression that volume has reduced. What seems normal may, in fact, be harmful. To guard against this before hearing adapts,set the volume at a low

level and slowly increase the volume level until sound can be heard comfortably and clearly without distortion. Damage to hearing is cumulative and

irreversible. Ringing or discomfort in the ears indicates that the volume is too loud. Once a comfortable listening level has been established, do not increase

the volume level further.

Cautions

•If you experience a ringing sound in your ear, lower the volume or discontinue the use of this product.

•Do not use the headphones while driving or cycling. Because this product reduces the external noises, you might not be able to hear the warning sounds,

such as an automobile horn, and might result in a traffic accident. Additionally, listening to headphones while driving is illegal in many places

Stereo Audio System for Your iPod V10M10_IM_EN_12072007

www.i-Luv.com- 5 -

TABLE OF CONTENTS

Getting Started

General features ……………………………………………………………………………………………………………………………………………...… 6

Installing the AC adapter…………….……………………………………………………………..………………………………………………………..… 7

Installing batteries………………..……………………….………………………………………………………. 8

Installing the dock adapter …………………………………………………………………………………………………………………………………….. 10

Location of controls on the main unit ……………………………………………………………………………………………………………….…...…… 11

Location of controls on the remote control …………………………………………………………………………………………………………………... 12

Location of indications on the LCD screen …...……………………………………………………………………………………………………………... 13

Operational Instructions

Setting the time…………………………………………………………………………………………………………………………………………………. 14

Turning on / turning off the unit……………………………………………………………………………………………………………………………... 14

Turning on / turning off the woofer light……………………………………………………………………………………………………………………… 14

Listening to your favorite radio stations … ………………………………………………………………………………………………………………... 14

Listening to your favorite songs on your iPod ………………………………………………………………………………………………………….. 15

Listening to other audio devices ………...……………………………………………………………………………………………………………………. 16

Charging your iPod …………………………………………………………………………………………………………………………………………….. 17

BluePin Setup and operating Instructions ………………………………………………………………………………………………………..………….. 18

Maintenance & Troubleshooting Guide ……………………………………………………………………………………………………………..………….. 24

Specifications ……………………………………………………………………………………………………………………………………………………….. 27

Stereo Audio System for Your iPod V10M10_IM_EN_12072007

www.i-Luv.com- 6 -

Congratulations on your purchase of the new iLuv i399/i398 for your iPod. Uniquely designed to work with your iPod, this iLuv Hi-Fi audio system with built-in

universal dock provides advanced audio and radio performance that brings out the best in your music. Remember to keep this manual for future reference.

Maximize Your Enjoyment of the Music on Your iPod with the iLuv Hi-Fi Audio System

•Enjoy Wireless freedom with new BluePinTM adapter with Bluetooth Wireless Technology

•Bluetooth wireless speakerphone function

•Enhance the richness of your iPod sound with jAuraTM acoustic speaker technology

•Powerful built-in speakers with subwoofer allow you to hear music with depth and clarity

•Digital clock display

•Charges your iPod

•Integrated universal dock for your iPod

•Auxiliary line input for 1st , 2nd , and 3rd generations of the iPod and other audio devices

•Stereo FM radio with PLL digital tuning technology

•20 presets memory stations

•Negative liquid crystal display with white backlight

•Remote control included

What’s included?

•BluePinTM Adapter (for i399 only)

•2.1 channel audio system

•Remote control (Battery included)

•Dock adapters

•AC adapter

•Instruction manual

•Warranty card

•Made for all iPod modes except the 1st, 2nd and 3rd generation iPod

Note: All iPod Shuffle or other device users must use the Line-In feature of i399/i398 to listen to music stored in these players.

GETTING STARTED

Stereo Audio System for Your iPod V10M10_IM_EN_12072007

www.i-Luv.com- 7 -

IMPORTANT:

1. Occasionally, files on iPod can become corrupted. This may cause an erratic behavior with your iLuv products. Apple Inc. recommends that you visit

their website www.apple.com to obtain instructions on resetting or restoring your iPod to factory settings.

2. It is imperative that you use the correct dock adapter for your iPod and that the dock adapter fits appropriately into the built-in universal dock. Ignoring

these rules can cause severe damage to your iPod. Please refer to the section “Installing the Dock Adapter” to properly install the dock adapter

before operating the i399/i398 with your iPod.

Installing the AC Adapter

Locate the AC adapter jack on the back of the unit. Insert the AC adapter cable into the jack, and plug into the wall outlet.

