Image Access WideTEK 36CL Manual

WideTEK® 36CL/48CL/60CL
Setup Instructions
English
07/2021

Table of Contents
Revision overview.....................................................................................4
Notes on the instructions and the manufacturer ......................................5
Keep instructions available......................................................................5
Design features in the text ......................................................................6
Design features in illustrations ................................................................7
Associated documents.............................................................................7
Copyright .................................................................................................8
Contact details of the manufacturer in Germany....................................8
Technical support ....................................................................................8
Contact details of the manufacturer in the USA......................................8
Device safety ............................................................................................9
Intended use............................................................................................9
Basic safety instructions ........................................................................10
Responsibility of the operator ...............................................................11
Personnel qualification ..........................................................................11
Design features of warnings ..................................................................12
Design features of notices of damage to property................................12
Description .............................................................................................13
Task and function...................................................................................13
Overview WideTEK® 36CL/48CL/60CL ...................................................14
Overview back side................................................................................15
Overview screen page for the setup menu ...........................................16
Rating plate............................................................................................17
Serial number ........................................................................................18
User interfaces.......................................................................................19
Installation site .......................................................................................20
Environmental conditions......................................................................20

Prepare setup..........................................................................................21
Connecting the power adapter ............................................................. 21
Establish network connection ............................................................... 22
Place the scanner on the optional base ................................................ 22
Connecting the optional monitor .......................................................... 23
Connect optional touch screen ............................................................. 24
Switch on scanner ................................................................................. 25
Switch off scanner ................................................................................. 27
Perform setup .........................................................................................29
Setup Wizard ......................................................................................... 29
Activate setup menu ............................................................................. 31
Height Adjustment - Changing the Height Adjustment (WT60CL) ........ 34
System Restore .......................................................................................36
Solid State Disk Software Error.............................................................. 36
Recovery points..................................................................................... 36
System Restore to Factory Defaults ...................................................... 37
System recovery of user settings........................................................... 38
Cleaning ..................................................................................................39
Technical Specifications ..........................................................................40
Scanner specification............................................................................. 40
Environmental conditions ..................................................................... 42
Electrical Specifications ......................................................................... 43
Document specification......................................................................... 43
Dimensions and weight WideTEK® 36CL-600........................................ 44
Dimensions and weight WideTEK® 48CL-600........................................ 44
Dimensions and weight WideTEK® 60CL-600........................................ 45

Revision overview
4
Revision overview
Date
Rev.
Name
Description of
change
Reason for change
15.07.2021
1.0
JKN
First draft
First published version

Notes on the instructions and the manufacturer
5
Notes on the instructions and the
manufacturer
This manual will help you to safely prepare and perform the setup for the
WideTEK® 36CL/48CL/60CL large format scanners. The WideTEK®
36CL/48CL/60CL large format scanners are hereinafter referred to as the
"scanners".
The start button is referred to as the "power button" in this manual.
Keep instructions available
This manual is part of the scanner.
➢Always keep this manual with the scanner.
➢Make sure the manual is available to the user.
➢Include this manual when selling or otherwise transferring the scanner.

Notes on the instructions and the manufacturer
6
Design features in the text
Various elements of this guide have specified design features. This allows
you to easily distinguish the following elements:
normal text
BUTTONS OF THE SCREEN
"menu labels"
➢Action steps
•first level enumeration
Cross-references
Tips contain additional information, such as specific details on how to
prepare and perform the setup.

Notes on the instructions and the manufacturer
7
Design features in illustrations
When elements are referred to in a legend or in the running text, they are
given a number (1).
Associated documents
Accompanying documents include:
•Unpacking and packing instructions
•Legal information (EC declaration of conformity, safety and EMC
certificates, RoHS etc.).

Notes on the instructions and the manufacturer
8
Copyright
This manual contains information that is subject to copyright. This manual
may not be copied, printed, filmed, processed, reproduced or distributed
in any form, in whole or in part, without the prior written permission of
Image Access GmbH.
© Image Access GmbH 2021
All rights reserved.
Trademark
Scan2Net®, Scan2Pad®, Bookeye® and WideTEK® are registered
trademarks of Image Access, all other trademarks belong to their
respective owners.
Contact details of the manufacturer in Germany
Image Access GmbH
Hatzfelderstraße 161-163
42281 Wuppertal
Tel.: [phone]
E-Mail: [e-mail]
Internet address: www.imageaccess.de
Technical support
You can reach Image Access GmbH technical support at the following e-
mail address: su[email protected]e.
Contact details of the manufacturer in the USA
Image Access LP
2511 Technology Drive, Suite 109
Elgin, IL 60124
Tel: [phone]
Email: [e-mail]
Web address: www.imageaccess.us

Device safety
9
Device safety
Intended use
The scanner is used for scanning all kinds of images and documents. The
documents must comply with the characteristics according to the technical
specifications. The scanner is intended for use in closed rooms in the
commercial sector.
Intended use also includes reading and understanding this manual and
observing and following all instructions in this manual, especially the safety
instructions. Any other use is expressly considered improper and will void
any warranty and liability claims.
Environmental conditions
Make sure that the scanner is used only under the following environmental
conditions:
•Ambient temperature during operation: 5 °C to 40 °C (41 °F - 104 °F)
•Storage temperature: 0 °C to 60 °C (32 °F to 140 °F)
•Relative humidity: 20 to 80 %, non-condensing
➢Ensure that the scanner is not exposed to direct sunlight.

