JVC UX-J60 User manual

SERVICE MANUAL
COPYRIGHT © 2003 VICTOR COMPANY OF JAPAN, LTD. No.22029
2003/03
UX-J60
MICRO COMPONENT SYSTEM
22029200303
UX-J60
TABLE OF CONTENTS
1 Important Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
2 Disassembly method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
3 Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-19
4 Description of major ICs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-25
Area Suffix
B -------------------------- U.K.
E ------- Continental Europe
EN --------- Northern Europe
SP-UXJ60CA-UXJ60
RM-SUXJ60R REMOTE CONTROL
SP-UXJ60

UX-J60
1-2 (No.22029)
SECTION 1
Important Safety Precautions
1.1 Safety Precautions
(1) This design of this product contains special hardware and
many circuits and components specially for safety purposes.
For continued protection, no changes should be made to the
original design unless authorized in writing by the man-
ufacturer. Replacement parts must be identical to those
used in the original circuits. Services should be per-
formed by qualified personnel only.
(2) Alterations of the design or circuitry of the product should
not be made. Any design alterations of the product should
not be made. Any design alterations or additions will void
the manufacturers warranty and will further relieve the
manufacture of responsibility for personal injury or property
damage resulting therefrom.
(3) Many electrical and mechanical parts in the products have
special safety-related characteristics. These characteris-
tics are often not evident from visual inspection nor can the
protection afforded by them necessarily be obtained by us-
ing replacement components rated for higher voltage, watt-
age, etc. Replacement parts which have these special safety
characteristics are identified in the Parts List of Service Manu-
al. Electrical components having such features are iden-
tified by shading on the schematics and by ( ) on the
Parts List in the Service Manual. The use of a substitute re-
placement which does not have the same safety character-
istics as the recommended replacement parts shown in the
Parts List of Service Manual may create shock, fire, or oth-
er hazards.
(4) The leads in the products are routed and dressed with ties,
clamps, tubings, barriers and the like to be separated from
live parts, high temperature parts, moving parts and/or
sharp edges for the prevention of electric shock and fire
hazard. When service is required, the original lead routing
and dress should be observed, and it should be confirmed
that they have been returned to normal, after reassembling.
(5) Leakage shock hazard testing)
After reassembling the product, always perform an isolation
check on the exposed metal parts of the product (antenna
terminals, knobs, metal cabinet, screw heads, headphone
jack, control shafts, etc.) to be sure the product is safe to
operate without danger of electrical shock.
Do not use a line isolation transformer during this check.
• Plug the AC line cord directly into the AC outlet. Using a
"Leakage Current Tester", measure the leakage current
from each exposed metal parts of the cabinet, particular-
ly any exposed metal part having a return path to the
chassis, to a known good earth ground. Any leakage cur-
rent must not exceed 0.5mA AC (r.m.s.).
• Alternate check method
Plug the AC line cord directly into the AC outlet. Use an AC
voltmeter having, 1,000 ohms per volt or more sensitivity in
the following manner. Connect a 1,500 ohm 10W resistor
paralleled by a 0.15 µF AC-type capacitor between an
exposed metal part and a known good earth ground.
Measure the AC voltage across the resistor with the AC
voltmeter.
Move the resistor connection to each exposed metal part,
particularly any exposed metal part having a return path to
the chassis, and measure the AC voltage across the resistor.
Now, reverse the plug in the AC outlet and repeat each
measurement. Voltage measured any must not exceed 0.75
V AC (r.m.s.). This corresponds to 0.5 mA AC (r.m.s.).
1.2 Warning
(1) This equipment has been designed and manufactured to
meet international safety standards.
(2) It is the legal responsibility of the repairer to ensure that
these safety standards are maintained.
(3) Repairs must be made in accordance with the relevant
safety standards.
(4) It is essential that safety critical components are replaced
by approved parts.
(5) If mains voltage selector is provided, check setting for local
voltage.
1.3 Caution
Burrs formed during molding may be left over on some parts
of the chassis.
Therefore, pay attention to such burrs in the case of pre-
forming repair of this system.
1.4 Critical parts for safety
In regard with component parts appearing on the silk-screen
printed side (parts side) of the PWB diagrams, the parts that are
printed over with black such as the resistor ( ), diode ( )
and ICP ( ) or identified by the " " mark nearby are critical
for safety.
When replacing them, be sure to use the parts of the same type
and rating as specified by the manufacturer. (Except the JC version)