GETTING STARTED

Stereo Audio System for Your iPod V10M10_IM_EN_12072007

www.i-Luv.com- 8 -

Installing the battery

i399/i398 supports both of external DC power supply and battery power supply, before operate in battery power

supply, please unplug the external DC plug and install the batteries as following instructions:

1. Locate the battery compartment on the rear side of the unit and open the battery door.

2. Insert 8 pcs “D” size batteries, following the correct polarity (+/-) drawings inside the battery compartment.

For longer battery life, alkaline batteries are suggested.

3. Secure the battery compartment by closing the door.

Installing the Backup Battery for Clock Settings

In order to offer consistent clock settings, the i399/i398 uses a backup battery system. This means that in the event of a power failure, all time settings of the

i399 will remain saved. For example, after the installation of the Backup Battery, the AC cord is disconnected or a power failure occurs, the display will NOT

remain lit, but the time and date settings will be temporarily maintained. To install Backup Battery, follow the instructions below:

1. Make sure the connection between the AC adapter and the unit is secure. This is important because during

battery replacement it is possible for all settings to be lost if time have already been set.

2. Locate the battery compartment on the rear side of the unit and open.

3. Insert 2 “AAA” batteries, following the correct polarity (+/-) drawings inside the battery compartment. For longer

battery life, alkaline batteries are suggested. Please note that new and used batteries should not be mixed.

Likewise, alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium) batteries should not be used

together.

4. Secure the battery compartment by closing the cover.

GETTING STARTED

Stereo Audio System for Your iPod V10M10_IM_EN_12072007

www.i-Luv.com- 9 -

Important Notes on Batteries

To prevent battery leakage, which may result in bodily injury, property damage or damage to the unit, follow these instructions.

•Install all batteries correctly according to the polarity (+/-) as marked on the unit.

•Do not mix old and new batteries, carbon and alkaline, etc.

•Remove batteries from the unit when the device will not be used for an extended period of time.

Please dispose the used batteries properly according to your local government regulations.

Installing the Remote Control Battery

The remote control battery has been previously installed and ready for operation for immediate use. When the remote control stops functioning, you must

replace the battery with a new one. To do so, locate the battery compartment on the side of the remote and follow the steps below:

1. Squeeze the notch labeled “Tab A” while pulling the “battery door latch B” out towards you. This will allow the battery

holder to release and pop out. Please refer to the picture on the right side.

2. Insert a “CR2025” 3V lithium battery. Make certain to follow the correct polarity, following the directions of the

corresponding symbols (+/-).

3. Secure battery and push the battery holder back into the remote control until fully inserted.

GETTING STARTED

Stereo Audio System for Your iPod V10M10_IM_EN_12072007

www.i-Luv.com- 10 -

Installing the Dock Adapter

To guarantee that your iPod will fit properly into the built-in universal dock, several detachable dock adapters are included with this product. Please check

the bottom of dock adapters to determine compatibility with your iPod.

1. Inserting the dock adapter

a. Choose a dock adapter that corresponds with the iPod you would like to dock. Using the correct dock

adapter ensures a proper fit.

b. Gently push the dock adapter down into the universal dock.

c. Carefully place your iPod into the universal dock. Please note that iPod must not be in a case or “Skin”.

2. Removing the dock adapter

a. Remove your iPod, grasp the dock adapter and lift upwards carefully.

GETTING STARTED

Stereo Audio System for Your iPod V10M10_IM_EN_12072007

www.i-Luv.com- 11 -

GETTING STARTED

Location of Controls on the Main Unit

Stereo Audio System for Your iPod V10M10_IM_EN_12072007

www.i-Luv.com- 12 -

23. MUTE button: Mutes the sound; turns off the

woofer light

24. FM button: To select FM band

25. AUX Button: To select AUX IN function 26. UP button; 31. DOWN button: Up/Down iPod

navigation

27. MENU button: Menu for iPod navigation 28. ENTER button: Enter for iPod navigation

29.36. SEARCH/SKIP buttons: To set time/FM

search/Skip and search iPod functions

30. CALL/END CALL buttons: To receive, end or

reject a call

32. PRESET/PLAY/Pause button: Play or Pause on

your iPod/Preset stations on FM radio

33. POWER button: Turns the unit on/off

34. iPod button: To select iPod function 35. BluePin button: To select the BluePin receive

function

37. VOLUME +/- buttons: Increase/decrease

volume level

GETTING STARTED

Location of Controls on the Main Unit-continued

1. PRESET / PLAY / PAUSE button 2. iPod dock 3. MEMORY button

4. VOLUME +/- buttons 5. SEARCH/SKIP buttons 6. PAIRING button

7. Bluepin ON/OFF button 8. END CALL button 9. SPEAKERPHONE/CALL button

10. Headphone jack 11. MODE button 12. POWER button

13. TIME button 14. MUTE/LIGHT button 15. BluePin dock

16. AUX IN jack 17. Remote control hold 18. Back-up battery compartment

19. Battery compartment 20. FM rod antenna 21. Display Panel

22. DC IN jack

Location of Controls on the Remote Control

Note: The included remote control controls all basic functions on the i399/i398 and iPod. Aim the remote control toward the IR sensor of the main unit for the

best results.