Device safety
10
Basic safety instructions
Avoid injury or death from electric shock
➢Never open the scanner case.
➢Do not expose the scanner to dripping or splashing water, and do not
place containers filled with liquid on the scanner. Liquid ingress may
damage the scanner.
➢Do not insert any objects into the scanner through any slots or
openings.
➢Only connect the scanner to a properly installed and grounded power
outlet using the supplied power adapter.
➢Do not use the power adapter if the housing or the cable of the power
adapter is damaged. In this case, replace the power adapter with a one
of the same type.
➢Do not use the scanner if it is visibly damaged. In this case, unplug the
power cord from the wall outlet. Contact Image Access technical
support, see the Technical Support section beginning on page 8.
Avoid burns
➢Do not cover the existing openings in the scanner housing. They are
used for ventilation. Otherwise, the scanner could overheat.
➢Do not place the scanner in front of air conditioners that emit intense
heat.
Avoid broken bones, bruises and contusions
Incorrect routing of the cables can cause tripping.
➢Route the connecting cables so that no one can trip over them.
The scanner weighs between 19 kg (42 lbs.) and 35 kg (77 lbs.).
➢Handle the scanner only with the help of a second person.
➢Place the scanner only on a firm, level, vibration-free surface that is
strong enough to support the weight of the scanner.
Avoid material damage or malfunctions
➢Ensure good room ventilation to maintain ambient conditions.
➢Do not place the scanner near equipment that emits strong
electromagnetic radiation.
➢Always place the scanner on a suitable, stable table or on the optionally
available base.

Device safety
11
➢Do not lean on the scanner.
➢Make sure that the thickness of the original to be scanned does not
exceed 3 mm.
➢Do not use cleaning agents containing abrasive additives, solvents or
acids. Use a damp microfiber cloth.
➢Only operate the touchscreen with your finger or a suitable, conductive
pen with a rubber tip. Other objects can damage the touchscreen.
Responsibility of the operator
The scanner operator must ensure that only qualified personnel perform
the scanner setup.
Personnel qualification
Personnel performing setup of the scanner must be knowledgeable in
setting up, connecting, and operating computer accessories.

Device safety
12
Design features of warnings
This manual contains the following warnings:
WARNING
Notes with the word WARNING warn of a dangerous
situation that can possibly lead to death or serious injury.
CAUTION
Notes with the word CAUTION warn of a situation that may
result in minor or moderate injury.
The following symbols are used in the warnings:
Symbol
Explanation
Danger due to electric shock
General danger symbol
Design features of notices of damage to property
CAUTION!
Notes with the word CAUTION warn of a situation that will
result in property damage.

Description
13
Description
Task and function
The scanner is used for scanning all kinds of images and documents. The
characteristics of the documents such as size, weight must comply with the
specifications found in the technical data. The scanner is intended for use
in closed rooms in the commercial sector.
Intended use also includes observing and following all information in this
manual, especially the safety instructions. Any other use is considered
improper and will void the warranty and liability claims.

Description
14
Overview WideTEK® 36CL/48CL/60CL
No.
Designation
1
Document transport
2
Touchscreen
3
USB connection socket
4
Power button
5
Transport aids
6
Stop button
7
Height adjustment screws (for example WideTEK 60CL)

Description
15
Overview back side
No.
Designation
1
USB connection socket
2
HDMI connection socket
3
Network connection socket
4
Main switch
5
Connection socket 19 V DC for external power adapter

Description
16
Overview screen page for the setup menu
No.
Designation
1
Buttons and parameters
2
Display of the menu designation
3
Display of online help 1
4
Button for exiting the setup menu to the "Select Application"
screen
5
Display of the serial number
6
Display of IP address
7
Display of firmware version
8
Button to drive the document forward in the scanner
9
Button to drive the document backward in the scanner (rewind)
1Online Help display is only available when a second touch screen is
connected to the scanner.

Description
17
Rating plate
The rating plate is located on the back of the scanner.
The following figure shows the nameplate of the model
WideTEK® 36CL-600.
The following figure shows the nameplate of the model
WideTEK® 48CL-600.

Description
18
The following figure shows the nameplate of the model
WideTEK® 60CL-600.
Serial number
The serial number of the scanner is located on the back of the device.
Keep the serial number handy when calling for support.

Description
19
User interfaces
The scanner can be operated in five ways.
•Via the touch screen and the ScanWizard Touch user interface.
•Via EasyScan or a client application.
•Via a standard web browser and the ScanWizard Client interface.
•Via the optional Scan2Pad® Hotspot.
•Via external scanning applications.

Installation site
20
Installation site
Environmental conditions
When operating the scanner, make sure that the room is well ventilated to
ensure the proper operating conditions.
The installation site must be chosen so that
•The side distance between scanner and wall is at least 100 mm,
•The distance between the back of the scanner and the wall is at least 50
mm,
•The distance to a door or room entrance is at least one meter.
Place the scanner on a level and stable base. The load-bearing capacity of
the base must be suitable for the weight of the scanner (maximum 50 kg,
110 lbs.). The dimensions of the base must be suitable for the footprint of
the scanner.
After changing from a cold to a warm environment, allow at least one
hour for the scanner to adjust to the ambient temperature before
turning it on.
When the scanner changes from a cold to a warm environment,
condensation moisture may form inside the housing.
This disappears when the housing temperature has adjusted to the
ambient temperature. Condensation moisture can lead to poor scanning
results or even damage the scanner.