UX-J60
(No.22029)1-3
1.5 Safety Precautions (U.K only)
(1) This design of this product contains special hardware and many circuits and components specially for safety purposes. For con-
tinued protection, no changes should be made to the original design unless authorized in writing by the manufacturer. Replace-
ment parts must be identical to those used in the original circuits.
(2) Any unauthorised design alterations or additions will void the manufacturer's guarantee; furthermore the manufacturer cannot
accept responsibility for personal injury or property damage resulting therefrom.
(3) Essential safety critical components are identified by ( ) on the Parts List and by shading on the schematics, and must never
be replaced by parts other than those listed in the manual. Please note however that many electrical and mechanical parts in
the product have special safety related characteristics. These characteristics are often not evident from visual inspection. Parts
other than specified by the manufacturer may not have the same safety characteristics as the recommended replacement parts
shown in the Parts List of the Service Manual and may create shock, fire, or other hazards.
(4) The leads in the products are routed and dressed with ties, clamps, tubings, barriers and the like to be separated from live parts,
high temperature parts, moving parts and/or sharp edges for the prevention of electric shock and fire hazard. When service is
required, the original lead routing and dress should be observed, and it should be confirmed that they have been returned to
normal, after re-assembling.
1.5.1 Warning
(1) Service should be performed by qualified personnel only.
(2) This equipment has been designed and manufactured to meet international safety standards.
(3) It is the legal responsibility of the repairer to ensure that these safety standards are maintained.
(4) Repairs must be made in accordance with the relevant safety standards.
(5) It is essential that safety critical components are replaced by approved parts.
(6) If mains voltage selector is provided, check setting for local voltage.
Burrs formed during molding may be left over on some parts of the chassis. Therefore,
pay attention to such burrs in the case of preforming repair of this system.

UX-J60
1-4 (No.22029)
1.6 Preventing static electricity
Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged,
can destroy the laser diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs.
1.6.1 Grounding to prevent damage by static electricity
Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as CD players.
Be careful to use proper grounding in the area where repairs are being performed.
(1) Ground the workbench
Ground the workbench by laying conductive material (such as a conductive sheet) or an iron plate over it before placing the
traverse unit (optical pickup) on it.
(2) Ground yourself
Use an anti-static wrist strap to release any static electricity built up in your body.
(3) Handling the optical pickup
• In order to maintain quality during transport and before installation, both sides of the laser diode on the replacement optical
pickup are shorted. After replacement, return the shorted parts to their original condition.
(Refer to the text.)
• Do not use a tester to check the condition of the laser diode in the optical pickup. The tester's internal power source can easily
destroy the laser diode.
1.7 Handling the traverse unit (optical pickup)
(1) Do not subject the traverse unit (optical pickup) to strong shocks, as it is a sensitive, complex unit.
(2) Cut off the shorted part of the flexible cable using nippers, etc. after replacing the optical pickup. For specific details, refer to the replace-
ment procedure in the text. Remove the anti-static pin when replacing the traverse unit. Be careful not to take too long a time
when attaching it to the connector.
(3) Handle the flexible cable carefully as it may break when subjected to strong force.
(4) I t is not possible to adjust the semi-fixed resistor that adjusts the laser power. Do not turn it.
1.8 Attention when traverse unit is decomposed
*Please refer to "Disassembly method" in the text for the CD pickup unit.
• Apply solder to the short land sections before the flexible wire is disconnected from the connector CN101 on the CD servo board.
(If the flexible wire is disconnected without applying solder, the CD pickup may be destroyed by static electricity.)
• In the assembly, be sure to remove solder from the short land sections after connecting the flexible wire.
CN601 on
mechanism
board
Shorting round
Shorting round
Flexible wire