Stereo Audio System for Your iPod V10M10_IM_EN_12072007

www.i-Luv.com- 13 -

Location of Indications on the LCD Screen

GETTING STARTED

Stereo Audio System for Your iPod V10M10_IM_EN_12072007

www.i-Luv.com- 14 -

Setting the Time

1. To set the time, locate the TIME button. Press and hold the TIME button down until the display begins to flash. First setting is to set the year. Press the

SEARCH/SKIP buttons to change the year, press the TIME button once more to confirm and enter to Month setting.

2. Press the SEARCH/SKIP buttons until the desired month is displayed, press the TIME button again to confirm and enter to date setting.

3. Press the SEARCH/SKIP buttons until the desired date is displayed, press the TIME button again to confirm and enter to time system selection.

4. Press the SEARCH/SKIP buttons to select 12H or 24H time system, press the TIME button again to confirm and enter to hour setting.

5. Press the SEARCH/SKIP buttons until the desired hour is displayed, press the TIME button again to confirm and enter to minute setting. Please note

the AM, PM setting if the time system set to 12H.

6. Press the SEARCH/SKIP buttons until the desired minute is displayed, press the TIME button once more to confirm and exit time setting.

Turning the unit on / off

1. After connected to the included external DC power supply or installed 8x”D” batteries, the unit will be in standby state as default, press the POWER

button of unit or remote control to turn on the unit.

2. To turn off the unit, press the POWER button again, unit will enter to standby state with time (clock or date) display on LCD.

3. Press and hold the POWER button for three (3) seconds enter to sleep mode, at this state, nothing displays on LCD and the backlight of LCD will go

out.

Turning the woofer light on / off

1. After turn on the unit, the woofer light will be turned on at the same time as default, to turn off it, press and hold the MUTE button of unit or remote

control for three (3) seconds.

2. To turn on the woofer light, press and hold the MUTE button for three (3) seconds again.

OPERATIONAL INSTRUCTIONS

Stereo Audio System for Your iPod V10M10_IM_EN_12072007

www.i-Luv.com- 15 -

Listening to Your Favorite Radio Station

For the best FM radio clarity, fully extend the rod antenna, and rotate it for best reception.

1. Press the POWER button to turn the unit on, press the MODE button on the i399/i398 or the FM button on the Remote Control. The radio frequency will

appear on the display.

2. To tune in to a desired station, press the SEARCH/SKIP buttons on the i399/i398 or Remote Control.

3. To scan the next clear station, press and hold the SEARCH/SKIP buttons on i399/i398 or the Remote Control for 1 second. Press again to enter the

seek mode.

4. To adjust the volume, rotate the VOLUME +/- buttons on the i399/i398 or remote control. To power OFF, press the POWER button (or the POWER

button on the Remote Control).

Programming Preset Stations

1. Set to FM radio by using MODE button of i399/i398 or FM button of remote control.

2. Tune to the desired station using SEARCH/SKIP buttons on the i399/i398 unit or remote control.

3. Press and hold MEMORY button to start programming. You will notice flashing preset number on the LCD.

4. Press the PRESET/PLAY/PAUSE button to select the preset station number.

5. Press MEMORY button again to save and store the station.

6. Repeat above 2-5 steps to store other presets into the memory, total 20 preset stations can be stored.

Listening to the preset stations

1. Set to FM radio using MODE button of i399/i398 unit or the FM button of remote control.

2. Press the PRESET/PLAY/PAUSE button to select the desired preset stations, you can press and hold the PRESET/PLAY/PAUSE button for quick

searching.

OPERATIONAL INSTRUCTIONS

Stereo Audio System for Your iPod V10M10_IM_EN_12072007

www.i-Luv.com- 16 -

Listening to Your Favorite Songs on Your iPod

1. To listen to music, make sure that your iPod is in play mode. NOTE: If i399/i398 fails to automatically play or you do not hear any sound coming from

the unit, make sure your iPod is securely docked in the Built-In Universal dock and press the PLAY/PAUSE button on the i399 or on the Remote

Control twice for music play to begin.

2. To play music when your iPod is already in the dock and in the standby mode, press the PLAY/PAUSE button on the i399/i398 or the PLAY/PAUSE

button on the Remote Control.

