Imagilights TEBUR TABLE LIGHTING COLLECTION User manual

USER MANUAL 12 LED
TEBUR TABLE LIGHTING COLLECTION
USED IN THE FOLLOWING MODELS:

THANK YOU FOR HAVING SELECTED AN IMAGILIGHTS® LAMP.
Carefully read this guide before using your lamp. Always use your lamp in conformity with the utilization precautions.
Failure to do so will void any warranty. IMAGILIGHTS® disclaims any responsibility for incorrect use of the product
or charger in combination with another product which could be defective, dangerous or inappropriate.
FIRST USAGE PRECAUTIONS
To guarantee the maximum autonomy of your product, please conform to the first usage precautions:
1) Connect the charger
2) Fully charge your lamp’s battery by placing the lamp on the charger for at least 5 hours. While the lamp is charging the light
indicator on the charger will appear red. A green luminous indicator indicates the lamp is fully charged.
It is recommended to empty (discharge) the full capacity of the battery before recharging fully. The internal battery has a charge
accumulator and will require 5 or 6 complete charges/discharges before reaching optimal charge capacity.
Your lamp automatically turns off when placed on its charger plate. This to protect the long life of the battery and to assure that
charging and discharging is not done simultaneously.
TECHNICAL INFORMATION
Number of Leds
Led lifetime
Battery type
Battery power
Energy consumption
Remote
12
+50.000 hours
3.7 V Li-Polymer - 1200 mAh
1200 mAh
2.04 Watt
Infrared
MATERIAL
Plastic: PE
DC 7.5 V
Light automatically turns
IP68
DC 7.5 V
The flexible external cable of this charger cannot be replaced. In case of damage the charger should be discarded.

YOUR LAMP
COLOR UP: Choose between one of our 24 pre-programmed colors.
COLOR DOWN: Choose between one of our 24 pre-programmed colors.
Start the 160.000 color mix mode 1 which will take approximately 14 minutes (= ultra slow), and will continue without
interruption.To fix a color, press the same button again. To continue the cycle, press this same button again.
Shift through 4 different light intensity modes.
PRE-PROGRAMMED COLORS
1. Warm white
2. Galactic white
3. Candle mode in yellow
4. Candle mode in orange
5. Dark red
6. Light red
7. Light orange
8. Dark orange
9. Yellow
10. White / Green
11. Light green
12. Dark green
13. Turquoise
14. Blue / Turquoise
15. Blue / Green
16. Purple / Blue
17. Dark blue
18. Light pink
19. Medium pink
20. Dark pink
21. Salmon
22. Light purple
23. Dark purple
24. Pink / Purple
LIGHT HOURS (APPROXIMATELY)
Charging time: 4-5 hours
High intensity in warm white: 9 hours
Low intensity in warm white: 32 hours
Color mix: 9 hours
Color fix: 13 hours
Candle effect: 11 hours
Press color up for + 2sec. to switch your lamp ON or OFF
COLORS UP
COLORS DOWN
MIX+PAUSE
BRIGHTNESS
.
ON/
LAY-OUT MODELS WITH CODE IL54 LAY-OUT MODELS STARTING FROM CODE IL60
metal ring to suspend your shape metal ring to suspend your shape
I
A
M
U
S
E
L
E
S
S
W
I
T
H
O
U
T
C
H
A
R
G
E
R
ON/OFF
press 2 sec
WWW.IMAGILIGHTS.COM
!
I AM USELESS
WITHOUT MY
CHARGER
I
A
M
U
S
E
L
E
S
S
W
I
T
H
O
U
T
C
H
A
R
G
E
R
IL/
27 LED
7,5V-1,62W
TAMPER PROTECTED
PATENT PENDING
WWW.IMAGILIGHTS COM
.
.
/
ON/OFF
press 2 sec

INFRARED REMOTE CONTROL
ON OFF
UP DOWN
RGB + WHITE RGB
BRIGHTNESS CANDLE MODE
COLOR LOCK
COLOR UP & DOWN: Choose between one of our 24 pre-programmed colors.
Start the 160.000 color mix mode 1 or 2 which will take approximately 14 minutes (= ultra slow),
and will continue without interruption.To fix a color, press the same button again. To continue the
cycle, press this same button again.
BRIGHTNESS: Shift through 4 different light intensity modes.
CANDLE MODE: Choose candle light mode 1 (yellow) or 2 (orange).
COLOR LOCK*: Press this button multiple times while aiming at your lamps to disable the
pushbuttons fuctions on the bottom of the lamps. To cancel the color lock function turn off your
lamp with the remote or place it back on the charger.
The remote operates on one Lithium battery CR2025 3V
Charger plates are not standard included when purchasing a table lamp
One INDU-8 MULTI CHARGER plate charges up to 8 lamps
simultaneously. These can be stacked on top of each other.
The INDU-8 MULTI CHARGER operates with the following
adapter: Input 100-240V AC~50/60 Hz - Output DC 7.5V 5A
The INDU-1 MINI CHARGER charges one
single lamp and operates with the following adapter:
Input 100-240V AC~50/60 Hz - Output DC 7.5V 1.5A
Lamp is useless without its specific prescribed IMAGILIGHTS® charger.
Your lamp automatically turns off when placed on its charger plate. This to protect the long life of the battery and to assure that
charging and discharging is not done simultaneously. While the lamp is charging the indicator on the charger will appear red.
A green luminous indicator indicates the lamp is fully charged.
IP68
DC 7.5 V
Light automatically turns
RECHARGING
*COLOR LOCK function depending on production date
OPTION 1 OPTION 2
The lamp must be charged inside, as the IP level does not count
during charging.

© 2016 IMAGILIGHTS®
RECYCLING
Do not throw this lamp away with your regular household garbage. Contact the approriate service within your
community to learn the best way to dispose of the device. Electrical products contain substances harmful to human
health and the environment so must be adequately recycled.
LEGAL INFORMATION AND WARRANTY
IMAGILIGHTS® wireless lamps are covered by design registration, copyright and patent pending. All rights reserved. All shapes
and models are registred. Patented LED module and patented charging possibilities. Any tampering with or repairing the unit voids
the warranty. The unit is equipped with special labels to avoid tampering.
Manufacturer’s warranty:1 year.
COMPANY DATA
IMAGILIGHTS BVBA
Nijverheidslaan 62C
B-8540 Deerlijk
BELGIUM
CAUTION
- Do not use the charger and lamp near a heat source or expose to fire.
- The IP waterproof level cannot be maintained during charing. Do not charge the lamp in a humid or aqueous place.
- Do not try to open or dismount the lamp or charger to avoid any risk of electrical shock or altering its waterproofing.
Failure to comply will cancel your warranty.
- Do not connect the lamp to any other device.
- Do not try to charge the lamp with a charger other than the one supplied in your pack.
- Do not try to replace the battery with a battery other than the battery inserted.
- Keep charger and lamp out of reach of young children.
- Do not store the lamp and charger in a humid area or outdoors.
- When storing your lamp, put it in its original box to avoid any damages or scratches.
CLEANING YOUR LAMP
It is recommended to clean your lamp with a soft humid cloth. Do not use any aggressive liquids or materials.
Tel. [phone]
Email: [email protected]
Website: www.imagilights.com
PACKAGE CONTENT
Shape with integrated LED module.