UX-J60
(No.22029)1-5
1.9 Important for laser products
(1) CLASS 1 LASER PRODUCT
(2) DANGER : Invisible laser radiation when open and inter
lock failed or defeated. Avoid direct exposure to beam.
(3) CAUTION : There are no serviceable parts inside the
Laser Unit. Do not disassemble the Laser Unit. Replace the
complete Laser Unit if it malfunctions.
(4) CAUTION : The compact disc player uses invisible laser
radiation and is equipped with safety switches which
prevent emission of radiation when the drawer is open and
the safety interlocks have failed or are de feated.
It is dangerous to defeat the safety switches.
(5) CAUTION : If safety switches malfunction, the laser is able
to function.
(6) CAUTION : Use of controls, adjustments or performance of
procedures other than those specified herein may result in
hazardous radiation exposure.
CAUTION
Please use enough caution not to see the beam directly
or touch it in case of anadjustment or operation check.
VARNING
Osynlig laserstrålning är denna del är öppnad och spårren är
urkopplad. Betrakta ej strålen.
VARO
Avattaessa ja suojalukitus ohitettaessa olet alttiina näkymät-
tömälle lasersäteilylle. Älä katso säteeseen.
ADVARSEL
Usynlig laserstråling ved åbning, når sikkerhedsafbrydere er
ude af funktion. Undgå udsasttelse for stråling.
ADVARSEL
Usynlig laserstråling ved åpning, når sikkerhetsbryteren er avs-
lott. unngå utsettelse for stråling.
REPRODUCTION AND POSITION OF LABELS
Caution label

UX-J60
1-6 (No.22029)
SECTION 2
Disassembly method
2.1 Main body
2.1.1 Removing the metal cover
(See Fig.1~3)
(1) Remove the six screws Aon the back of the main body.
(2) Remove the two screws Bon each side and remove the
metal cover in the direction of the arrow.
Fig.1
Fig.2
Fig.3
Metal cove
r
A
A
A
B
B

UX-J60
(No.22029)1-7
2.1.2 Removing the rear cover
(See Fig.4)
(1) Remove the two screws Cattaching the rear cover.
Fig.4
2.1.3 Removing the rear panel / fan assembly
(See Fig.5, 6)
• Prior to performing the following procedure, remove the metal
cover and the rear cover.
(1) Remove the eleven screws Dattaching the rear panel. Re-
lease the two joints aon the rear side and the two joints
bon each side.
(2) Remove the two screws Eattaching the fan bracket and
release the two joints con the rear panel, and remove.
(3) Disconnect the wire from the connector CN916 on the main
board.
Fig.5
Fig.6
C
Rear cove
r
Rear panel
Fan assembly
DD
D
D
D
EE
cc
a
bb
Main board
CN916

UX-J60
1-8 (No.22029)
2.1.4 Removing the tuner board
(See Fig.7)
• Prior to performing the following procedure, remove the metal
cover.
(1) Disconnect the card wire from the connector CN1 on the
tuner board.
(2) Remove the two screws Fon the rear side and the screw
Gin the side.
Fig.7
2.1.5 Removing the CD-R/RW mechanism assembly
(See Fig.8)
• Prior to performing the following procedure, remove the metal
cover, the rear cover, the rear panel and the tuner board.
(1) Disconnect the card wire from the connector CN903,
CN902 and CN904 on the main board.
(2) Pull the joint din the direction of the arrow and remove the
CD-R/RW mechanism assembly backward while releasing
the joint e.
Fig.8
Tuner board
CN1
F
G
CN902
CN904
CN903
CD-R/RW mechanism assembly
Main board
d
d
e

UX-J60
(No.22029)1-9
2.1.6 Removing the main board / the heat sink board / the
speaker jack board
(See Fig.9~12)
• Prior to performing the following procedure, remove the metal
cover, the rear cover, the rear panel, the tuner board and the
CD-R/RW mechanism assembly.
(1) Remove the two screws Hattaching the main board.
(2) Disconnect the card wire from the connector CN900,
CN901, CN930, CN931 and CN932, and disconnect the
flat wire from the connector CN913, CN917 and CN918 on
the main board.
(3) Remove the band and disconnect the flat wire from the
connector CN951 on the power transformer assembly, and
then remove the main board / the heat sink board / the
speaker jack board from the body.
(4) Release the two joints fof the main board and disconnect
the connector CN944 and CN945 of the heat sink board
from the connector CN912 and CN911 of the main board
respectively, and disconnect the flat wire from the connec-
tor CN914 and CN915, and remove.
(5) Remove the screw Iattaching the speaker jack board and
disconnect the flat wire from the connector CN946 and
CN947 on the heat sink board, and then remove the speak-
er jack board.
Fig.9
Fig.10
Fig.11
Fig.12
H
f
Power transformer assembly
CN951
CN930
CN917
CN900
CN901
CN918
CN931
CN913
CN932
Band
Main board
CN944
CN945
CN912
CN911
CN915 CN914
I
CN946 CN947
Speaker jack board
Heat sink board
Main board
Speaker jack board