3. To pause music, press the PLAY/PAUSE button during the play mode. To resume playback, press it again.

4. To adjust the volume, either press the VOLUME +/- buttons on the i399/i398 or remote control.

5. To go to the Next or Previous track, use the SEARCH/SKIP buttons on the i399/i398 or remote control. To search the current track using high speed

forward or rewind, press and hold SEARCH/SKIP buttons while track is playing.

6. You can use the MENU, UP, DOWN and ENTER buttons of remote control to operate iPod as iPod own operation guide.

7. To power the unit off, press the POWER button on the i399/i398 or on the remote. Your iPod will continue to charge when left on the universal dock.

8. This unit may not operate while in the pause mode. Press the PLAY/PAUSE button on the i399/i398 or on your iPod to initiate the play mode.

OPERATIONAL INSTRUCTIONS

Stereo Audio System for Your iPod V10M10_IM_EN_12072007

www.i-Luv.com- 17 -

Listening to Other Audio Devices using line-in port

You can still listen to the first, second and third generations of iPod, or any other audio players other then iPod, with the i399/i398 by simply using the AUX-

IN port, located on the top of the i399/i398.

1. Insert the plug of the 3.5mm to 3.5mm audio patch cord (Not Included) into the HEADPHONE jack or LINE-OUT jack on your audio device, and then

insert the other end of the patch cord into the AUX-IN jack, located on the top of the i399/i398.

2. For AUX mode, press the MODE button on the i399, or the AUX on the Remote Control, until the AUX icon appears on the i399/i398s display.

3. It is now safe to turn ON your device and enjoy the music.

4. Use the VOLUME +/- buttons on the i399/i398 or Remote Control to adjust the decibel level. You may also need to adjust the audio device volume.

Charging Your iPod

Your iPod will always be in charge mode when left in the built-in Universal Dock until the unit is fully charged. Your iPod will also be in charge mode when

not in use if your iPod is left in the Built-in Universal Dock. Your iPod will not charge when the unit is NOT docked in the Built-in Universal Dock.

Note: Older generation (includes 3G) iPods are not supported, only newer 30pin connectors are supported by i399’s Universal Dock. Please see

compatibility list for i399/i398.

OPERATIONAL INSTRUCTIONS

Aux-In

Stereo Audio System for Your iPod V10M10_IM_EN_12072007

www.i-Luv.com- 18 -

BluePinTM Setup and operating Instructions

Overview:

*Status Indicator mode

•No light: Not in operation and power off

•Blue Light slow flashing: Normal standby mode

•Blue Light fast flashing: Search Mode

•Blue & Red Light Flashing: Pairing Mode

•Solid Blue Light: Paired with a device

*BluePinTM Device Password: “0000”

*SEND: Transmitting sound to other devices such as Stereo Headset with Bluetooth technology with Bluetooth stereo Profile (A2DP)

*RCV: Receiving sound from other media players such as MP3 Cell Phones with Bluetooth Stereo Profile (A2DP) or Other Media Players with Bluetooth

Stereo Profile (A2DP). Also it can receive the phone call from a cell phone with Bluetooth hands-free profile (HSP and HFP).

NOTE: Certain devices with Bluetooth technology might not be compatible with the BluePinTM, please check with your dealer for compatibility. The best

product for this operation is iLUV Stereo Headsets with Bluetooth technology which are fully compatible with the BluePinTM.

1. Plug the BluePinTM unit securely into the i399/i398’s BluePinTM port with

below status on BluePinTM indicator :

SEND: Blue indicator will slow flashing ( standby mode ) or RCV : Blue

indicator will fast flashing ( search mode )

Note: Illustrations on these pages depict the first version of the BluePin. This unit,

however, supports BluePin 2 (i120). This does not effect the operational

instructions listed here.

OPERATIONAL INSTRUCTIONS

Pairing Button

Status Indicator

TX/RX Switch

Stereo Audio System for Your iPod V10M10_IM_EN_12072007

www.i-Luv.com- 19 -

BluePinTM Setup and operating Instructions-continued

2. Notice that when the BluePinTM is connected, main display will show Bluetooth logo and the current status of the SEND/RCV mode. Example

shows the BluePinTM is set to Transmit(SEND).

3. Once the BluePin is securely plugged in to the i399/i398, press the BluePin on/off button on the i399/i398 and press the SEND/RCV button on the

right side of BluePin to select the working mode (Transmit or Receive).

4. Long press the PAIRING button of BluePin or i399/i398 unit for 3 seconds to start pairing with other devices. You will notice that blue and red light