UX-J60
1-10 (No.22029)
2.1.7 Removing the power transformer assembly
(See Fig.13)
• Prior to performing the following procedure, remove the metal
cover, the rear cover, the rear panel, the CD-R/RW mecha-
nism assembly and the main board.
(1) Disconnect the power cord from the connector J1000 on
the power transformer assembly.
(2) Remove the four screws J.
Fig.13
2.1.8 Removing the front panel assembly
(See Fig.14,15)
• Prior to performing the following procedure, remove the metal
cover.
(1) Remove the two screws Kon each side. Release the two
joints gon the both sides and lift the front panel assembly
to release the joint h.
(2) Disconnect the card wire from the connector CN900,
CN901, CN930, CN931 and CN932 on the main board.
Fig.14
Fig.15
Powe transformer assembly
J1000
JJ
K
g
Front panel assembly
K
g
h
Front panel assembly
CN932CN931 CN930
CN900 CN901
Main board

UX-J60
(No.22029)1-11
2.1.9 Removing the phones board
(See Fig.16)
• Prior to performing procedure, remove the metal cover and the
front panel assembly.
(1) Disconnect the flat wire from the connector CN913 on the
main board.
Fig.16
2.1.10 Removing the cassette mechanism assembly
(See Fig.17)
• Prior to performing the following procedure, remove the metal
cover and the front panel assembly.
(1) Remove the four screws Lattaching the cassette mecha-
nism assembly.
Fig.17
Phones board
Mian board
CN913
L
L
Cassette mechanism assembly

UX-J60
1-12 (No.22029)
2.1.11 Removing the switch board
(See Fig.18,19)
• Prior to performing the following procedure, remove the metal
cover and the front panel assembly.
(1) Remove the four screws Mattaching the switch board.
(2) Move the switch board in the direction of the arrow to dis-
connect the wire from the connector CN762 and the card
wire from the connector CN761.
2.1.12 Remove the LCD board assembly
(See Fig.18)
• Prior to performing the following procedure, remove the metal
cover and the front panel assembly.
(1) Remove the four screws Nattaching the LCD board as-
sembly.
Fig.18
Fig.19
M
NN
M
Switch board
LCD board assembly
Switch board
CN762 CN761

UX-J60
(No.22029)1-13
2.1.13 Removing the control panel assembly
(See Fig.20,21)
• Prior to performing the following procedure, remove the metal
cover, the front assembly, the switch board and the LCD board
assembly.
(1) Remove the three screws Oattaching the control panel as-
sembly.
(2) Release the three joints iand open the cassette door
while pressing the cassette door, and then remove the con-
trol panel assembly in the direction of the arrow.
Fig.20
Fig.21
O
O
Cotrol panel assembly
i

UX-J60
1-14 (No.22029)
2.1.14 Remiving the control board
(See Fig.22,23)
• Prior to performing the following procedure, remove the metal
cover, the front panel assembly, the switch board, the LCD
board assembly and the control panel assembly.
(1) Pull out the volume knob.
(2) Remove the seven screws Pattaching the control board.
Fig.22
Fig.23
Control panel assembly
Volume knob
P
P
P
Control board
Control panel assembly

UX-J60
(No.22029)1-15
2.2 Cassette mechanism assembly
2.2.1 Removing the Play/Record & Clear head
(See Fig.1~3)
(1) While moving the trigger arm on the right side of the head
mount in the direction of the arrow, turn the flywheel R
counterclockwise until the head mount comes ahead and
clicks.
(2) The head turns counterclockwise as you turn the flywheel
R counterclockwise (See Fig.2 and 3).
(3) Disconnect the flexible wire from connector CN31 on the
head amplifier & mechanism control board.
(4) Remove the spring from the back of the head.
(5) Loosen the azimuth screw for reversing attaching the head.
(6) Remove the head on the front side of the head mount.
Fig.1
Fig.2
Fig.3
Cassette mechanism assembly Fly wheelR
Trigger armHead mount
Head
Fly wheel R
Azimuth screw
for reversing
Flexible wire
Spring
CN31
Head amplifer & mecha control board
Head

UX-J60
1-16 (No.22029)
2.2.2 Removing the head amplifier & mechanism control board
(See Fig.4)
(1) Turn over the cassette mechanism assembly and remove
the three screws Aattaching the head amplifier & mecha-
nism control board.
(2) Disconnect the flexible wire from connector CN31 on the
head amplifier & mechanism control board.
(3) Disconnect connector CN32 of the head amplifier & mech-
anism control board from connector CN1 on the reel pulse
board.REFERENCE: If necessary, unsolder the 4-pin wire
soldered to the main motor.
2.2.3 Removing the main motor
(See Fig.4~7)
(1) Remove the two screws B.
(2) Half raise the motor and remove the capstan belt from the
motor pulley.
ATTENTION:
Be careful to keep the capstan belt from grease. When reas-
sembling, refer to Fig.6 and 7 for attaching the capstan belt.
Fig.4
Fig.5
Fig.6
Fig.7
Head amplifier & mecha control board
AA
AB
CN31
CN32
4pin wire
Flexible wire
Main motor assembly
Main motor assembly
Capstan belt
Main motor assembly
Capstan belt
Motor pulley
Main motor assembly
Capstan belt
Fly wheel
Motor pulley

UX-J60
(No.22029)1-17
2.2.4 Removing the flywheel
(See Fig.8, 9)
• Prior to performing the following procedure, remove the head
amplifier & mechanism control board and the main motor as-
sembly.
(1) From the front side of the cassette mechanism, remove the
slit washers attaching the capstan shaft Land R. Pull out
the flywheels backward.
Fig.8
Fig.9
2.2.5 Removing the reel pulse board and solenoid
(See Fig.10)
• Prior to performing the following procedure, remove the head amplifier & mechanism control board.
(1) Remove the screw C.
(2) Release the tab a, b, c, dand eretaining the reel pulse board.
(3) Release the tab fand gattaching the solenoid on the reel pulse board.
(4) The reel pulse board and the solenoid come off.
Fig.10
Fly wheel R Fly wheel L
Capstan shaft R Capstan shaft L
Fly wheel R
Slit washer
Fly wheel L
a
fg
bc d
e
C
Reel pulse board
Solenoid

UX-J60
1-18 (No.22029)
2.2.6 Reattaching the Play/ Record & Clear head
(See Fig.11~13)
(1) Reattaching the head mount assembly.
a) Change front of the direction cover of the head
mount assembly to the left (Turn the head forward).
b) Fit the bosses O', P', Q', U' and V' on the head mount
assembly to the holes Pand V, the slots O, Uand Q
of the mechanism sub assembly (See Fig.11 to 13).
CAUTION:
To remove the head mount assembly, turn the direction
cover to the left to disengage the gear. If the gear can not
be disengaged easily, push up the boss Q' slightly and
raise the rear side of the head mounts slightly to return
the direction lever to the reversing side.
(2) Tighten the azimuth screw for reversing.
(3) Reattach the spring from the back of the Play/ Record &
Clear head.
(4) Connect the flexible wire to connector CN31 on the head
amplifier & mechanism control board. Fig.11
Fig.12
Fig.13
P'
V'
O'
P'
V'
U' Q' Direction cove
r
Head mount assembly
Direction cove
r
Head mount assembly
O
U
V
PQ
Azimuth screw for reversing
Head mount
Spring
Flexible wire
Head amplifier &
mechanism control board
CN31
Head

UX-J60
(No.22029)1-19
SECTION 3
Adjustment
3.1 Adjustment method
Tuner section
FM tuning range: 87.5MHz~108.00MHz
AM tuning range: 522kHz~1,629kHz
Voltage applied to tuner +B : DC5.7
V
VT : DC 12
V
Reference measurement
output 26.1mV(0.28V)/3
Input positions AM : Standard loop antenn
a
FM :TP1 (hot) and TP2 (GND
)
Standard measurement position of volume
Function switch to Tap
e
Beat cut switch to Cu
t
Super Bass/Active hyper Bass to OF
F
Bass Treble to Cente
r
Adjustment of main volume to reference output
VOL : 2
8
Precautions for measurement
1. Apply 30pF and 33k to the IF sweeper output
side and 0.082 F and 100k in series to the
sweeper input side.
2.The IF sweeper output level should be made as
low as possible within the adjustable range.
3. Since the IF sweeper is a fixed device, there is no
need to adjust this sweeper.
4. Since a ceramic oscillator is used, there is no need
to perform any MIX adjustment.
5. Since a fixed coil is used, there is no need to adjus
t
the FM tracking.
6.The input and output earth systems are separated.
In case of simultaneously measuring the voltage in
both of the input and output systems with an
electronic voltmeter for two channels, therefore, the
earth should be connected particularly carefully.
7. In the case of BTL connection amp., the minus
terminal of speaker is not for earthing.Therefore, b
e
sure not to connect any other earth terminal to this
terminal.This system is of an BTL system.
8. For connecting a dummy resistor when measuring
the output, use the wire with a greater code size.
9.Whenever any mixed tape is used, use the band
pass filter (DV-12).
Measurement conditions
Power supply voltage
AC 230V ~ , 50Hz
Reference output : Speaker : 0.775V/4
: Headphone : 0.077V/32
Reference frequency and
input level ------------------------------ 1kHz, AUX : -8dBs
Measurement output terminal ------- at Speaker J3002
Load resistance --------------------------- 4
Radio Input signal
AM frequency --------------------------------------- 400Hz
AM modulation ---------------------------------------- 30%
FM frequency --------------------------------------- 400Hz
FM frequency deviation ------------------------ 22.5kHz
Measurement Instruments Required for
Adjustment
1. Low frequency oscillator
This oscillator should have a capacity to output
0dBs to 600 at an oscillation frequency of
50Hz-20kHz.
2. Attenuator impedance : 600
3. Electronic voltmeter
4. Distortion meter
5. Frequency counter
6.Wow & flutter meter
7.Test tape
VT703L :Head azimuth
VT712 :Tape speed and running unevenness
(3kHz)
VT724 :Reference level (1kHz)
8. Blank tape
TYPE : AC-225
TYPE : AC-514
9.Torque gauge : For play and back tension
FWD(TW2111A), REV(TW2121a) and
FF/REW(TW2231A)
10.Test disc: CTS-1000

UX-J60
1-20 (No.22029)
3.2 Cassette mechanism adjustment
Motor speed
VR37
BIAS adjust
VR31
Mecha control board
Head azinuth
adjustment screw
(Forward side)
Head azinuth
adjustment screw
(Reverse side)
Head azinuth
adjustment screw
(Forward side)
Head azinuth
adjustment screw
(Reverse side)
R/P head, Erase head
CN31
D1
FW100
R371
VR37
P1
SW1
SW6
CN1
SW2
SW5
IC1
C201
C102
C103
C105
C106
C107
C209
C110
C113
C121
C101
C202
C203
C205
C206
C207
C109
C210
C213
C221
C300
C301
C304
C306
C307
C308
C310
C313
C314
C316
C319
C331
C340
C341
C342
C371
C374
C376
CN31
CN33
CN34
D340
D375
IC32
IC33
L301
L303
Q302
Q305
Q342
Q343
Q344
Q345
Q346
Q371
Q372
Q375
Q376
R101
R102
R104
R105
R106
R107
R108
R110
R116
R121
R201
R202
R204
R205
R206
R207
R208
R210
R216
R221
R301
R302
R303
R304
R305
R306
R310
R313
R314
R315
R327
R335
R336
R337
R338
R339
R340
R341
R342
R343
R344
R345
R346
R353
R372
R375
R376
VR31
CN32
C204
C104 R109
Q347
R347
W1
W1
